- •Verilog-AMS
- •Language Reference Manual
- •Table of Contents
- •1. Verilog-AMS introduction
- •1.1 Overview
- •1.2 Mixed-signal language features
- •1.3 Systems
- •1.3.1 Conservative systems
- •1.3.1.1 Reference nodes
- •1.3.1.2 Reference directions
- •1.3.2 Kirchhoff’s Laws
- •1.3.3 Natures, disciplines, and nets
- •1.3.4 Signal-flow systems
- •1.3.5 Mixed conservative/signal flow systems
- •1.4 Conventions used in this document
- •1.5 Contents
- •2. Lexical conventions
- •2.1 Overview
- •2.2 Lexical tokens
- •2.3 White space
- •2.4 Comments
- •2.5 Operators
- •2.6 Numbers
- •2.6.1 Integer constants
- •2.6.2 Real constants
- •2.7 String literals
- •2.8 Identifiers, keywords, and system names
- •2.8.1 Escaped identifiers
- •2.8.2 Keywords
- •2.8.3 System tasks and functions
- •2.8.4 Compiler directives
- •2.9 Attributes
- •2.9.1 Standard attributes
- •2.9.2 Syntax
- •3. Data types
- •3.1 Overview
- •3.2 Integer and real data types
- •3.2.1 Output variables
- •3.3 String data type
- •3.4 Parameters
- •3.4.1 Type specification
- •3.4.2 Value range specification
- •3.4.3 Parameter units and descriptions
- •3.4.4 Parameter arrays
- •3.4.5 Local parameters
- •3.4.6 String parameters
- •3.4.7 Parameter aliases
- •3.5 Genvars
- •3.6 Net_discipline
- •3.6.1 Natures
- •3.6.1.1 Derived natures
- •3.6.1.2 Attributes
- •3.6.1.3 User-defined attributes
- •3.6.2 Disciplines
- •3.6.2.1 Nature binding
- •3.6.2.2 Domain binding
- •3.6.2.3 Empty disciplines
- •3.6.2.4 Discipline of nets and undeclared nets
- •3.6.2.5 Overriding nature attributes from discipline
- •3.6.2.6 Deriving natures from disciplines
- •3.6.2.7 User-defined attributes
- •3.6.3 Net discipline declaration
- •3.6.3.1 Net descriptions
- •3.6.3.2 Net Discipline Initial (Nodeset) Values
- •3.6.4 Ground declaration
- •3.6.5 Implicit nets
- •3.7 Real net declarations
- •3.8 Default discipline
- •3.9 Disciplines of primitives
- •3.10 Discipline precedence
- •3.11 Net compatibility
- •3.11.1 Discipline and Nature Compatibility
- •3.12 Branches
- •3.13 Namespace
- •3.13.1 Nature and discipline
- •3.13.2 Access functions
- •3.13.4 Branch
- •4. Expressions
- •4.1 Overview
- •4.2 Operators
- •4.2.1 Operators with real operands
- •4.2.1.1 Real to integer conversion
- •4.2.1.2 Integer to real conversion
- •4.2.1.3 Arithmetic conversion
- •4.2.2 Operator precedence
- •4.2.3 Expression evaluation order
- •4.2.4 Arithmetic operators
- •4.2.5 Relational operators
- •4.2.6 Case equality operators
- •4.2.7 Logical equality operators
- •4.2.8 Logical operators
- •4.2.9 Bitwise operators
- •4.2.10 Reduction operators
- •4.2.11 Shift operators
- •4.2.12 Conditional operator
- •4.2.13 Concatenations
- •4.3 Built-in mathematical functions
- •4.3.1 Standard mathematical functions
- •4.3.2 Transcendental functions
- •4.4 Signal access functions
- •4.5 Analog operators
- •4.5.1 Vector or array arguments to analog operators
- •4.5.2 Analog operators and equations
- •4.5.3 Time derivative operator
- •4.5.4 Time integral operator
- •4.5.5 Circular integrator operator
- •4.5.6 Derivative operator
- •4.5.7 Absolute delay operator
- •4.5.8 Transition filter
- •4.5.9 Slew filter
- •4.5.10 last_crossing function
- •4.5.11 Laplace transform filters
- •4.5.11.1 laplace_zp
- •4.5.11.2 laplace_zd
- •4.5.11.3 laplace_np
- •4.5.11.4 laplace_nd
- •4.5.11.5 Examples
- •4.5.12 Z-transform filters
- •4.5.13 Limited exponential
- •4.5.14 Constant versus dynamic arguments
- •4.5.15 Restrictions on analog operators
- •4.6 Analysis dependent functions
