7) Calculation of quantities:
7.1) Compensation method:
Statistical absolute error:
.
Device error of voltmeter:
.
Total absolute error and relative error of in compensation method:
; .
7.2) Direct measurement method:
Relative error of direct measurement method:
; ;
; ;
; .
8) Final results: 8.1) Compensation method: x = (<x> x)VV; =… %.
8.1) Direct measurement method: Graph of dependence of β2DIR from r/RV : |
9) Conclusions: In compensation method … (ststistical or device) error make a main contribution to an absolute error. For a direct method the measuring we can consider correct in range where resistance of voltmeter … (more greater or more less), then internal resistance of source.
10) Data: “___” _____20___. Work done by: ______ Work checked by:
(Surname, readable)
Laboratory work № 2-4
1. Topic: POWER IN THE DIRECT CURRENT CIRCUIT
2. Goal of the work:
2.1. Study total power, useful power, and electrical efficiency dependence on current and external load resistance.
2.2. Finding the condition of matching of source to a circuit loading.
3. Main concepts
3.1. Types of power in a DC circuit
For direct current flowing in the circuit, there must be a source, where the extraneous forces create the excess of positive charges on one terminal of a device. Work of extraneous forces for moving the electric charge q between terminals inside the source, is equal (53):
АEXTR=q, (68)
where – EMF of the source.
As the result charges get potential energy, which is equal q. If we close the circuit this potential energy will change into kinetic energy of electric charge's motion and the current will flow. The kinetic energy of electric charges will change into a heat, if there are no other energy transformations (for example, into mechanical in electric motors etc.). According to the energy conservation law, this total energy, which is being dissipated along the whole circuit during a time interval t, is equal to work of extraneous forces for this time WT= АEXTR.
Therefore a total power РT, which is being dissipated in electric circuit, is equal to work of extraneous forces per unit time:
. (69)
Using (68) and definition of current (19), we obtain:
. (70)
Useful power PU is being dissipated in on the external part of the circuit R (heat, light, mechanical work, etc.):
, (71)
where UR – potential difference on the external part of the circuit R.
The power loss PL due to heating of the internal resistance of source r:
, (72)
where Ur – potential difference on the internal part of the circuit r.
By magnitude of efficiency we can estimate how the energy of the source is consumed. Efficiency of the source is the quantity, which is numerically equal to ratio of useful power PU due to total power РT:
=. (73)
If we take into account equations (70) and (71) we can write
=. (74)
