Chapter 143: Optimization in C++

Section 143.1: Introduction to performance

C and C++ are well known as high-performance languages - largely due to the heavy amount of code customization, allowing a user to specify performance by choice of structure.

When optimizing it is important to benchmark relevant code and completely understand how the code will be used.

Common optimization mistakes include:

Premature optimization: Complex code may perform worse after optimization, wasting time and e ort. First priority should be to write correct and maintainable code, rather than optimized code.

Optimization for the wrong use case: Adding overhead for the 1% might not be worth the slowdown for the other 99%

Micro-optimization: Compilers do this very e ciently and micro-optimization can even hurt the compilers ability to further optimize the code

Typical optimization goals are:

To do less work

To use more e cient algorithms/structures

To make better use of hardware

Optimized code can have negative side e ects, including:

Higher memory usage

Complex code -being di cult to read or maintain

Compromised API and code design

Section 143.2: Empty Base Class Optimization

An object cannot occupy less than 1 byte, as then the members of an array of this type would have the same address. Thus sizeof(T)>=1 always holds. It's also true that a derived class cannot be smaller than any of its base classes. However, when the base class is empty, its size is not necessarily added to the derived class:

class Base {};

class Derived : public Base

{

public: int i;

};

In this case, it's not required to allocate a byte for Base within Derived to have a distinct address per type per object. If empty base class optimization is performed (and no padding is required), then sizeof(Derived) == sizeof(int), that is, no additional allocation is done for the empty base. This is possible with multiple base classes as well (in C++, multiple bases cannot have the same type, so no issues arise from that).

Note that this can only be performed if the first member of Derived di ers in type from any of the base classes. This includes any direct or indirect common bases. If it's the same type as one of the bases (or there's a common base), at least allocating a single byte is required to ensure that no two distinct objects of the same type have the same address.

Section 143.3: Optimizing by executing less code

The most straightforward approach to optimizing is by executing less code. This approach usually gives a fixed speed-up without changing the time complexity of the code.

Even though this approach gives you a clear speedup, this will only give noticable improvements when the code is called a lot.

Removing useless code

void func(const A *a); // Some random function

//useless memory allocation + deallocation for the instance auto a1 = std::make_unique<A>();

func(a1.get());

//making use of a stack object prevents

auto a2 = A{}; func(&a2);

Version ≥ C++14

From C++14, compilers are allowed to optimize this code to remove the allocation and matching deallocation.

Doing code only once

std::map<std::string, std::unique_ptr<A>> lookup;

//Slow insertion/lookup

//Within this function, we will traverse twice through the map lookup an element

//and even a thirth time when it wasn't in

const A *lazyLookupSlow(const std::string &key) { if (lookup.find(key) != lookup.cend())

lookup.emplace_back(key, std::make_unique<A>()); return lookup[key].get();

}

// Within this function, we will have the same noticeable effect as the slow variant while going at double speed as we only traverse once through the code

const A *lazyLookupSlow(const std::string &key) { auto &value = lookup[key];

if (!value)

value = std::make_unique<A>(); return value.get();

}

A similar approach to this optimization can be used to implement a stable version of unique

std::vector<std::string> stableUnique(const std::vector<std::string> &v) { std::vector<std::string> result;

std::set<std::string> checkUnique; for (const auto &s : v) {

//As insert returns if the insertion was successful, we can deduce if the element was already in or not

//This prevents an insertion, which will traverse through the map for every unique element

//As a result we can almost gain 50% if v would not contain any duplicates

if (checkUnique.insert(s).second) result.push_back(s);

}

return result;

}

Preventing useless reallocating and copying/moving

In the previous example, we already prevented lookups in the std::set, however the std::vector still contains a growing algorithm, in which it will have to realloc its storage. This can be prevented by first reserving for the right size.

std::vector<std::string> stableUnique(const std::vector<std::string> &v) { std::vector<std::string> result;

//By reserving 'result', we can ensure that no copying or moving will be done in the vector