- •4.6.1 Analysis
- •4.6.2 DC analysis
- •4.6.3 AC stimulus
- •4.6.4 Noise
- •4.6.4.1 white_noise
- •4.6.4.2 flicker_noise
- •4.6.4.3 noise_table
- •4.6.4.4 Noise model for diode
- •4.6.4.5 Correlated noise
- •4.7 User defined functions
- •4.7.1 Defining an analog user defined function
- •4.7.2 Returning a value from an analog user defined function
- •4.7.2.1 Analog user defined function identifier variable
- •4.7.2.2 Output arguments
- •4.7.2.3 Inout arguments
- •4.7.3 Calling an analog user defined function
- •5. Analog behavior
- •5.1 Overview
- •5.2 Analog procedural block
- •5.2.1 Analog initial block
- •5.3 Block statements
- •5.3.1 Sequential blocks
- •5.3.2 Block names
- •5.4 Analog signals
- •5.4.1 Access functions
- •5.4.2 Probes and sources
- •5.4.2.1 Probes
- •5.4.2.2 Sources
- •5.4.3 Port branches
- •5.4.4 Unassigned sources
- •5.5 Accessing net and branch signals and attributes
- •5.5.1 Accessing net and branch signals
- •5.5.2 Signal access for vector branches
- •5.5.3 Accessing attributes
- •5.6 Contribution statements
- •5.6.1 Direct branch contribution statements
- •5.6.1.1 Relations
- •5.6.1.2 Evaluation
- •5.6.1.3 Value retention
- •5.6.2 Examples
- •5.6.2.1 The four controlled sources
- •5.6.3 Resistor and conductor
- •5.6.4 RLC circuits
- •5.6.5 Switch branches
- •5.6.6 Implicit Contributions
- •5.6.7 Indirect branch contribution statements
- •5.6.7.1 Multiple indirect contributions
- •5.6.7.2 Indirect and direct contribution
- •5.7 Analog procedural assignments
- •5.8 Analog conditional statements
- •5.8.1 if-else-if statement
- •5.8.2 Examples
- •5.8.3 Case statement
- •5.8.4 Restrictions on conditional statements
- •5.9 Looping statements
- •5.9.1 Repeat and while statements
- •5.9.2 For statements
- •5.9.3 Analog For Statements
- •5.10 Analog event control statements
- •5.10.1 Event OR operator
- •5.10.2 Global events
- •5.10.3 Monitored events
- •5.10.3.1 cross function
- •5.10.3.2 above function
- •5.10.3.3 timer function
- •5.10.4 Named events
- •5.10.5 Digital events in analog behavior
- •6. Hierarchical structures
- •6.1 Overview
- •6.2 Modules
- •6.2.1 Top-level modules
- •6.2.2 Module instantiation
- •6.3 Overriding module parameter values
- •6.3.1 Defparam statement
- •6.3.2 Module instance parameter value assignment by order
- •6.3.3 Module instance parameter value assignment by name
- •6.3.4 Parameter dependence
- •6.3.5 Detecting parameter overrides
- •6.3.6 Hierarchical system parameters
- •6.4 Paramsets
- •6.4.1 Paramset statements
- •6.4.2 Paramset overloading
- •6.4.3 Paramset output variables
- •6.5 Ports
- •6.5.1 Port definition
- •6.5.2 Port declarations
- •6.5.2.1 Port type
- •6.5.2.2 Port direction
- •6.5.3 Real valued ports
- •6.5.4 Connecting module ports by ordered list
- •6.5.5 Connecting module ports by name
- •6.5.6 Detecting port connections
- •6.5.7 Port connection rules
- •6.5.7.1 Matching size rule
- •6.5.7.2 Resolving discipline of undeclared interconnect signal
- •6.5.8 Inheriting port natures
- •6.6 Generate constructs
- •6.6.1 Loop generate constructs
- •6.6.2 Conditional generate constructs
- •6.6.2.1 Dynamic parameters
- •6.6.3 External names for unnamed generate blocks
- •6.7 Hierarchical names
- •6.7.1 Usage of hierarchical references
- •6.8 Scope rules
- •6.9 Elaboration
- •6.9.1 Concatenation of analog blocks
- •6.9.2 Elaboration and paramsets
- •6.9.3 Elaboration and connectmodules
- •6.9.4 Order of elaboration
- •7. Mixed signal
- •7.1 Overview
- •7.2 Fundamentals
- •7.2.1 Domains
