3.3. Kirchhoff’s rules
For a solution of branched circuits it is used two rules, which are algorithm for set up of equations that relate currant, voltages, and electromotive forces on elements of branched circuit.
Before usage of Kirchhoff’s rules for solution of branched circuit, for example, of bridge circuit (see Fig. 11), we should assign three topological elements of the circuit:
Junction – is a point of connection of three or greater conductors. On Fig. 11 junctions are marked by letters A, B, C and D.
Branch – is a way from one junction to a neighbour junction with its own elements. One's own current flows in each branch from initial junction to end junction through all elements of this branch. Therefore the branch's number usually same as the current's number.
For example, on Fig. 11 we see: current I1 flows through branch AD, current I2 flows through branch DС, current I3 flows through branch BС, current I4 flows through branch AB, current I5 flows through branch CA, current I6 flows through branch BD. If in the branch we have a source of EMF, then direction of current should coincide with direction of extraneous forces work (from “–“ to “+” inside the source). If in the branch a source is absent, direction of current should be set any way.
Fig.
11 – Bridge’s
branched
circuit
1st Kirchhoff’s rule – is a junction’s rule:
, (23)
where – algebraic sum of a current into the junction (which is positive when the currents flow in the junction, and negative when the currents flow out of the junction);
2nd Kirchhoff’s rule – is a closed loop’s rule:
, (24)
–algebraic sum of voltage drops on external resistors around any closed loop, and – algebraic sum of the voltage drops on internal resistance of sources (which are positive, when the direction of a current coincides with chosen direction of path-tracing);
–algebraic sum of the source electromotive force of the closed loop (which are positive, when the direction of extraneous forces work (from “–“ to “+” inside the source coincides with chosen direction of path-tracing).
4. Description of laboratory research facility and methodology of measurements
Devices and outfits (See Fig. 12): source of EMF e, microamperemeter mA (zero-indicator with null in the middle of a scale), resistor with known resistance R1, one-decate resistor box R2, four-decate resistor box R3, resistor with unknown resistance RX.
The bridge circuit of measurings of resistance is the most accurate method of measuring of resistances.
Wheatstone bridge is a circuit, shown in Fig. 12, that consists of four branches with resistors R1, R2, R3, RX. These parts are called the bridge arms. Unknown resistor RX is connected in the arm AB, which has to be measured in this work. Resistors boxes are connected in the arms BC and CD, so R3 and R2 can be varied. Resistor R1, of the arm AD is constant. So, resistors R1, R2, R3 are known. Diagonal AC has a source of EMF - e; the diagonal BD has microampermeter as zero-indicator (zero is in the middle of the scale).
Fig.
12 – Installation
diagram of lab 2-2 equipment
Let's derive the relation between resistances of bridge's arms, when becomes its balance.
