SECTION 6 – AUTOMATIC
FLIGHT CONTROL
6.2FLIGHT DIRECTOR OPERATION
With the flight director activated, the aircraft can be hand-flown to follow the path shown by the Command Bars. Maximum commanded pitch (+20°/-15°) and bank (22°) angles, vertical acceleration, and roll rate are limited to values established during AFCS certification. The flight director also provides commands to the autopilot.
Activating the Flight Director
Pressing the FD or AP Key (when the flight director is not active) activates the flight director in default pitch/roll modes. PushingtheGASwitchoranyfightdirectormode key activates the flight director in the respective mode(s).
The flight director may be turned off by pressing the FD Key.
Command Bars
Upon activation of the flight director, Command Bars are displayed on the PFD as a single cue. If the attitude information sent to the flight director becomes invalid or unavailable, the Command Bars are removed from the display. The Command Bars do not override the aircraft symbol.
Figure 6-2 Command Bars
|
|
|
|
|
Autopilot |
|
|
|
Pitch |
Modes |
|
|
||
|
|
Roll Modes |
Status |
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Armed |
|
Active |
|
|
Active |
Mode |
|
|
|
|||||
|
|
|
|
Armed |
||||||||||
|
|
|
|
|
|
|
|
|
Reference |
|||||
|
|
|
|
|
|
|
|
|
|
|
||||
AFCS Status Box
Selected Altitude
Command Bars
Selected Heading |
|
|
|
Selected Course |
|
|
GPS is Selected
Navigation Source
|
Figure 6-3 PFD AFCS Display |
6-2 |
Garmin G1000 Cockpit Reference Guide for the Cessna Nav III |