- •7.2.2 Contexts
- •7.2.3 Nets, nodes, ports, and signals
- •7.2.4 Mixed-signal and net disciplines
- •7.3 Behavioral interaction
- •7.3.1 Accessing discrete nets and variables from a continuous context
- •7.3.2 Accessing X and Z bits of a discrete net in a continuous context
- •7.3.2.1 Special floating point values
- •7.3.3 Accessing continuous nets and variables from a discrete context
- •7.3.4 Detecting discrete events in a continuous context
- •7.3.5 Detecting continuous events in a discrete context
- •7.3.6 Concurrency
- •7.3.6.1 Analog event appearing in a digital event control
- •7.3.6.2 Digital event appearing in an analog event control
- •7.3.6.3 Analog primary appearing in a digital expression
- •7.3.6.4 Analog variables appearing in continuous assigns
- •7.3.6.5 Digital primary appearing in an analog expression
- •7.3.7 Function calls
- •7.4 Discipline resolution
- •7.4.1 Compatible discipline resolution
- •7.4.2 Connection of discrete-time disciplines
- •7.4.3 Connection of continuous-time disciplines
- •7.4.4 Resolution of mixed signals
- •7.4.4.1 Basic discipline resolution algorithm
- •7.4.4.2 Detail discipline resolution algorithm
- •7.4.4.3 Coercing discipline resolution
- •7.5 Connect modules
- •7.6 Connect module descriptions
- •7.7 Connect specification statements
- •7.7.1 Connect module auto-insertion statement
- •7.7.2 Discipline resolution connect statement
- •7.7.2.1 Connect Rule Resolution Mechanism
- •7.7.3 Parameter passing attribute
- •7.7.4 connect_mode
- •7.8 Automatic insertion of connect modules
- •7.8.1 Connect module selection
- •7.8.2 Signal segmentation
- •7.8.3 connect_mode parameter
- •7.8.3.1 merged
- •7.8.3.2 split
- •7.8.4 Rules for driver-receiver segregation and connect module selection and insertion
- •7.8.5 Instance names for auto-inserted instances
- •7.8.5.1 Port names for Verilog built-in primitives
- •8. Scheduling semantics
- •8.1 Overview
- •8.2 Analog simulation cycle
- •8.2.1 Nodal analysis
- •8.2.2 Transient analysis
- •8.2.3 Convergence
- •8.3 Mixed-signal simulation cycle
- •8.3.1 Circuit initialization
- •8.3.2 Mixed-signal DC analysis
- •8.3.3 Mixed-signal transient analysis
- •8.3.3.1 Concurrency
- •8.3.3.2 Analog macro process scheduling semantics
- •8.3.3.3 A/D boundary timing
- •8.3.4 The synchronization loop
- •8.3.5 Synchronization and communication algorithm
- •8.3.6 Assumptions about the analog and digital algorithms
- •8.4 Scheduling semantics for the digital engine
- •8.4.1 The stratified event queue
- •8.4.2 The Verilog-AMS digital engine reference model
- •8.4.3 Scheduling implication of assignments
- •8.4.3.1 Continuous assignment
- •8.4.3.2 Procedural continuous assignment
- •8.4.3.3 Blocking assignment
- •8.4.3.4 Non blocking assignment
- •8.4.3.5 Switch (transistor) processing
- •8.4.3.6 Processing explicit D2A events (region 1b)
- •8.4.3.7 Processing analog macro-process events (region 3b)
- •9. System tasks and functions
- •9.1 Overview
- •9.2 Categories of system tasks and functions
- •9.3 System tasks/functions executing in the context of the Analog Simulation Cycle
- •9.4 Display system tasks
- •9.4.1 Behavior of the display tasks in the analog context
- •9.4.2 Escape sequences for special characters
- •9.4.3 Format specifications
- •9.4.4 Hierarchical name format
- •9.4.5 String format
- •9.4.6 Behavior of the display tasks in the analog block during iterative solving
- •9.4.7 Extensions to the display tasks in the digital context
- •9.5.1 Opening and closing files
