DICOM PS3.17 2020a - Explanatory Information​

Page 871​

Node​

Code Meaning of Concept​ Code Meaning or Example Value​

Reference to TID/ CID/ Comments​

Name​

1.13.6​

Body Mass Index​

21.23​

TID 10024​

UNITS=EV (kg/m2, UCUM, "kg/m2")​

1.13.6.1​

Equation​

(122265, DCM, "BMI=Wt/Ht^2")​

TID 10024​

1.13.7​

Serum Creatinine​

2.7​

TID 10024​

UNITS=DT (mg/dl, UCUM, "mg/dl")​

1.13.8​

Glomerular Filtration Rate​

38​

TID 10024​

UNITS=DT (ml/min{1.73_m2}, UCUM,​

"ml/min/1.73m2")​

1.13.8.1​

Measurement Method​

(113570, DCM, "Cockroft-Gault Formula​

TID 10024​

estimation of GFR")​

CID 10047​

1.13.8.2​

Equivalent meaning of​

(33914-3, LN, "Glomerular Filtration Rate​ TID 10024​

concept name​

(MDRD)")​

CID 10046​

1.14​

Imaging Agent Information​

TID 11002​

1.14.1​

Imaging Agent Identifier​

INJECTOR_CONTRAST_AGENT​

TID 11002​

1.14.2​

Imaging Agent Warmed​

(373066001, SCT, "Yes")​

TID 11002​

CID 231​

1.14.3​

Imaging Agent Component​

TID 11002​

Usage​

1.14.3.1​

Imaging Agent Component​

TID 11004​

1.14.3.1.1​

Drug administered​

(353903006, SCT, "Iopromide")​

TID 11004​

CID 12​

1.14.3.1.2​

Active Ingredient​

(44588005, SCT, "Iodine")​

TID 11004​

CID 13​

1.14.3.1.3​

Concentration​

370​

TID 11004​

UNITS=EV(mg/ml,"UCUM","mg/ml")​

1.14.3.1.4​

Osmolality at 37C​

770​

TID 11004​

UNITS=EV (mosm/kg, UCUM,​

"mosm/kg")​

1.14.3.1.5​

Viscosity at 37C​

10​

TID 11004​

UNITS = EV (cP, "UCUM", "centi​

Poise")​

1.14.3.1.6​

Unit of Presentation​

(68276009, SCT, "Bottle")​

TID 11004​

CID 68​

1.14.3.1.7​

Imaging Agent Volume Per​500​

TID 11004​

Unit of Presentation​

UNITS=EV (ml, UCUM, "ml")​

1.14.3.1.8​

Medical Product Expiration​ 20190301​

TID 11004​

Date​

1.14.3.1.9​

Manufacturer Name​

ContrastMed Corp​

TID 11004​

DICOM PS3.17 2020a - Explanatory Information​

Page 873​

Node​

Code Meaning of Concept​ Code Meaning or Example Value​

Reference to TID/ CID/ Comments​

Name​

1.16.3.1.3​

Concentration​

370​

TID 11004​

UNITS=EV(mg/ml,"UCUM","mg/ml")​

1.16.3.1.4​

Viscosity at 37C​

8.9​

TID 11004​

UNITS = EV (cP, "UCUM",​

"centiPoise")​

1.16.3.1.5​

Unit of Presentation​

(68276009, SCT, "Bottle")​

TID 11004​

CID 68​

1.16.3.1.6​

Imaging Agent Volume Per​100​

TID 11004​

Unit of Presentation​

UNITS=EV (ml, UCUM, "ml")​

1.16.3.1.7​

Manufacturer Name​

ContrastMed Corp​

TID 11004​

1.16.3.1.8​

Brand Name​

OralContrastofin​

TID 11004​

1.16.3.1.9​

Barcode Value​

-00408497​

TID 11004​

PZN number​

1.16.3.1.10​

Lot Identifier​

6X14325​

TID 11004​

1.16.3.2​

Component Volume​

24.4​

TID 11002​

UNITS=EV (ml, UCUM, "ml")​

1.16.4​

Imaging Agent Component​

TID 11002​

Usage​

1.16.4.1​

Imaging Agent Component​

TID 11002​

TID 11004​

1.16.4.1.1​

Drug administered​

(11713004, SCT, "Water")​

TID 11004​

CID 12​

1.16.4.1.2​

Unit of Presentation​

(68276009, SCT, "Bottle")​

TID 11004​

CID 68​

1.16.4.1.3​

Imaging Agent Volume Per​1000​

TID 11004​

Unit of Presentation​

UNITS=EV (ml, UCUM, "ml")​

1.16.4.1.4​

Manufacturer Name​

Fresh Water Corp​

TID 11004​

1.16.4.1.5​

Brand Name​

BestWaterEver​

TID 11004​

1.16.4.1.6​

Barcode Value​

-4801694​

TID 11004​

PZN number​

1.16.4.2​

Component Volume​

975.6​

TID 11002​

UNITS=EV (ml, UCUM, "ml")​

1.17​

Summary​

