Device description
4.6 Dimensions
4.6.1 7.0" Power Panel T80
1
117
196
2
153 |
140 |
209 |
View A |
36.5 |
6 |
|
|
|
|
View A |
|
|
|
|
3 |
|
|
16x retaining clips with torque limiting
2Anodized front plate E6/C8 (black)
3Power-coated cover, RAL 9005, fine structure, flat
Dimensions of the installation cutout for this Power Panel variant: 198 ±1 mm x 142 ±1 mm See also "Installation cutout requirements" on page 28.
Power Panel T80 User's manual V1.01 |
21 |
Device description
4.6.2 10.1" Power Panel T80 |
|
|
|
|
1 |
|
|
117 |
|
|
|
266 |
|
|
|
|
2 |
|
|
191 |
178 |
|
|
279 |
View A |
36.5 |
5.7 |
View A |
|
|
|
|
3 |
|
|
18x retaining clips with torque limiting
2Anodized front plate E6/C8 (black)
3Power-coated cover, RAL 9005, fine structure, flat
Dimensions of the installation cutout for this Power Panel variant: 268 ±1 mm x 180 ±1 mm See also "Installation cutout requirements" on page 28.
22 |
Power Panel T80 User's manual V1.01 |
Device description
4.6.3 12.1" Power Panel T80
|
1 |
97 |
117 |
2
.5 R3 4x
221.5 |
|
208.5 |
|
|
|
324 |
View A |
38 |
5.7 |
|
|
View A
18x retaining clips with torque limiting
2Anodized front plate E6/C8 (black)
3Power-coated cover, RAL 9005, fine structure, flat
Dimensions of the installation cutout for this Power Panel variant: 313 ±1 mm x 210.5 ±1 mm See also "Installation cutout requirements" on page 28.
Power Panel T80 User's manual V1.01 |
23 |
Device description
4.6.4 15.6" Power Panel T80 |
|
|
|
|
|
|
12.1 |
|
|
|
|
|
1 |
|
123 |
155 |
|
|
|
|
401 |
|
|
|
|
|
2 |
4 |
|
|
|
|
|
|
258.5 |
|
|
245.5 |
|
|
414 |
|
View A |
|
|
|
|
5.7 |
|
|
|
|
38 |
|
View A |
|
|
|
|
|
|
|
3 |
|
|
|
54,05 |
|
|
19x retaining clips with torque limiting
2Anodized front plate E6/C8 (black)
3Power-coated cover, RAL 9005, fine structure, flat
Dimensions of the installation cutout for this Power Panel variant: 403 ±1 mm x 247.5 ±1 mm See also "Installation cutout requirements" on page 28.
24 |
Power Panel T80 User's manual V1.01 |
