126806​ IEC61217 Table Top Lateral​

Table Top Lateral Position IEC TABLE TOP Coordinate​

Position​

System [IEC 61217].​

126807​

IEC61217 Table Top​

Table Top Longitudinal Position IEC TABLE TOP​

Longitudinal Position​

Coordinate System [IEC 61217].​

126808​ IEC61217 Table Top Vertical​

Table Top Vertical Position in IEC TABLE TOP​

Position​

Coordinate System [IEC 61217].​

126809​ IEC61217 Gantry Continuous​ GantryContinuousRollAngleindegreesoftheradiation​

Roll Angle​

source, i.e., the rotation about the Y-axis of the IEC​

GANTRY coordinate system [IEC 61217].​

126810​ IEC61217 Gantry Continuous​ GantryPitchContinuousAngleindegreesoftheradiation​

Pitch Angle​

source, i.e., the rotation about the X-axis of the IEC​

GANTRY coordinate system [IEC 61217].​

126811​ IEC61217 Gantry Continuous​ GantryYawContinuousAngleindegreesoftheradiation​

Yaw Angle​

source, i.e., about the Z-axis of the IEC GANTRY​

coordinate system [IEC 61217].​

126830​

left first​

The body position of the imaging subject relative to the​

imaging equipment is with the subject's left side​

positioned towards the front of the equipment viewed​

from the front​

126831​

right first​

The body position of the imaging subject relative to the​

imaging equipment is with the subject's right side​

positioned towards the front of the equipment viewed​

from the front​

126832​

posterior first​

The body position of the imaging subject relative to the​

imagingequipmentiswiththesubject'sposterior(dorsal)​

sidepositionedtowardsthefrontoftheequipmentviewed​

from the front​

126833​

anterior first​

The body position of the imaging subject relative to the​

imagingequipmentiswiththesubject'santerior(ventral)​

sidepositionedtowardsthefrontoftheequipmentviewed​

from the front​

126850​

ILCR​

The International Laboratory Code Registry (ILCR) of​

the Institute of Laboratory Animal Research (ILAR). See​

http://dels.nas.edu/global/ilar/lab-codes.​

127001​ PreclinicalSmallAnimalImaging​Adescriptionoftheconditionspresentduringacquisition​

