8XC196EA USER’S MANUAL
Because the RISM begins at location FF2000H in serial port programming mode, the ROM locations are automatically remapped as shown in Table 17-4. For example, to access ROM location FF2000H in serial port mode, you must address it as FFA000H.
Table 17-4. Serial Port Mode Memory Map
|
|
Address Range (Hex) |
|
Description |
|
|
|
Normal Operation |
Serial Port Programming Mode |
||
|
|||
|
|
|
|
Internal ROM |
FF2000–FF3FFF |
FFA000–FFBFFF |
|
|
|
|
|
External memory |
— |
FF4000–FF5FFF |
|
|
|
|
|
Do not address |
— |
FF2400–FF3FFF |
|
|
|
|
|
Test ROM and RISM |
— |
FF2000–FF23FF |
|
|
|
|
17.6 SDU RISM EXECUTION ROUTINE
The SDU RISM execution routine contains a built-in reduced instruction set monitor (RISM), which enables you to access user routines that reside in test-ROM. The on-chip RISM commands are accessed via the SDU module (see Table 17-7 on page 17-15). To access the RISM routine, set the interrupt (SDU_INT) bit of the SDU command byte and program your software to vector to the RISM. (Refer to Figure 16-7 on page 16-8 for additional information on using the SDU command byte.)
NOTE
The SDU interrupt occurs at the execution of the SDU command byte. The mode select (SDU_COM.5:2) bits must not equal 00H or 0FH, or the reset SDU instruction will take precedence. Use 68H as the SDU command byte to generate an interrupt.
When accessing the SDU RISM execution routine, code RAM address locations 0400–0407H are reserved (see Figure 17-4) and must not be used in any user routines that are called. The eight bytes of the SDU RISM control block are used to communicate to the CPU, since the CPU has no direct access to any SDU register.
17-10
USING THE TEST-ROM ROUTINES
SDU RISM Control Block
The SDU RISM control block contains data and address registers (RISM_DATA and RISM_ADDR) and a command byte register (RISM_COM) for initializing a data transfer.
|
|
7 |
0 |
|
RISM_TEMP |
|
|
Reserved |
|
|
|
|
7 |
0 |
RISM_TEMP |
|
|
|
|
|
|
Reserved |
||
|
|
|
15 |
8 |
|
|
|
|
|
RISM_DATA(H) |
|
|
SDU RISM Data (high byte) |
|
|
|
|
7 |
0 |
|
|
|
|
|
RISM_DATA(L) |
|
|
SDU RISM Data (low byte) |
|
|
|
|
23 |
16 |
|
|
|
|
|
RISM_ADDR(H) |
|
|
SDU RISM Address (high byte) |
|
|
|
|
15 |
8 |
RISM_ADDR(M) |
|
|
||
|
SDU RISM Address (middle byte) |
|||
|
|
|
7 |
0 |
|
|
|
|
|
RISM_ADDR(L) |
|
|
SDU RISM Address (low byte) |
|
|
|
|
7 |
0 |
|
|
|
|
|
RISM_COM |
|
|
SDU RISM Command Byte |
|
|
|
|
|
|
Register |
|
Address |
Function |
|
|
|
|
||
RISM_TEMP |
407–406H |
Reserved. |
||
|
|
|
|
|
RISM_DATA |
|
405–404H |
SDU RISM Data |
|
|
|
|
|
Stores the data content to be written. |
|
|
|
|
|
RISM_ADDR |
|
403–401H |
SDU RISM Address |
|
|
|
|
|
Stores the address to which the data content is to be read or written. |
|
|
|
|
|
RISM_COM |
|
400H |
SDU RISM Command Byte |
|
|
|
|
|
See Table 17-7 on page 17-15 for the RISM commands supported by |
|
|
|
|
the SDU. |
|
|
|
|
|
Figure 17-4. SDU RISM Control Block
17-11
