DICOM PS3.16 2020a - Content Mapping Resource |
Page 1371 |
|
Code Value |
Code Meaning |
Definition |
Notes |
130137 RT Treatment Planning Input |
Image Instances available as input for planning a |
|
|
|
Images |
Radiotherapy treatment plan. |
|
130138 |
Multiple Fixed Sources |
A treatment technique using multiple decaying radiation |
|
|
|
sources at fixed spatial locations. |
|
130139 |
SynchronizedRoboticTreatmentA treatment technique using a robotic delivery device |
|
|
|
|
with real-time motion tracking and compensation. |
|
130140 |
Non-Synchronized Robotic |
A treatment technique using a robotic delivery device |
|
|
Treatment |
without real-time motion tracking and compensation. |
|
130141 |
^3^Helium nucleus |
Ionized helium atom with 2 protons and 1 neutron. |
|
130142 |
^4^Helium nucleus |
Ionized helium atom with 2 protons and 2 neutrons. |
|
130143 |
^12^Carbon nucleus |
Ionized carbon atom with 6 protons and 6 neutrons. |
|
130144 |
^16^Oxygen nucleus |
Ionized oxygen atom with 8 protons and 8 neutrons. |
|
130150 Pressure above warning limit |
The injector device detected a pressure above the |
|
|
|
|
warning threshold, generated a warning and did not |
|
|
|
automatically terminate the administration. |
|
130151 PressureaboveadjustmentlimitThe injector device detected a pressure above the |
|
||
|
|
adjustment limit, took compensating action and did not |
|
|
|
automatically terminate the administration. |
|
130152 |
Flow rate above warning limit The injector device detected a flow rate above the |
|
|
|
|
warning threshold, generated a warning and did not |
|
|
|
automatically terminate the administration. |
|
130153 FlowrateaboveadjustmentlimitThe injector device detected a flow rate above the adjustment limit, took compensating action and did not automatically terminate the administration.
130154 Terminated due to request fromThe injector device terminated the administration due to
operator |
detection of an abort request by the operator. |
130155 Fixed duration pause ended |
The device detected that a pause duration has been |
|
reached and the device resumed automatically. |
130156 Terminated due to pressure |
The injector device detected a pressure above the |
above termination limit |
termination limit and automatically terminated the |
|
administration. |
130157 Terminated due to flow rate |
The injector device detected a flow rate above the |
above termination limit |
termination limit and automatically terminated the |
|
administration. |
130158 Terminated due to excessive The Injector device detected that a pause duration has duration pause exceeded limit and the injector device terminated the
administration.
130159 Terminated due to injector communication loss
The injector device detected a communication loss and automatically
terminated the administration.
130160 Terminated due to unspecifiedThe injector device detected an unspecified failure and
injector failure |
automatically |
|
terminated the administration. |
130161 Keep vein open started |
The injector device started saline flow for the purpose of |
|
keeping vein open. |
130162 Keep vein open ended |
The injector device ended saline flow for the purpose of |
|
keeping vein open. |
- Standard -
Page 1372 |
DICOM PS3.16 2020a - Content Mapping Resource |
|
|
Code Value |
Code Meaning |
Definition |
Notes |
130163 |
Syringe attached |
Theinjectordevicedetectedthatasyringewasattached |
|
|
|
to the injector. |
|
130164 |
Syringe detached |
Theinjectordevicedetectedthatasyringewasdetached |
|
|
|
from the injector. |
|
130165 Total Keep Vein Open VolumeTotal volume of flush delivered by the keep vein open |
|
||
|
Administered |
function of the injector. |
|
130168 AutomaticAdministrationPhaseAn administration phase where fluid is being delivered |
|
||
|
|
by an injector system according to the programmed |
|
|
|
instructions. |
|
130169 |
Automatic Programmed Hold |
An administration phase where fluid delivery is stopped |
|
|
Phase |
by the injector system until a programmed time elapses. |
|
130170 Automatic with Manual Hold |
An administration phase where the fluid is delivered |
|
|
|
Phase |
automatically by an injector system and stopped under |
|
|
|
manual control by the operator. |
|
130171 Automatic with Manual Inject |
An administration phase where the fluid is delivered by |
|
|
|
Phase |
theinjectorsystemundermanualcontrolbytheoperator. |
|
|
|
E.g., Cardiac Cath. |
|
130172 |
Manually Triggered Injection |
Information only available if injection was triggered |
|
|
Information |
manually. |
|
130173 |
Automated Administration |
An administration mode where the fluid is delivered by |
