Software

7.5.2.1.7 Time

Path to the object directory:

Path:

0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/3:Configuration/4:Time

ns

BrowseName of the parameter

Description

Service page

R

W

4

EnableNTPClient

Enables/Disables the NTP client for time synchronization.

Time

+

+



NTPServer1

Address of an NTP server.

Time

+

+

7.5.2.1.7.1 EnableNTPClient

Function identical to: Service page Time "NTP client" on page 44

Path to the node (BrowsePath)

Path:

0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/2:ParameterSet/4:EnableNTPClient

Alternative path (function group):

0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/3:Configuration/4:Time/4:EnableNTPClient

Node attributes

NodeClass

Variable

DataType

Boolean

AccessLevel

CurrentRead, CurrentWrite

UserAccessLevel

CurrentRead, CurrentWrite

7.5.2.1.7.2 NTPServer1

Function identical to: Service page Time NTPServer1

Path to the node (BrowsePath)

Path:

0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/2:ParameterSet/4:NTPServer1

Alternative path (function group):

0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/3:Configuration/4:Time/4:NTPServer1

Node attributes

NodeClass

Variable

DataType

String

AccessLevel

CurrentRead, CurrentWrite

UserAccessLevel

CurrentRead, CurrentWrite

Power Panel T80 User's manual V1.01

91

Software

7.5.2.1.8 Vnc

Path to the object directory:

Path:

0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/3:Configuration/4:Vnc

ns

BrowseName of the parameter

Description

Service page

R

W

4

VNCServer

Address of the VNC server.

VNC

+

+



UseRfbExtension

Enables/Disables the RFB extension in VNC mode.

VNC

+

+



VNCLocalWindowScaling

Enables/Disables automatic scaling of the HMI application in VNC mode.

VNC

+

+

7.5.2.1.8.1 VNCServer

Function identical to: Service page VNC "Server" on page 50

Path to the node (BrowsePath)

Path:

0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/2:ParameterSet/4:VNCServer

Alternative path (function group):

0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/3:Configuration/4:Vnc/4:VNCServer

Node attributes

NodeClass

Variable

DataType

String

AccessLevel

CurrentRead, CurrentWrite

UserAccessLevel

CurrentRead, CurrentWrite

7.5.2.1.8.2 UseRfbExtension

Function identical to: Service page VNC "Use RFB extension" on page 51

Path to the node (BrowsePath)

Path:

0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/2:ParameterSet/4:UseRfbExtension

Alternative path (function group):

0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/3:Configuration/4:Vnc/4:UseRfbExtension

Node attributes

NodeClass

Variable

DataType

Boolean

AccessLevel

CurrentRead, CurrentWrite

UserAccessLevel

CurrentRead, CurrentWrite

7.5.2.1.8.3 VNCLocalWindowScaling

Function identical to: Service page VNC "Enable local window scaling" on page 51

Path to the node (BrowsePath)

Path:

0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/2:ParameterSet/4:VNCLocalWindowScaling

Alternative path (function group):

0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/3:Configuration/4:Vnc/4:VNCLocalWindowScaling

Node attributes

NodeClass

Variable

DataType

Boolean

AccessLevel

CurrentRead, CurrentWrite

UserAccessLevel

CurrentRead, CurrentWrite

92

Power Panel T80 User's manual V1.01

Software

7.5.2.1.9 Web

Path to the object directory:

Path:

0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/3:Configuration/4:Web

ns

BrowseName of the parameter

Description

Service page

R

W

4

WebServer

Address of the web server.

Web

+

+



VirtualKeyboardWeb

Enables/Disables the on-screen keyboard in web mode.

Web

+

+



DisablePinchGesture

The two-finger gesture (pinch-to-zoom) for zooming the browser content is disabled. Zooming

Web

+

+





the entire HMI application is prevented.







7.5.2.1.9.1 WebServer

Function identical to: Service page Web "Server" on page 52

Path to the node (BrowsePath)

Path:

0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/2:ParameterSet/4:WebServer

Alternative path (function group):

0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/3:Configuration/4:Web/4:WebServer

Node attributes

NodeClass

Variable

DataType

String

AccessLevel

CurrentRead, CurrentWrite

UserAccessLevel

CurrentRead, CurrentWrite

7.5.2.1.9.2 VirtualKeyboardWeb

Function identical to: Service page Web "Virtual keyboard" on page 53

Path to the node (BrowsePath)

Path:

0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/2:ParameterSet/4:VirtualKeyboardWeb

Alternative path (function group):

0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/3:Configuration/4:Web/4:VirtualKeyboardWeb

Node attributes

NodeClass

Variable

DataType

Boolean

AccessLevel

CurrentRead, CurrentWrite

UserAccessLevel

CurrentRead, CurrentWrite

7.5.2.1.9.3 DisablePinchGesture

Function identical to: Service page Web "Disable pinch gesture" on page 53

Path to the node (BrowsePath)

Path:

0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/2:ParameterSet/4:DisablePinchGesture

Alternative path (function group):

0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/3:Configuration/4:Web/4:DisablePinchGesture

Node attributes

NodeClass

Variable

DataType

Boolean

AccessLevel

CurrentRead, CurrentWrite

UserAccessLevel

CurrentRead, CurrentWrite

Power Panel T80 User's manual V1.01

93
