NP 286(7) South Central America Caribbean
.pdf
CONTENTS LIST |
|
INDEX |
|
|
|
DOMINICAN REPUBLIC
AES ANDRES LNG TERMINAL
Pilots and Terminal
CONTACT DETAILS:
VHF Frequency: Ch 16
Telephone: +1 809 5235160
Fax: +18095235117
Control Room
VHF Frequency: Ch 19
PROCEDURE:
(1) All notices should be sent to the vessel'sagent bye-:mail, telex or facsimile. The agent will advise the terminal immediately bye-mail or facsimile.
(2) The agent should be advised of the vessel'sdata upon departure from the load port. Masters should also include confirmation of pre-arrival checks and any deficiences that would affect safety or hinder cargo unloading of the vessel. This confirmation may be sent separately but no later that the final ETA notice.
(3) Notice of ETA:
|
(a) |
Vessels should send ETA at noon daily whilst on loaded passage. " the ETA |
|
|
changes by more than 6h, the Master shall promptly advise the corrected |
|
|
ETA. |
|
(b) |
Vessels should provide ETA 24h prior to arrival. "the ETA changes by more |
|
|
than 2h, the Master shall promptly advise the corrected ETA. |
|
(c) |
Vessels should give afinal ETA of 5h (but not more than 1Oh) prior to arrival. |
(4) |
Pilotage is arranged through vessel'sagent. |
|
(5) |
Vessels should contact pilot 1hbefore scheduled ETA on VHF Ch 16. |
|
(6) |
Pilot boards In position 18°21'·50N69°36'·50W. |
|
ARROYO BARRIL (SAMANA or PUERTO
DUARTE)
UNCTAD LOCO DE: DO PUD
Pilots and Port
CONTACT DETAILS:
Pilots
Call: Samana Pilots
VHF Frequency: Ch 16
Telephone: +1 8095382283
Port
VHF Frequency: Ch 16
Telephone: +1 8092482289
Puerto Duarte
Telephone: +1 8095382292
National Port Authority
Website: www.apordom.gov_do
HOURS:HX
PROCEDURE:
(1) Pilotage Is compulsory and is available HJ.
(2) Vessels should send request for pilot and ETA through the agents.
(3) Pilot boards in position 19°10'·20N69°15'·50W.
AZUA (PUERTO VIEJO)
UNCTAD LOCO DE: DO PVA
Pilots
CONTACT DETAILS:
VHF Frequency: Ch 16
RT Frequency (kHz): 2738
Telephone: +1 8095213246
HOURS: H24
PROCEDURE:
(1) Pilotage Is compulsory and is available HJ.
(2) Pilot boards 0·3nmiles S of the inlets.
NOTE:
Pilotage is provided by SANTO DOMINGO.
109
CONTENTS LIST |
|
INDEX |
|
|
|
DOMINICAN REPUBLIC
Port
CONTACT DETAILS:
HrMr
VHF Frequency: Ch 16
RT Frequency (kHz): 2738
Telephone: +1809 2480277
National Port Authority
Website: www.apordom.gov.do
HOURS: H24
BARAHONA |
18°12'N71 °05'W |
UNCTAD LOCODE: DO BAX
Pilots and Port
CONTACT DETAILS:
VHF Frequency: Ch 16
RT Frequency (kHz): 2738
Telephone: +1 809 5242384
National Port Authority
Website: www.apordom.gov.do
HOURS:HX
PROCEDURE:
(1)Pilotage Is compulsory and is available HJ.
(2)Notice of ETA: Vessels should send ETA 24h and 12h in advance.
(3)Pilot boards in position 18·13'·36N71 ·03'·00W(1·5nmiles outside the harbour entrance).
NOTE:
Provides pilotage for CABO ROJO.
BOCA CHICA, Dominican Republic |
18°27'N69°36'W |
UNCTAD LOCODE: DO BCC
Pilots and Port
CONTACT DETAILS:
VHFFrequency: Ch 16
RT Frequency (kHz): 2738
Telephone: +1809 5234669
+1809 5234328
Natlona I Port Authority
Website: www.apordom.gov.do
HOURS:HX
PROCEDURE:
(1)Pilotage Is compulsory and is available HJ.