- •9.5.1.1 opening and closing files during multiple analyses
- •9.5.1.2 Sharing of file descriptors between the analog and digital contexts
- •9.5.2 File output system tasks
- •9.5.3 Formatting data to a string
- •9.5.4 Reading data from a file
- •9.5.4.1 Reading a line at a time
- •9.5.4.2 Reading formatted data
- •9.5.5 File positioning
- •9.5.6 Flushing output
- •9.5.7 I/O error status
- •9.5.8 Detecting EOF
- •9.5.9 Behavior of the file I/O tasks in the analog block during iterative solving
- •9.6 Timescale system tasks
- •9.7 Simulation control system tasks
- •9.7.1 $finish
- •9.7.2 $stop
- •9.7.3 $fatal, $error, $warning, and $info
- •9.8 PLA modeling system tasks
- •9.9 Stochastic analysis system tasks
- •9.10 Simulator time system functions
- •9.11 Conversion system functions
- •9.12 Command line input
- •9.13 Probabilistic distribution system functions
- •9.13.1 $random and $arandom
- •9.13.2 distribution functions
- •9.13.3 Algorithm for probablistic distribution
- •9.14 Math system functions
- •9.15 Analog kernel parameter system functions
- •9.16 Dynamic simulation probe function
- •9.17 Analog kernel control system tasks and functions
- •9.17.1 $discontinuity
- •9.17.2 $bound_step task
- •9.17.3 $limit
- •9.18 Hierarchical parameter system functions
- •9.19 Explicit binding detection system functions
- •9.20 Table based interpolation and lookup system function
- •9.20.1 Table data source
- •9.20.2 Control string
- •9.20.3 Example control strings
- •9.20.4 Lookup algorithm
- •9.20.5 Interpolation algorithms
- •9.20.6 Example
- •9.21 Connectmodule driver access system functions and operator
- •9.21.1 $driver_count
- •9.21.2 $driver_state
- •9.21.3 $driver_strength
- •9.21.4 driver_update
- •9.21.5 Receiver net resolution
- •9.21.6 Connect module example using driver access functions
- •9.22 Supplementary connectmodule driver access system functions
- •9.22.1 $driver_delay
- •9.22.2 $driver_next_state
- •9.22.3 $driver_next_strength
- •9.22.4 $driver_type
- •10. Compiler directives
- •10.1 Overview
- •10.2 `default_discipline
- •10.3 `default_transition
- •10.4 `define and `undef
- •10.5 Predefined macros
- •10.6 `begin_keywords and `end_keywords
- •11. Using VPI routines
- •11.1 Overview
- •11.2 The VPI interface
- •11.2.1 VPI callbacks
- •11.2.2 VPI access to Verilog-AMS HDL objects and simulation objects
- •11.2.3 Error handling
- •11.3 VPI object classifications
- •11.3.1 Accessing object relationships and properties
- •11.3.2 Delays and values
- •11.4 List of VPI routines by functional category
- •11.5 Key to object model diagrams
- •11.5.1 Diagram key for objects and classes
- •11.5.2 Diagram key for accessing properties
- •11.5.3 Diagram key for traversing relationships
- •11.6 Object data model diagrams
- •11.6.1 Module
- •11.6.2 Nature, discipline
- •11.6.3 Scope, task, function, IO declaration
- •11.6.4 Ports
- •11.6.5 Nodes
- •11.6.6 Branches
- •11.6.7 Quantities
- •11.6.8 Nets
- •11.6.9 Regs
- •11.6.10 Variables, named event
- •11.6.11 Memory
- •11.6.12 Parameter, specparam
- •11.6.13 Primitive, prim term
- •11.6.15 Module path, timing check, intermodule path
- •11.6.16 Task and function call
- •11.6.17 Continuous assignment
- •11.6.18 Simple expressions
- •11.6.19 Expressions
- •11.6.20 Contribs
- •11.6.21 Process, block, statement, event statement
- •11.6.22 Assignment, delay control, event control, repeat control
- •11.6.23 If, if-else, case
- •11.6.24 Assign statement, deassign, force, release, disable
- •11.6.25 Callback, time queue