Acquisition Context​

of images of small animals during preclinical research.​

Page 1332​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

127006​

Phase of animal handling​

A specified phase of handling of an animal (e.g.,​

transport, preparation).​

127010​

Biosafety conditions​

Adescriptionofbiosafetyconditions(e.g.,presentduring​

small animal handling for research).​

127011​

Reason for biosafety controls​ The reason that biosafety controls are in place.​

127040​

Heating conditions​

A description of heating conditions (e.g., present during​

small animal handling for research).​

127050​

Circadian effects​

A description of Circadian effects (e.g., present during​

small animal handling for research).​

127060​

Nose cone​

A form of face mask that fits over the nose used for​

delivery of inhalational anesthesia (usually for small​

animals)​

127061​

Nasal cannula​

Cannula inserted in the nose used for delivery of​

inhalational anesthesia or other inhaled gases.​

127070​

Retro-orbital route​

A route of administration of a substance via the​

retro-orbital venous sinus.​

Yardeni T et al. (2011). Retro-orbital injections in mice.​

LabAnimal,40(5),155-160.doi:10.1038/laban0511-155.​

http://www.ncbi.nlm.nih.gov/pmc/articles/PMC3158461/​

127101​

In home cage​

The phase of handling of an animal that provides their​

normal environment between procedures.​

127102​

During transport​

The phase of handling of an animal that is transport​

between environments.​

127103​

Staging prior to imaging​

The phase of handling of an animal that is staging prior​

to an imaging procedure (e.g., after removal from their​

home environment and transport cage, and awaiting​

preparation,inductionorimaging).Duringthisphasethe​

animals are not subject to intervention (e.g., injection,​

catheterization) (cf. 127104, DCM, "Preparation for​

imaging")).​

127104​

Preparation for imaging​

The phase of handling of an animal that is preparation​

priortoanimagingprocedurethatinvolveshandlingand​

intervention (e.g., such as injection, catheterization) (cf.​

127103, DCM, "Staging prior to imaging")).​

127110​

Housing role​

The phase of handling of an animal during which the​

housing conditions are applicable.​

127120​

Animal housing​

The manner in which animals are housed.​

127121​

Animal room type​

The room type in which racks of animal cages are​

housed.​

127122​

Animal room identifier​

The identifier of the room in which racks of animal cages​

are housed.​

127125​

Housing manufacturer​

The manufacturer of the animal housing.​

127126​

Housing rack product name​

The manufacturer's product name of the animal housing​

rack.​

127127​

Housing rack product code​

The manufacturer's product code of the animal housing​

rack.​

127128​

Housing unit product name​

The manufacturer's product name of the animal housing​

unit (or bottom of unit if separate lid).​

Page 1334​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

127190​

Enrichment material​

Material provided to enrich the environment of a small​

animal for the purpose of reducing stress, improving​

health and/or improving reproducibility of results. E.g.,​

nesting material.​

127191​

Enrichment manufacturer​

The manufacturer of the material provided to enrich the​

environment of a small animal.​

127192​

Enrichment material present​

Whether or not material is provided to enrich the​

environmentofasmallanimalforthepurposeofreducing​

stress,improvinghealthand/orimprovingreproducibility​

of results. E.g., nesting material.​

127193​

Exerciser device present​

Whether or not an exerciser device is present.​

127195​

Shelter type​

Thetypeofshelterprovidedforsmallanimalswithintheir​

housing.​

127196​

Shelter manufacturer​

The manufacturer of the small animal shelter.​

127197​

Shelter product name​

The manufacturer's product name of the small animal​

shelter.​

127198​

Shelter product code​

The manufacturer's product code of the small animal​

shelter.​

127200​

Feed manufacturer​

The manufacturer of the feed.​

127201​

Feed product name​

The manufacturer's product name of the feed.​

127202​

Feed product code​

The manufacturer's product code of the feed.​

127205​

Feed source​

The source of animal feed.​

127210​

Feedback temperature​

Temperatureisregulatedbyfeedbackfromatemperature​

regulation​

sensor used to control an active heating or cooling​

device.​

127214​ Totaldurationoflight-darkcycle​The total duration of single light-dark cycle (e.g., usually​

