Translation Versus Connection 79

Bidirectional Network Address Translation

Cisco PIX Firewall software version 6.2 allows NAT of external source IP addresses for packets traveling from the outside interface to an inside interface. All the functionality available with traditional nat, pat, and static commands is available bidirectionally.

Translation Versus Connection

A single user on a workstation located on the internal network is connecting to his webbased e-mail, making an online stock purchase, researching a new software package that he intends to buy, and backing up a database at a remote branch office. How many connections does he have going from his workstation? It is difficult to tell, because many of these tasks require multiple connections between the source and destination. How many translated sessions does he have going? One.

Most configurations create a single translated session, and from that session the user can create multiple connections. It is possible to create multiple translated sessions. This normally occurs when the internal node is accessing resources via different network segments all attached to the firewall (such as outside, DMZ1, DMZ2, and so on).

Translation occurs at the network layer (Layer 3) of the OSI model and deals only with packets. Connections, however, deal with the transport layer (Layer 4). Therefore, connections can be considered a subset of a single translation. It is possible to troubleshoot both translation and connection issues. It is recommended that you verify translation before attempting to troubleshoot a connection problem, because the connection cannot be established if the translation has not occurred.

The command used to troubleshoot translations is xlate. You can see the translation table by using the command show xlate, or you can clear the table with clear xlate. Any time you make a change to the translation table, it is a good idea to clear xlate. This forces the translation slots to drop, and the Cisco PIX Firewall rebuilds the translation table. If you do not run the clear xlate command, the system does not drop the translation slots until they time out, which is 3 hours by default. The following commands can make a change to the translation table:

•nat

•global

•static

•route

•alias

•conduit

80 Chapter 5: Understanding Cisco PIX Firewall Translation and Connections

Table 5-2 documents the options and arguments that come into play with the show xlate and clear xlate commands.

If you cannot clear xlate, it is possible (but not preferred) to clear the translation table by doing a reload, or by rebooting the PIX.

The command used to troubleshoot connections is show conn. This command displays the number and status of all active TCP connections for the specific options selected. Table 5- 4 lists the many options for the show conn command.

82 Chapter 5: Understanding Cisco PIX Firewall Translation and Connections

Table 5-5 Connection Flags (Continued)

Configuring DNS Support

It is not necessary to configure DNS support on the Cisco PIX Firewall. By default, the PIX identifies each outbound DNS request and allows only a single response to that request. The internal host can query several DNS servers for a response, and the PIX allows the outbound queries. However, the PIX allows only the first response to pass through the firewall. All subsequent responses to the original query are dropped.
