Page 1312​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

125273​

Left Ventricle Mass by Area​

Equation = Left Ventricle Mass by Area Length /​

Length - adjusted by Height​

Height^2.7​

Reference:​

Giovanni De Simone, et al. "Effect of Growth on​

Variability of Left Ventricular Mass: Assessment of​

Allometric Signals in Adults and Children and Their​

CapacitytoPredictCardiovascularRisk".NewYork,New​

York and Cincinnati, Ohio.​

125301​

Pre-coordinatedMeasurements​Measurements that are described by a single​

pre-coordinated code.​

125302​

Post-coordinatedMeasurements​Measurements that are described by a collection of​

(generally atomic) post-coordinated codes.​

125303​

Adhoc Measurements​

Measurements taken in an ad hoc fashion without any​

coordinated semantics.​

125304​

Untrackable Measurement​

The source system of the measurement does not​

maintain a persistent pre-coordinated code by which​

differentinstancesofthemeasurementcanbeassociated​

and tracked over multiple procedures.​

125305​

Finding Observation Type​

The type of observation made at the finding site, e.g.,​

whetheritisanobservationofthestructureofthefinding​

site, an observation of the behavior of the finding site, or​

an observation of the blood flow at the finding site.​

125306​

Measurement Type​

The type of derivation used to obtain the measurement​

value. E.g. whether it is taken directly, formed as a ratio,​

normalized against an index, or calculated using a more​

elaborate equation.​

125307​

Measured Property​

The property that is being measured.​

Examples include mass, diameter, peak blood velocity.​

125308​

Measurement Divisor​

The measurement which is the denominator of a​

measurement that is divided. This applies to​

measurements such as ratios or indexed values.​

125309​

Short Label​

A brief label, suitable for display on a screen or report.​

(Not suitable for matching).​

125310​

Staged Measurements​

Measurementsthatneedtobeassociatedwithaspecific​

stage in a procedure or acquisition protocol.​

125311​ Structure of the Finding Site​

The subject of a measurement is the physical structure​

of the Finding Site, such as the mass or diameter.​

125312​ Behavior of the Finding Site​

The subject of a measurement is the behavior of the​

Finding Site, such as the velocity or duration of motion.​

125313​

Indexed​

The measurement has been normalized by dividing it by​

an index value (such as Body Surface Area).​

125314​

Fractional Change​

The measurement is a change value expressed as a​

fractionofitsbaselinevalue.E.g.cardiacejectionfraction​

or fractional shortening.​

125315​

Calculated​

The measurement is calculated by incorporating one or​

more measured values into an equation other than a​

ratio, fractional change or indexed calculation.​

125316​

Directly measured​

Themeasurementisadirectoutputofthemeasurement​

tool.​

Page 1314​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

125907​

Targestar-B​

Targestar™-B ultrasonic contrast agent produced by​

Targeson LLC.​

125908​

Targestar-P​

Targestar™-P ultrasonic contrast agent produced by​

Targeson LLC.​

human or machine analysis of images for oncology​

evaluation.​

126002​

Dynamic Contrast MR​

A structured report containing the quantitative results of​

Measurement Report​

human or machine analysis of DCE-MR.​

126003​

PET Measurement Report​

A structured report containing the quantitative results of​

human or machine analysis of PET images.​

126010​

Imaging Measurements​

Measurements made on images​

126020​ Multiparametric MRI​

AnMRIprocedureinwhichmultipleparametersincluding​

diffusion, dynamic contrast and T2 are measured.​

parametersincludingdiffusion,dynamiccontrastandT2​

are measured.​

126022​

Multiparametric MRI of whole​ An MRI procedure of the whole body in which multiple​