24 hours).​

127215​

Lights on time of day​

The time of day when the lights are turned on.​

127220​

Igloo​

Igloo shaped small animal shelter​

127221​

Red translucent igloo​

Red translucent igloo-shaped small animal shelter​

127230​

Aspen chip bedding​

Animal bedding material made from aspen chips.​

127231​

Aspen shaving bedding​

Animal bedding material made from aspen shavings.​

127232​

Corn cob bedding​

Animal bedding material made from (milled) corn cobs.​

127233​

Paper-based bedding​

Animal bedding material made from paper.​

127234​

Pine chip bedding​

Animal bedding material made from pine chips.​

127235​

Pine shaving bedding​

Animal bedding material made from pine shavings.​

127240​

Carrier temperature sensor​

A device for measuring the temperature of the carrier​

(holder) used for small animal imaging as a means of​

monitoring or regulating the animal's temperature (e.g.,​

a non-magnetic thermocouple embedded in or attached​

to the carrier for MRI).​

127250​

Forced air heater​

A method or device that uses forced hot air to maintain​

the body temperature of a subject.​

127251​

Heated imaging device​

An imaging device that contains an integrated method​

of temperature regulation for maintaining the body​

temperature of the imaging subject.​

Page 1336​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

127313​

Airway Sub-Management​

Subtype of airway management of airway management​

Method​

used during a procedure (from AQI Schema​

AirwayManagementSubMethodCodeType; see http://​

www.aqihq.org/aqischdoc/​

AirwayManagementSubMethodCodeType.html).​

127320​

Medications Set​

Set of medications applied during the anesthesia (from​

AQI Schema MedicationsSetType; see http://​

www.aqihq.org/aqischdoc/MedicationsSetType.html).​

127330​

Carrier gas​

Agasthatdeliversaninhalationalanesthetictoasubject​

(e.g., air, oxygen).​

127370​

Animal housing room​

A room for keeping and raising animals for observation​

or research (vivarium).​

127371​

Preparation room​

Aroomforpreparingasubject(suchasaresearchsmall​

animal) prior to a procedure (such as an imaging​

procedure).​

127372​

Imaging procedure room​

A room in which an imaging procedure is performed.​

127390​ Locally manufactured product​ A product that is locally manufactured (i.e., within the​

