Cursor Attributes

Cursor Attributes

Every explicit cursor and cursor variable has four attributes: %FOUND, %ISOPEN %NOTFOUND, and %ROWCOUNT. When appended to the cursor or cursor variable, these attributes return useful information about the execution of a data manipulation statement. For more information, see "Using Cursor Expressions" on page 6-27.

The implicit cursor SQL has additional attributes, %BULK_ROWCOUNT and %BULK_EXCEPTIONS. For more information, see "SQL Cursor" on page 13-131.

Syntax

cursor_attribute

FOUND

cursor_name

ISOPEN

NOTFOUND

: host_cursor_variable_name

ROWCOUNT

Keyword and Parameter Description

cursor_name

An explicit cursor previously declared within the current scope.

cursor_variable_name

A PL/SQL cursor variable (or parameter) previously declared within the current scope.

%FOUND Attribute

A cursor attribute that can be appended to the name of a cursor or cursor variable. Before the first fetch from an open cursor, cursor_name%FOUND returns NULL. Afterward, it returns TRUE if the last fetch returned a row, or FALSE if the last fetch failed to return a row.

host_cursor_variable_name

A cursor variable declared in a PL/SQL host environment and passed to PL/SQL as a bind variable. The datatype of the host cursor variable is compatible with the return type of any PL/SQL cursor variable. Host variables must be prefixed with a colon.

%ISOPEN Attribute

A cursor attribute that can be appended to the name of a cursor or cursor variable. If a cursor is open, cursor_name%ISOPEN returns TRUE; otherwise, it returns FALSE.

%NOTFOUND Attribute

A cursor attribute that can be appended to the name of a cursor or cursor variable. Before the first fetch from an open cursor, cursor_name%NOTFOUND returns NULL. Thereafter, it returns FALSE if the last fetch returned a row, or TRUE if the last fetch failed to return a row.

PL/SQL Language Elements 13-31

Cursor Attributes

%ROWCOUNT Attribute

A cursor attribute that can be appended to the name of a cursor or cursor variable. When a cursor is opened, %ROWCOUNT is zeroed. Before the first fetch, cursor_name%ROWCOUNT returns 0. Thereafter, it returns the number of rows fetched so far. The number is incremented if the latest fetch returned a row.

Usage Notes

The cursor attributes apply to every cursor or cursor variable. For example, you can open multiple cursors, then use %FOUND or %NOTFOUND to tell which cursors have rows left to fetch. Likewise, you can use %ROWCOUNT to tell how many rows have been fetched so far.

If a cursor or cursor variable is not open, referencing it with %FOUND, %NOTFOUND, or %ROWCOUNT raises the predefined exception INVALID_CURSOR.

When a cursor or cursor variable is opened, the rows that satisfy the associated query are identified and form the result set. Rows are fetched from the result set one at a time.

If a SELECT INTO statement returns more than one row, PL/SQL raises the predefined exception TOO_MANY_ROWS and sets %ROWCOUNT to 1, not the actual number of rows that satisfy the query.

Before the first fetch, %NOTFOUND evaluates to NULL. If FETCH never executes successfully, the EXIT WHEN condition is never TRUE and the loop is never exited. To be safe, you might want to use the following EXIT statement instead:

EXIT WHEN c1%NOTFOUND OR c1%NOTFOUND IS NULL;

You can use the cursor attributes in procedural statements but not in SQL statements.

Examples

This PL/SQL block uses %FOUND to select an action.

DECLARE

CURSOR emp_cur IS SELECT * FROM employees ORDER BY employee_id; emp_rec employees%ROWTYPE;

BEGIN

OPEN emp_cur;

LOOP -- loop through the table and get each employee FETCH emp_cur INTO emp_rec;

IF emp_cur%FOUND THEN

dbms_output.put_line('Employee #' || emp_rec.employee_id || ' is ' || emp_rec.last_name);

ELSE

dbms_output.put_line('--- Finished processing employees ---'); EXIT;

END IF; END LOOP; CLOSE emp_cur;

END;

/

Instead of using %FOUND in an IF statement, the next example uses %NOTFOUND in an EXIT WHEN statement.

