104—Chapter 6. EViews 5.1 Command Reference Update Summary
Cross-references
See Chapter 1, “EViews 5.1 Enhanced Graph Customization”, on page 33 for a discussion of graph objects in EViews.
See addtext (p. 70) and textdefault (p. 136). See setelem (p. 126) for changing legend text and other graph options.
line
Command || Coef View | Graph Command | Group View | Matrix View | Rowvector View | Series View | Sym View | Vector View
Display a line graph of object, or change existing graph object type to line plot.
The line graph view of a group plots all series in the group in a graph. The line graph view of a matrix plots each column in the matrix in a graph.
Syntax
Command: |
line(options) arg1 [arg2 arg3 ...] |
Object View: |
object_name.line(options) |
Graph Proc: |
graph_name.line(options) |
Options
Template and printing options
o= template |
Use appearance options from the specified template. |
|
template may be a predefined template keyword |
|
(‘default” - current global defaults, “classic”, “modern”, |
|
“reverse”, “midnight”, “spartan”, “monochrome”) or a |
|
graph in the workfile. |
|
|
t=graph_name |
Use appearance options and copy text and shading from |
|
the specified graph. |
|
|
b / -b |
[Apply / Remove] bold modifiers of the base template |
|
style specified using the “o=” option above. |
|
|
w / -w |
[Apply / Remove] wide modifiers of the base template |
|
style specified using the “o=” option above. |
|
|
p |
Print the line graph. |
|
|
The options which support the “-” may be proceeded by a “+” or “-” indicating whether to turn on or off the option. The “+” is optional.
EViews 5.1 Command Reference Update Summary—105
Scale options (for multiple line views of group and matrix objects)
a (default) |
Automatic single scale. |
|
|
d |
Dual scaling with no crossing. The first series is scaled |
|
on the left and all other series are scaled on the right. |
|
|
x |
Dual scaling with possible crossing. See the “d” option. |
|
|
n |
Normalized scale (zero mean and unit standard devia- |
|
tion). May not be used with the “s” option. |
|
|
s |
Stacked line graph. Each area represents the cumulative |
|
total of the series listed. The difference between areas |
|
corresponds to the value of a series. May not be used |
|
with the “l” option. |
|
|
m |
Plot lines in multiple graphs (will override the “s” or “l” |
|
options). Not for use with an existing graph object. |
Panel options
The following options apply when graphing panel structured data:
panel=arg |
Panel data display: “stack” (stack the cross-sections), |
(default taken |
“individual” or “1” (separate graph for each cross-sec- |
from global settion), “combine” or “c” (combine each cross-section in
tings) |
single graph; one time axis), “mean” (plot means |
|
across cross-sections), “mean1se” (plot mean and +/- |
|
1 standard deviation summaries), “mean2sd” (plot |
|
mean and +/- 2 s.d. summaries), “mean3sd” (plot |
|
mean and +/- 3 s.d. summaries), “median” (plot |
|
median across cross-sections), “med25” (plot median |
|
and +/- .25 quantiles), “med10” (plot median and +/- |
|
.10 quantiles), “med05” (plot median +/- .05 quan- |
|
tiles), “med025” (plot median +/- .025 quantiles), |
|
“med005” (plot median +/- .005 quantiles), “med- |
|
mxmn” (plot median, max and min). |
Examples
group g1 gdp cons m1
g1.line(d)
plots line graphs of the three series in group G1 with dual scaling (no crossing). The latter two series will share the same scale.
106—Chapter 6. EViews 5.1 Command Reference Update Summary
matrix1.line(t=mygra)
displays line graphs of the columns of MATRIX1 using the graph object MYGRA as a template.
line(m) gdp cons m1
creates an untitled graph object that contains three line graphs of GDP, CONS, and M1, with each plotted separately.
g1.line(o=midnight, b, w)
creates a line graph of the group G1, using the settings of the predefined template “midnight”, applying the bold and wide modifiers.
Cross-references
See Chapter 1, “EViews 5.1 Enhanced Graph Customization”, on page 33 for a detailed discussion of graphs in EViews.