facility or institution).​

127391​

Food treat​

A food item that is out of the ordinary and provides​

pleasure.​

127400​

Exogenous substance​

A substance from a source external to a subject.​

E.g., a homograft or xenograft (including tumor cells or​

tissue), fibrils, viruses, cytokines or toxins.​

127401​

Tissue of origin​

The tissue from which a substance originated.​

E.g., the tissue or organ from which a homograft or​

xenograft (including tumor cells or tissue) was obtained.​

127402​ Taxonomic rank of origin​

The taxonomic rank value (e.g., genus, subgenus,​

species or subspecies) from which a substance​

originated.​

E.g., the species of animal from which a homograft or​

xenograft (including tumor cells or tissue) was obtained.​

127411​

Strain​

An identifier of a group of animals that is genetically​

uniform.​

127412​

Strain description​

A description of a group of animals that is genetically​

uniform.​

127413​

Nomenclature​

A system of names or descriptions used in a particular​

field.​

127414​

Genetic modifications​

An identifier of a specific variation of a targeted gene or​

introduced transgene.​

127415​

Genetic modifications​

A description of a specific variation of a targeted gene​

description​

or introduced transgene.​

127450​

Stereotactic coordinates​

Thethreedimensionalcoordinatesthatidentifya(usually​

small) target within the body.​

The Position Reference Indicator may or may not​

coincide with the origin of the fixed frame of reference​

related to the Frame of Reference.​

For a Patient-related Frame of Reference, this is an​

anatomical reference point, often a well-known surface​

anatomical point.​

127460​

Tumor graft​

Tumor cells or tissue or other material obtained from a​

donor intended to be implanted in a research subject.​

127801​

Embryonic Kidney​

The kidney of an embryo. E.g., used as the source of​

human embryonic kidney cell lines, though the concept​

is not specifically human.​

127851​

Human alpha synuclein​

Preformed fibrils of human alpha synuclein.​

preformed fibrils​

127852​

Mouse alpha synuclein​

Preformed fibrils of mouse alpha synuclein.​

preformed fibrils​

127853​ Human Tau preformed fibrils​

Preformed fibrils of human Tau.​

127854​ Mouse Tau preformed fibrils​

Preformed fibrils of mouse Tau.​

127855​

Non-ionic iodinated contrast​

An iodine containing X-Ray contrast agent that does not​Retired.​

agent​

dissociate in water, therefore, is lower in osmolality, and​

has a significantly lower incidence of adverse reactions​Replaced by (RID38696,​

than ionic iodinated contrast agents.​

RADLEX, "Non-ionic​

iodinated contrast agent").​

Replaces (96388005, SCT,​

"Non-ionic iodinated contrast​

agent"), which is retired in​

SNOMED CT (Duplicate).​

127856​

Heart valve flail​

Unrestricted motion of a heart valve. E.g., a prolapsing​

mitral valve leaflet may be classified as non-flail or flail​

(abnormal leaflet coaptation or ruptured chordae).​

127857​

Glucose Measurement Date​

The date that a glucose measurement was performed.​

127858​

Glucose Measurement Time​

The time that a glucose measurement was performed.​

127901​ SPECT of whole body​

A nuclear medicine imaging procedure using a single​

photon emissive radionuclide with tomographic​

reconstruction, over an anatomical extent of the entire​

body.​

127902​ SPECT CT of whole body​

A nuclear medicine imaging procedure using a single​

photon emissive radionuclide with tomographic​

reconstruction combined with transmissive X-Ray​

computed tomography for attenuation compensation,​

over an anatomical extent of the entire body.​

128001​ Add Addendum to Report​

The task is to add an addendum to an existing report.​

128002​

Modality to Read​

The imaging study to be read involves the specified​

modality​

128003​

Reader Specialty​

The specialty of the reader of the imaging study​

128004​

Report Requested​

The type of report that is being requested.​

Page 1338​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

128005​

Final Report​

A final report is a report that is expected to contain all​

information and all the reportable findings.​

128006​

128007​

Cardiac Imaging Specialty​

A medical specialty concerned with cardiac imaging.​

128008​ Head and Neck Imaging​

A medical specialty concerned with head and neck​

Specialty​

imaging.​

128009​

Musculoskeletal Imaging​

A medical specialty concerned with musculoskeletal​

Specialty​

imaging.​

128010​

Neurology Specialty​

A medical specialty concerned with neurology.​

128011​

Neuroradiologic Imaging​

A medical specialty concerned with neuroradiologic​

Specialty​

imaging.​

128012​

OB/Gyn Imaging Specialty​

A medical specialty concerned with obstetric and​

gynecologic imaging.​

128013​

Oncologic Imaging Specialty​

A medical specialty concerned with oncologic imaging.​

128014​

Oncology Specialty​

A medical specialty concerned with oncology.​

128015​

Thoracic Imaging Specialty​

A medical specialty concerned with thoracic imaging.​

128016​

Pediatric Imaging Specialty​

A medical specialty concerned with pediatric imaging.​

128017​

Vascular Imaging Specialty​

A medical specialty concerned with vascular imaging.​

128040​ FWP by GA, Campbell, 1991​

Fetal body weight growth percentile estimated from​

Replaces the use of​

gestational age by method of Campbell 1991.​

LN:33183-5.​

See Campbell WA, Nardi D, Vintzileos AM, Rodis JF,​

Turner GW, Egan JF. Transverse Cerebellar​

Diameter/Abdominal Circumference Ratio Throughout​

Pregnancy: A Gestational Age-Independent Method to​

Assess Fetal Growth. Obstetrics & Gynecology.​

1991;77(6):893-6. Available at: http://journals.lww.com/​

greenjournal/Fulltext/1991/06000/​

Transverse_Cerebellar_Diameter_Abdominal.19.aspx.​

128041​ FWP by GA, Hadlock, 1991​

Fetal body weight growth percentile estimated from​

Replaces the incorrect use of​

gestational age by method of Hadlock 1991.​

LN:33183-5.​

See Hadlock FP, Harrist RB, Martinez-Poyer J. In utero​

analysis of fetal growth: a sonographic weight standard.​

Radiology. 1991 Oct 1;181(1):129-33.​

DOI:10.1148/radiology.181.1.1887021. Available at:​

http://dx.doi.org/10.1148/radiology.181.1.1887021.​

128120​

the head) of the referenced feature​

128121​ Plane through Inferior Extent​

A plane passing through the inferior extent (i.e., towards​

the feet) of the referenced feature​

128122​

the torso) of the referenced feature​

128123​ Plane through Distal Extent​

A plane passing through the distal extent (i.e., towards​

the end of the extremity) of the referenced feature​

128124​ Plane through Medial Extent​

A plane passing through the medial extent (i.e., towards​

the midline of the body) of the referenced feature​

128125​ Plane through Lateral Extent​

A plane passing through the lateral extent (i.e., away​

from the midline of the body) of the referenced feature​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 1339​

