SECTION 9 – PROCEDURES
7)A second window is displayed listing available will not have this designation, meaning the GPS receiver transitions for the arrival. Turn either FMS Knob can be used for supplemental navigation guidance only. to highlight the desired transition waypoint and If the GPS receiver cannot be used for primary guidance,
press the ENT Key.
Figure 9-4 Select Arrival Transition
8)A third window is displayed listing the available runways. Turn either FMS Knob to select the desired runway and press the ENT Key.
the appropriate navigation receiver must be used for the selected approach (e.g., VOR or ILS). The final course segment of ILS approaches, for example, must be flown by tuning the Nav receiver to the proper frequency and selecting that Nav receiver on the CDI.
Load and/or Activate an Approach Procedure
1)Press the PROC Key.
2)Turn the large FMS Knob to highlight ‘SELECT APPROACH’.
3)Press the ENT Key.
4)If a flight plan is active, the destination airport will be displayed as the default. A list of available approaches is also displayed. If no flight plan is active, use the FMS Knobs to enter the identifier of the desired airport. Press the ENT Key.
5)Turn the large FMS Knob to highlight the Approach field. Turn the small FMS Knob to display a list of available approaches.
Figure 9-5 Select Arrival Runway
9)With ‘LOAD?’ highlighted, press the ENT Key. If a flight plan is active, the selected arrival procedure is inserted after the destination airport and becomes part of the active flight plan. If no flight plan is active when the arrival is loaded, the arrival procedure will become the active flight plan.
9.2APPROACHES
NotallapproachesinthedatabaseareapprovedforGPS |
|
|
use. When selecting an approach, a “GPS” designation to |
|
|
the right of the procedure name indicates the procedure |
Figure 9-6 Selecting an Approach Procedure |
|
can be flown using the GPS receiver. Some procedures |
||
|
9-2 |
Garmin G1000 Cockpit Reference Guide for the Cessna Nav III |
SECTION 9 – PROCEDURES
6)Turn either FMS Knob to highlight the desired Activate An Approach in the Active Flight Plan approach. Press the ENT Key.
1)With the Navigation Map Page displayed, press
7)The cursor will move to the TRANSITIONS field. the PROC Key. Turn the large FMS Knob to highlight the desired
2)Turn the large FMS Knob to highlight ‘ACTIVATEtransition waypoint and press the ENT Key. (The
“Vectors”option assumes vectors will be received to the final course segment of the approach and will provide navigation guidance relative to the final approach course.)
APPROACH’.
3)Press the ENT Key. The approach procedure is now active.
Figure 9-7 Selecting an Approach Transition
8)Turn the large FMS Knob to highlight ‘Activate?’ and press the ENT Key to activate the approach. Selecting ‘Load?’ will add the procedure to the flight plan without immediately using it for navigation guidance.
Garmin G1000 Cockpit Reference Guide for the Cessna Nav III |
9-3 |
SECTION 9 – PROCEDURES
Blank Page