|
|
|
a mechanical injector system. |
|
130174 |
Manual Administration |
Anadministrationmodewherethesubstanceisdelivered |
|
|
|
manually |
|
|
|
E.g., Clinician manual injection of an Imaging Agent or |
|
|
|
oral consumption by a patient. |
|
130175 |
Air detected |
The injector device detected air in the tubing or syringe |
|
|
|
before or during the Imaging Agent administration and |
|
|
|
did not automatically terminate the administration. |
|
130176 Terminated due to air detectedThe injector device detected air in the tubing or syringe |
|
||
|
|
and terminated the administration. |
|
130177 |
Terminated by scanner |
The injector device received instruction from scanner to |
|
|
|
terminate the administration and terminated the |
|
|
|
administration. |
|
130178 TerminatedduetocriticalbatteryThe injector device detected critical battery level and |
|
||
|
level |
terminated the administration. |
|
130179 Terminated due to consumableThe injector device detected removal of a consumable |
|
||
|
removal |
from the injector device and terminated the |
|
|
|
administration. |
|
130181 |
Administration Mode |
A code that specifies how the Imaging Agent is |
|
|
|
administered to the patient. |
|
130182 |
Planned Imaging Agent |
A report of the planned patient-specific Imaging Agent |
|
|
AdministrationProcedureReportadministration steps. |
|
|
130183 |
Imaging Agent Information |
DescriptionofaspecificImagingAgentthatwasplanned |
|
|
|
or was administered. |
|
130184 |
Osmolality at 37C |
Number of osmoles of solute per kilogram of solvent at |
|
|
|
37°C. |
|
130185 |
Osmolarity at 37C |
Number of osmoles of solute per liter (L) at 37°C. |
|
130186 |
Viscosity at 37C |
A measure of a resistance of a fluid to gradual |
|
|
|
deformation by stress, measured at 37°C. |
|
- Standard -
|
DICOM PS3.16 2020a - Content Mapping Resource |
Page 1373 |
|
Code Value |
Code Meaning |
Definition |
Notes |
130187 |
Imaging Agent Warmed |
Indicates if an Imaging Agent was warmed prior to the |
|
|
|
administration procedure. |
|
130188 Contrast Transverse RelaxivityThe degree to which a paramagnetic contrast agent can enhance the proton transverse relaxation rate constant (R2,1/T2),normalizedtotheconcentrationofthecontrast agent.
|
|
Also referred to as r2. Typically expressed in units |
|
|
l/mmol/s. |
130189 |
Is Ionic |
IndicateswhethertheImagingAgentisIonicornon-ionic. |
130190 |
Dosing Factor |
Indicates normalized dose of Imaging Agent per kg of |
|
|
patient weight. Typically recommended by the vendor. |
|
|
For e.g,. grams Iodine per Kg (gI / Kg). |
130191 |
Imaging Agent Component |
Information about use of Imaging Agent component(s). |
|
Usage |
|
130192 Imaging Agent Administration Information about list of administration steps for |
||
|
Steps |
administering Imaging Agent. |
130193 |
Pressure Limit |
A limit set at the power injector device indicating the |
|
|
maximum allowed pressure planned for administering |
|
|
the Imaging Agent. |
130194 Time after the start of injectionTime after the start of injection of a delivered Imaging Agent administration.
130195 Imaging Agent Administration An individual administration step in the Imaging Agent
Step |
administration plan. |
130196 Imaging Agent Administration IdentifiesastepinanImagingAgentadministrationplan. |
|
Step Identifier |
|
130197 Imaging Agent Administration Time difference between the nominal start of the |
|
Delay |
administrationstepandtheactualstartofImagingAgent |
|
administration. |
130198 Scan Delay |
Time delay for start of image acquisition after start of |
|
Imaging Agent administration. |
130199 Imaging Agent Administration Description of Imaging Agent administration plan. |
|
Steps Description |
|
130200 Imaging Agent Administration Protocol name for Imaging Agent administration. Protocol Name
130202 Imaging Agent Administration Information about a delivery phase of an Imaging Agent Phase administration step.
130203 Imaging Agent Administration Identifies a phase in an Imaging Agent administration Phase Identifier step.
130204 Imaging Agent Administration Type of phase in an Imaging Agent administration step. Phase Type
130205 Initial Volume of Imaging AgentThe volume of the Imaging Agent in an Imaging Agent
|
in Container |
container before administration. |
130206 |
Residual Volume of Imaging |
The volume of the Imaging Agent remaining in the |
|
Agent in Container |
Imaging Agent container after administration. |
130207 |
Rise Time |
Time for the injector to build up from zero to the set |
|
|
pressure. |
130208 Starting Flow Rate of administration
Flow rate at the start of an administration of the Imaging Agent.