Code Value​

Code Meaning​

Definition​

Notes​

referenced feature​

128130​

Plane through Center​

A plane passing approximately through the center of the​

referenced feature​

128137​

Geometric Centerpoint​

The geometric center point of a feature, such as an​

organ, implanted device or morphologic anomaly.​

128138​

Center of Mass​

The center of mass of a feature, such as an organ,​

implanted device or morphologic anomaly​

128144​

Impaired Renal Function​

The procedure is contraindicated for patients with​

impaired renal function.​

128151​

Laser Cross-hairs​

Positioning the patient based on alignment of laser​

cross-hairs.​

128160​

Acquired Volume​

Theanatomicalregionrepresentedintheacquireddata.​

128170​

Abdominal Radiology​

Organizational department or section responsible for​

Abdominal Radiology​

128171​

Biomedical Engineering​

Organizational department or section responsible for​

Biomedical Engineering​

128172​

Cardiovascular Radiology​

Organizational department or section responsible for​

Cardiovascular Radiology​

128173​

Information Technology​

Organizational department or section responsible for​

Information Technology​

128174​

Medical Physics​

Organizational department or section responsible for​

Medical Physics​

128175​

Musculoskeletal Radiology​

Organizational department or section responsible for​

Musculoskeletal Radiology​

128177​

Pediatric Radiology​

Organizational department or section responsible for​

Pediatric Radiology​

128179​

Thoracic Radiology​

Organizational department or section responsible for​

Thoracic Radiology​

128180​

For RT Workflow​

Instancesavailableasinputforageneralradiotherapeutic​

workflow.​

128181​

Diagnostic Source Images​

Instances used to make a diagnosis.​

128182​

Segmentation Result​

Instances created during a segmentation session.​

128183​

Registration Result​

Instances created during a spatial registration.​

128184​

Pre-Planning Result​

Instances created during preparation prior to planning.​

128185​

RT Prescription Result​

Instances created for prescription of a radiotherapeutic​

treatment.​

Page 1340​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

radiotherapeutic treatment delivery session. May also​

include input objects actually used.​

128189​

RT Planning Result​

Instances created during the planning of a​

radiotherapeutictreatment.Mayalsoincludeinputobjects​

actually used.​

128190​

Dosimetric Result​

Instances created during the creation of the dosimetric​

result of a radiotherapeutic treatment plan. May also​

include input objects actually used.​

include input objects actually used.​

128194​ RT Treatment QA Result​

Instances created during evaluation of the treatment​

delivery quality. May also include input objects actually​

used.​

128195​

For Diagnosis​

Instances available to make a diagnosis.​

128196​

For Segmentation​

Instances available for segmentation.​

128197​

For RT Prescription​

Instances available for prescribing a radiotherapeutic​

treatment delivery.​

128198​ For RT Treatment Planning​

Instances available for creating a radiotherapeutic​

treatment plan.​

128199​

For Plan Comparison​

Instances available for comparing plans.​

128200​ For RT Plan Summation​

Instances available to combine radiotherapeutic plans​

or doses.​

128201​

For Physician Review​

Instances available for review by a physician.​

128202​

For Physicist Review​

Instances available for review by a physicist.​

128203​

For Tumor Board​

Instances available for review of a tumor board.​

128204​ For Plan Quality Assurance​

Instances available to perform quality assurance of a​

radiotherapeutic treatment delivery plan.​

of the hardware or software components involved in a​

radiotherapeutic treatment delivery.​

128206​

For Patient Setup Verification​ Instancesavailableforverificationofthepatienttreatment​

position.​

128207​

For Clinical Trial Submission​

Instancesavailableforsubmissionforaclinicaltrialstudy.​

128208​

For Tumor Registry​

Instances available for submission to a tumor registry.​

128209​

RT Workflow Input Used​

Instancesusedasaninputofageneralradiotherapeutic​

workflow.​

128210​

RT Prescription Input Used​

Instances used for prescribing a radiotherapeutic​

treatment delivery.​