See also graph for graph declaration and other graph types.
linkto |
Link Proc |
|
|
Define the specification of a series link.
Specify the method by which the object uses data in an existing series. Links are used to perform cross-page match merging or frequency conversion.
Syntax
Link Proc: |
link_name.linkto(options) source_page\series_name [src_id |
|
dest_id] |
Link Proc: |
link_name.linkto(options) source_page\series_name [@src src_ids |
|
@dest dest_ids] |
The most common use of linkto will be to define a link that employs general match merging. You should use the keyword linkto followed by any desired options, and then provide the name of the source series followed by the names of the source and destination IDs. If more than one identifier series is used, you must separate the source and destination IDs using the “@SRC” and “@DEST” keywords.
In the special case where you wish to link your data using date matching, you must use the special keyword “@DATE” as an ID series for a regular frequency page. If “@DATE” is not specified as either a source or destination ID, EViews will perform an exact match merge using the specified identifiers.
EViews 5.1 Command Reference Update Summary—107
The other use of linkto will be to define a frequency conversion link between two date structured pages. To specify a frequency conversion link, you should use the linkto keyword followed by any desired options and then the name of a numeric source series. You must not specify ID series since a frequency conversion link uses the implicit dates associated with the regular frequency pages—if ID series are specified, the link will instead employ general match merging. Note also that if ID series are not specified, but a general match merge specific conversion option is provided (e.g., “c=med”), “@DATE @DATE” will be appended to the list of IDs and a general match merge employed.
It is worth mentioning that a frequency conversion link that uses an alpha source series will generate an evaluation error.
Note that linking by frequency conversion is the same as linking by general match merge using the source and destination IDs “@DATE @DATE” with the following exceptions:
•General match merge linking offers contraction methods not available with frequency conversion (e.g., median, variance, skewness).
•General match merge linking allows you to use samples to restrict the source observations used in evaluating the link.
•General match merge linking allows you to treat NA values in the ID series as a category to be used in matching.
•Frequency conversion linking offers expansion methods other than repeat.
•Frequency conversion linking provides options for the handling of NA values.
•Frequency conversion linking uses special handling for panel structured pages. Links involving panel pages first perform a mean contraction in the source page, if necessary, then a frequency conversion to the destination page, then an expansion in the destination, if necessary.
Options
General Match Merge Link Options
The following options are available when linking with general match merging:
smpl= |
Sample to be used when computing contractions during |
smpl_spec |
linkin using match merge. Either provide the sample |
|
range in double quotes or specify a named sample |
|
object. By default, EViews will use the entire workfile |
|
sample “@ALL”. |
|
|
108—Chapter 6. EViews 5.1 Command Reference Update Summary
c=arg |
Set the match merge contraction or the frequency con- |
|
version method. |
|
If you are linking a numeric source series by general |
|
match merge, the argument can be one of: “mean”, |
|
“med” (median), “max”, “min”, “sum”, “sumsq” (sum- |
|
of-squares), “var” (variance), “sd” (standard devia- |
|
tion), “skew” (skewness), “kurt” (kurtosis), “quant” |
|
(quantile, used with “quant=” option), “obs” (number |
|
of observations), “nas” (number of NA values), “first” |
|
(first observation in group), “last” (last observation in |
|
group), “unique” (single unique group value, if |
|
present), “none” (disallow contractions). |
|
If linking an alpha series, only the non-summary meth- |
|
ods “max”, “min”, “obs”, “nas”, first”, “last”, “unique” |
|
and “none” are supported. For numeric links, the |
|
default contraction method is “c=mean”; for alpha |
|
links, the default is “c=unique”. |
|
If you are linking by frequency conversion, you may use |
|
this argument to specify the upor down-conversion |
|
method using the options found in fetch. The default |
|
frequency conversion methods are taken from the series |
|
defaults. |
quant=number Quantile value to be used when contracting using the “c=quant” option (e.g, “quant=.3”).
nacat |
Treat “NA” values as a category when performing link |
|
by general match merge operations. |
Most of the conversion options should be self-explanatory. As for the others: “first” and “last” give the first and last non-missing observed for a given group ID; “obs” provides the number of non-missing values for a given group; “nas” reports the number of NAs in the group; “unique” will provide the value in the source series if it is the identical for all observations in the group, and will return NA otherwise; “none” will cause the link to fail if there are multiple observations in any group—this setting may be used if you wish to prohibit all contractions.