- Standard -
Page 1374 |
DICOM PS3.16 2020a - Content Mapping Resource |
|
|
Code Value |
Code Meaning |
Definition |
Notes |
130209 Ending Flow Rate of |
Flow rate at the end of an administration of the Imaging |
|
|
|
administration |
Agent. |
|
130210 |
Bolus Shaping Curve |
A vendor-specific code indicating the shape of the flow |
|
|
|
rate curve within an administration phase. |
|
130211 |
Imaging Agent Administration ThestatusoftheImagingAgentadministrationprocedure |
|
|
|
Completion Status |
at completion as reported by the automated injector or |
|
|
|
by the administering person. |
|
130212 |
Imaging Agent Administration Information about adverse events occurring during |
|
|
|
Adverse Events |
administration of an Imaging Agent. |
|
130214 |
EstimatedExtravasationVolumeThe estimated volume lost at the injection site. |
|
|
|
|
The estimation includes extravasation, paravenous |
|
|
|
administration and leakage at the injection site. |
|
130215 |
Adverse Event Detection |
Date and Time when an adverse event was noticed by |
|
|
DateTime |
the observer. |
|
130216 |
Referenced Imaging Agent |
TheuniqueidentifieroftheImagingAgentadministration |
|
|
Administration Step UID |
step being referenced. |
|
130217 |
Referenced Imaging Agent |
The identifier of an Imaging Agent administration phase |
|
|
Administration Phase Identifierbeing referenced. |
|
|
130218 |
Programmable Device |
Can be configured to execute a series of steps |
|
|
|
automatically. |
|
130219 Number of Injector Heads |
Numberofinjectorheadsorpumps(single,dualormany) |
|
|
|
|
in an injector device. |
|
130220 |
Administration discontinued |
Whether the agent administration was discontinued. |
|
130221 Imaging Agent Volume per UnitThevolumeofImagingAgentinoneunitofpresentation. |
|
||
|
of Presentation |
The capacity of the unit of presentation may be larger |
|
|
|
than this. |
|
130222 |
Imaging Agent Administration Information about the Imaging Agent accessory or |
|
|
|
Consumable |
consumable used for performing the Imaging Agent |
|
|
|
administration. |
|
130223 |
Imaging Agent Administration Type of consumable used for performing the Imaging |
|
|
|
Consumable Type |
Agent administration. |
|
130224 |
Consumable is New |
If the consumable is installed newly during the |
|
|
|
preparation process for this Imaging Agent |
|
|
|
Administration. |
|
130226 |
Planned Imaging Agent |
InformationabouttheImagingAgentadministrationsteps |
|
|
Administration |
that is patient-specific. |
|
130227 |
Performed Imaging Agent |
InformationabouttheImagingAgentadministrationsteps |
|
|
Administration |
that were delivered to a patient. |
|
130228 |
Contrast Volume Limit |
The maximum volume of contrast agent allowed to be |
|
|
|
administered. |
|
|
|
This is typically specified by the prescribing health care |
|
|
|
professional for patient safety and quality purposes. |
|
130229 Flow Rate vs Time |
Graph depicting the measurement of flow rate of fluid |
|
|
|
|
against time. |
|
130230 |
Pressure vs Time |
Graph depicting the measurement of pressure of fluid |
|
|
|
against time. |
|
130231 |
Barcode Value |
The alphanumeric string from reading a barcode. |
|
- Standard -
|
DICOM PS3.16 2020a - Content Mapping Resource |
Page 1375 |
|
Code Value |
Code Meaning |
Definition |
Notes |
130232 |
Imaging Agent Administration Information about two-dimensional graph data for a |
|
|
|
Graph |
syringe or pump. |
|
130233 |
Imaging Agent Administration Information about events that occurred at an injector |
|
|
|
Injector Events |
during an Imaging Agent administration. |
|
130234 |
Imaging Agent Administration Type of event that occurred at an injector during an |
|
|
|
Injector Event Type |
Imaging Agent administration. |
|
130235 |
Injector Event Detection |
Date and time when an injector event was detected. |
|
|
DateTime |
|
|
130236 |
Planned Imaging Agent |
Reference to a Planned Imaging Agent Administration |
|
|
Administration SOP Instance |
SOP instance. |
|
130237 |
Imaging Agent Administration Information about the activity in an Imaging Agent |
|
|
|
Activity |
administration phase. In an Automated Injection system |
|
|
|
this describes the activity of one of the pump or syringe |
|
|
|
units used. |
|
130238 |
Imaging Agent Component |
Information about a component of an Imaging Agent. |
|
130239 |
Component Volume |
Volume of one agent component in a mixture of multiple |
|
|
|
components. |
|
130240 |
Total Phase Volume |
Total volume administered by all syringes/pump actions |
|
|
Administered |
during a single phase. |
|
130241 TotalStepVolumeAdministeredTotal volume administered by all syringes/pump actions |
|
||
|
|
within all phases during a single Step. |
|
130242 Total number of manually |
Total number of times that an injection was triggered |
|
|
|
triggered injections |
manually. |
|
130244 Peak Flow Rate in Phase |
Peak flow rate value detected at a specific location |
|
|
|
Activity |
(syringe or pump) during a specific activity of an |
|
|
|
administration phase. |
|
130245 PeakPressureinPhaseActivityPeak pressure value detected at a location (syringe or |
|
||
|
|
pump) during a single administration phase activity. |
|
130246 |
Imaging Agent Administration UniqueidentificationofasingleperformedImagingAgent |
|
|
|
Performed Step UID |
administration step actually delivered on a specific |
|
|
|
occasion |
|
130247 |
Patency Test Injection |
An injection of an inactive agent to test for blockages or |
|
|
|
leakages in the delivery path, usually performed prior to |
|
|
|
an administration of an imaging or therapeutic agent. |
|
130248 Transit Time Test Injection |
AninjectionofabolusofImagingAgenttodeterminethe |
|
|
|
|
appropriate delay time for a diagnostic administration. |
|
130249 |
Diagnostic Administration |
Administration of an Imaging Agent for the purpose of |
|
|
|
enhancing contrast in an image. |
|
130250 |
Administration Step Type |
Type of step in an Imaging Agent administration. For |
|
|
|
example, a test administration or a diagnostic |
|
|
|
administration. |
|
130251 |
Flush Administration |
Injection of an inactive fluid to clear the administration |
|
|
|
path of an active agent. |
|
130252 |
Negative exponential |
A curve that decays exponentially from a specified start |
|
|
|
value, at a specified decay rate. |
|
- Standard -
Page 1376 |
DICOM PS3.16 2020a - Content Mapping Resource |
|
|
Code Value |
Code Meaning |
Definition |
Notes |
130253 |
Linear Curve |
Acurvethatchangeslinearlyfromaspecifiedstartvalue |
|
|
|
to a specified end value. |
|
|
|
Note |
|
|
|
Note: The start value and the end value may |
|
|
|
be the same, indicating a flat curve. |
|
130254 |
Imaging Agent Identifier |
Identifies an Imaging Agent uniquely within a set of |
|
|
|
Imaging Agents. The Imaging Agent may be a single |
|
|
|
component or a mix of multiple components. |
|
130255 |
Referenced Imaging Agent |
The identifier of an Imaging Agent being referenced. |
|
|
Identifier |
|
|
130257 |
Consumable Catheter Type |
Type of catheter used for Imaging Agent administration. |
|
130259 |
Contrast Reaction ProphylacticApharmaceuticalagentadministeredasapre-medication |
|
|
|
Agent |
to prevent contrast reactions. |
|
130261 |
Imaging Agent Administration Unique identification of a single Imaging Agent |
|
|
|
Performed Phase UID |
administration performed phase. |
|
130262 |
Referenced Imaging Agent |
TheuniqueidentifieroftheImagingAgentadministration |
|
|
Administration Phase UID |
performed phase being referenced |
|
130290 |
Median |
Towards the mid-sagittal plane of the body. |
|
130300 |
Skin of paraspinal area of the Structure of skin of paraspinal area of the neck. |
|
|
|
neck |
|
|
130301 |
Skin of paraspinal area of the Structure of skin of paraspinal area of the superior back. |
|
|
|
superior back |
|
|
130302 Skin of upper paraspinal regionStructure of skin of upper paraspinal region. |
|
||
130303 |
Skin of mid paraspinal region |
Structure of skin of mid paraspinal region. |
|
130304 Skin of lower paraspinal regionStructure of skin of lower paraspinal region. |
|
||
130305 |
Skin of anterior helix of ear |
Structure of skin of anterior helix of ear. |
|
130306 |
Skin of caruncle of eye |
Structure of skin of caruncle of eye. |
|
130307 |
Skin of inferior helix of ear |
Structure of skin of inferior helix of ear. |
|
130308 Skin of inferior posterior surfaceStructureofskinofinferiorposteriorsurfaceofthepinna. |
|
||
|
of the pinna |
|
|
130309 Skin of lateral part of dorsum ofStructure of skin of lateral part of dorsum of foot. |
|
||
|
foot |
|
|
130310 |
Skin of lower antihelix of ear |
Structure of skin of lower antihelix of ear. |
|
130311 |
Skin of lower eyelid margin |
Structure of skin of lower eyelid margin. |
|
130312 |
Skin of infraalar groove |
Structure of skin of infraalar groove. |
|
130313 Skin of medial part of dorsum ofStructure of skin of medial part of dorsum of foot. |
|
||
|
foot |
|
|
130314 |
Skin of paranasal cheek |
Structure of skin of paranasal cheek. |
|
130315 |
Skin of posterior helix of ear |
Structure of skin of posterior helix of ear. |
|
130316 |
Skin of posterior lobule of the Structure of skin of posterior lobule of the ear. |
|
|
|
ear |
|
|
130317 |
Skin of sole of forefoot |
Structure of skin of sole of forefoot. |
|
130318 Skin of superior antihelix of earStructure of skin of superior antihelix of ear.
130319 Skin of superior posterior helixStructure of skin of superior posterior helix of ear. of ear
- Standard -
|
DICOM PS3.16 2020a - Content Mapping Resource |
Page 1377 |
|
Code Value |
Code Meaning |
Definition |
Notes |
130320 Skin of superior posterior |
Structure of skin of superior posterior surface of the |
|
|
|
surface of the pinna |
pinna. |
|
130321 Skin of upper antihelix of ear |
Structure of skin of upper antihelix of ear. |
|
|
130322 Skin of upper eyelid margin |
Structure of skin of upper eyelid margin. |
|
|
130323 Skin of mid back |
Structure of skin of mid back. |
|
|
130324 |
Functional condition present |
A functional condition present during acquisition, such |
|
|
during acquisition |
as phonation, weight bearing, voiding of the bladder or |
|
|
|
hemodynamic physiological challenges. |
|
130330 |
Jaw Pair |
RT beam limiting device jaw pair |
|
130331 |
Leaf Pairs |
RT beam limiting device multi-element leaf pairs |
|
130332 |
Variable Circular Collimator |
A circular, aperture size adjustable beam limiting device |
|
|
|
for an RT treatment device. |
|
130333 |
Single Leaves |
RT beam limiting device multi-element unpaired leaves |
|
130334 |
X Orientation |
Oriented in the X direction of a defined coordinate |
|
|
|
system. |
|
130335 |
Y Orientation |
Oriented in the Y direction of a defined coordinate |
|
|
|
system. |
|
130340 |
Physical Compensator |
PhysicalRTexternalbeamcompensatortocompensate |
|
|
|
for inhomogeneity. |
|
130341 |
Total Body Irradiation |
RT Treatment irradiating the body of the Patient in part |
|
|
|
or in whole. |
|
130342 |
Total Skin Irradiation |
RT Treatment irradiating the surface of the skin of the |
|
|
|
Patient in part or in whole. |
|
126812 |
Isocentric Patient Support |
Patient SupportContinuous Pitch Angle at the isocenter |
|
|
Continuous Pitch Angle |
position about the x-axis of the Equipment Coordinate |
|
|
|
System. |
|
126813 |
Isocentric Patient Support |
Patient Support Continuous Roll Angle at the isocenter |
|
|
Continuous Roll Angle |
position about the y-axis of the Equipment Coordinate |
|
|
|
System. |
|
