DICOM PS3.16 2020a - Content Mapping Resource​

Page 1351​

Code Value​

Code Meaning​

Definition​

Notes​

128670​

Head of Radiology​

The senior ranking radiologist in the organization​

128671​ Chair of Protocol Committee​

The chair of a committee tasked with reviewing and​

approving protocols in the organization.​

128673​

Administrator of Radiology​

The administrative head of a department that provides​

Department​

radiology services.​

organization.​

128675​

Head of Cardiology​

The senior ranking cardiologist in the organization.​

128676​

Representative of Protocol​

A representative of a committee tasked with reviewing​

Committee​

and approving protocols in the organization.​

128677​

Representative of Ethics​

A representative of a committee tasked with evaluating​

Committee​

medical ethics. E.g. Institutional Review Board.​

128701​

3D Gel​

A volume of gel that changes physical characteristics​

when exposed to ionizing radiation.​

128702​

Diode Array​

A number of semiconductor devices that generates​

current when exposed to ionizing radiation. The devices​

are arranged systematically in a regular pattern.​

128703​

Ion Chamber Array​

Anumberofdevicesthatmeasureschargefromtheions​

produced in a medium when exposed to ionizing​

radiation. The devices are arranged systematically in a​

regular pattern.​

128704​

Diode​

A semiconductor device that generates current when​

exposed to ionizing radiation.​

128705​

Liquid Ion Chamber​

An ion chamber that uses a liquid as the medium.​

128706​

OSLD​

Optically Stimulated Luminescent Dosimeter. It is a​

crystal that when exposed to green light, emits blue light​

in proportion to the amount of ionizing radiation it has​

been exposed to.​

128707​

Ion Chamber​

A device that measures charge from the ions produced​

in a medium when exposed to ionizing radiation.​

Page 1352​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

128708​

Diamond Detector​

A semiconductor detector that uses diamond as the​

medium.​

128710​

For Teaching File Export​

Instances that have been selected for export to a​

teaching file.​

128711​

For Clinical Trial Export​

Instancesthathavebeenselectedforexportforaclinical​

trial.​

128712​

Additional Teaching File​

The title of a document containing additional teaching​

Information​

file information.​

128713​ For Research Collection Export​Instances that have been selected for export to a​

research collection.​

128714​

For Publication Export​

Instances that have been selected for export for​

publication.​

128715​ Delay export until final report is​Delay export until final report is available.​

available​

128716​

Delay export until clinical​

Delay export until clinical information is available.​

information is available​

128717​ Delay export until confirmation​Delay export until confirmation of diagnosis is available.​

of diagnosis is available​

128718​

Delayexportuntilhistopathology​Delay export until histopathology is available.​

is available​

128719​

Delay export until other​

Delay export until other laboratory results are available.​

laboratory results are available​

128720​

Delay export until patient is​

Delay export until patient is discharged.​

discharged​

128721​ Delay export until patient dies​ Delay export until patient dies.​

128722​ Delay export until expert review​Delay export until expert review is available.​

is available​

128723​

Teaching File Category​

The category that describes the subject matter of a​

teaching file. E.g., a selection from the American Board​

of Radiology (ABR) subject headings.​

128724​

Level of Difficulty​

The level of difficult that the material represents. E.g.,​

advanced.​

128725​

Primary level​

The teaching material is of a primary level of difficulty.​

128726​

Intermediate level​

The teaching material is of an intermediate level of​

difficulty.​

128727​

Advanced level​

Theteachingmaterialisofanadvancedlevelofdifficulty.​

128728​ Musculoskeletalimagingsubject​The subject matter pertains to musculoskeletal imaging.​

matter​

128729​

Pulmonary imaging subject​

The subject matter pertains to pulmonary imaging.​

matter​

128730​ Cardiovascular imaging subject​The subject matter pertains to cardiovascular imaging.​

matter​

128731​

Gastrointestinalimagingsubject​The subject matter pertains to gastrointestinal imaging.​

matter​

128732​

Genitourinary imaging subject​The subject matter pertains to genitourinary imaging.​

matter​

128733​

Neuroimaging subject matter​

The subject matter pertains to neuroimaging .​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 1353​

