DICOM PS3.16 2020a - Content Mapping Resource |
Page 1341 |
|
Code Value |
Code Meaning |
Definition |
Notes |
128211 RT Treatment Planning Input |
Instances used to create a radiotherapeutic treatment |
|
|
|
Used |
plan. |
|
128212 RT Plan Summation Input UsedInstances used to combine radiotherapeutic plans or |
|
||
|
|
doses. |
|
128213 |
Physician Review Input Used Instances used for review by a physician. |
|
|
128214 Physicist Review Input Used |
Instances used for review by a physicist. |
|
|
128215 Plan Quality Assurance Input |
Instances used to perform quality assurance of a |
|
|
|
Used |
radiotherapeutic treatment delivery plan. |
|
128216 |
Machine Quality Assurance |
Instances used to perform quality assurance of one of |
|
|
Input Used |
the hardware or software components involved in a |
|
|
|
radiotherapeutic treatment delivery. |
|
128217 Patient Setup Verification InputInstancesusedduringverificationofthepatienttreatment |
|
||
|
Used |
position. |
|
128218 |
Diagnosis Input Used |
Instances used to make a diagnosis. |
|
128219 |
Contouring Input Used |
Instances used for segmentation. |
|
128220 Plan Comparison Input Used |
Instances used for comparing plans. |
|
|
128221 Tumor Board Input Used |
Instances used for review of a tumor board. |
|
|
128222 Tumor Registry Input Used |
Instances submitted to a tumor registry. |
|
|
128223 Clinical Trial Submission InputInstances submitted to a clinical trial study. |
|
||
|
Used |
|
|
128224 |
Source measurement |
Measurement used as the source for derivation. |
|
128225 |
Source report |
Report used as the source for derivation. |
|
128226 |
Source raw data |
Raw Data used as the source for derivation. |
|
128227 Source real world value map |
Real world value map used as the source for derivation. |
|
|
|
|
E.g.,themapappliedtosourceimagesbeforeprocessing |
|
|
|
them, such as for a threshold based segmentation |
|
|
|
operation. |
|
128230 |
Pulse Sequence Name |
NameofanMRpulsesequenceforannotationpurposes. |
|
|
|
Potentially vendor-specific name. |
|
128250 Structural image for image |
A structural image used for image processing. |
|
|
|
processing |
|
|
128251 Flow image for image |
A flow image used for image processing. |
|
|
|
processing |
|
|
128252 OCT-A amplitude decorrelationOCT angiography method that de-correlates the amplitudes between two consecutive B-scans from the narrowed spectral bands was computed, and all the decorrelation values within certain repeated B-scans were averaged to visualize blood vessels. Methods and algorithms for optical coherence tomography-based angiography: a review and comparison. Anqi Zhang ; QinqinZhang;Chieh-LiChen;RuikangK.Wang(2015). See http://biomedicaloptics.spiedigitallibrary.org/ article.aspx?articleid=2464650#QuantitativeComparisons.
- Standard -
Page 1342 |
DICOM PS3.16 2020a - Content Mapping Resource |
|
|
Code Value |
Code Meaning |
Definition |
Notes |
128253 |
OCT-A complex variance |
OCT angiography method based on variations in the |
|
|
|
complex (amplitude and phase) OCT signal from |
|
|
|
repeated B-scans at the same location. There are a |
|
|
|
number of factors that may cause a change in the OCT |
|
|
|
signalfrequencyrelativetothesignalduetostatictissue |
|
|
|
background. These factors include, for example, the |
|
|
|
Doppler effect that induces optical frequency shift and |
|
|
|
thechangeinbackscatteringduetotheparticlesthatare |
|
|
|
moving in and out of the OCT-probe volume during |
|
|
|
imaging. The changes in signal frequency cause the |
|
|
|
changesinboththeamplitudeandthephaseoftheOCT |
|
|
|
signal.Comparisonofthecomplex(amplitudeandphase) |
|
|
|
signal from repeated B-scans at the same location |
|
|
|
provides an image that has higher contrast in areas of |
|
|
|
erythrocyte motion. This method is referred to as |
|
|
|
OCT-based micro-angiography - complex (OMAGC). |
|
128254 |
OCT-A speckle variance |
OCT angiography method that analyzes the temporal or |
|
|
|
spatial statistics of the intensity of speckle from OCT |
|
|
|
images and identifies blood vessels. |
|
128255 |
OCT-A correlation mapping |
OCTangiographymethodthatdifferentiatesflowregions. |
|
|
|
Static regions usually have high correlation values while |
|
|
|
flow regions have lower correlation values. |
|
128256 |
Doppler OCT-A |
OCTangiographymethodthatutilizestheDopplerphase |
|
|
|
resolved information to provide the velocity of flow. |
|
|
|
Sometimes referred to as the phase variance method. |
|
128257 |
Retina depth encoded |
ImageusingpseudocolorstoillustratemultipleOPTENF |
|
|
vasculature flow |
images obtained at various depth levels within the retina |
|
|
|
from the OPT flow volume. |
|
128258 RetinadepthencodedstructuralImageusingpseudocolorstoillustratemultipleOPTENF |
|
||
|
reflectance map |
images obtained at various depth levels within the retina |
|
|
|
from the OPT structural volume. |
|
128259 |
Retina vasculature flow |
Imagethatillustratesthevasculatureflowwithintheentire |
|
|
|
retina. Generated from the OPT flow volume with pixels |
|
|
|
approximately from inner limiting membrane (ILM) to |
|
|
|
photoreceptor inner segment/ellipsoid region (ISe). |
|
128260 |
Retina structural reflectance |
ImagethatillustratestheOCTstructuralreflectancewithin |
|
|
map |
the entire retina. Generated from the OPT structural |
|
|
|
volume with pixels approximately from inner limiting |
|
|
|
membrane(ILM)tophotoreceptorinnersegment/ellipsoid |
|
|
|
region (ISe). |
|
128261 |
Vitreous vasculature flow |
Image that illustrates the vasculature flow within the |
|
|
|
vitreous.GeneratedfromtheOPTflowvolumewithpixels |
|
|
|
approximately from a selected location anterior to ILM, |
|
|
|
to ILM. This space/potential space is referred clinically |
|
|
|
as the Vitreo-retinal Interface (VRI). |
|
128262 Vitreous structural reflectanceImagethatillustratestheOCTstructuralreflectancewithin |
|
||
|
map |
the vitreous. Generated from the OPT structural volume |
|
|
|
with pixels approximately from a selected location that |
|
|
|
is anterior to ILM, to ILM. This space/potential space is |
|
|
|
referred clinically as the Vitreo-retinal Interface (VRI). |
|
128263 Radial peripapillary vasculatureImage that illustrates the OCT vasculature flow within |
|
||
|
flow |
theRNFLaroundtheopticdisk.GeneratedfromtheOPT |
|
|
|
flow volume with pixels approximately from ILM to the |
|
|
|
outer boundary of the RNFL. |
|
- Standard -
|
DICOM PS3.16 2020a - Content Mapping Resource |
Page 1343 |
|
Code Value |
Code Meaning |
Definition |
Notes |
128264 Radial peripapillary structural ImagethatillustratestheOCTstructuralreflectancewithin reflectance map theRNFLaroundtheopticdisk.GeneratedfromtheOPT structural volume with pixels approximately from ILM to
the outer boundary of the RNFL.
128265 |
Superficial retina vasculature |
Image that illustrates the vasculature flow within the |
|
flow |
anterior layers of retina. Generated from the OPT flow |
|
|
volume with pixels approximately from ILM to ganglion |
|
|
cell layer/inner plexiform layer (GCL/IPL). |
128266 |
Superficial retina structural |
ImagethatillustratestheOCTstructuralreflectancewithin |
|
reflectance map |
the anterior layers of retina. Generated from the OPT |
|
|
structural volume with pixels approximately from ILM to |
|
|
ganglion cell layer/inner plexiform layer (GCL/IPL). |
128267 Middle inner retina vasculatureImage that illustrates the vasculature flow in the |
||
|
flow |
capillaries that connect the superficial and deeper |
|
|
capillarybeds.GeneratedfromtheOPTflowvolumewith |
|
|
pixels approximately at the level of the IPL. Sometimes |
|
|
referred to as the intermediate retina flow. |
128268 |
Middle inner structural |
Image that illustrates the OCT structural reflectance in |
|
reflectance map |
the capillaries that connect the superficial and deeper |
|
|
capillarybeds.GeneratedfromtheOPTstructuralvolume |
|
|
with pixels approximately at the level of the IPL. |
|
|
Sometimes referred to as the intermediate retina flow. |
128269 Deep retina vasculature flow |
Image that illustrates the vasculature flow at the level of |
|
|
|
the plexiform layers within the retina. Generated from |
|
|
theOPTflowvolumewithpixelsapproximatelyfrominner |
|
|
plexiform layer (IPL) to outer plexiform layer (OPL). |
128270 |
Deep retina structural |
Image that illustrates the structural reflectance at the |
|
reflectance map |
level of the plexiform layers within the retina. Generated |
|
|
fromtheOPTstructuralvolumewithpixelsapproximately |
|
|
from inner plexiform layer (IPL) to outer plexiform layer |
|
|
(OPL). |
128271 Outer retina vasculature flow |
Image that illustrates the vasculature flow at the level of |
|
|
|
theposteriorlayersoftheretina(outerretina).Generated |
|
|
from the OPT flow volume with pixels approximately in |
|
|
the translucent layers, from OPL to ISe. Sometimes |
|
|
referred to as flow in the deep avascular structure. Note |
|
|
For normal eyes, this image would not show detectable |
|
|
vascular flow. |
128272 |
Outer retina structural |
Image that illustrates the structural reflectance at the |
|
reflectance map |
level of the posterior layers of the retina (outer retina). |
|
|
Generated from the OPT structural volume with pixels |
|
|
approximatelyinthetranslucentlayers,fromOPLtoISe. |
128273 ChoriocapillarisvasculatureflowImage that illustrates the vasculature flow at the level of
|
the chroriocapillaris. Generated from the OPT flow |
|
volume with pixels approximately below the retinal |
|
pigment epithelium (RPE) encompassing the thickness |
|
of choriocapillaris. |
128274 Choriocapillaris structural |
Image that illustrates the structural reflectance at the |
reflectance map |
level of the chroriocapillaris. Generated from the OPT |
|
structural volume with pixels approximately below the |
|
retinal pigment epithelium (RPE) encompassing the |
|
thickness of choriocapillaris. |
- Standard -
Page 1344 |
DICOM PS3.16 2020a - Content Mapping Resource |
|
|
Code Value |
Code Meaning |
Definition |
Notes |
128275 |
Choroid vasculature flow |
Image that illustrates the vasculature flow at the level of |
|
|
|
the choroid. Generated from the OPT flow volume with |
|
|
|
pixels approximately below RPE, encompassing the |
|
|
|
thickness of choroid. |
|
128276 |
Choroid structural reflectance Image that illustrates the structural reflectance at the |
|
|
|
map |
level of the choroid. Generated from the OPT structural |
|
|
|
volume with pixels approximately below RPE, |
|
|
|
encompassing the thickness of choroid. |
|
128277 Whole eye vasculature flow |
Image that illustrates the vasculature flow at the entire |
|
|
|
|
posterior segment, including retina and choroid. |
|
|
|
Generated from the OPT flow volume with pixels |
|
|
|
encompassing the entire OCT scan. |
|
128278 |
WholeeyestructuralreflectanceImage that illustrates the structural reflectance from the |
|
|
|
map |
entire posterior segment, including retina and choroid. |
|
|
|
Generated from the OPT structural volume with pixels |
|
|
|
encompassing the entire OCT scan. |
|
128279 |
Cube B-scan pattern |
Aseriesofdenselyspaced,parallelB-scansofthesame |
|
|
|
length covering an area. |
|
128280 |
Raster B-scan pattern |
Aseriesofsparselyspaced,parallelB-scansofthesame |
|
|
|
length covering an area. |
|
128281 |
Line B-scan pattern |
A single line B-scan. |
|
128282 |
Radial B-scan pattern |
A series of B-scans arranged in a radial pattern of the |
|
|
|
same length covering an area. |
|
128283 |
Cross B-scan pattern |
A pair of horizontal and vertical B-scans in a cross |
|
|
|
pattern. |
|
128284 |
Circle B-scan pattern |
A single circular pattern B-scan. |
|
128285 ConcentriccircleB-scanpatternA series of concentric circular pattern B-scans with |
|
||
|
|
various diameters. |
|
128286 |
Circle-raster B-scan pattern |
A series of concentric circular pattern B-scans with |
|
|
|
various diameters combined with a series of raster |
|
|
|
B-scan patterns. |
|
128287 |
Circle-radial B-scan pattern |
A series of concentric circular pattern B-scans with |
|
|
|
variousdiameterscombinedwithaseriesofradialB-scan |
|
|
|
patterns. |
|
128288 |
Grid B-scan pattern |
A series of vertical and horizontal B-scans. |
|
128289 Outer surface of RNFL |
Retinal surface located approximately at the outer |
|
|
|
|
boundary of the retinal nerve fiber layer (RNFL). |
|
128290 Outer surface of GCL |
Retinal surface approximately at the outer boundary of |
|
|
|
|
the Ganglion Cell Layer (GCL). |
|
128291 Outer surface of IPL |
Retinal surface located approximately at the outer |
|
|
|
|
boundary of the Inner Plexiform Layer (IPL). |
|
128292 Outer surface of INL |
Retinal surface located approximately at the outer |
|
|
|
|
boundary of the Inner Nuclear Layer (INL). |
|
128293 Outer surface of OPL |
Retinal surface located approximately at the outer |
|
|
|
|
boundary of the Outer Plexiform Layer (OPL). |
|
128294 Outer surface of HFL |
Retinal surface located approximately at the outer |
|
|
|
|
boundary of the Henle Fiber Layer (HFL) when present. |
|
128295 Surface between Inner and Outer Segments of the photoreceptors
Retinal surface approximately located at the boundary betweentheInnerSegmentsandOuterSegmentsofthe photoreceptors.
- Standard -
|
DICOM PS3.16 2020a - Content Mapping Resource |
Page 1345 |
|
Code Value |
Code Meaning |
Definition |
Notes |
128296 |
Surface of the interdigitating |
Retinal surface located approximately at the retina-RPE |
|
|
zone between retina and RPEinterdigitating zone when present. |
|
|
128297 |
Anterior surface of the RPE |
Retinal surface located approximately at the anterior |
|
|
|
surface of the Retinal Pigment Epithelium (RPE). |
|
128298 SurfaceofthecenteroftheRPERetinal surface located approximately at the center of the Retinal Pigment Epithelium (RPE).
128299 Posterior surface of the RPE |
Retinal surface located approximately at the posterior |
|
surface of the Retinal Pigment Epithelium (RPE). |
128300 Outer surface of the BM |
Retinal surface located approximately at the outer |
|
boundary of the Bruch’s Membrane (BM). |
128301 Surface of the choroid-sclera |
Retinal surface located approximately at the |
interface |
choroid-sclera interface (SC). |
128302 Outer surface of the CC |
Retinal surface located approximately at the outer |
|
boundary of the choriocapillaris (CC). |
128303 OCT B-scan analysis |
Values are derived from performing analysis on OCT |
|
B-scans |
128304 OCT-A one-sided ratio (lesser)OCT angiography method that utilizes a one-sided ratio on a pixel by pixel basis between various combinations of B-scan repetitions. The ratio is inverted when necessarysuchthatvaluesarelessthanorequaltoone. Individual ratio calculations are averaged or combined across eligible frame combinations for each pixel in the OCT image.
128305 OCT-Aone-sidedratio(greater)OCT angiography method that utilizes a one-sided ratio on a pixel by pixel basis between various combinations of B-scan repetitions. The ratio is inverted when necessary such that values are greater than or equal to one. Individual ratio calculations are averaged or combined across eligible frame combinations for each pixel in the OCT image.
128401 Patient Radiation Dose ReportReport title for the report of estimated absorbed energy
|
|
from ionizing radiation to a patient. |
128402 |
Radiation Dose Estimate |
Estimate of absorbed energy from ionizing radiation. |
128403 Radiation Dose Estimate NameName used to identify a radiation dose estimate. |
||
128404 |
Anthropomorphic Model |
A mathematical description of a patient model for |
|
|
estimating radiation dose that describes or is thought of |
|
|
as having a human form or human attributes. |
128405 |
Breast Thickness |
Thickness of the breast. |
128406 |
BREP Radiation Transport |
Boundary based representation of the model for the |
|
Model |
estimation of radiation transport and absorbed dose in |
|
|
materials. |
128407 |
DgN |
Normalized Mean Glandular Dose (DgN) is the |
|
|
conversion value used to calculate the absorbed dose |
|
|
from radiation to the fibroglandular tissue component of |
|
|
the breast from the exposure in air. |
128408 |
Patient AP Dimension |
The size of a patient in the anterior-posterior dimension. |
128409 |
Patient Lateral Dimension |
The size of a patient in the lateral dimension. |
128410 |
SSDE Conversion Factor |
Conversion factor for Size Specific Dose Estimate |
|
|
(SSDE) calculations from CTDIvol. |
- Standard -
Page 1346 |
DICOM PS3.16 2020a - Content Mapping Resource |
|
|
Code Value |
Code Meaning |
Definition |
Notes |
128411 |
Backscatter |
Scattering of radiation in a direction opposite to that of |
|
|
|
the incident radiation. |
|
128412 |
Radiation Dose Estimate |
The description of the representation of the estimated |
|
|
Representation |
absorbed energy to an organ, a set of organs or the |
|
|
|
whole body, e.g., surface segmentation, mesh, |
|
|
|
parametric map, RT dose , Secondary Capture SOP |
|
|
|
Instances, etc. |
|
128413 |
Distribution Representation |
The form of the representation used to describe the |
|
|
|
distribution of the radiation dose. |
|
128414 Radiation Dose RepresentationThe absorbed energy data estimated by the method. |
|
||
|
Data |
|
|
128415 |
Radiation Dose Estimate |
The methodology and parameters used to estimate the |
|
|
Methodology |
radiationdosetoanorgan,thewholebodyoraphantom. |
|
128416 |
SR Instance Used |
Reference to an SR instance used. |
|
128417 |
Patient Model Type |
Thetypeofmodelusedtodefinetheshape,size,location |
|
|
|
of objects, etc. to represent a patient or phantom for use |
|
|
|
in radiation transport analysis. |
|
128418 |
Simple Object Model |
A simple object (e.g., cylinder) used to model a patient |
|
|
|
or organ. |
|
128420 RadiationTransportModelTypeThetypeofmodelusedtoestimateenergytransportand |
|
||
|
|
absorbed dose in materials. |
|
128421 Geometric Radiation TransportAmodelthatusesgeometricalshapesfortheestimation |
|
||
|
Model |
of radiation transport and absorbed dose in materials. |
|
128422 Voxelized Radiation TransportAmodelthatusesvolumetricelementsfortheestimation |
|
||
|
Model |
of radiation transport and absorbed dose in materials. |
|
128423 |
MeshRadiationTransportModelA model that uses a mesh structure representation for |
|
|
|
|
the estimation of radiation transport and absorbed dose |
|
|
|
in materials. |
|
128424 |
NURBS Radiation Transport |
A model that uses surfaces of a non-uniform rational |
|
|
Model |
B-spline (NURBS) based representation for the |
|
|
|
estimation of radiation transport and absorbed dose in |
|
|
|
materials. |
|
128425 |
Patient Radiation Dose ModelThedatafromthemodelusedtoestimateradiationdose |
|
|
|
Data |
to a patient or organ. |
|
128426 |
Patient Radiation Dose ModelRationale or reference to the methodology for the model |
|
|
|
Reference |
used in the estimation of radiation dose. |
|
128427 |
Patient Model Demographics |
The demographics for which the patient model used by |
|
|
|
the radiation dose estimation method is intended. |
|
128428 |
Model Minimum Age |
The minimum age used in the patient model in the |
|
|
|
radiation dose estimation method. |
|
128429 |
Event UID Used |
Unique Identifier of an event used. |
|
128430 |
Model Maximum Age |
The maximum age used in the patient model in the |
|
|
|
radiation dose estimation method. |
|
128431 |
