elite foreign policy decision makers “employ rather large structures in presenting their images of their policy environment,” citing three maps whose sizes were 31 nodes and 43 arcs, 53 nodes and 84 arcs, and 73 nodes and 116 arcs. Analyzing dozens of similarly sized causal maps is a daunting task. This problem would be exacerbated by including association, categorical, argument, and other cognitive maps into such analyses.

Set-Theoretic Representations of Causal Mapping

The increased computational complexity of the social causal mapping problem space requires a concurrent increase in the representational power of the corresponding information system. Accordingly, Winston’s (1984) characteristics of “good” representations (i.e., make important things explicit, expose natural constraints, completeness, etc.) can be applied to information systems representing cognitive maps, just as they have been applied to cognitive maps representing human cognition.

While computer programs have been available for some time to create and evaluate individual causal maps, most of those systems store individual maps in separate files whose contents are not easily integrated. This shortcoming severely restricts their use for social causal mapping. Other information systems that have been used to represent cognitive maps are set-theoretic relational databases, i.e., those based on the axioms and mathematical theories about sets (Codd, 1970). Such databases exhibit many of the characteristics of “good” representations: they are explicit about their important features (e.g., the membership relationship between an element and a set) and clear about their constraints (e.g., they cannot express operations that produce transitive closure over binary relations) (Ullman, 1988). They are also concise, transparent, efficient, and abstract (i.e., details can be hidden unless requested). Some processes (e.g., inventorying organizational knowledge) can be addressed efficiently via set-theoretic algorithms similar to those now employed in some knowledge management systems, e.g., “knowledge Yellow Pages” (Davenport & Prusak, 1998).

Unfortunately, set-theoretic approaches do not fully reflect the graph-theoretic nature of causal and other cognitive maps. That is, the relationships between elements in settheoretic approaches correspond to membership in a set, while those in graph-theoretic approaches correspond to one element “pointing to” another. For example, determining the shortest path between two non-adjacent nodes in a causal map cannot be done with set-theoretic approaches because set theory does not represent the logic necessary to travel across—or traverse—multiple node-arc-node segments. This limitation is important because it restricts the types of analysis that can be performed (i.e., it contradicts the representational requirement for the existence of computational procedures). These analyses include: tracing paths along multiple nod-arc-node segments, summing the effects of a series of direct and inverse relationships, and identifying feedback loops. These graph-theoretic procedures cannot be performed efficiently—if at all—by settheoretic relational databases on long series of node-arc-node segments. Differences between set and graph theories are summarized in Table 2.

Copyright © 2005, Idea Group Inc. Copying or distributing in print or electronic forms without written permission of Idea Group Inc. is prohibited.

Object-Oriented Approaches to Causal Mapping 351

Table 2. Set theory versus graph theory

Graph-Theoretic Representations of Causal Mapping

Computer-based systems designed upon graph-theoretic representations and algorithms (Smith & Smith, 1977a, 1977b; Ullman, 1988) are a more promising approach. The cognitive maps in Figure 1 can again serve as an example. The map in Figure 1 represents assertions from two individuals about their conceptualizations and perceptions of risk. Since it contains the causal assertions of multiple individuals, it can be considered as a social causal map. Consider the problem of identifying and comparing the individuals’ causal assertions between IS security procedures and risk. The traversal algorithm must identify two and only two paths of node-arc-node chains:

1.IS security procedures !" “acceptable IS use” training − → litigation + → settlement costs !" risk

2.IS security procedures !" updating firewalls − → damage from virus attacks loss of data !" risk

where !" represents synonymous (i.e., categorical) relationships, + → and −→ represent causal relationships of direct and inverse proportionality, respectively.

Graph theory facilitates the analysis of cognitive maps because it has long supported the development of algorithms that can efficiently and effectively travel across the repetitive “node-arc-node” structures of graphs (i.e., node-arc-node-arc-node-arc-node-etc.). Other programs can build upon these traversal algorithms to assess the total effects of chains of node-arc-node segments. For example, a computer program can be developed to support the query whether two individuals agree if IS security procedures and risk are directly or inversely proportional (e.g., the parallel paths 1 and 2 above). The program can be conceptualized as follows: 1) use a traversal algorithm to identify parallel node- arc-node chains between IS security procedures and risk, regardless of whether the arcs are causal and linguistic (i.e., word categorical); 2) sum the “+” and “-” values of the