- •12. VPI routine definitions
- •12.1 Overview
- •12.2 vpi_chk_error()
- •12.3 vpi_compare_objects()
- •12.4 vpi_free_object()
- •12.6 vpi_get_cb_info()
- •12.7 vpi_get_analog_delta()
- •12.8 vpi_get_analog_freq()
- •12.9 vpi_get_analog_time()
- •12.10 vpi_get_analog_value()
- •12.11 vpi_get_delays()
- •12.13 vpi_get_analog_systf_info()
- •12.14 vpi_get_systf_info()
- •12.15 vpi_get_time()
- •12.16 vpi_get_value()
- •12.17 vpi_get_vlog_info()
- •12.18 vpi_get_real()
- •12.19 vpi_handle()
- •12.20 vpi_handle_by_index()
- •12.21 vpi_handle_by_name()
- •12.22 vpi_handle_multi()
- •12.22.1 Derivatives for analog system task/functions
- •12.22.2 Examples
- •12.23 vpi_iterate()
- •12.24 vpi_mcd_close()
- •12.25 vpi_mcd_name()
- •12.26 vpi_mcd_open()
- •12.27 vpi_mcd_printf()
- •12.28 vpi_printf()
- •12.29 vpi_put_delays()
- •12.30 vpi_put_value()
- •12.31 vpi_register_cb()
- •12.31.1 Simulation-event-related callbacks
- •12.31.2 Simulation-time-related callbacks
- •12.31.3 Simulator analog and related callbacks
- •12.31.4 Simulator action and feature related callbacks
- •12.32 vpi_register_analog_systf()
- •12.32.1 System task and function callbacks
- •12.32.2 Declaring derivatives for analog system task/functions
- •12.32.3 Examples
- •12.33 vpi_register_systf()
- •12.33.1 System task and function callbacks
- •12.33.2 Initializing VPI system task/function callbacks
- •12.34 vpi_remove_cb()
- •12.35 vpi_scan()
- •12.36 vpi_sim_control()
- •A.1 Source text
- •A.1.1 Library source text
- •A.1.2 Verilog source text
- •A.1.3 Module parameters and ports
- •A.1.4 Module items
- •A.1.5 Configuration source text
- •A.1.6 Nature Declaration
- •A.1.7 Discipline Declaration
- •A.1.8 Connectrules Declaration
- •A.1.9 Paramset Declaration
- •A.2 Declarations
- •A.2.1 Declaration types
- •A.2.1.1 Module parameter declarations
- •A.2.1.2 Port declarations
- •A.2.1.3 Type declarations
- •A.2.2 Declaration data types
- •A.2.2.1 Net and variable types
- •A.2.2.2 Strengths
- •A.2.2.3 Delays
- •A.2.3 Declaration lists
- •A.2.4 Declaration assignments
- •A.2.5 Declaration ranges
- •A.2.6 Function declarations
- •A.2.7 Task declarations
- •A.2.8 Block item declarations
- •A.3 Primitive instances
- •A.3.1 Primitive instantiation and instances
- •A.3.2 Primitive strengths
- •A.3.3 Primitive terminals
- •A.3.4 Primitive gate and switch types
- •A.4 Module instantiation and generate construct
- •A.4.1 Module instantiation
- •A.4.2 Generate construct
- •A.5 UDP declaration and instantiation
- •A.5.1 UDP declaration
- •A.5.2 UDP ports
- •A.5.3 UDP body
- •A.5.4 UDP instantiation
- •A.6 Behavioral statements
- •A.6.1 Continuous assignment statements
- •A.6.2 Procedural blocks and assignments
- •A.6.3 Parallel and sequential blocks
- •A.6.4 Statements
- •A.6.5 Timing control statements
- •A.6.6 Conditional statements
- •A.6.7 Case statements
- •A.6.8 Looping statements
- •A.6.9 Task enable statements
- •A.6.10 Contribution statements
- •A.7 Specify section
- •A.7.1 Specify block declaration
- •A.7.2 Specify path declarations
- •A.7.3 Specify block terminals
- •A.7.4 Specify path delays
- •A.7.5 System timing checks
- •A.7.5.1 System timing check commands
- •A.7.5.2 System timing check command arguments
- •A.7.5.3 System timing check event definitions
- •A.8 Expressions
- •A.8.1 Concatenations
- •A.8.2 Function calls
- •A.8.3 Expressions
- •A.8.4 Primaries
- •A.8.5 Expression left-side values
- •A.8.6 Operators
- •A.8.7 Numbers
- •A.8.8 Strings
- •A.8.9 Analog references