Beam Block |
A material placed in the radiation beam that is used to |
|
|
|
completelyattenuatethebeaminaspecificregionofthe |
|
|
|
field of view. |
|
128433 |
Tissue Air Ratio |
Ratio of the absorbed dose at a given depth in tissue to |
|
|
|
the absorbed dose at the same point in air. |
|
- Standard -
|
DICOM PS3.16 2020a - Content Mapping Resource |
Page 1347 |
|
Code Value |
Code Meaning |
Definition |
Notes |
128434 |
Radiation Dose Estimate |
The parameters used in the algorithms for determining |
|
|
Parameters |
the radiation dose to a patient, organs, or any material. |
|
128436 |
Radiation Dose Composite |
Reference to the SOP Instance that describes the |
|
|
Parameters |
parameters and values used in the algorithms for |
|
|
|
determining the radiation dose to a patient, organs, or |
|
|
|
any material. |
|
128437 |
Model Patient Sex |
The sex used in the patient model in the radiation dose |
|
|
|
estimation method. |
|
128438 |
Model Minimum Weight |
The minimum weight used in the patient model in the |
|
|
|
radiation dose estimation method. |
|
128439 |
Model Minimum Height |
The minimum height used in the patient model in the |
|
|
|
radiation dose estimation method. |
|
128441 |
Model Maximum Weight |
The maximum weight used in the patient model in the |
|
|
|
radiation dose estimation method. |
|
128442 |
Model Maximum Height |
The maximum height used in the patient model in the |
|
|
|
radiation dose estimation method. |
|
128444 Spatial Registration ReferenceReference to the Spatial Registration instance or |
|
||
|
|
Deformable Spatial Registration instance. |
|
128446 |
Registration Method |
Name of the method used to register the frame of |
|
|
|
reference for two or more sets of data. |
|
128447 |
Spatial Fiducials |
Reference to Spatial Fiducials SOP Instance. |
|
128452 |
Correction Factor |
A factor used to make an adjustment to a calculation to |
|
|
|
account for deviations. |
|
128453 |
Curve Fit Parameter |
Avalueusedinamathematicalfunctiontocreateacurve |
|
|
|
or a function that approximates a set of data. |
|
128455 |
Homogeneity Factor |
A value used to describe the uniformity or composition |
|
|
|
of data or a material that relates to the same degree of |
|
|
|
variability. |
|
128456 |
Patient Model Registration |
The spatial registration used in the patient model in the |
|
|
|
radiation dose estimation method. |
|
128457 |
X-Ray Beam Attenuator |
Attenuator in the radiation beam that may alter the |
|
|
|
estimated radiation dose to the patient, organs, or |
|
|
|
phantoms. |
|
128458 |
Attenuator Category |
The type of object in the radiation beam that may alter |
|
|
|
the estimated radiation dose to the patient, organs, or |
|
|
|
phantoms. |
|
128459 |
Table |
The table a patient is sitting, standing, or lying on and |
|
|
|
that is in the radiation beam such that it may alter the |
|
|
|
estimated radiation dose to the patient, organs, or |
|
|
|
phantoms. |
|
128460 |
Table Core |
The core material of a table a patient is sitting, standing, |
|
|
|
or lying on and that is in the radiation beam such that it |
|
|
|
may alter the estimated radiation dose to the patient, |
|
|
|
organs, or phantoms. |
|
128461 |
Table Outer Liner |
The outer shell of a table a patient is sitting, standing, or |
|
|
|
lyingonandthatisintheradiationbeamsuchthatitmay |
|
|
|
alter the estimated radiation dose to the patient, organs, |
|
|
|
or phantoms. |
|
- Standard -
Page 1348 |
DICOM PS3.16 2020a - Content Mapping Resource |
|
|
Code Value |
Code Meaning |
Definition |
Notes |
128462 |
Table Pad |
The padding on a table a patient is sitting, standing, or |
|
|
|
lyingonandthatisintheradiationbeamsuchthatitmay |
|
|
|
alter the estimated radiation dose to the patient, organs, |
|
|
|
or phantoms. |
|
128464 |
Radiation Dose Estimation |
Parameters used in mathematical, simulation, or |
|
|
Parameter Type |
empirical calculations for radiation dose estimation. |
|
128465 Equivalent Attenuator MaterialThe equivalent material used to estimate the reduction |
|
||
|
|
in radiation intensity. |
|
128468 |
Attenuator Description |
An explanation of the actual attenuator material used in |
|
|
|
the estimation of radiation dose. |
|
128469 EquivalentAttenuatorThicknessThe thickness of a specified material that provides the |
|
|
same attenuation as the actual attenuator. |
128470 X-Ray Attenuator Model Data The stored data from the model used to represent the |
|
|
X-Ray beam attenuator. |
128472 X-Ray Beam Attenuator ModelModeloftheattenuatorusedintheestimationofradiation |
|
|
dose. |
128474 X-Ray Beam Attenuator ModelReference to the methodology or rationale for the model |
|
Reference |
ofthebeamattenuatorusedintheestimationofradiation |
|
dose. |
128475 X-Ray Beam Attenuator ModelSpatial registration of the beam attenuator model. |
|
Registration |
|
128476 RadiationDoseEstimateMethodThe container for the radiation dose estimation methods |
|
|
and parameters. |
128477 RadiationDoseEstimateMethodType of method used to estimate the radiation dose to
|
Type |
a patient, organs or phantoms. |
128479 |
Tabular Data Algorithm |
Algorithms that use a table of values indexed by a key. |
128480 |
Analytical Algorithm |
Algorithms that use mathematical models that have a |
|
|
deterministic result. |
128481 |
Empirical Algorithm |
Algorithms that use mathematical models that use |
|
|
parameters derived from observation. |
128482 RadiationDoseEstimateMethodA reference to the methodology or rationale for the
|
Reference |
estimation methodology used for the estimation of |
|
|
radiation dose. |
128484 |
Isodose |
Representation of radiation dose of equal intensity as a |
|
|
surface, curve, or line. |
128485 |
Skin Dose Map |
Representation of radiation dose intensity at the surface |
|
|
on the skin. |
128487 |
3D Dose Map |
Representationofradiationdoseasa3Dshapeorobject. |
128488 |
Dose Gradient |
Representation of the change in radiation dose with |
|
|
respect to the change in another variable. Often |
|
|
representedasachangewithrespecttotimeordistance. |
128492 |
Physical Support |
Material that is in radiation beam that is used to provide |
|
|
physical support to the patient or other objects. |
128494 |
Patient Segmented Model |
A model for estimating radiation dose defined from the |
|
|
actual patient anatomy or characteristics. |
128496 |
Dose Point Cloud |
Radiation dose represented as a distribution of points. |
128497 |
Measured Radiation Dose |
The measured amount of energy that is deposited in a |
|
|
material by ionizing radiation. |
- Standard -
|
DICOM PS3.16 2020a - Content Mapping Resource |
Page 1349 |
|
Code Value |
Code Meaning |
Definition |
Notes |
128500 |
Patient Radiation Dose ModelAcomputationalrepresentationofahumanbodyorother |
|
|
|
|
object used to simulate the attenuation of radiation in |
|
|
|
human tissue. |
|
128511 |
Reference to Uncertainty |
A reference to the methodology used to determine the |
|
|
Determination Method |
uncertainty in the estimation of radiation dose. |
|
128512 |
Equivalent Dose |
Absorbeddosetoatissueororganmultipliedbyaquality |
|
|
|
factor to normalize the dose to the type of radiation that |
|
|
|
is depositing the dose. |
|
128513 |
Absorbed Dose |
Energy from ionizing radiation absorbed per unit mass. |
|
128522 |
Normalization Factor |
A factor that is used to make an adjustment to a |
|
|
|
calculation to normalize the data. |
|
128523 |
Offset Factor |
A factor that is used to make an adjustment to a |
|
|
|
calculation to translate or move the data in a defined |
|
|
|
manner. |
|
128526 |
Tissue Fraction |
The amount of a specific tissue content, either mass or |
|
|
|
volume, in a material. |
|
128527 |
Distance Correction |
A correction factor for a measurement of distance or |
|
|
|
location. |
|
128528 |
Conversion Factor |
A numerical ratio to express a measurement from one |
|
|
|
unit to another unit. |
|
128531 Maximum Absorbed RadiationThe largest absorbed radiation dose amount estimated. |
|
||
|
Dose |
|
|
128532 Minimum Absorbed Radiation The smallest absorbed radiation dose value estimated. |
|
||
|
Dose |
|
|
128533 |
MeanAbsorbedRadiationDoseThe average value of the absorbed radiation dose |
|
|
|
|
estimated. |
|
128534 ModeAbsorbedRadiationDoseTheabsorbedradiationdosevalueestimatedthatoccurs |
|
||
|
|
most frequently. |
|
128535 Maximum Equivalent RadiationThe largest equivalent radiation dose value estimated. |