//as it will have capacity for the maximum number of elements we will be inserting

//If we make the assumption that no allocation occurs for size zero

//and allocating a large block of memory takes the same time as a small block of memory

//this will never slow down the program

//Side note: Compilers can even predict this and remove the checks the growing from the generated code

result.reserve(v.size()); std::set<std::string> checkUnique; for (const auto &s : v) {

// See example above

if (checkUnique.insert(s).second) result.push_back(s);

}

return result;

}

Section 143.4: Using e cient containers

Optimizing by using the right data structures at the right time can change the time-complexity of the code.

//This variant of stableUnique contains a complexity of N log(N)

//N > number of elements in v

//log(N) > insert complexity of std::set

std::vector<std::string> stableUnique(const std::vector<std::string> &v) { std::vector<std::string> result;

std::set<std::string> checkUnique; for (const auto &s : v) {

// See Optimizing by executing less code if (checkUnique.insert(s).second)

result.push_back(s);

}

return result;

}

By using a container which uses a di erent implementation for storing its elements (hash container instead of tree), we can transform our implementation to complexity N. As a side e ect, we will call the comparison operator for std::string less, as it only has to be called when the inserted string should end up in the same bucket.

//This variant of stableUnique contains a complexity of N

//N > number of elements in v

//1 > insert complexity of std::unordered_set

std::vector<std::string> stableUnique(const std::vector<std::string> &v) { std::vector<std::string> result;

std::unordered_set<std::string> checkUnique; for (const auto &s : v) {

// See Optimizing by executing less code if (checkUnique.insert(s).second)

result.push_back(s);

}

return result;

}

Section 143.5: Small Object Optimization

Small object optimization is a technique which is used within low level data structures, for instance the std::string (Sometimes referred to as Short/Small String Optimization). It's meant to use stack space as a bu er instead of some allocated memory in case the content is small enough to fit within the reserved space.

By adding extra memory overhead and extra calculations, it tries to prevent an expensive heap allocation. The benefits of this technique are dependent on the usage and can even hurt performance if incorrectly used.

Example

A very naive way of implementing a string with this optimization would the following:

explicit string(const char *cStyleString)

{

auto stringSize = std::strlen(cStyleString); _isAllocated = (stringSize > SMALL_BUFFER_SIZE); if (_isAllocated)

_buffer = new char[stringSize];

else

_buffer = &_smallBuffer[0]; std::strcpy(_buffer, &cStyleString[0]);

}

string(string &&rhs)

: _isAllocated(rhs._isAllocated)

,_buffer(rhs._buffer)

,_smallBuffer(rhs._smallBuffer) //< Not needed if allocated

{

if (_isAllocated)

{

// Prevent double deletion of the memory rhs._buffer = nullptr;

}

else

{

// Copy over data

std::strcpy(_smallBuffer, rhs._smallBuffer); _buffer = &_smallBuffer[0];

}

}

//Other methods, including other constructors, copy constructor,

//assignment operators have been omitted for readability

};

As you can see in the code above, some extra complexity has been added in order to prevent some new and delete operations. On top of this, the class has a larger memory footprint which might not be used except in a couple of cases.

Often it is tried to encode the bool value _isAllocated, within the pointer _buffer with bit manipulation to reduce the size of a single instance (intel 64 bit: Could reduce size by 8 byte). An optimization which is only possible when its known what the alignment rules of the platform is.

When to use?

As this optimization adds a lot of complexity, it is not recommended to use this optimization on every single class. It will often be encountered in commonly used, low-level data structures. In common C++11 standard library implementations one can find usages in std::basic_string<> and std::function<>.

As this optimization only prevents memory allocations when the stored data is smaller than the bu er, it will only give benefits if the class is often used with small data.

A final drawback of this optimization is that extra e ort is required when moving the bu er, making the moveoperation more expensive than when the bu er would not be used. This is especially true when the bu er contains a non-POD type.