126814 |
Isocentric Patient Support |
Patient Support Continuous Yaw Angle at the isocenter |
|
|
Continuous Yaw Angle |
position about the z-axis of the Equipment Coordinate |
|
|
|
System. |
|
126815 |
Isocentric Patient Support |
Patient Support Lateral Position along the x-axis of the |
|
|
Lateral Position |
Equipment Coordinate System. |
|
126816 |
Isocentric Patient Support |
Patient Support Longitudinal Position along the y-axis of |
|
|
Longitudinal Position |
the Equipment Coordinate System. |
|
126817 |
Isocentric Patient Support |
Patient Support Vertical Position along the z-axis of the |
|
|
Vertical Position |
Equipment Coordinate System. |
|
130343 |
Electron Fixed Aperture |
A type of device (or cone) for electron treatments that |
|
|
|
attaches to the applicator carriage of an RT treatment |
|
|
|
deviceforthepurposeofholdinganapertureandabolus |
|
|
|
closetothepatient'sskin.Severalbeamapplicatorsmay |
|
|
|
be available to reduce the weight of apertures lifted by |
|
|
|
therapists,decreasetheaperture/bolus-to-skindistance, |
|
|
|
and reduce leakage radiation. |
|
130344 |
Photon Fixed Aperture |
A type of device (or cone) for photon treatments that is |
|
|
|
attachedtotheradiationheadofanRTtreatmentdevice |
|
|
|
into which beam modifiers are installed. |
|
- Standard -
Page 1378 |
DICOM PS3.16 2020a - Content Mapping Resource |
|
|
Code Value |
Code Meaning |
Definition |
Notes |
130345 |
Intraoperative Fixed Aperture A type of device which is used to delimit the radiation of |
|
|
|
|
an RT treatment device in case of an intraoperative |
|
|
|
radiotherapeutic treatment. |
|
130346 |
Hard Wedge |
A physical device placed inside the radiation head used |
|
|
|
to modify the fluence distribution across the field. |
|
130347 |
Motorized Wedge |
Aphysicaldevicemanuallyplacedbetweentheradiation |
|
|
|
head and the patient used to modify the fluence |
|
|
|
distribution across the field. It is motorized and can be |
|
|
|
inserted/extracted from the beam path. |
|
130348 |
Dynamic Wedge |
An effective wedge generated by the movement of a jaw |
|
|
|
across the treatment field while delivering radiation. |
|
130349 |
Graticule |
Mechanical grid to embed scaling information in a |
|
|
|
radiographic image |
|
130350 |
Reticle |
Mechanicalcrosshairtoembedacrosshairrepresenting |
|
|
|
axes and scaling information in a radiographic image |
|
130351 |
Image Detector |
An electronic radiographic imaging device |
|
130352 |
Film Holder |
Mechanical device to hold imaging film |
|
130353 |
Winston-Lutz Pointer |
A spherical mechanical indicator used for alignment |
|
130354 |
Bowtie Filter |
A bowtie-shaped filter used in imaging |
|
130355 |
Flattening Filter Beam |
Beam that uses a filter to produce a nearly uniform |
|
|
|
intensity profile. |
|
130356 |
Non-Flattening Filter Beam |
Beam that does not use a filter to produce a nearly |
|
|
|
uniform intensity profile. |
|
130357 |
Partial Flattening Filter Beam |
Beamthatusesafiltertoproduceanearlyuniformregion |
|
|
|
across part of the intensity profile. |
|
128678 |
Physics Assistant |
A medical professional capable of developing a |
|
|
|
radiotherapy plan from a Physicians prescription and |
|
|
|
assisting in radiation machine calibration and other |
|
|
|
radiotherapy quality assurance work under supervision |
|
|
|
of a Medical Physicist. |
|
130358 |
Nominal Radiation Source |
The point location defined as the nominal source of |
|
|
Location |
radiation. |
|
130359 |
Treatment Machine Isocenter Thecenterpointofthetreatmentmachinethroughwhich |
|
|
|
|
all beam central axes pass under all gantry angles. |
|
130360 |
Fixed Laser Setup Point |
A fixed point at which initial patient setup is performed |
|
|
|
based on lasers. |
|
130361 RadiotherapyTreatmentDeviceA device delivering radiotherapy treatments. |
|
||
