- •Contents
- •Introduction
- •1.1 Scope
- •Figure 1-1: Main system blocks
- •1.2 Summary
- •See Chapter 2, Memory Map.
- •Level sensitive interrupts.
- •Programmed interrupt source available
- •See Chapter 3, Interrupt Controller.
- •Free-running or periodic timer modes.
- •See Chapter 4, Timer.
- •See Chapter 5, Communications Channel.
- •"Wait for Interrupt" Pause mode.
- •See Chapter 6, Remap and Pause.
- •Memory Map
- •2.1 Introduction
- •2.2 Memory Map Base Addresses
- •Interrupt Controller
- •3.1 Introduction
- •Figure 3-1: FIQ and IRQ interrupts
- •3.2 Interrupt Control
- •Figure 3-2: Interrupt Controller Bit Slice
- •3.3 Interrupt Controller Register Descriptions
- •3.5 Interrupt Controller Memory Map
- •Timer
- •4.1 Introduction
- •4.2 Timer Operation
- •Figure 4-1: Timer Block Diagram
- •Figure 4-2: Timer Pre-scale Unit
- •4.3 Timer Register Descriptions
- •4.3.1 Load Register
- •4.3.2 Value
- •4.3.3 Clear
- •4.3.4 Control Register
- •Figure 4-3: Timer Register Bit Positions
- •1—Timer Enabled
- •1—Periodic Timer Model
- •Clock
- •Divided by
- •Stages of
- •Pre-scale
- •Undefined
- •Table 4-1: Bits 3 – 2: Prescale bits
- •4.4 Timer Memory Map
- •Address
- •Read Location
- •Write Location
- •TimerBase
- •Timer1Load
- •Timer1Load
- •TimerBase + 0x04
- •Timer1Value
- •Reserved
- •TimerBase + 0x08
- •Timer1Control
- •Timer1Control
- •TimerBase + 0x0C
- •Reserved
- •Timer1Clear
- •TimerBase + 0x10
- •Reserved
- •Reserved
- •TimerBase + 0x20
- •Timer2Load
- •Timer2Load
- •TimerBase + 0x24
- •Timer2Value
- •Reserved
- •TimerBase + 0x28
- •Timer2Control
- •Timer2Control
- •TimerBase + 0x2C
- •Reserved
- •Timer2Clear
- •TimerBase + 0x30
- •Reserved
- •Reserved
- •Table 4-2: Timer Address Map
- •Communications Channel
- •5.1 Introduction
- •Remap and Pause
- •6.1 Introduction
- •6.2 Pause
- •6.4 Reset Status
- •6.5 Clear Reset Memory Map
- •6.6 Remap and Pause Memory Map
- •Address
- •Read Location
- •Write Location
- •RemapBase
- •Reserved
- •Pause
- •RemapBase + 0x10
- •Identification
- •Reserved
- •RemapBase + 0x20
- •Reserved
- •ClearResetMap
- •RemapBase + 0x30
- •ResetStatus
- •ResetStatusSet
- •RemapBase + 0x34
- •Reserved
- •ResetStatusClear
- •Table 6-1: Remap and Pause Memory Map

Remap and Pause
6.5Clear Reset Memory Map
The Reset Memory Map location provides a method of overlaying the system base memory at reset.
The Clear Reset Map location is write only. Writing to the Clear Reset Memory Map location causes the system memory map to change from that required after reset, to that required during normal operation.
Once the reset memory map has been cleared and the normal memory map is in use there shall be no method of resuming the reset memory map, other than undergoing a reset condition.
A typical system implementation would be to map the system ROM to location 0 at reset, but to change the memory map after reset, such that RAM were located at location 0 for normal operation. In a system where such remapping does not occur writing to this register shall have no effect.
6-6 |
Reference Peripherals Specification |
|
|
|
ARM DDI 0062D |
|
|
|
|
|
|