Administered 1000 ml of Oral Contrastofin​TID 11020​

via oral route and 88ml of ContrastStuff 370​

via intravenous route in Left Arm Vein.​

1.18​

ImagingAgentAdministration​

TID 11005​

Consumable​

DICOM PS3.17 2020a - Explanatory Information​

Page 875​

Node​

Code Meaning of Concept​ Code Meaning or Example Value​

Reference to TID/ CID/ Comments​

Name​

1.21.2​

Steps Description​

administration of first 2 hours in advance of​

the procedure. I.v. administration is done​

with a pre-inject to determine scan delay​

time.Patenttestinjectionappliesasadefault​

procedure.​

1.21.3​

ImagingAgentAdministration​

TID 11007​

Step​

1.21.3.1.​

ImagingAgentAdministration​ORAL_STEP_1​

TID 11007​

Step Identifier​

1.21.3.2​

ImagingAgentAdministration​1.2.3.4.47110815.3​

TID 11007​

Performed Step UID​

Since "Root Concept Name Code​

Sequence" is "Performed Imaging​

Agent Administration"​

1.21.3.3​

Administration Mode​

(130174, DCM, "Manual Administration")​

TID 11007​

CID 63​

1.21.3.4​

Person Role in Organization​(121025, DCM, "Patient")​

TID 11007​

CID 7450​

Since"AdministrationMode"is"Manual​

Administration", condition holds​

(self-administration)​

1.21.3.5​

Administration Step Type​

(130249,DCM,"DiagnosticAdministration")​TID 11007​

CID 72​

1.21.3.6​

Scan Delay​

7200​

TID 11007​

UNITS = EV (s, UCUM, "s")​

1.21.3.7​

Route of Administration​

(26643006, SCT, "Oral route")​

TID 11007​

CID 11​

1.21.3.8​

ImagingAgentAdministration​

TID 11008​

Phase​

1.21.3.8.1​

ImagingAgentAdministration​ORAL_PHASE​

TID 11008​

Phase Identifier​

1.21.3.8.2​

ImagingAgentAdministration​1.2.3.4.47110815.4​

TID 11008​

Performed Phase UID​

Since "Root Concept Name Code​

Sequence" is "Performed Imaging​

Agent Administration"​

1.21.3.8.3​

ImagingAgentAdministration​

TID 11003​

Activity​

1.21.3.8.3.1​

Referenced Imaging Agent​ ORAL_CONTRAST_AGENT​

TID 11003​

Identifier​

Value of 1.16.1​

1.21.3.8.3.2​

Volume Administered​

1000​

TID 11003​

UNITS = EV (ml, UCUM, "ml")​

Same value as 1.21.3.8.4​

DICOM PS3.17 2020a - Explanatory Information​

Page 877​

Node​

Code Meaning of Concept​ Code Meaning or Example Value​

Reference to TID/ CID/ Comments​

Name​

1.21.4.5.1.1​

Laterality​

(7771000, SCT, "Left")​

TID 11007​

CID 244​

Since "Site of" is "Via arm vein"​

1.21.4.6​

ImagingAgentAdministration​

TID 11008​

Phase​

1.21.4.6.1​

ImagingAgentAdministration​EXTRAVASATION_TEST_PHASE​

TID 11008​

Phase Identifier​

1.21.4.6.2​

ImagingAgentAdministration​1.2.3.4.47110815.6​

TID 11008​

Performed Phase UID​

Since "Root Concept Name Code​

Sequence" is "Performed Imaging​

Agent Administration"​

1.21.4.6.3​

ImagingAgentAdministration​(130171, DCM, "Automatic with Manual​

TID 11008​

Phase Type​

Inject Phase")​

CID 62​

Since 1.21.4.3 (Administration Mode)​

is "Automated Administration"​

1.21.4.6.4​

ImagingAgentAdministration​

TID 11003​

Activity​

1.21.4.6.4.1​

Referenced Imaging Agent​ INJECTOR_FLUSH_AGENT​

TID 11003​

Identifier​

Value of 1.15.1​

1.21.4.6.4.2​

Volume Administered​

30​

TID 11003​

UNITS = EV (ml, UCUM, "ml")​

Same value as 1.21.4.6.5 and​

1.21.4.9.1​

1.21.4.6.4.3​

Starting Flow Rate of​

3​

TID 11003​

administration​

UNITS = EV (ml/s, UCUM "ml/s")​

1.21.4.6.4.4​

Peak Flow Rate in Phase​

3​

TID 11003​

Activity​