130362 |
Head Node Set |
Set of Robotic Nodes that can be used for targets |
|
|
|
associated with the patient's head. |
|
130363 |
Body Node Set |
Set of Robotic Nodes that can be used for targets within |
|
|
|
the patient's body, excluding the head. |
|
130364 |
Trigeminal Node Set |
Set of Robotic Nodes that can be used for targets near |
|
|
|
the patient's trigeminal nerve. |
|
130365 |
QA Node Pair |
Two Robotic Nodes for Quality Assurance, for example |
|
|
|
daily checks. |
|
130366 |
QA Node |
Single Robotic Node for Quality Assurance. |
|
130370 |
RTV Rendition |
DICOMobjectscommunicatedintime-synchronizedflows |
|
|
|
using DICOM-RTV, intended for a simultaneous |
|
|
|
presentation. |
|
- Standard -
|
DICOM PS3.16 2020a - Content Mapping Resource |
Page 1379 |
|
Code Value |
Code Meaning |
Definition |
Notes |
130371 RTV Audio and Video RenditionAudio and Video DICOM objects communicated in |
|
||
|
|
time-synchronized flows using DICOM-RTV, intended |
|
|
|
for a simultaneous presentation. |
|
130372 |
RTV Stereo Video Rendition |
Two Video DICOM objects communicated in |
|
|
|
time-synchronized flows using DICOM-RTV, intended |
|
|
|
for a stereo video. |
|
130373 RTV Audio and Stereo Video |
Audio and two Video DICOM objects communicated in |
||
|
Rendition |
time-synchronized flows using DICOM-RTV, intended |
|
|
|
for a stereo video. |
|
130400 Geometric purpose of region |
The purpose of defining a region. E.g., to define a |
|
|
|
|
bounding box, center or outline. |
|
130401 |
Visual explanation |
A visual explanation of how an algorithm produced its |
|
|
|
results. E.g., for a machine learning application, a class |
|
|
|
activation or saliency map. |
|
130402 |
Class activation |
Values are derived using global average pooling in |
Zhou B, Khosla A, Lapedriza |
|
|
convolutional neural networks to produce a localizationA, Oliva A, Torralba A. |
|
|
|
map highlighting the important regions in the image forLearning Deep Features for |
|
|
|
predicting a class. The class activation map (CAM) |
Discriminative Localization. |
|
|
indicates the discriminative image regions used by theIEEE Conference on |
|
|
|
network to identify a class. |
Computer Vision and Pattern |
|
|
|
Recognition (CVPR). 2016. p |
|
|
|
2921–9. http://dx.doi.org/ |
|
|
|
10.1109/CVPR.2016.319 |
130403 |
Gradient-weighted class |
Values are derived using the gradients of a target classSelvaraju RR, Cogswell M, |
|
|
activation |
flowingintothefinalconvolutionallayerofaconvolutionalDas A, Vedantam R, Parikh |
|
|
|
neuralnetworktoproducealocalizationmaphighlightingD,BatraD.Grad-CAM:Visual |
|
|
|
the important regions in the image for predicting a class.Explanations from Deep |
|
|
|
Thegradient-weightedclassactivationmap(Grad-CAM)NetworksviaGradient-based |
|
|
|
indicates the discriminative image regions used by theLocalization. 2016. http:// |
|
|
|
network to identify a class. |
arxiv.org/abs/1610.02391 |
130404 |
Saliency |
Valuesarederivedusingasingleback-propagationpassSimonyan K, Vedaldi A, |
|
|
|
through a network to produce a localization map |
Zisserman A. Deep Inside |
|
|
highlightingthespatialsupportofagivenclassinagivenConvolutional Networks: |
|
|
|
image. |
Visualising Image |
|
|
|
Classification Models and |
|
|
|
Saliency Maps. 2013. http:// |
|
|
|
arxiv.org/abs/1312.6034 |
130405 Patient-Attached Dose ControlAn object which is attached to the patient to attenuate |
|
||
|
Object |
the therapeutic dose (such as a Bolus or a lead shield). |
|
130406 |
Non-uterine leiomyosarcoma |
A leiomyosarcoma (sarcoma containing large spindle |
|
|
|
cells of smooth muscle) occuring at a site other than the |
|
|
|
uterus. |
|
130407 Bone and soft tissue |
Body structures of bone and soft tissue. |
|
- Standard -
Page 1380 |
DICOM PS3.16 2020a - Content Mapping Resource |
- Standard -
