Page 1272​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

121094​

Performing​

The person responsible for performing the procedure.​

121095​

Referring​

The person responsible for referring the patient for the​Retired. Replaced by​

procedure.​

(C1709880,UMLS,"Referring​

physician").​

121096​

Requesting​

The person responsible for requesting the procedure.​

121097​

Recording​

The person responsible for recording the procedure or​

observation.​

121098​

Verifying​

The person responsible for verifying the recorded​

procedure or observation.​

121099​

Assisting​

Thepersonresponsibleforassistingwiththeprocedure.​

121100​

Circulating​

The person responsible for making preparations for and​Retired. Replaced by​

monitoring the procedure.​

(413854007, SCT,​

"Circulating Nurse").​

121101​

Standby​

Thepersonresponsibleforstandingbytoassistwiththe​

precedure if required.​

121102​

Other sex​

Other sex.​

121103​

Undetermined sex​

Sex of subject undetermined at time of encoding.​

121104​

Ambiguous sex​

Ambiguous sex.​

121105​

Radiation Physicist​

Radiation Physicist.​

Retired. Replaced by​

(C2985483,UMLS,"Radiation​

Physicist").​

121106​

Comment​

Comment.​

121109​

Indications for Procedure​

Indications for Procedure​

Retired. Replaced by​

(18785-6,LN,"Indicationsfor​

Procedure")​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 1273​

Code Value​

Code Meaning​

Definition​

Notes​

121122​

Equipment Identification​

Equipment identification.​

121123​

Patient Status or Event​

ArecordedPatientStatusoraneventinvolvingapatient.​

121124​

Procedure Action Item ID​

Identification of a step, action, or phase of a procedure.​

121125​ DateTime of Recording of Log​DateTime of Recording of an Entry in an Event Log.​

Entry​

121126​ PerformedProcedureStepSOP​SOP Instance UID of a Performed Procedure Step.​

Instance UID​

121127​ PerformedProcedureStepSOP​SOP Class UID of a Performed Procedure Step.​

Class UID​

121128​

Procedure Action Duration​

Duration of a step, action, or phase of a procedure.​

121130​

Start Procedure Action Item​

Beginning of a step, action, or phase of a procedure.​

121131​

End Procedure Action Item​

End of a step, action, or phase of a procedure.​

121132​ SuspendProcedureActionItem​Suspension of a step, action, or phase of a procedure.​

121133​ Resume Procedure Action Item​Resumption of a step, action, or phase of a procedure.​

121135​ Observation DateTime Qualifier​Concept modifier for the DateTime of Recording of an​