|
||
|
Dose |
|
|
128536 Minimum Equivalent RadiationThe smallest equivalent radiation dose value estimated. |
|
||
|
Dose |
|
|
128537 |
MeanEquivalentRadiationDoseThe average value of the equivalent radiation dose |
|
|
|
|
estimated. |
|
128538 ModeEquivalentRadiationDoseTheequivalentradiationdosevalueestimatedthatoccurs |
|
||
|
|
most frequently. |
|
128539 |
Median Absorbed Radiation |
The central value of the absorbed radiation dose |
|
|
Dose |
estimated. |
|
128540 |
Median Equivalent Radiation |
The central value of the equivalent radiation dose |
|
|
Dose |
estimated. |
|
128551 |
Is Repeated Acquisition |
This acquisition of data (e.g., for constructing an image) |
|
|
|
is a repeat of an earlier acquisition that was for some |
|
|
|
reason unsatisfactory. |
|
128552 |
Reason for Repeating |
The reason that data (e.g., for constructing an image) |
|
|
Acquisition |
was acquired again. |
|
128553 |
Patient motion |
The acquired data is unsatisfactory because the patient |
|
|
|
moved. |
|
128554 |
Suboptimal contrast timing |
Theacquireddataisunsatisfactorybecausethecontrast |
|
|
|
timing was not adequate. |
|
- Standard -
Page 1350 |
DICOM PS3.16 2020a - Content Mapping Resource |
|
|
Code Value |
Code Meaning |
Definition |
Notes |
128601 Appropriate for the indicationsThe protocol is appropriate for the indications recordedThe American Academy of in the protocol instance. Orthopaedic Surgeons
(AAOS) defines an appropriateprocedureasone forwhichtheexpectedhealth benefitsexceedtheexpected healthrisksbyawidemargin.
128602 Consistent with labeling of theThe protocol is consistent with the regulatory product device labeling of the device recorded in the protocol instance.
128603 Approved for use at the institution
The protocol is approved for use at the institution recorded in the protocol instance.
128604 Approved for use in the clinicalThe protocol is approved for use in the clinical trial trial recorded in the protocol instance.
128605 Approved for use on pregnantTheprotocolisspecificallyapprovedforuseonpregnant
patients |
patients. |
128606 Appropriate for the device |
The protocol is appropriate for execution on the device |
|
recorded in the protocol instance (which may identify an |
|
individualdevicebyserialnumberormayidentifyafamily |
|
of devices). I.e. the protocol has incorporated |
|
model-specific parameters and optimizations as |
|
necessary. |
128607 Inside operational limits of theThe protocol specifies parameters that are within the device operational limits of the device recorded in the protocol
instance. I.e. execution of the protocol is not expected todamageorexceedtheoperationallimitsofthedevice.
128608 Optimized for the device |
The protocol is optimized for the characteristics of the |
instance |
specific instance of the device recorded in the protocol |
|
instance.I.e.theprotocolhasincorporatedmodel-specific |
|
parameters and optimizations as necessary. |
128609 Disapproved for any use |
The protocol is explicitly disapproved, or approval of the |
|
protocol has been withdrawn. |
128610 Deprecated protocol |
The protocol is no longer to be used. E.g. it has been |
|
replaced by another protocol. |
128611 Approved for experimental useThe protocol is approved for use in experimental |
|
|
procedures. |
128612 Disapproved for experimental The protocol is disapproved for use in experimental
|
use |
procedures. |
128613 |
Eligible for reimbursement |
The protocol is understood to be eligible for |
|
|
reimbursement by a given payer. |
128614 Eligible for reimbursement on The protocol is understood to be eligible for |
||
|
per patient basis |
reimbursement on a per patient basis by a given payer. |
128615 |
Ineligible for reimbursement |
The protocol is understood to be ineligible for |
|
|
reimbursement by a given payer. |
128617 DisapprovedforuseonpregnantTheprotocolisexplicitlydisapprovedforuseonpregnant |
||
|
patients |
patients. |
128618 Inappropriate for the device |
Theprotocolisinappropriateforexecutiononthedevice |
|
|
|
recorded in the protocol instance (which may identify an |
individualdevicebyserialnumberormayidentifyafamily of devices).
- Standard -