- •A.9 General
- •A.9.1 Attributes
- •A.9.2 Comments
- •A.9.3 Identifiers
- •A.9.4 White space
- •A.10 Details
- •C.1 Verilog-AMS introduction
- •C.1.1 Verilog-A overview
- •C.1.2 Verilog-A language features
- •C.2 Lexical conventions
- •C.3 Data types
- •C.4 Expressions
- •C.5 Analog signals
- •C.6 Analog behavior
- •C.7 Hierarchical structures
- •C.8 Mixed signal
- •C.9 Scheduling semantics
- •C.10 System tasks and functions
- •C.11 Compiler directives
- •C.12 Using VPI routines
- •C.13 VPI routine definitions
- •C.14 Analog language subset
- •C.15 List of keywords
- •C.16 Standard definitions
- •C.17 SPICE compatibility
- •C.18 Changes from previous Verilog-A LRM versions
- •C.19 Obsolete functionality
- •D.1 The disciplines.vams file
- •D.2 The constants.vams file
- •D.3 The driver_access.vams file
- •E.1 Introduction
- •E.1.1 Scope of compatibility
- •E.1.2 Degree of incompatibility
- •E.2 Accessing Spice objects from Verilog-AMS HDL
- •E.2.1 Case sensitivity
- •E.2.2 Examples
- •E.3 Accessing Spice models
- •E.3.1 Accessing Spice subcircuits
- •E.3.1.1 Accessing Spice primitives
- •E.4 Preferred primitive, parameter, and port names
- •E.4.1 Unsupported primitives
- •E.4.2 Discipline of primitives
- •E.4.2.1 Setting the discipline of analog primitives
- •E.4.2.2 Resolving the disciplines of analog primitives
- •E.4.3 Name scoping of SPICE primitives
- •E.4.4 Limiting algorithms
- •E.5 Other issues
- •E.5.1 Multiplicity factor on subcircuits
- •E.5.2 Binning and libraries
- •F.1 Discipline resolution
- •F.2 Resolution of mixed signals
- •F.2.1 Default discipline resolution algorithm
- •F.2.2 Alternate expanded analog discipline resolution algorithm
- •G.1 Changes from previous LRM versions
- •G.2 Obsolete functionality
- •G.2.1 Forever
- •G.2.2 NULL
- •G.2.3 Generate
- •G.2.4 `default_function_type_analog

|
Accellera |
Analog and Mixed-signal Extensions to Verilog HDL |
Version 2.3.1, June 1, 2009 |
10. Compiler directives
10.1 Overview
All Verilog-AMS HDL compiler directives are preceded by the ( ` ) character. This character is called accent grave (ASCII 0x60). It is different from the character ( ’ ), which is the apostrophe character (ASCII 0x27). The scope of compiler directives extends from the point where it is processed, across all files processed, to the point where another compiler directive supersedes it or the processing completes.
The following compiler directives are supported:
`begin_keywords |
[1364-2005] |
`celldefine |
[1364-2005] |
`default_discipline |
[10.2] |
`default_nettype |
[1364-2005] |
`default_transition |
[10.3] |
`define |
[10.4] |
`else |
[1364-2005] |
`elsif |
[1364-2005] |
`end_keywords |
[1364-2005] |
`endcelldefine |
[1364-2005] |
`endif |
[1364-2005] |
`ifdef |
[1364-2005] |
`ifndef |
[1364-2005] |
`include |
[1364-2005] |
`line |
[1364-2005] |
`nounconnected_drive |
[1364-2005] |
`pragma |
[1364-2005] |
`resetall |
[1364-2005] |
`timescale |
[1364-2005] |
`unconnected_drive |
[1364-2005] |
`undef |
[10.4] |
10.2 `default_discipline
The default discipline is applied to all discrete signals without a discipline declaration that appear in the text stream following the use of the `default_discipline directive, until either the end of the text stream or another `default_discipline directive with the qualifier (if applicable) is found in the subsequent text, even across source file boundaries. Therefore, more than one `default_discipline directive can be in force simultaneously, provided each differs in qualifier.