Entry in an Event Log.​

121136​

DateTime Unsynchronized​

RecordedDateTimehaditssourceinasystemclocknot​

synchronized to other recorded DateTimes.​

121137​

DateTime Estimated​

Recorded DateTime is estimated.​

121138​

Image Acquired​

Event of the acquisition of an image.​

121139​

Modality​

Type of data acquisition device.​

121140​

Number of Frames​

Number of Frames in a multi-frame image.​

121141​

Image Type​

Descriptor of an Image.​

121142​

Acquisition Duration​

Duration of the acquisition of an image or a waveform.​

121143​

Waveform Acquired​

Event of the acquisition of an image.​

121144​

Document Title​

Document Title.​

121145​

Description of Material​

Description of Material used in a procedure.​

121146​

Quantity of Material​

Quantity of Material used in a procedure.​

121147​

Billing Code​

Billing Code for materials used in a procedure.​

121148​

Unit Serial Identifier​

Unit or Device Serial Identifier.​

121149​

Lot Identifier​

Lot Identifier.​

121150​

Device Code​

Vendor or local coded value identifying a device.​

121151​

Lesion Identifier​

Identification of a Lesion observed during an imaging​

procedure.​

121152​

Person administering​

Person administering drug/contrast.​

drug/contrast​

121153​

Lesion Risk​

Assessment of the risk a coronary lesion presents to the​

health of a patient.​

121154​

Intervention attempt identifier​

Identifier for an attempted Intervention.​

121155​

Deployment​

Use of a device to deploy another device.​

121156​

Percutaneous Entry Action​

Action of a clinical professional at the site of​

percutaneous access to a patient's cardiovascular​

system.​

121157​

Begin Circulatory Support​

The action or event of beginning circulatory support for​

a patient.​

Page 1274​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

121158​

End Circulatory Support​

The action or event of ending circulatory support for a​

patient.​

121160​

Oxygen Administration Rate​

Rate of Oxygen Administration.​

121161​

Begin Oxygen Administration​

Theactionoreventofbeginningadministrationofoxygen​

to a patient.​

121162​

End oxygen administration​

The action or event of ending administration of oxygen​

to a patient.​

121163​

By ventilator​

Method of administration of oxygen to a patient by​

ventilator.​

patient.​

121166​

Begin Pacing​

The action or event of beginning pacing support for a​

patient.​

121167​

End Pacing​

Theactionoreventofendingpacingsupportforapatient.​

121168​

Begin Ventilation​

The action or event of beginning ventilation support for​

a patient.​

121169​

End Ventilation​

The action or event of ending ventilation support for a​

patient.​

121171​

Tech Note​

Procedural note originated by a technologist.​

121172​

Nursing Note​

Procedural note originated by a nurse.​

121173​

Physician Note​

Procedural note originated by a Physician.​

121174​

Procedure Note​

General procedural note.​

121180​

Key Images​

List of references to images considered significant​

Retired. Replaced by​

(55113-5, LN, "Key Images")​

121181​

DICOM Object Catalog​

List of references to DICOM SOP Instances.​

121190​

Referenced Frames​

Individual frames selected as a subset of a multi-frame​

image.​

121191​

Referenced Segment​

Segmentselectedasasubsetofasegmentationimage,​

specifically the pixels/voxels identified as belonging to​

the classification of the identified segment.​

121192​

Device Subject​

A device is the subject of observations.​

121193​

Device Subject Name​

Name or other identifier of a device that is the subject of​

observations.​

121194​

Device Subject Manufacturer​

Manufacturer of a device that is the subject of​

observations.​

121195​

Device Subject Model Name​

Model Name of a device that is the subject of​

observations.​

121196​ Device Subject Serial Number​Serial Number of a device that is the subject of​

observations.​

121197​

Device Subject Physical​

Physical Location of a device that is the subject of​

Location during observation​

observations during those observations.​

121198​

Device Subject UID​

Unique Identifier of a device that is the subject of​

observations.​

121200​

Illustration of ROI​

Illustration of a region of interest.​

121201​

Area Outline​

Retired. Replaced by​

(121056, DCM, "Area​

Outline").​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 1275​

Code Value​

Code Meaning​

Definition​

Notes​

121202​ Area of Defined Region​

Retired. Replaced by​

(131184002, SCT, "Area of​

defined region").​

121206​

Distance​

A one dimensional, or linear, numeric measurement.​

121207​

Height​

Vertical measurement value.​

121208​

Inter-Marker Distance​

Distance between marks on a device of calibrated size.​

E.g., a ruler.​

121210​

Path​

Retired. Replaced by​

(121055, DCM, "Path").​

121211​

Path length​

Aonedimensional,orlinear,numericmeasurementalong​

a polyline.​

121213​

Perimeter Outline​

Retired. Replaced by​

(121057, DCM, "Perimeter​

Outline").​

121214​

Referenced Segmentation​

Frame selected from a segmentation image, specifically​

Frame​

the pixels/voxels identified as belonging to the​

classificationofthesegmentencompassingtheidentified​

frame.​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 1277​

Code Value​

Code Meaning​

Definition​

Notes​

121321​ Mask image for image​

Image used as the mask for an image processing​

processing operation​

operation, such as subtraction.​

121322​ Source image for image​

Image used as the source for an image processing​

processing operation​

operation.​

121323​ Source series for image​

Series used as the source for an image processing​

processing operation​

operation.​

121324​

Source Image​

Image used as the source for a derived or compressed​

image.​

121325​

Lossy compressed image​

Imageencodedwithalossycompressiontransfersyntax.​

121326​ Alternate SOP Class instance​ SOP Instance encoded with a different SOP Class but​

otherwise equivalent data.​

121327​

Full fidelity image​

Full fidelity image, uncompressed or lossless​

compressed.​

121328​

Alternate Photometric​

Imageencodedwithadifferentphotometricinterpretation.​

Interpretation image​

121329​ Source image for montage​

Image used as a source for a montage (stitched) image.​

121330​ Lossycompressedpredecessor​An image that has previously been lossy compressed​

that is used as the source for creation of another lossy​

compressed image.​

121331​

Equivalent CDA Document​

HL7 Document Architecture (CDA) Document that​

contains clinical content equivalent to the referencing​

Instance.​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 1279​

Code Value​

Code Meaning​

Definition​

Notes​

121384​

RT Plan Label​

Human readable label of the radiotherapy plan.​

121385​

Current Fraction Number​

The index of the fraction of the radiotherapy plan to be​

delivered.​

121386​ Number of Fractions Planned​ The total number of prescribed radiotherapy fractions.​