(2)Pilot boards 1nmile outside the harbour entrance.
CABOROJO |
17°56'N71 °39'W |
UNCTAD LOCODE: DO CBJ
Pilots and Port
NOTE:
Pilotage is provided by BARAHONA.
CONTACT DETAILS:
VHF Frequency: Ch 16
RT Frequency (kHz): 2736
National Port Authority
Website: www.apordom.gov.do
HOURS: HJ
PROCEDURE:
(1)Pilotage Is compulsory and is available HJ.
(2)Notice of ETA: Vessels should advise ETA 24h in advance.
(3)Pilot boards approximately 2 n miles from the port.
110
CONTENTS LIST |
|
INDEX |
|
|
|
|
DOMINICAN REPUBLIC |
CAUCEDO |
18°26'N69°38'W |
UNCTAD LOCODE: DO CAU |
|
Pilots and Port |
|
CONTACT DETAILS: |
|
Pilots |
|
Call: Caucedo Pilot Station |
|
VHF Frequency: Ch 16; 10 13 |
|
Port
Telephone: +1 B09 3737630 (Office hours) +1809 3737676 (AOH)
HOURS: H24
PROCEDURE:
(1) Pilotage is compulsory tor all vessels entering and leaving the port.
(2) Notice of ETA: Vessels should advise ETA 24h prior to arrival, or on departure from last port it less than 24h distant.
(3) Pilot boards in position 18°24'·60N69°36'·30W.
LA ROMANA |
18°25'N68°57'W |
UNCTAD LOCODE: DO LRM |
|
Pilots and Port
CONTACT DETAILS:
VHF Frequency: Ch 16
RT Frequency (kHz): 2738
Telephone: +1 809 5507300
Fax: +1809 5503342
National Port Authortty
Websile: www.apordom.gov.do
HOURS: HJ
PROCEDURE:
(1) Pilotage Is compulsory and is available HJ.
(2) Notice of ETA: Vessels should send request with ETA 72h, 48h and 24h in advance.
(3) Pilot boards in position 18°23'·50N68°57'·00W(within 1·5n miles at the port entrance).
MANZANILLO, Dominican Republic |
19°43'N71 °44'W |
UNCTAD LOCODE: DO MAN
Pilots and Port
NOTE:
Pilotage is provided by PUERTO PLATA.
CONTACT DETAILS:
VHF Frequency: Ch 16
RT Frequency (kHz): 2738
Telephone: +1 809 5799557
Fax: +18095799416
National Port Authortty
Website: www.apordom.gov.do
HOURS: H24
PROCEDURE:
(1) Pilotage Is compulsory and is available H24.
(2) Pilot boards 1n mile off the pier.
PUERTO PLATA |
19°48'N70 0 42'W |
UNCTAD LOCODE: DO POP
Pilots and Port
CONTACT DETAILS:
VHF Frequency: Ch 16
RT Frequency (kHz): 2738
111
CONTENTS LIST |
|
INDEX |
|
|
|
DOMINICAN REPUBLIC
Telephone: +1 |
8095866566 |
(Reception) |
+1 |
8092611279 |
(Port Administration) |
+1 |
809 5869493 (Port Director) |
|
National Port Authority
Website: www.apordom.gov.do
HOURS: H24
PROCEDURE:
(1)Pilotage is compulsory and is available HJ.
(2)Pilot boards in position 19°48'·74N70041'·72W.
NOTE:
Provides pilotage for MANZANILLO.
PUNTA PALENQUE OIL TERMINAL
UNCTAD LOCODE: DO PAL
Pilots and Terminal
CONTACT DETAILS:
Pilots
VHFFrequency: Ch 16; 14
Telephone: +18095621661
E-mail: ops@navierabr.com
Website: www.navierabr.com
Operators
Telephone: +1 8094729817
Fax: +1809 5423566
HOURS: H24
PROCEDURE:
(1)Pilotage Is compulsory.