body​

parametersincludingdiffusion,dynamiccontrastandT2​

are measured.​

126030​ Sum of segmented voxel​

The volume derived by summing the volumes of all the​

volumes​

voxels(andpartialvoxelsifthesegmentcontainspartially​

occupied voxels) included in the segment​

126031​ Peak Value Within ROI​

Maximum average gray value that is calculated from a​

1 cubic centimeter sphere placed within the region of​

interest.​

See Wahl RL, Jacene H, Kasamon Y, Lodge MA. From​

RECIST to PERCIST: Evolving Considerations for PET​

Response Criteria in Solid Tumors. Journal of Nuclear​

Medicine. 2009;50(Suppl 1):122S - 150S.​

126032​

Metabolic Volume​

The volume of a lesion (e.g., a tumor) ascertained​

throughinformationaboutitsmetabolicactivity(e.g.,SUV​

on PET).​

The volume may be defined on the same modality (e.g.,​

the MV on FDG-PET by some thresholding or other​

technique) or on another spatially registered modality​

(e.g., the lesion outline segmented on CT or MR).​

Doesnotapplytootherradiopharmaceuticalsthanthose​

involved in glucose metabolism.​

Abbreviated TLG. Synonymnous with "Tumor Lesion​

Glycolysis".​

126034​

Glycolysis​

The amount glycolytic activity summed across all voxels​

in a defined region or within a defined range of SUV (on​

FDG-PET).​

126035​

Total Lesion Proliferation​

The total activity of a lesion obtained as the product of​

its volume and its proliferative activity (on FLT-PET).​

The volume may be defined on the same modality (e.g.,​

the MV on FDG-PET by some thresholding or other​

technique) or on another spatially registered modality​

(e.g., the lesion outline segmented on CT or MR).​

Doesnotapplytootherradiopharmaceuticalsthanthose​

involved in cellular proliferation.​

Abbreviated TLP. Synonymnous with "Tumor Lesion​

Proliferation".​

126036​

Proliferative Activity​

The amount proliferative activity summed across all​

voxels in a defined region or within a defined range of​

SUV (on FLT-PET).​

Activity (SAM)​

version of TLG.​

SAMiscalculatedbydrawingavolumeofinterest(VOI1)​

aroundthetumourandalargerVOI(VOI2)aroundVOI1.​

Subtracting the background activity in VOI2-VOI1 from​

VOI1 yields SAM.​

SeeMertensetal."Standardizedaddedmetabolicactivity​

(SAM): a partial volume independent marker of total​

lesion glycolysis in liver metastases". Eur J Nucl Med​

Mol Imaging (2012) 39:1441-1448.​

Retired.​

Replaced by (WF0Z, IBSI,​

"Inverse Difference Moment​

of GLCM").​

126063​

Contrast of GLCM​

The sum of squares of a Gray Level Co-occurrence​

Distinct from "joint (sum of​

Matrix (GLCM). A measure of gray level variations.​

squares) variance" and​

Abbreviated CON.​

"dissimilarity".​

See Fcm.contrast in [IBSI Features].​

Retired.​

Replaced by (ACUI, IBSI,​

"Contrast of GLCM").​

126064​

Dissimilarity of GLCM​

The dissimilarity of a Gray Level Co-occurrence Matrix​Distinctfrom"contrast",which​

(GLCM). Abbreviated DIS.​

uses square rather than​

absolute value of difference.​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 1317​