121387​

NumberofFractionsCompleted​The number of fully completed radiotherapy fractions of​

theradiotherapyplantobedelivered.Partiallycompleted​

fractions are not included.​

121388​

Checked-In Status​

Whetherornotthepatienthasbeenchecked-in,i.e.,are​

physically present and are waiting to be called in to the​

treatment room.​

121389​

Referenced Beam Number​

The referenced beam number within the radiotherapy​

plan to be delivered.​

121401​

Derivation​

Methodofderivingorcalculatingameasuredvalue.E.g.,​

mean, or maximum of set.​

121402​

Normality​

Assessmentofameasurementrelativetoanormalrange​

of values; may be considered subtype of term​

(363713009, SCT, "has interpretation").​

121403​

Level of Significance​

Significance of a measurement.​

121404​

Selection Status​

Status of selection of a measurement for further​

processing or use.​

121405​

Population description​

Description of a population of measurements.​

121406​

Reference Authority​

Bibliographic or clinical reference for a Description of a​

population of measurements.​

121407​

Normal Range description​

Description of a normal range of values for a​

measurement concept.​

121408​

Normal Range Authority​

Bibliographic or clinical reference for a Description of a​

normal range of values.​

121410​

User chosen value​

Observationvalueselectedbyuserforfurtherprocessing​

or use, or as most representative.​

121411​ Most recent value chosen​

Observationvalueistherecentlyobtained,andhasbeen​

selected for further processing or use.​

121412​

Mean value chosen​

Observationvalueisthemeanofseveralmeasurements,​

and has been selected for further processing or use.​

121414​

Standarddeviationofpopulation​Standard deviation of a measurement in a reference​

population.​

121415​

Percentile Ranking of​

Percentile Ranking of an observation value with respect​

measurement​

a reference population.​

121416​

Z-Score of measurement​

Z-scoreofanobservationvaluewithrespectareference​

population, expressed as the dimensionless quantity​

(x-m) /s, where (x-m) is the deviation of the observation​

value (x) from the population mean (m), and s is the​

standard deviation of the population.​

121417​ 2 Sigma deviation of population​2 Sigma deviation of a measurement in a reference​

population.​

121420​

Equation​

Formula used to compute a derived measurement.​

121421​

Equation Citation​

Bibliographic reference to a formula used to compute a​

derived measurement; reference may be to a specific​

equation in a journal article.​

Page 1280​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

121422​ Table of Values Citation​

BibliographicreferencetoaTableofValuesusedtolook​

up a derived measurement.​

121423​

Method Citation​

Bibliographic reference to a method used to compute a​

derived measurement.​

121424​

Table of Values​

A Table of Values used to look up a derived​

measurement.​

121425​

Index​

Factor (divisor or multiplicand) for normalizing a​

measurement. E.g., body surface area used for​

normalizing hemodynamic measurements.​

121427​

Estimated​

Measurement obtained by observer estimation, rather​Retired. Replaced by​

than with a measurement tool or by calculation​

(414135002, SCT,​

"Estimated")​

121428​

Calculated​

Measurement obtained by calculation​

Retired. Replaced by​

(258090004, SCT,​

"Calculated")​

121430​

Concern​

Identified issue about a state or process that has the​

potential to require intervention or management.​

121431​

DateTime Concern Noted​

DateTime concern noted (noted by whom is determined​

by context of use).​

121432​

DateTime Concern Resolved​

DateTime the concern was resolved.​

121433​

DateTime Problem Resolved​

DateTime the problem was resolved.​

121434​

Service Delivery Location​

Place at which healthcare services may be provided.​

121435​

Service Performer​

Identification of a healthcare provider who performed a​

healthcare service; may be either a person or an​

organization.​

121436​

Medical Device Used​

Type or identifier of a medical device used on, in, or by​

a patient.​

121437​

Pharmacologic and exercise​

Cardiac stress test using pharmacologic and exercise​ Retired. Replaced by​

stress test​

stressors​

(428813002, SCT,​

"Pharmacologicandexercise​

stress test")​

121438​

Paced stress test​

Cardiacstresstestusinganimplantedorexternalcardiac​Retired. Replaced by​

pacing device​

(428685003, SCT, "Stress​

test using cardiac pacing")​

121439​

Correction of congenital​

Procedure for correction of congenital cardiovascular​

Retired.​

cardiovascular deformity​

deformity​

Replaced by (428613004,​

SCT, "Correction of​

congenital cardiovascular​

deformity")​

121701​

RT Patient Setup​

Process of placing patient in the anticipated treatment​

position,includingspecificationandlocationofpositioning​

aids, and other treatment delivery accessories.​