(2)Notice of ETA: Vessels should advise ETA 72h, 48h, 24h and 12h before arrival.
(3)Pilot boards 1nmile SW of the SBM (IS012'·45N70o W95W).
NOTES:
(1)Terminal is operated by Refineria Dominicana de Petroleo SA (REFIDOM).
(2)Pilotage is provided by Agencias Navieras.
RloHAINA
UNCTAD LOCODE: DO HAI
Pilots and Port
CONTACT DETAILS:
VHF Frequency: Ch 16; 12
RT Frequency (kHz): 2182; 2638 2738
Telephone: +1 8099572696
Fax: +18099570797
National Port Authority
Website: www.apordom.gov.do
HOURS: H24
PROCEDURE:
(1)Pilotage Is compulsory and is available H24.
(2)Pilot boards in position 18°24'·50N70 000'·00W(approximately 0·6n miles Sof the entrance).
SAN PEDRO DE MACORIS |
18°27'N69°19'W |
UNCTAD LOCODE: DO SPM
Pilots and Port
CONTACT DETAILS:
VHF Frequency: Ch 16
AT Frequency (kHz): 2738
Telephone: +1 809 5292093
Fax: +1 809 5292069
112
CONTENTS LIST |
|
INDEX |
|
|
|
DOMINICAN REPUBLIC
National Port Authority
Websije: www.apordom.gov.do
HOURS: H24
PROCEDURE:
(1) Pilotage Is compulsory and is available HJ.
(2) Notice 01 ETA: Vessels should send ETA 24h in advance.
(3) Pilot boards in position 18°25'·00N69°18'·00W(0·5nmiles seaward of the outermost Lt buoy).
SANTO DOMINGO |
18°28'N69°53'W |
UNCTAD LOCODE: DO SDa |
|
Pilots and Port |
|
CONTACT DETAILS: |
|
Pilots |
|
Call: Agua Marina Primera |
|
VHF Frequency: Ch 16; 12 |
|
RT Frequency (kHz): 2182; 2638 2738 |
|
Port |
|
VHF Frequency: Ch 16; 12 |
|
RT Frequency (kHz): 2182; 2638 2738 |
|
Telephone: +1 809 6874n2 |
|
Fax: +1 8096872661 |
|
National Port AuthOrity |
|
Websoo: www.apordom.gov.do |
|
HOURS: H24 |
|
PROCEDURE:
(1) Pilotage is compulsory and is arranged by the agent.
(2) Notice 01 ETA: Vessels should send ETA 72h and 24h in advance.
(3) Pilot boards in position 18°26'·81N69°53'·35W.
ECUADOR
GENERAL NOTES
ISPS DESIGNATED AUTHORITY:
Direccion General de la Marina Mercante y del Lijoral, Secretaria de Proteccion
Mamima.
Telephone: +593(O}4 2324827
Fax: +593(O}4 2324827
Mobile: +593(O}9 4029527
Telex: +30843325
E-mail: nvillaciS@digmer.org
Websije: www.digmer.org
NOTICE OF ETA:
(1) All vessels bound for Ecuadorian ports should advise the Port Authority of their destination 72h before their ETA at the pilot station. The message, which should be in Spanish, should be addressed to the following:
(a) Port Captain
(b) Heanh Officer
(c) Customs Administration (name of port)
(d) Immigration Office
(2) The message should include the following information:
(a) Vessel'sname
(b) Nationality
(c) Last port of call
(d) Destination
(e) Any sick crew on board? (~ Any explosives on board?
(g) Number of passengers for port
(h) Number of passengers in transn
(i) Weight of cargo to be unloaded (in tonnes) m Weight of cargo in transij (in tonnes)
(k) Any mail to discharge?
(I) ETA at outer buoy (sea buoy or pilot station)
(m) Agent'sname
(n) Master'sname
113