Code Value​

Code Meaning​

Definition​

Notes​

126065​ Angular Second Moment of​

The Angular Second Moment of a Gray Level​

Sometimes referred to as​

GLCM​

Co-occurrence Matrix (GLCM). Abbreviated ASM.​

"energy", "uniformity" or​

See Fcm.energy in [IBSI Features].​

"uniformityofenergy"butthen​

potentially confused with​

square root of ASM.​

Retired.​

Replaced by (8ZQL, IBSI,​

"Angular Second Moment of​

GLCM").​

126066​

Correlation of GLCM​

A measure of the linear dependency of gray levels on​ Correlation is NaN for a​

those of neighbouring pixels of a Gray Level​

constant image.​

Co-occurrence Matrix (GLCM). Abbreviated COR.​

Retired.​

See Fcm.corr in [IBSI Features].​

Replaced by (NI2N, IBSI,​

"Correlation of GLCM").​

126067​

Gray Level Co-occurrence​

A tabulation of how often different combinations of pixel​

Matrix​

values (gray levels) occur in an image. Abbreviated​

GLCM.​

See [IBSI Features].​

126070​ Subject Time Point Identifier​

Anidentifierofaspecifictimepointinacontinuum,which​

is unique within an appropriate local context (such as an​

entireorganization,systemortreatmentprotocol),which​

identifies the time point for a specific patient.​

126071​ Protocol Time Point Identifier​

Anidentifierofaspecifictimepointinacontinuum,which​

is unique within an appropriate local context (such as an​

entireorganization,systemortreatmentprotocol),which​

identifies the time point "slot" within a treatment protocol​

using the same value for all patients in the protocol.​

126072​

Time Point Type​

Apre-definedtypeofaspecifictimepointinacontinuum.​

126073​

Time Point Order​

A number indicating the order of a time point relative to​

other time points in the same continuum.​

126074​

Posttreatment​

The time after the treatment of interest.​

126075​

Eligibility​

For the purpose of determining eligibility for a protocol.​Similar but not identical to​

(21954-3, LN, "Protocol​

eligibility status Cancer"),​

since not constrained to​

cancer, etc.​

126080​

RECIST 1.0​

Response Evaluation Criteria in Solid Tumors version​ More specific than (112022,​

1.0. See [RECIST] in Normative References.​

DCM, "RECIST") or​

(C1709926, UMLS,​

"RECIST") or (C49164, NCIt,​

"RECIST") in that a specific​

version is specified.​

126081​

RECIST 1.1​

Response Evaluation Criteria in Solid Tumors Version​More specific than (112022,​

1.1. See Eisenhauer et al. "New Response Evaluation​DCM, "RECIST") or​

Criteria in Solid Tumours: Revised RECIST Guideline​ (C1709926, UMLS,​

(version 1.1)." European Journal of Cancer 45, no. 2​

"RECIST") or (C49164, NCIt,​

(n.d.): 228-47. doi:10.1016/j.ejca.2008.10.026.​

"RECIST") in that a specific​

version is specified.​

Page 1318​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

126100​ Real World Value Map used for​A reference to the Real World Value Map applied to the​

measurement​

stored image pixel values before their use for a​

measurement​

126200​

Image Library Group​

Acontainerthatgroupscommoninformationaboutaset​

of images used as evidence to produce a report.​

126201​

Acquisition Date​

The date the acquisition of data started​

126202​

Acquisition Time​

The time the acquisition of data started​

126203​

PET Radionuclide Incubation​

The time between the start of injection of the PET​

Time​

radionuclide and the start of acquisition of the PET data.​

126220​

R2-Coefficient​

Coefficient of determination, R2. An indication of​

goodness of fit.​

126221​

Chi-square​

Pearson's Χ2 test.​

126222​

D-W​

Durbin-Watson statistic for detecting serial correlation in​

residuals.​

See http://en.wikipedia.org/wiki/​

Durbin%E2%80%93Watson_statistic.​

126223​

AIC​

Akaike information criterion. A measure of the balance​

betweengoodnessoffitandnumberoffreeparameters.​

See Akaike H. A new look at the statistical model​

identification. IEEE Transactions on Automatic Control.​

1974 Dec;19(6):716-23. http://dx.doi.org/10.1109/​

TAC.1974.1100705.​

126224​

BIC​

Bayesianinformationcriterion.Ameasureofthebalance​

between goodness of fit and model complexity.​

See http://en.wikipedia.org/wiki/​

Bayesian_information_criterion.​

126300​ Perfusion analysis by Stable​

Perfusion analysis by Stable Xenon CT technique​

Xenon CT technique​

126301​ Perfusion analysis by IV​

PerfusionanalysisbyIVIodinatedContrastCTtechnique​

IodinatedContrastCTtechnique​

126302​ Perfusion analysis by Arterial​

Perfusion analysis by Arterial Spin Labeling (ASL) MR​

Spin Labeling MR technique​

technique​

126303​

Perfusion analysis by​

Perfusion analysis by Susceptibility (T2*) MR technique​

Susceptibility MR technique​

126310​ Least Mean Square (LMS)​

Least Mean Square (LMS) deconvolution​

deconvolution​

126311​ Singular Value Decomposition​Singular Value Decomposition (SVD) deconvolution​