UNITS = EV (ml/s, UCUM "ml/s")​

Page 878​

DICOM PS3.17 2020a - Explanatory Information​

Node​

Code Meaning of Concept​ Code Meaning or Example Value​

Reference to TID/ CID/ Comments​

Name​

1.21.4.6.4.6​

Initial Volume of Imaging​

197​

TID 11003​

Agent in Container​

UNITS = EV (ml, UCUM, "ml")​

Since "Root Concept Name Code​

Sequence" is "Performed Imaging​

Agent Administration"​

1.21.4.6.4.7​

Residual Volume of Imaging​167​

TID 11003​

Agent in Container​

UNITS = EV (ml, UCUM, "ml")​

Since "Root Concept Name Code​

Sequence" is "Performed Imaging​

Agent Administration"​

1.21.4.6.4.8​

DateTime Started​

20181012121537​

TID 11003​

Since root Concept Name is​

"Performed Imaging Agent​

Administration"​

1.21.4.6.4.9​

Duration​

10​

TID 11003​

UNITS = EV (s, UCUM, "s")​

Since root Concept Name is​

"Performed Imaging Agent​

Administration"​

1.21.4.6.5​

Total Phase Volume​

30​

TID 11008​

Administered​

UNITS = EV (ml, UCUM, "ml")​

In this case the same value as​

1.21.4.6.4.2 and 1.21.4.9.1​

1.21.4.6.6​

DateTime Started​

20181012121537​

TID 11008​

Since root Concept Name Code​

Sequenceis"PerformedImagingAgent​

Administration"​

1.21.4.6.7​

Duration​

10​

TID 11008​

UNITS = EV (s, UCUM, "s")​

Since root Concept Name Code​

Sequenceis"PerformedImagingAgent​

Administration")​

1.21.4.7​

Number of Injector Heads​

2​

TID 11007​

1.21.4.8​

Programmable Device​

(373066001, SCT, "Yes")​

TID 11007​

CID 231​

1.21.4.9​

Manually triggered injection​

TID 11007​

information​

Since 1.21.4.3 (Administration Mode)​

is"AutomatedAdministration"androot​

DICOM PS3.17 2020a - Explanatory Information​

Page 879​

Node​

Code Meaning of Concept​ Code Meaning or Example Value​

Reference to TID/ CID/ Comments​

Name​

1.21.4.9.1​

Total Step Volume​

30​

TID 11007​

Administered​

UNITS = EV (ml, UCUM, "ml")​

In this case the same value as​

1.21.4.6.4.2 and 1.21.4.6.5​

1.21.4.9.2​

Total number of manually​

1​

TID 11007​

triggered injections​

1.21.5​

ImagingAgentAdministration​

TID 11007​

Step​

1.21.5.1​

ImagingAgentAdministration​DELAY_ESTIMATE_STEP_3​

TID 11007​

Step Identifier​

1.21.5.2​

ImagingAgentAdministration​1.2.3.4.47110815.7​

TID 11007​

Performed Step UID​

Since "Root Concept Name Code​

Sequence" is "Performed Imaging​

Agent Administration"​

1.21.5.3​

Administration Mode​

(130173,DCM,"AutomatedAdministration")​TID 11007​

CID 63​

1.21.5.4​

Administration Step Type​

(130248,DCM,"TransitTimeTestInjection")​TID 11007​

CID 72​

1.21.5.5​

Pressure Limit​

15​

TID 11007​

UNITS = EV (kPa, UCUM "kPa")​

Since 1.21.5.3 is "Automated​

Administration"​

1.21.5.6​

Route of Administration​

(47625008, SCT, "Intravenous route")​

TID 11007​

CID 11​

1.21.5.6.1​

Site of​

(261459001, SCT, "Via arm vein")​

TID 11007​

CID 3746​

Since "Route of Administration" is​

"Intravenous route"​

1.21.5.6.1.1​

Laterality​

(7771000, SCT, "Left")​

TID 11007​

CID 244​

Since "Site of" is "Via arm vein"​

1.21.5.7​

ImagingAgentAdministration​

TID 11008​

Phase​

1.21.5.7.1​

ImagingAgentAdministration​DELAY_ESTIMATE_PHASE_1​

TID 11008​

Phase Identifier​

1.21.5.7.2​

ImagingAgentAdministration​1.2.3.4.47110815.8​

TID 11008​

Performed Phase UID​

Since "Root Concept Name Code​

Sequence" is "Performed Imaging​

Agent Administration"​
