FIFO Products for the TMS320C6000™ DSP Platform
TI DSP-Sync™ FIFO Products
•Industry’s fastest 3.3-V FIFOs fully optimize DSP performance in high bandwidth telecom and internetworking applications by eliminating data bottlenecks
Applications
•Network security cameras
•Wireless LAN
•Streaming video servers
•Remote Access Servers (RAS)
•Wireless basestations
•Digital Subscriber Lines (xDSL)
•Medical and industrial imaging
•Multi-channel telephony
•Gigabit Ethernet routers
•ATM switches
•SONET/ATM multiplexers
•Broadband video transcoders
Features and Benefits
•
TI DSP-Sync FIFOs for the TMS320C6000 DSP Platform
|
|
|
|
|
Supply |
Max Clock |
Access |
|
Device |
Description |
Package |
Voltage (V) |
Freq (MHz) |
Time (ns) |
$U.S./1KU* |
||
SN74V215 |
512 × 18, Sync FIFO |
64 TQFP |
3.3 |
133 |
5 |
5.67 |
||
|
|
|
|
|
|
|
|
|
SN74V225 |
1K |
× 18, Sync FIFO |
64 TQFP |
3.3 |
133 |
5 |
6.36 |
|
SN74V235 |
2K |
× 18, Sync FIFO |
64 TQFP |
3.3 |
133 |
5 |
7.18 |
|
SN74V245 |
4K |
× 18, Sync FIFO |
64 TQFP |
3.3 |
133 |
5 |
7.87 |
|
SN74V263 |
8K |
× 18/16K × 9, Sync FIFO |
80 TQFP |
3.3 |
166 |
4.5 |
20.26 |
|
|
|
|
|
100 BGA+ |
|
|
|
|
SN74V273 |
16K |
× 18/32K × 9, Sync FIFO |
80 TQFP |
3.3 |
166 |
4.5 |
22.00 |
|
|
|
|
|
100 BGA+ |
|
|
|
|
SN74V283 |
32K |
× 18/64K × 9, Sync FIFO |
80 TQFP |
3.3 |
166 |
4.5 |
23.74 |
|
|
|
|
|
100 BGA+ |
|
|
|
|
SN74V293 |
64K |
× 18/128K × 9, Sync FIFO |
80 TQFP |
3.3 |
166 |
4.5 |
25.48 |
|
|
|
|
|
100 BGA+ |
|
|
|
|
SN74V3640+ |
1K |
× 36, Sync FIFO |
128 TQFP |
3.3 |
166 |
4.5 |
16.79 |
|
SN74V3650+ |
2K |
× 36, Sync FIFO |
128 TQFP |
3.3 |
166 |
4.5 |
18.53 |
|
SN74V3660+ |
4K |
× 36, Sync FIFO |
128 TQFP |
3.3 |
166 |
4.5 |
20.26 |
|
SN74V3670+ |
8K |
× 36, Sync FIFO |
128 TQFP |
3.3 |
166 |
4.5 |
22.00 |
|
SN74V3680+ |
16K |
× 36, Sync FIFO |
128 TQFP |
3.3 |
166 |
4.5 |
23.74 |
|
|
|
|
|
|
|
|
|
|
SN74V3690+ |
32K |
× 36, Sync FIFO |
128 TQFP |
3.3 |
166 |
4.5 |
25.48 |
* Prices are quoted in U.S. dollars and represent year 2002 suggested resale pricing for the fastest available device. + Contact factory for availability.
For a complete list of TI FIFO devices, please see our web site at www.ti.com/sc/fifo
•
•