(SVD) deconvolution​

126312​

Ktrans​

Ktrans, the volume transfer constant of a tracer diffusion​

kinetic model, specifically the volume transfer constant​

between blood plasma and extravascular extracellular​

space (EES)​

See Tofts et al, "Estimating Kinetic Parameters From​

Dynamic Contrast-Enhanced T1-Weighted MRI of a​

DiffusableTracer:StandardizedQuantitiesandSymbols",​

Journal of Magnetic Resonance Imaging, vol. 10, pp.​

223-232, 1999.​

126314​

ve​

ve, the fractional (not absolute) volume of extravascular​

extracellular space (EES) per unit volume of tissue​

See Tofts et al, "Estimating Kinetic Parameters From​

Dynamic Contrast-Enhanced T1-Weighted MRI of a​

DiffusableTracer:StandardizedQuantitiesandSymbols",​

Journal of Magnetic Resonance Imaging, vol. 10, pp.​

223-232, 1999.​

126320​

IAUC​

The initial area under the contrast agent​

concentration-time curve​

126321​

IAUC60​

The initial area under the contrast agent​

concentration-time curve at 60 seconds after the onset​

time​

126322​

IAUC90​

The initial area under the contrast agent​

concentration-time curve at 90 seconds after the onset​

time​

126323​

IAUC180​

The initial area under the contrast agent​

concentration-time curve at 180 seconds after the onset​

time​

126324​

IAUCBN​

The initial area under the contrast agent​

concentration-time curve, normalized with the​

corresponding arterial input function, such that IAUCBN​

= IAUC / IAUCAIF.​

126325​

IAUCBN60​

The initial area under the contrast agent​

concentration-time curve at 60 seconds after the onset​

time, normalized with the corresponding arterial input​

function, such that IAUC60BN = IAUC60 / IAUC60AIF.​

126326​

IAUCBN90​

The initial area under the contrast agent​

concentration-time curve at 90 seconds after the onset​

time, normalized with the corresponding arterial input​

function, such that IAUC90BN = IAUC90 / IAUC90AIF.​

126327​

AUCBN180​

The initial area under the contrast agent​

concentration-time curve at 180 seconds after the onset​

time, normalized with the corresponding arterial input​

function,suchthatIAUC180BN =IAUC180/IAUC180AIF.​

126330​

tau_m​

τm. The mean intracellular water lifetime (τi). Used in the​

Shutter-Speed Model (SSM) of tracer kinetics.​

126331​

vp​

vp. The fractional (not absolute) blood plasma volume​

per unit volume of tissue.​

Page 1320​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

126340​

Standard Tofts Model​

A tracer diffusion kinetic model in which the permeability​

is assumed to be isodirectional.​

See P. Tofts, "Modeling tracer kinetics in dynamic​

Gd-DTPAMRimaging",JournalofMagneticResonance​

Imaging, vol. 7, pp. 91-101, 1997.​

MathematicallyequivalenttothemodelproposedbyKety​

in a non-MRI context, hence sometimes refered to as​

theTofts-Kety(TK)model.SeeKetySS.TheTheoryand​

Applications of the Exchange of Inert Gas at the Lungs​

and Tissues. Pharmacological Reviews. 1951 Mar​

1;3(1):1-41.​

126341​ Extended Tofts Model​

A tracer diffusion kinetic model in which the permeability​

is not assumed to be isodirectional, and which includes​

the contribution of tracer in the blood plasma to the total​

tissue concentration.​

126343​ First Pass Leakage Profile​

A tracer diffusion kinetic model that accounts for the​

(FPLP) Model​

tumor leakage profile during the first pass of contrast.​