On a match merge expansion, linking by ID will repeat the values of the source for every matching value of the destination. If both the source and destination have multiple values for a given ID, EViews will first perform a contraction in the source (if not ruled out by “c=none”), and then perform the expansion by replicating the contracted value in the destination.
EViews 5.1 Command Reference Update Summary—109
Frequency Conversion Link Options
If the linkto command does not specify identifier series, EViews will link series data using frequency conversion where appropriate.
The following options control the frequency conversion method when creating a frequency conversion link, converting from low to high frequency:
c=arg |
Low to high conversion methods: “r” (constant match |
|
average), “d” (constant match sum), “q” (quadratic |
|
match average), “t” (quadratic match sum), “i” (linear |
|
match last), “c” (cubic match last). |
|
|
The following options control the frequency conversion method when creating a frequency conversion link, converting from high to low frequency:
c=arg |
High to low conversion methods removing NAs: “a” |
|
(average of the nonmissing observations), “s” (sum of |
|
the nonmissing observations), “f” (first nonmissing |
|
observation), “l” (last nonmissing observation), “x” |
|
(maximum nonmissing observation), “m” (minimum |
|
nonmissing observation). |
|
High to low conversion methods propagating NAs: “an” |
|
or “na” (average, propagating missings), “sn” or “ns” |
|
(sum, propagating missings), “fn” or “nf” (first, propa- |
|
gating missings), “ln” or “nl” (last, propagating miss- |
|
ings), “xn” or “nx” (maximum, propagating missings), |
|
“mn” or “nm” (minimum, propagating missings). |
|
|
Note that if no conversion method is specified, the series specific default conversion method or the global settings will be employed.
Examples
General Match Merge Linking
Let us start with a concrete example. Suppose our active workfile page contains observations on the 50 states of the US, and contains a series called STATE containing the unique state identifiers. We also have a workfile page called INDIV that contains data on individuals from all over the country, their incomes (INCOME), and their state of birth (BIRTHSTATE).
Now suppose that we wish to find the median income of males in our data for each possible state of birth, and then to match merge that value into our 50 observation state page.
The following commands:
110—Chapter 6. EViews 5.1 Command Reference Update Summary
link male_income
male_income.linkto(c=med, smpl="if male=1") indiv\income birthstate state
create the series link MALE_INCOME. MALE_INCOME contains links to the individual INCOME data, telling EViews to subsample only observations where MALE=1, to compute median values for individuals in each BIRTHSTATE, and to match observations by comparing the values of BIRTHSTATE to STATE in the current page.
In this next example, we link to the series X in the INDIV page, matching values of the IND1 and the IND2 series in the two workfile pages. The link will compute the number of valid observations in the X series for each index group, with NA values in the ID series treated as a valid identifier value.
link l1.linkto(c=obs,nacat) indiv\x @src ind1 ind2 @dest ind1 ind2
You may wish to use the “@DATE” keyword as an explicit identifier, in order to gain access to our expanded date matching feature. In our annual workfile, the command:
link gdp.linkto(c=sd) monthly\gdp @date @date
will create link that computes the standard deviation of the values of GDP for each year and then match merges these values to the years in the current page. Note that this command is equivalent to:
link gdp.linkto(c=sd) quarterly\gdp
since the presence of the match merge option “c=sd” and the absence of indices instructs EViews to perform the link by ID matching using the defaults “@DATE” and “@DATE”.
Frequency Conversion Linking
Suppose that we are in an annual workfile page and wish to link data from a quarterly page. Then the commands:
link gdp
gdp.linkto quarterly\gdp
creates a series link GDP in the current page containing a link by date to the GDP series in the QUARTERLY workfile page. When evaluating the link, EViews will automatically frequency convert the quarterly GDP to the annual frequency of the current page, using the series default conversion options. If we wish to control the conversion method, we can specify the conversion method as an option:
