Chapter 128: Accessing Databases

Section 128.1: Connection Strings

A Connection String is a string that specifies information about a particular data source and how to go about connecting to it by storing credentials, locations, and other information.

Server=myServerAddress;Database=myDataBase;User Id=myUsername;Password=myPassword;

Storing Your Connection String

Typically, a connection string will be stored within a configuration file (such as an app.config or web.config within ASP.NET applications). The following is an example of what a local connection might look like within one of these files :

<connectionStrings>

<add name="WidgetsContext" providerName="System.Data.SqlClient" connectionString="Server=.\SQLEXPRESS;Database=Widgets;Integrated Security=True;"/>

</connectionStrings>

<connectionStrings>

<add name="WidgetsContext" providerName="System.Data.SqlClient" connectionString="Server=.\SQLEXPRESS;Database=Widgets;Integrated Security=SSPI;"/>

</connectionStrings>

This will allow your application to access the connection string programmatically through WidgetsContext. Although both Integrated Security=SSPI and Integrated Security=True perform the same function;Integrated Security=SSPI is preferred since works with both SQLClient & OleDB provider where as Integrated Security=true throws an exception when used with the OleDb provider.

Di erent Connections for Di erent Providers

Each data provider (SQL Server, MySQL, Azure, etc.) all feature their own flavor of syntax for their connection strings and expose di erent available properties. ConnectionStrings.com is an incredibly useful resource if you are unsure about what yours should look like.

Section 128.2: Entity Framework Connections

Entity Framework exposes abstraction classes that are used to interact with underlying databases in the form of classes like DbContext. These contexts generally consist of DbSet<T> properties that expose the available collections that can be queried :

public class ExampleContext: DbContext

{

public virtual DbSet<Widgets> Widgets { get; set; }

}

The DbContext itself will handle making the connections with the databases and will generally read the appropriate Connection String data from a configuration to determine how to establish the connections :

public class ExampleContext: DbContext

{

//The parameter being passed in to the base constructor indicates the name of the

//connection string

public ExampleContext() : base("ExampleContextEntities")

{

}

public virtual DbSet<Widgets> Widgets { get; set; }

}

Executing Entity Framework Queries

Actually executing an Entity Framework query can be quite easy and simply requires you to create an instance of the context and then use the available properties on it to pull or access your data

using(var context = new ExampleContext())

{

// Retrieve all of the Widgets in your database var data = context.Widgets.ToList();

}

Entity Framework also provides an extensive change-tracking system that can be used to handle updating entries within your database by simply calling the SaveChanges() method to push changes to the database :

using(var context = new ExampleContext())

{

// Grab the widget you wish to update

var widget = context.Widgets.Find(w => w.Id == id);

// If it exists, update it if(widget != null)

{

// Update your widget and save your changes widget.Updated = DateTime.UtcNow; context.SaveChanges();

}

}

Section 128.3: ADO.NET Connections

ADO.NET Connections are one of the simplest ways to connect to a database from a C# application. They rely on the use of a provider and a connection string that points to your database to perform queries against.

Common Data Provider Classes

Many of the following are classes that are commonly used to query databases and their related namespaces :

SqlConnection,SqlCommand,SqlDataReader from System.Data.SqlClient

OleDbConnection,OleDbCommand,OleDbDataReader from System.Data.OleDb

MySqlConnection, MySqlCommand, MySqlDbDataReader from MySql.Data

All of these are commonly used to access data through C# and will be commonly encountered throughout building data-centric applications. Many other classes that are not mentioned that implement the same FooConnection,FooCommand,FooDataReader classes can be expected to behave the same way.

Common Access Pattern for ADO.NET Connections

A common pattern that can be used when accessing your data through an ADO.NET connection might look as follows :

// This scopes the connection (your specific class may vary) using(var connection = new SqlConnection("{your-connection-string}")

{

// Build your query

var query = "SELECT * FROM YourTable WHERE Property = @property");

// Scope your command to execute

using(var command = new SqlCommand(query, connection))

{

//Open your connection connection.Open();

//Add your parameters here if necessary

//Execute your query as a reader (again scoped with a using statement) using(var reader = command.ExecuteReader())

{

// Iterate through your results here

}

}

}

Or if you were just performing a simple update and didn't require a reader, the same basic concept would apply :

using(var connection = new SqlConnection("{your-connection-string}"))

{

var query = "UPDATE YourTable SET Property = Value WHERE Foo = @foo"; using(var command = new SqlCommand(query,connection))

{

connection.Open();

//Add parameters here

//Perform your update command.ExecuteNonQuery();

}

}

You can even program against a set of common interfaces and not have to worry about the provider specific classes. The core interfaces provided by ADO.NET are:

IDbConnection - for managing database connections

IDbCommand - for running SQL commands

IDbTransaction - for managing transactions

IDataReader - for reading data returned by a command

IDataAdapter - for channeling data to and from datasets

var connectionString = "{your-connection-string}";

var providerName = "{System.Data.SqlClient}"; //for Oracle use "Oracle.ManagedDataAccess.Client" //most likely you will get the above two from ConnectionStringSettings object

var factory = DbProviderFactories.GetFactory(providerName);

using(var connection = new factory.CreateConnection()) { connection.ConnectionString = connectionString; connection.Open();

using(var command = new connection.CreateCommand()) {

command.CommandText = "{sql-query}"; //this needs to be tailored for each database system using(var reader = command.ExecuteReader()) {

while(reader.Read()) {

...

}

}

}

}
