Хід роботи
Увімкнути блок живлення газорозрядної трубки (при цьому газорозрядна трубка починає світитись).
Обертаючи барабан монохроматора і спостерігаючи в окуляр спектр, відмітити по барабану положення найбільш яскравих ліній спектра атомарного водню Н, Н, Ні Нсерії Бальмера, коли вони послідовно збігаються з візиром окуляра.
Результати вимірювань занести до таблиці.
-
№
Колір лінії
1
2
3
4
По градуювальному графіку визначити довжину хвилі ліній.
По формулі (8.2) для чотирьох ліній серії Бальмера розрахувати чотири значення сталої Рідберга і знайти її середнє значення. Порівняти отриманий результат з табличним значенням сталої Ридберга - .
Контрольні запитання
Які спектри випромінюють вільні атоми?
Які серії існують у спектрі атома водню?
Який фізичний зміст спектральних термів?
Сформулювати постулати Бора?
Модель атома. Досліди Резерфорда по розсіюванню -частинок.
Записати умову квантування стаціонарних орбіт.
Теорія атома водню по Бору. Вивести формулу енергії стаціонарного положення.
Література
Савельєв І.В. “Курс загальної фізики”, т.2.М.,1980.
Методичні вказівки до лабораторного практикуму з загальної фізики. Розділ “Оптика”. Запоріжжя, 1984.
Методичні вказівки розробив доц. Лущін С.П.
Рецензент доц. Правда М. І.
Laboratory work № 61 studying the phenomenon of interference
THE AIM: to define the length of a laser light wave.
INSTRUMENTATION AND APPLIANCES: a laser, a plate with two parallel slits, a screen, a ruler.
The short theory
Phenomenon of interference is the imposing coherent waves and distribution the light stream in the space with a weak and amplified intensity of light. Amplitude of result oscillation is
,
where A1, A2 - amplitudes; ,- elementary phases of imposed oscillations. The intensity of light is proportional to squared of amplitude ,
then ,
if > 0 , I > I1 + I2: max,
< 0 , I < I1 + I2: min.
Coherent waves are waves with the same frequency and with the constant phase difference in the time.
Experimental part
1. Switch on a LASER and receive the interference pattern.
2. Draw this picture in your own notebook and measure the distance between max in different places. For example:
y = S / ( N – 1 ).
3. Fill the table
№ |
, | |||||
1 |
|
|
|
|
0,22 |
|
2 |
|
| ||||
3 |
|
|
4. Measure the distance L between the plate with slits and screen.
5. Calculate the length of a laser light wave by this formula:
,
where d - is the distance between two parallel slits, d = 0.22 mm.
6. Calculate the errors for these measurements.
Control questions
1. What is the phenomenon of interference?
2. What are the coherent waves?
3. Why are there max and min on the screen?
4. What are conditions of max and min of interference?
5. What are the factors that influence the distance between interference bands?
