ECHO 2013 / Contrast for Diagnosis and Therapy
.pdfContrast for Diagnosis and Therapy
James D. Thomas, M.D., F.A.C.C.
Cardiovascular Imaging Center
Department of Cardiology
The Cleveland Clinic Foundation
Cleveland, Ohio, USA
Past-President, American Society of Echocardiography
Conflict of Interest: None
Contrast12:1
80 yo Man with Exertional Dyspnea s/p CABG, PCI, now severe DOE
Severe LV dysfunction
Contrast12:2
What’s going on in the apex??
A.Thrombus
B.Reverb/nearfield artifact
C.Can’t tell, let’s try contrast
Contrast12:4
• Severe apical dysfunction but no sign of clot
Contrast12:5
Transpulmonary Ultrasound
Contrast Agents?
Tiny microbubbles (2-5µm) sized to pass through capillaries
Use gas with low diffusivity
Increase echo signal strength
Shell: 15 - 25 nm Albumin
Lipid
Surfactant
Galactose
Polymer
2 - 5
Air
Nitrogen
Gas PFC
SF6
Contrast12:6
Examples of Commercially-Produced
Microbubble Contrast Agents
Name |
Shell |
Optison* |
Albumin |
Definity* |
Lipid/surfactant |
Imagent* |
Lipid surfactant |
Sonovue |
Lipid |
BR38 |
Lipid |
Cardiosphere |
PLGA/albumin |
Acusphere |
PLGA polymer |
Sonozoid |
Lipid |
Gas |
Size ( m) |
Octafluoropropane |
2-4.5 |
Octafluoropropane |
1.1-3.3 |
Perfluorohexane |
6.0 |
Sulfur hexafluoride |
2-3 |
Decafluorobutane |
<4 |
N2/Air |
2-3 |
Perfluorocarbon |
|
Decafluorobutane |
2-3 |
*Approved for use by the US FDA for LV opacification
Contrast12:7
Safety Concerns
The “Black Box” Warning
October 10, 2007
Warning: serous cardiopulmonary reactions and
fatalities within 30 min of contrast administration
Contraindications: any ACS, unstable CHF, ventricular arrhythmias
Administration guidelines: 30 min observation period with vital signs, ECG and O2 monitoring
May 14, 2008
Warning: serous cardiopulmonary reactions and fatalities within 30 min of contrast administration
Administration guidelines: 30 min observation in patients with PH or unstable cardiopulmonary cond.
Contrast12:8
Current Black Box Further Modified
• Anaphylactoid reactions (complement activation) from lipid agents, true allergy to albumen
• ?Pseudocomplication of underlying disease
– 6 deaths reported within an hour of ~3,000,000 doses (1/500,000 hours)
– Average lifespan: 600,000 hours!
• Be prepared: Benedryl and epinephrine
• Be aware of contraindications
– Prior adverse reaction
– Blood product sensivity (Optison)
– Pregnant or lactating female (no data)
– Shunt physiology
– Severe PAH
Contrast12:9
Salvaging nondiagnostic echoes
Contrast12:10