DECLARE

CURSOR emp_cur IS SELECT * FROM employees ORDER BY employee_id; emp_rec employees%ROWTYPE;

13-32 PL/SQL User's Guide and Reference

Cursor Attributes

BEGIN

OPEN emp_cur;

LOOP -- loop through the table and get each employee FETCH emp_cur INTO emp_rec;

EXIT WHEN emp_cur%NOTFOUND;

dbms_output.put_line('Employee #' || emp_rec.employee_id || ' is ' || emp_rec.last_name);

END LOOP; CLOSE emp_cur;

END;

/

The following example uses %ISOPEN to make a decision:

IF NOT (emp_cur%ISOPEN) THEN

OPEN emp_cur;

END IF;

FETCH emp_cur INTO emp_rec;

The following PL/SQL block uses %ROWCOUNT to fetch the names and salaries of the five highest-paid employees:

DECLARE

CURSOR c1 is

SELECT last_name, employee_id, salary FROM employees

EXIT WHEN (c1%ROWCOUNT > 5) OR (c1%NOTFOUND); dbms_output.put_line('Employee ' || my_name || ' (' || my_empno || ') makes

'|| my_sal); END LOOP;

CLOSE c1; END;

/

The following example raises an exception if many rows are deleted:

DELETE FROM accts WHERE status = 'BAD DEBT';

IF SQL%ROWCOUNT > 10 THEN

RAISE out_of_bounds;

END IF;

Related Topics

Cursors, Cursor Variables

PL/SQL Language Elements 13-33

Cursor Variables

Cursor Variables

To execute a multi-row query, Oracle opens an unnamed work area that stores processing information. You can access this area through an explicit cursor, which names the work area, or through a cursor variable, which points to the work area. To create cursor variables, you define a REF CURSOR type, then declare cursor variables of that type.

Cursor variables are like C or Pascal pointers, which hold the address of some item instead of the item itself. Declaring a cursor variable creates a pointer, not an item.

For more information, see "Using Cursor Variables (REF CURSORs)" on page 6-19.

Syntax

ref_cursor_type_definition

TYPE type_name IS REF CURSOR

record_type_name ref_cursor_type_name

;

cursor_variable_declaration

cursor_variable_name type_name ;

Keyword and Parameter Description

cursor_name

An explicit cursor previously declared within the current scope.

cursor_variable_name

A PL/SQL cursor variable previously declared within the current scope.

db_table_name

A database table or view, which must be accessible when the declaration is elaborated.

record_name

A user-defined record previously declared within the current scope.

record_type_name

A user-defined record type that was defined using the datatype specifier RECORD.

13-34 PL/SQL User's Guide and Reference

Cursor Variables

REF CURSOR

Cursor variables all have the datatype REF CURSOR.

RETURN

Specifies the datatype of a cursor variable return value. You can use the %ROWTYPE attribute in the RETURN clause to provide a record type that represents a row in a database table, or a row from a cursor or strongly typed cursor variable. You can use the %TYPE attribute to provide the datatype of a previously declared record.

%ROWTYPE

A record type that represents a row in a database table or a row fetched from a cursor or strongly typed cursor variable. Fields in the record and corresponding columns in the row have the same names and datatypes.

%TYPE

Provides the datatype of a previously declared user-defined record.

type_name

A user-defined cursor variable type that was defined as a REF CURSOR.

Usage Notes

Cursor variables are available to every PL/SQL client. For example, you can declare a cursor variable in a PL/SQL host environment such as an OCI or Pro*C program, then pass it as a bind variable to PL/SQL. Application development tools that have a PL/SQL engine can use cursor variables entirely on the client side.

You can pass cursor variables back and forth between an application and the database server through remote procedure calls using a database link. If you have a PL/SQL engine on the client side, you can use the cursor variable in either location. For example, you can declare a cursor variable on the client side, open and fetch from it on the server side, then continue to fetch from it back on the client side.

You use cursor variables to pass query result sets between PL/SQL stored subprograms and client programs. Neither PL/SQL nor any client program owns a result set; they share a pointer to the work area where the result set is stored. For example, an OCI program, Oracle Forms application, and the database can all refer to the same work area.

REF CURSOR types can be strong or weak. A strong REF CURSOR type definition specifies a return type, but a weak definition does not. Strong REF CURSOR types are less error-prone because PL/SQL lets you associate a strongly typed cursor variable only with type-compatible queries. Weak REF CURSOR types are more flexible because you can associate a weakly typed cursor variable with any query.

Once you define a REF CURSOR type, you can declare cursor variables of that type. You can use %TYPE to provide the datatype of a record variable. Also, in the RETURN clause of a REF CURSOR type definition, you can use %ROWTYPE to specify a record type that represents a row returned by a strongly (not weakly) typed cursor variable.

Currently, cursor variables are subject to several restrictions. See "Restrictions on Cursor Variables" on page 6-27.

You use three statements to control a cursor variable: OPEN-FOR, FETCH, and CLOSE. First, you OPEN a cursor variable FOR a multi-row query. Then, you FETCH rows from the result set. When all the rows are processed, you CLOSE the cursor variable.