In addition to `resetall, if this directive is used without a discipline name, it turns off all currently active default disciplines without setting a new default discipline. Subsequent discrete signals without a discipline shall be associated with the empty discipline. Syntax 10-1 shows the syntax for this directive.
default_discipline_directive ::=
`default_discipline [discipline_identifier [ qualifier ] ]
239 |
Copyright © 2009 Accellera Organization, Inc. All rights reserved. |

Accellera |
|
Version 2.3.1, June 1, 2009 |
VERILOG-AMS |
qualifier ::=
integer | real | reg | wreal | wire | tri | wand | triand | wor | trior | trireg | tri0 | tri1 | supply0 | supply1
Syntax 10-1—Syntax for the default discipline compiler directive
Example:
`default_discipline ddiscrete module behavnand(in1, in2, out);
input in1, in2; output out; reg out; always begin
out = ~(in1 && in2); end
endmodule
This example illustrates the usage of the `default_discipline directive. The nets in1, in2, and out all have discipline ddiscrete by default.
There is a precedence of compiler directives; the more specific directives have higher precedence over general directives.
10.3 `default_transition
The scope of this directive is similar to the scope of the `define compiler directive although it can be used only outside of module definitions. This directive specifies the default value for rise and fall time for the transition filter (see 4.5.8). There are no scope restrictions for this directive. The syntax for this directive is shown in Syntax 10-2.
default_transition_compiler_directive ::=
`default_transition transition_time
transition_time ::= constant_expression
Syntax 10-2—Syntax for default transition compiler directive
transition_time is a real value.
For all transition filters which follow this directive and do not have rise time and fall time arguments specified, transition_time is used as the default rise and fall time values. If another `default_transition directive is encountered in the subsequent source description, the transition filters following the newly encountered directive derive their default rise and fall times from the transition time value of the newly encountered directive. In other words, the default rise and fall times for a transition filter are derived from the transition_time value of the directive which immediately precedes the transition filter.
If a `default_transition directive is not used in the description, transition_time is controlled by the simulator.
Copyright © 2009 Accellera Organization, Inc. |
240 |

|
Accellera |
Analog and Mixed-signal Extensions to Verilog HDL |
Version 2.3.1, June 1, 2009 |
10.4 `define and `undef
The ‘define and ‘undef compiler directives are described in IEEE std 1364-2005 Verilog HDL.
To avoid conflicts with predefined Verilog-AMS macros (10.5), the ‘define compiler directive’s macro text shall not begin with __VAMS_. The ‘undef compiler directive shall have no effect on predefined Ver- ilog-AMS macros; the simulator may issue a warning for an attempt to undefine one of these macros.
The syntax for text macro definitions is given in Syntax 10-3
text_macro_definition ::=
‘define text_macro_name macro_text
text_macro_name ::=
text_macro_identifier [ ( list_of_formal_arguments ) ]
list_of_formal_arguments ::=
formal_argument_identifier { , formal_argument_identifier }
formal_argument_identifier ::= simple_identifier
text_macro_identifier ::= identifier
Syntax 10-3—Syntax for text macro definition (not in Annex A)
10.5 Predefined macros
Verilog-AMS HDL supports a predefined macro to allow modules to be written that work with both IEEE std 1364-2005 Verilog HDL and Verilog-AMS HDL.The predefined macro is called __VAMS_ENABLE__.
This macro shall always be defined during the parsing of Verilog-AMS source text. Its purpose is to support the creation of modules which are both legal Verilog and Verilog-AMS. The Verilog-AMS features of such modules are made visible only when the __VAMS_ENABLE__ macro has previously been defined.
Example:
module not_gate(in, out); input in;
output out; reg out;
`ifdef __VAMS_ENABLE__
parameter integer del = 1 from [1:100];
`else
parameter del = 1;
`endif always @ in
out = #del !in; endmodule
Verilog-AMS HDL version 2.2 introduced a number of extensions to support compact modeling. A predefined macro allows modules to add functionality if these extensions are supported, or to generate warnings or errors if they are not. This predefined macro is called __VAMS_COMPACT_MODELING__ and shall be defined during the parsing of Verilog-AMS source text if and only if all the compact modeling extensions are supported by the simulator.
241 |
Copyright © 2009 Accellera Organization, Inc. All rights reserved. |
Accellera |
|
Version 2.3.1, June 1, 2009 |
VERILOG-AMS |
The following example computes noise of a nonlinear resistor only if the extensions, specifically ddx, are supported.
module nonlin_res(a, b); input a, b; electrical a, b;
parameter real rnom = 1; parameter real vc1 = 0; real reff, iab;
analog begin
iab = V(a,b) / (rnom * (1.0 + vc1 * V(a,b))); I(a,b) <+ iab;
`ifdef __VAMS_COMPACT_MODELING__ reff = ddx(iab, V(a));
I(a,b) <+ white_noise(4.0*‘P_K*$temperature*reff, "thermal");
`else
if (analysis("noise")) $strobe("Noise not computed.");
`endif end
endmodule
Verilog-AMS simulators shall also provide a predefined macro so that the module can conditionally include (or exclude) portions of the source text specific to a particular simulator. This macro shall be documented in the Verilog-AMS section of the simulator manual.
10.6 `begin_keywords and `end_keywords
Verilog-AMS HDL extends the `begin_keywords and `end_keywords compiler directives from IEEE std 1364-2005 Verilog HDL by adding a "VAMS-2.3" version specifier.
The version_specifier specifies the valid set of reserved keywords in effect when a design unit is parsed by an implementation. The `begin_keywords and `end_keywords directives can only be specified outside of a design element (module, primitive, configuration, paramset, connectrules or connectmodule). The `begin_keywords directive affects all source code that follows the directive, even across source code file boundaries, until the matching ‘end_keywords directive is encountered.
The version_specifier, "VAMS-2.3" specifies that only the identifiers listed as reserved keywords in the Verilog-AMS HDL are considered to be reserved words. These identifiers are listed in Annex B.
The `begin_keywords and `end_keywords directives only specify the set of identifiers that are reserved as keywords. The directives do not affect the semantics, tokens, and other aspects of the Verilog-AMS language.
The version specifiers "1364-1995", "1364-2001" and "1364-2005" must also be supported. "13641995" represents the keywords for IEEE std 1364-1995. "1364-2001" represents the keywords for IEEE std 1364-2001. "1364-2005" represents the keywords for IEEE std 1364-2005.
In the example below, it is assumed that the definition of module m1 does not have a `begin_keywords directive specified prior to the module definition. Without this directive, the set of reserved keywords in effect for this module shall be the implementation’s default set of reserved keywords.
module m1; // module definition with no `begin_keywords directive
...
endmodule
Copyright © 2009 Accellera Organization, Inc. |
242 |
|
Accellera |
Analog and Mixed-signal Extensions to Verilog HDL |
Version 2.3.1, June 1, 2009 |
The following example specifies a `begin_keywords "1364-2005" directive. The source code within the module uses the identifier sin as a port name. The `begin_keywords directive would be necessary in this example if an implementation uses Verilog-AMS as its default set of keywords because sin is a reserved keyword in Verilog-AMS but not in 1364-2005. Specifying the "1364-1995" or "1364-2001" Verilog keyword lists would also work with this example.
`begin_keywords "1364-2005" // use IEEE Std 1364-2005 Verilog keywords module m2 (sin ...);
input sin; // OK since sin is not a keyword in 1364-2005
...
endmodule `end_keywords
The next example is the same code as the previous example, except that it explicitly specifies that the Ver- ilog-AMS keywords should be used. This example shall result in an error because sin is reserved as a keyword in this standard.
`begin_keywords "VAMS-2.3" // use Verilog-AMS LRM2.3 keywords module m2 (sin, ... ); // ERROR: "sin" is a keyword in Verilog-AMS
input sin;
...
endmodule `end_keywords
The following example uses several Verilog-AMS constructs, and designates that the Verilog-AMS version 2.3 set of keywords should be used. Note that the word “logic” is not a keyword in Verilog-AMS 2.3, where as it is a keyword in the IEEE std 1800-2005 SystemVerilog.
`begin_keywords "VAMS-2.3" |
|
discipline logic; |
|
domain discrete; |
|
enddiscipline |
|
module a2d(dnet, anet); |
|
input dnet; |
|
wire dnet; |
|
logic dnet; |
|
output anet; |
|
electrical anet; |
|
real avar; |
|
analog begin |
|
if (dnet === 1’b1) |
|
avar = 5; |
|
else if (dnet === 1’bx) |
// hold value |
avar = avar; |
|
else if (dnet === 1’b0) |
|
avar = 0; |
|
else if (dnet === 1’bz) |
// high impedance - float value |
avar = 2.5; |
|
V(anet) <+ avar; |
|
end |
|
endmodule |
|
`end_keywords |
|
243 |
Copyright © 2009 Accellera Organization, Inc. All rights reserved. |
