Chapter 14: Entering New Dimensions 305
As much as we like the Drafting & Annotation workspace and the Ribbon, one task where using the classic interface just might be more efficient is in dimensioning. The classic Dimension toolbar provides access to more dimension tools than the Ribbon, and it does so while maintaining consistent one-click access to each command. With the Ribbon, you may find it takes a couple of clicks to get to the command you want, and some dimension commands aren’t even there.
Here’s how to turn on the Dimension toolbar in a Ribbon-based workspace:
1.Click the View tab on the Ribbon.
2.On the User Interface panel, click Toolbars.
AutoCAD displays a menu of loaded customization files. If your system doesn’t have Express Tools installed, or if you’re using AutoCAD LT, you may see only AutoCAD (or AutoCAD LT) on this menu. If you’re working for a large company, you may well see additional custom menus on this list.
3.Click AutoCAD or AutoCAD LT to display a list of classic toolbars.
4.Choose Dimension from the menu.
AutoCAD closes the Toolbars menu, and the classic Dimension toolbar appears either floating or docked on an edge of the drawing area.
Where, oh where, do my dimensions go?
In this section, we explain where to put your dimensions, not where to place them. Huh? Right. We aren’t going to tell you to place dimensions outside the part outline, with smaller ones closer to the part and longer ones farther away, and so on. What we’re covering next is the location in the file where your dimensions will live. Okay, if that still isn’t clear, then read on, and you’ll find that it is actually quite simple. You can choose one of three different methods for dimensioning your drawings:
You can place your dimensions in model space by using non-anno- tative dimensions. This is the oldest method, and for many years was the only possible way. We mention it here because you are bound to encounter many of the millions and millions of existing drawings that were created this way.
•Advantage: Dimensions are available in model space as you edit the drawing.
•Disadvantage: As with text (Chapter 13) and hatching (Chapter 15), dimension objects have to be scaled to suit the drawing scale. Placing dimensions on details at other scales can get really ugly. We cover scale factors in Chapter 4 as well as later in this chapter.