PL/SQL Language Elements 13-35

Cursor Variables

Other OPEN-FOR statements can open the same cursor variable for different queries. You need not close a cursor variable before reopening it. When you reopen a cursor variable for a different query, the previous query is lost.

PL/SQL makes sure the return type of the cursor variable is compatible with the INTO clause of the FETCH statement. For each column value returned by the query associated with the cursor variable, there must be a corresponding, type-compatible field or variable in the INTO clause. Also, the number of fields or variables must equal the number of column values. Otherwise, you get an error.

If both cursor variables involved in an assignment are strongly typed, they must have the same datatype. However, if one or both cursor variables are weakly typed, they need not have the same datatype.

When declaring a cursor variable as the formal parameter of a subprogram that fetches from or closes the cursor variable, you must specify the IN or IN OUT mode. If the subprogram opens the cursor variable, you must specify the IN OUT mode.

Be careful when passing cursor variables as parameters. At run time, PL/SQL raises ROWTYPE_MISMATCH if the return types of the actual and formal parameters are incompatible.

You can apply the cursor attributes %FOUND, %NOTFOUND, %ISOPEN, and %ROWCOUNT to a cursor variable.

If you try to fetch from, close, or apply cursor attributes to a cursor variable that does not point to a query work area, PL/SQL raises the predefined exception INVALID_CURSOR. You can make a cursor variable (or parameter) point to a query work area in two ways:

■OPEN the cursor variable FOR the query.

■Assign to the cursor variable the value of an already OPENed host cursor variable or PL/SQL cursor variable.

A query work area remains accessible as long as any cursor variable points to it. Therefore, you can pass the value of a cursor variable freely from one scope to another. For example, if you pass a host cursor variable to a PL/SQL block embedded in a Pro*C program, the work area to which the cursor variable points remains accessible after the block completes.

Examples

You can declare a cursor variable in a PL/SQL host environment such as an OCI or Pro*C program. To use the host cursor variable, you must pass it as a bind variable to PL/SQL. In the following Pro*C example, you pass a host cursor variable and a selector to a PL/SQL block, which opens the cursor variable for the chosen query:

EXEC SQL BEGIN DECLARE SECTION;

EXEC SQL ALLOCATE :generic_cv;

/* Pass host cursor variable and selector to PL/SQL block. */ EXEC SQL EXECUTE

BEGIN

IF :choice = 1 THEN

OPEN :generic_cv FOR SELECT * FROM emp; ELSIF :choice = 2 THEN

OPEN :generic_cv FOR SELECT * FROM dept;

13-36 PL/SQL User's Guide and Reference

Cursor Variables

ELSIF :choice = 3 THEN

OPEN :generic_cv FOR SELECT * FROM salgrade;

END IF;

END;

END-EXEC;

Host cursor variables are compatible with any query return type. They behave just like weakly typed PL/SQL cursor variables.

When passing host cursor variables to PL/SQL, you can reduce network traffic by grouping OPEN-FOR statements. For example, the following PL/SQL block opens three cursor variables in a single round-trip:

/* anonymous PL/SQL block in host environment */ BEGIN

OPEN :emp_cv FOR SELECT * FROM emp; OPEN :dept_cv FOR SELECT * FROM dept;

OPEN :grade_cv FOR SELECT * FROM salgrade; END;

You can also pass a cursor variable to PL/SQL by calling a stored procedure that declares a cursor variable as one of its formal parameters. To centralize data retrieval, you can group type-compatible queries in a packaged procedure, as the following example shows:

CREATE PACKAGE emp_data AS

TYPE EmpCurTyp IS REF CURSOR RETURN employees%ROWTYPE; PROCEDURE open_emp_cv (emp_cv IN OUT EmpCurTyp,

choice IN NUMBER);

END emp_data;

/

CREATE PACKAGE BODY emp_data AS

PROCEDURE open_emp_cv (emp_cv IN OUT EmpCurTyp, choice IN NUMBER) IS

BEGIN

IF choice = 1 THEN

OPEN emp_cv FOR SELECT * FROM employees WHERE commission_pct IS NOT NULL; ELSIF choice = 2 THEN

OPEN emp_cv FOR SELECT * FROM employees WHERE salary > 2500; ELSIF choice = 3 THEN

OPEN emp_cv FOR SELECT * FROM employees WHERE department_id = 20; END IF;

END open_emp_cv; END emp_data;

/

DROP PACKAGE emp_data;

You can also use a standalone procedure to open the cursor variable. Define the REF CURSOR type in a package, as above, then reference that type in the standalone procedure.

Related Topics

CLOSE Statement, Cursor Attributes, Cursors, FETCH Statement, OPEN-FOR

Statement

PL/SQL Language Elements 13-37