Code Value​

Code Meaning​

Definition​

Notes​

128734​

Vascular and interventional​

Thesubjectmatterpertainstovascularandinterventional​

imaging subject matter​

imaging.​

128735​

Nuclear medicine imaging​

Thesubjectmatterpertainstonuclearmedicineimaging.​

subject matter​

128736​

Ultrasound imaging subject​

The subject matter pertains to ultrasound imaging.​

matter​

128737​ Pediatricimagingsubjectmatter​The subject matter pertains to pediatric imaging.​

128738​ Breast imaging subject matter​The subject matter pertains to breast imaging.​

128739​

UDI​

The entire Human Readable Form of the Unique Device​See Section 10.29.1 “Unique​

Identifier as defined by the Issuing Agency.​

Device Identifier” in PS3.3.​

128750​

Equipment Landmark​

A well-known landmark of the equipment that is visible​

by the operator.​

128751​

Center of Table Head​

AnequipmentlandmarkontheX-RayTableheadlocated​

on the table top plane, centered in the left-right direction​

of the table.​

128754​ Patient Location Fiducial​

A patient fiducial used to establish the patient location​

relative to equipment.​

128757​ Positioner Isocenter Primary​

Angle in the XY plane of the isocenter reference system​Corresponds to Positioner​

Angle​

between the Y axis and a plane containing the Z axis​ Isocenter Primary Angle​

and the X-Ray center beam (deg).​

(0018,9463).​

Angle​

reference system and the X-Ray center beam, between​Isocenter Secondary Angle​

the XY plane and the X-Ray center beam (deg).​

(0018,9464).​

See “Positioner Coordinate​

System” in PS3.3.​

128759​ Positioner Isocenter Detector​ Rotation of the X-Ray detector plane (deg).​

Corresponds to Positioner​

Rotation Angle​

Isocenter Detector Rotation​

Angle (0018,9465).​

Page 1354​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

128760​

PositionerIsocenterPrimaryEnd​Position of the X-Ray center beam in the isocenter​

See (128757, DCM,​

Angle​

reference system in the X direction (deg) at the end of​"PositionerIsocenterPrimary​

an irradiation event.​

Angle") [1353].​

128761​

Positioner Isocenter Secondary​Position of the X-Ray center beam in the isocenter​

See (128758, DCM,​

End Angle​

reference system in the Z direction (deg) at the end of​"Positioner Isocenter​

an irradiation event.​

Secondary Angle") [1353].​

128762​

Positioner Isocenter Detector​

Rotation of the X-Ray detector plane (deg) at the end of​See (128759, DCM,​

Rotation End Angle​

an irradiation event.​

"PositionerIsocenterDetector​

Rotation Angle") [1353].​

128763​

Table Head Tilt End Angle​

Angle of the head-feet axis of the table (deg) relative to​See (113754, DCM, "Table​

the horizontal plane at the end of an irradiation event.​ Head Tilt Angle") [1257].​

Angle​

end of an irradiation event.​

Horizontal Rotation​

Angle") [1257].​

128765​ Table Cradle Tilt End Angle​

Angle of the left-right axis of the table (deg) relative to​See (113756, DCM, "Table​

the horizontal plane at the end of an irradiation event.​ Cradle Tilt Angle") [1257].​

128766​ Table X Position to Isocenter​

X position of the Table Reference Point with respect to​See “Table Coordinate​

the Isocenter (mm).​

System” in PS3.3.​

128767​ Table Y Position to Isocenter​

Y position of the Table Reference Point with respect to​See “Table Coordinate​

the Isocenter (mm).​

System” in PS3.3.​

128768​ Table Z Position to Isocenter​

Z position of the Table Reference Point with respect to​See “Table Coordinate​

the Isocenter (mm).​

System” in PS3.3.​

128773​ Reference Geometry​

Characterizes the geometry of the reference location​

(e.g., a plane or point).​

128775​ Identifier within Person​

Analphanumericdesignatorofanindividualwithinarole.​

Observer's Role​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 1355​

Code Value​

Code Meaning​

Definition​

Notes​

128779​

Neighbourhood Grey Tone​

A matrix containing the sum of grey level differences of​

Difference Matrix​

pixels/voxels with a discretised grey level and average​

discretisedgreylevelofneighbouringpixels/voxelswithin​

a specified Chebyshev distance. Abbreviated NGTDM.​

See [IBSI Features].​

128780​

Neighbouring Grey Level​

Atabulationofthecountsofdependent(withinaspecified​

Dependence Matrix​

coarseness parameter) neighbouring discretised grey​

levelswithinaspecifiedChebyshevdistance.Abbreviated​

NGLDM.​

See [IBSI Features].​

128781​ Joint Maximum of GLCM​

The probability corresponding to the most common gray​Retired.​

level co-occurrence in the GLCM. Abbreviated MAX.​

Replaced by (GYBY, IBSI,​

See Fcm.joint.max in [IBSI Features].​

"Joint Maximum of GLCM").​

128782​ Joint Average of GLCM​

The gray level weighted sum of joint probabilities of a​ Retired.​

Gray Level Co-occurrence Matrix (GLCM).​

Replaced by (60VM, IBSI,​

See Fcm.joint.avg in [IBSI Features].​

"Joint Average of GLCM").​

128783​ Joint Variance of GLCM​

The sum of squares of the difference from the joint​

Retired.​

average of a Gray Level Co-occurrence Matrix (GLCM).​

Replaced by (UR99, IBSI,​

See Fcm.joint.var in [IBSI Features].​

"Joint Variance of GLCM").​

128784​ Difference Average of GLCM​

TheaverageforthediagonalprobabilitiesofaGrayLevel​Retired.​

Co-occurrence Matrix (GLCM).​

Replaced by (TF7R, IBSI,​

See Fcm.diff.avg in [IBSI Features].​

"Difference Average of​

GLCM").​

128785​

Difference Variance of GLCM​ ThevarianceforthediagonalprobabilitiesofaGrayLevel​Retired.​

Co-occurrence Matrix (GLCM).​

Replaced by (D3YU, IBSI,​

See Fcm.diff.var in [IBSI Features].​

"Difference Variance of​

GLCM").​

128786​ Difference Entropy of GLCM​

TheentropyforthediagonalprobabilitiesofaGrayLevel​Retired.​

Co-occurrence Matrix (GLCM).​

Replaced by (NTRS, IBSI,​

See Fcm.diff.entr in [IBSI Features].​

"Difference Entropy of​

GLCM").​

128787​ Sum Average of GLCM​

Theaverageforthecross-diagonalprobabilitiesofaGray​Retired.​

Level Co-occurrence Matrix (GLCM).​

Replaced by (ZGXS, IBSI,​

See Fcm.sum.avg in [IBSI Features].​

"Sum Average of GLCM").​

128788​ Sum Variance of GLCM​

The variance for the cross-diagonal probabilities of a​

Retired.​

Gray Level Co-occurrence Matrix (GLCM).​

Replaced by (OEEB, IBSI,​

See Fcm.sum.var in [IBSI Features].​

"Sum Variance of GLCM").​

128789​ Sum Entropy of GLCM​

Theentropyforthecross-diagonalprobabilitiesofaGray​Retired.​

Level Co-occurrence Matrix (GLCM).​

Replaced by (P6QZ, IBSI,​

See Fcm.sum.entr in [IBSI Features].​

"Sum Entropy of GLCM").​

128810​ Gray Level Nonuniformity in​

A normalized measure of the similarity of gray level​

The US not UK spelling of​

Runs Normalized​

values throughout the image in a gray level run length​"normalized" is used to be​

matrix.​

consistent with the DICOM​

See Frlm.glnu.norm in [IBSI Features].​

convention, rather than the​

IBSI spelling.​

128812​

Run Length Nonuniformity​

A normalized measure of the the similarity of the length​The US not UK spelling of​

Normalized​

of runs throughout the image in a gray level run length​"normalized" is used to be​

matrix.​

consistent with the DICOM​

See Frlm.rlnu.norm in [IBSI Features].​

convention, rather than the​

IBSI spelling.​

Retired.​

Replaced by (IC23, IBSI,​

"Normalized Run Length​

Nonuniformity").​

128813​

Run Percentage​

A measure of the homogeneity and distribution of runs​Retired.​

of an image in a specific direction in a gray level run​

Replaced by (9ZK5, IBSI,​

length matrix. Abbreviated RPC.​

See Frlm.r.perc in [IBSI Features].​

"Run Percentage").​

Replaced by (8CE5, IBSI,​

See Frlm.gl.var in [IBSI Features].​

"Gray Level Variance in​

Runs").​

128815​

Run Length Variance​

length matrix.​

Replaced by (SXLW, IBSI,​

See Frlm.rl.var in [IBSI Features].​

"Run Length Variance").​

128816​

Run Entropy​

The entropy of runs in a gray level run length matrix.​

Retired.​

See Frlm.rl.entr in [IBSI Features].​

Replaced by (HJ9O, IBSI,​

"Run Entropy").​

128821​

Small Zone Emphasis​

size zone matrix. Abbreviated SZE.​

Replaced by (5QRC, IBSI,​

See Fszm.sze in [IBSI Features].​

"Small Zone Emphasis").​

Page 1360​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

128832​

Zone Size Nonuniformity​

The normalized distribution of zone counts over the​

The US not UK spelling of​

Normalized​

different zone sizes in a gray level size zone matrix.​

"normalized" is used to be​

See Fszm.zsnu.norm in [IBSI Features].​

consistent with the DICOM​

convention, rather than the​

IBSI spelling.​

Retired.​

Replaced by (VB3A, IBSI,​

"Normalized Zone Size​

Nonuniformity").​

128833​

Zone Percentage​

The fraction of the number of realised zones relative to​Retired.​

the maximum number of potential zones in a gray level​

size zone matrix. Abbreviated ZPERC.​

Replaced by (P30P, IBSI,​

"Size Zone Percentage").​

See Fszm.z.perc in [IBSI Features].​

128834​

Gray Level Variance in Zones​ The variance ithe variance in zone counts for the gray​Retired.​

levels in a gray level size zone matrix.​

Replaced by (BYLV, IBSI,​

See Fszm.gl.var in [IBSI Features].​

"Gray Level Variance in Size​

Zones").​

128835​

Zone Size Variance​

The variance in zone counts for the different zone sizes​Retired.​

in a gray level size zone matrix.​

Replaced by (3NSA, IBSI,​

See Fszm.zs.var in [IBSI Features].​

"Zone Size Variance").​

128836​

Zone Size Entropy​

The entropy of zone sizes in a gray level size zone​

Retired.​

matrix.​

Replaced by (GU8N, IBSI,​

See Fszm.zs.entr in [IBSI Features].​

"Zone Size Entropy").​

129001​

Eligibility Reader​

Person who looks at and interprets medical images​

against defined criteria for the purpose of establishing​

eligibility of the subject of said images to be enrolled in​

a research experiment or a clinical trial.​

129002​

Designator​

Person who designates locations on medical images​

(such as the location of lesions) for other persons or​

devices to measure or interpret. E.g., for the purpose of​

consistent target lesion selection for application of​

therapeutic response criteria by multiple independent​

readers.​

129003​

Image Quality Controller​

Person who reviews medical images to evaluate the​

compliance of said images with quality criteria.​

129004​

Results Quality Controller​

Personwhoreviewsresultsderivedfrommedicalimages​

to evaluate the compliance of said results with quality​

criteria.​

129010​

Edited Model​

Areferencetoapredecessormodelthathasbeenedited​

to produce the current model.​
