Chapter 148: Hash Functions

Section 148.1: PBKDF2 for Password Hashing

PBKDF2 ("Password-Based Key Derivation Function 2") is one of the recommended hash-functions for passwordhashing. It is part of rfc-2898.

.NET's Rfc2898DeriveBytes-Class is based upon HMACSHA1.

using System.Security.Cryptography;

...

public const int SALT_SIZE = 24; // size in bytes public const int HASH_SIZE = 24; // size in bytes

public const int ITERATIONS = 100000; // number of pbkdf2 iterations

public static byte[] CreateHash(string input)

{

// Generate a salt

RNGCryptoServiceProvider provider = new RNGCryptoServiceProvider(); byte[] salt = new byte[SALT_SIZE];

provider.GetBytes(salt);

// Generate the hash

Rfc2898DeriveBytes pbkdf2 = new Rfc2898DeriveBytes(input, salt, ITERATIONS); return pbkdf2.GetBytes(HASH_SIZE);

}

PBKDF2 requires a salt and the number of iterations.

Iterations:

A high number of iterations will slow the algorithm down, which makes password cracking a lot harder. A high number of iterations is therefor recommended. PBKDF2 is order of magnitudes slower than MD5 for example.

Salt:

A salt will prevent the lookup of hash values in rainbow tables. It has to be stored alongside the password hash. One salt per password (not one global salt) is recommended.

Section 148.2: Complete Password Hashing Solution using Pbkdf2

using System; using System.Linq;

using System.Security.Cryptography;

namespace YourCryptoNamespace

{

///<summary>

///Salted password hashing with PBKDF2-SHA1.

///Compatibility: .NET 3.0 and later.

///</summary>

///<remarks>See http://crackstation.net/hashing-security.htm for much more on password hashing.</remarks>

public static class PasswordHashProvider

{

///<summary>

///The salt byte size, 64 length ensures safety but could be increased / decreased

///</summary>

private const int SaltByteSize = 64;

///<summary>

///The hash byte size,

///</summary>

private const int HashByteSize = 64;

///<summary>

///High iteration count is less likely to be cracked

///</summary>

private const int Pbkdf2Iterations = 10000;

///<summary>

///Creates a salted PBKDF2 hash of the password.

///</summary>

///<remarks>

///The salt and the hash have to be persisted side by side for the password. They could be persisted as bytes or as a string using the convenience methods in the next class to convert from byte[] to string and later back again when executing password validation.

///</remarks>

///<param name="password">The password to hash.</param>

///<returns>The hash of the password.</returns>

public static PasswordHashContainer CreateHash(string password)

{

// Generate a random salt

using (var csprng = new RNGCryptoServiceProvider())

{

// create a unique salt for every password hash to prevent rainbow and dictionary based

attacks

var salt = new byte[SaltByteSize]; csprng.GetBytes(salt);

// Hash the password and encode the parameters

var hash = Pbkdf2(password, salt, Pbkdf2Iterations, HashByteSize);

return new PasswordHashContainer(hash, salt);

}

}

///<summary>

///Recreates a password hash based on the incoming password string and the stored salt

///</summary>

///<param name="password">The password to check.</param>

///<param name="salt">The salt existing.</param>

///<returns>the generated hash based on the password and salt</returns>

public static byte[] CreateHash(string password, byte[] salt)

{

// Extract the parameters from the hash

return Pbkdf2(password, salt, Pbkdf2Iterations, HashByteSize);

}

///<summary>

///Validates a password given a hash of the correct one.

///</summary>

///<param name="password">The password to check.</param>

///<param name="salt">The existing stored salt.</param>

///<param name="correctHash">The hash of the existing password.</param>

///<returns><c>true</c> if the password is correct. <c>false</c> otherwise. </returns> public static bool ValidatePassword(string password, byte[] salt, byte[] correctHash)

{

//Extract the parameters from the hash

byte[] testHash = Pbkdf2(password, salt, Pbkdf2Iterations, HashByteSize); return CompareHashes(correctHash, testHash);

}

///<summary>

///Compares two byte arrays (hashes)

///</summary>

///<param name="array1">The array1.</param>

///<param name="array2">The array2.</param>

///<returns><c>true</c> if they are the same, otherwise <c>false</c></returns> public static bool CompareHashes(byte[] array1, byte[] array2)

{

if (array1.Length != array2.Length) return false; return !array1.Where((t, i) => t != array2[i]).Any();

}

///<summary>

///Computes the PBKDF2-SHA1 hash of a password.

///</summary>

///<param name="password">The password to hash.</param>

///<param name="salt">The salt.</param>

///<param name="iterations">The PBKDF2 iteration count.</param>

///<param name="outputBytes">The length of the hash to generate, in bytes.</param>

///<returns>A hash of the password.</returns>

private static byte[] Pbkdf2(string password, byte[] salt, int iterations, int outputBytes)

{

using (var pbkdf2 = new Rfc2898DeriveBytes(password, salt))

{

pbkdf2.IterationCount = iterations; return pbkdf2.GetBytes(outputBytes);

}

}

}

///<summary>

///Container for password hash and salt and iterations.

///</summary>

public sealed class PasswordHashContainer

{

///<summary>

///Gets the hashed password.

///</summary>

public byte[] HashedPassword { get; private set; }

///<summary>

///Gets the salt.

///</summary>

public byte[] Salt { get; private set; }

///<summary>

///Initializes a new instance of the <see cref="PasswordHashContainer" /> class.

///</summary>

///<param name="hashedPassword">The hashed password.</param>

///<param name="salt">The salt.</param>

public PasswordHashContainer(byte[] hashedPassword, byte[] salt)

{

this.HashedPassword = hashedPassword; this.Salt = salt;

}

}

///<summary>

///Convenience methods for converting between hex strings and byte array.

///</summary>

public static class ByteConverter

{

///<summary>

///Converts the hex representation string to an array of bytes

///</summary>

///<param name="hexedString">The hexed string.</param>

///<returns></returns>

public static byte[] GetHexBytes(string hexedString)

{

var bytes = new byte[hexedString.Length / 2]; for (var i = 0; i < bytes.Length; i++)

{

var strPos = i * 2;

var chars = hexedString.Substring(strPos, 2); bytes[i] = Convert.ToByte(chars, 16);

}

return bytes;

}

///<summary>

///Gets a hex string representation of the byte array passed in.

///</summary>

///<param name="bytes">The bytes.</param>

public static string GetHexString(byte[] bytes)

{

return BitConverter.ToString(bytes).Replace("-", "").ToUpper();

}

}

}

/*

*Password Hashing With PBKDF2 (http://crackstation.net/hashing-security.htm).

*Copyright (c) 2013, Taylor Hornby

*All rights reserved.

*

*Redistribution and use in source and binary forms, with or without

*modification, are permitted provided that the following conditions are met:

*1. Redistributions of source code must retain the above copyright notice,

*this list of conditions and the following disclaimer.

*

*2. Redistributions in binary form must reproduce the above copyright notice,

*this list of conditions and the following disclaimer in the documentation

*and/or other materials provided with the distribution.

*

*THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS"

*AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE

*IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE

*ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDER OR CONTRIBUTORS BE

*LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR

*CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF

*SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS

*INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN

*CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE)

*ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE

*POSSIBILITY OF SUCH DAMAGE.

*/

Please see this excellent resource Crackstation - Salted Password Hashing - Doing it Right for more information. Part of this solution (the hashing function) was based on the code from that site.
