To help you set up and configure CBACs, Cisco has defined six steps for configuring CBAC:

1.Set audit trails and alerts.

2.Set global timeouts and thresholds.

3.Define Port-to-Application Mapping (PAM).

4.Define inspection rules.

5.Apply inspection rules and ACLs to interfaces.

6.Test and verify CBAC.

You’ll learn about each of these steps in detail throughout the rest of this chapter. The following graphic illustrates the network you’ll be working with and configuring:

152 Chapter 5 Context-Based Access Control Configuration

First, you need to understand the configuration and the order of the steps you’ll take to build CBAC on the Lab_B router as you work through the examples in the rest of this chapter.

You’ll be configuring the border router Lab_B with CBAC to protect the internal network, and you’ll need to provide full access to both the web server and the DNS server from the Internet. You’re also going to allow all general TCP and UDP traffic out to the Internet from your internal hosts, but not anything else.

The next section describes how to set up auditing and real-time alerts from routers running CBAC.

Using Audit Trails and Alerts

If you need it to, CBAC can generate real-time alerts and audit trails through the use of a Syslog server. This is an especially cool, useful feature if you have multiple routers running CBAC, because it allows you to monitor all enterprise alerts and even audit trails at a single, centralized location.

Alerts are triggered when CBAC discovers any suspicious activity. They’re reported as Syslog error messages to the central Syslog server that you’ve specified. Alerts provide a record of suspected problems, and they can be used to trigger other real-time events on the Syslog server.

You can use audit trails to create a log of all inspected activities. Think of this as a record of any and all accesses, whether they’re a problem or not. Audit trails are useful if your security policy identifies a need to keep a record of all network traffic.

The following example shows how both audit trails and alerts would be configured on your Lab_B router, assuming that your Syslog server is at 192.168.254.251:

Lab_B#conf t

Lab_B(config)#logging on

Lab_B(config)#logging 192.168.254.251

Lab_B(config)#ip inspect audit-trail

Lab_B(config)#no ip inspect alert-off

The no version of the ip inspect alert-off command enables alerts. Removing the no disables alerts. Likewise, the no version of the ip inspect audit-trail command disables the audit trail.

Great! You’re now logging both alerts and audit trails to your Syslog server. The next step is to configure global timeouts and thresholds.

Configuring Global Timeouts and Thresholds

CBAC uses global timeouts and thresholds to determine how long to preserve state information for all sessions, established or otherwise. You can use the defaults—and you need to know what these are—or you can modify them to meet your individual needs. If you’re going to change them, do it now before proceeding with any further CBAC configuration tasks.

Introduction to CBAC Configuration 153

Table 5.1 lists the commands you use to modify the default values and then describes the timeout or threshold and its default value. Once set, these values can be restored to default values by using the no form of the command, as in the following example:

Lab_B#conf t

Lab_B(config)#ip inspect tcp synwait-time 60

The default time of 30 seconds has now been changed to 60 seconds.

Lab_B(config)#no ip inspect tcp synwait-time 60

The default of 30 seconds has now been restored.

T A B L E 5 . 1 Some Commands for Changing CBAC Timeouts and Thresholds

Most of these commands should be familiar to you, but a few deserve special mention.

ip inspect max-incomplete These values can monitor both TCP and UDP sessions. Incomplete TCP sessions are defined as sessions where the three-way handshake hasn’t been completed. Incomplete UDP sessions are defined as sessions where no return traffic has been detected. Once the maximum number of incomplete sessions is reached, CBAC begins deleting half-open sessions until their numbers total below the minimum value.

ip inspect one-minute These commands are similar in operation, except instead of monitoring the total number of incomplete TCP or UDP sessions, they monitor the rate at which incomplete TCP or UDP sessions are being established. A sudden surge in incomplete sessions can trigger CBAC to aggressively close them, which it does until the low threshold is reached.

Let’s leave the defaults on the Lab_B router and continue on to the Port-to-Application Mapping section.

Configuring PAM

You ask, and Cisco delivers! Previous versions of CBAC assumed that applications were always hosted on the same, well-known port. Live and learn. In the real world, this isn’t always the case. Haven’t you all set up a rogue web server on some obscure port? Port-to-Application Mapping (PAM) allows you to modify the default values of well-known ports, and thus teach CBAC how to recognize these familiar apps in their new homes. Check out the default PAM mappings in Table 5.2.

Okay, so these are the defaults. But what if you have an HTTP server running on port 8000? That’s where PAM comes in. PAM allows you to map these applications or services to the ports

156 Chapter 5 Context-Based Access Control Configuration

that you’re really using and still get to enjoy all of CBAC’s capabilities. The available options in your configuration look like this:

Lab_B#conf t

Lab_B(config)#ip port-map ?

Lab_B(config)#ip port-map http port 8000

Introduction to CBAC Configuration 157

Configuring options such as these modifies the default port-mapping of HTTP. You can create multiple ports for the same application, but you’ll receive a warning if you try to map an application to the well-known port of another application. You can use the no version of the ip port-map command to remove the configuration, and you can use the show ip port-map command to review the changes and current PAM settings:

Did you notice that the HTTP mapping on port 8000 is user-defined, but all the other ports are system-defined? You can also set additional parameters for this command to get more than just one application or port, as follows:
