Software
7.5.2.1.6
Storage
Path to the object directory:
Path:
0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/3:Configuration/4:Storage
ns |
BrowseName of the parameter |
Description |
Service page |
R |
W |
4 |
USBMemoryShare |
Enables/Disables network sharing to the connected USB storage medium. |
Storage |
+ |
+ |
|
UserMemoryShare |
Enables/Disables network sharing to internal user memory. |
Storage |
+ |
+ |
7.5.2.1.6.1
USBMemoryShare / UserMemoryShare
Function identical to: Options on "Service page Storage" on page 56
•USBMemoryShare → Option Allow access to USB memory via network
•UserMemoryShare → Option Allow access to user memory via network
Path to the node (BrowsePath)
Path:
0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/2:ParameterSet/4:USBMemoryShare
0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/2:ParameterSet/4:UserMemoryShare
Alternative path (function group):
0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/3:Configuration/4:Storage/4:USBMemoryShare
0:Root/0:Objects/2:DeviceSet/4:PowerPanelT80/3:Configuration/4:Storage/4:UserMemoryShare
Node attributes
NodeClass |
Variable |
DataType |
Boolean |
AccessLevel |
CurrentRead, CurrentWrite |
UserAccessLevel |
CurrentRead, CurrentWrite |
90 |
Power Panel T80 User's manual V1.01 |
