Апсе ENVIRONMENTAL PROTECTION 2014

Evidently, the numerical evaluations obtained for the hightechnology implosive HNED are quite correct for the lowand mediumtechnology HNED with relatively thicker layers of aluminum and chemical HE. The weaker capabilities of heat removal from these HNED allowed us to conclude that the lower contents of 238Pu (in comparison with the high-technology HNED) could be sufficient to provoke the HNED failure.

a)

Fig. 6.17. Radial temperature profiles in the HNED, when all the measures on prolongation of the HNED lifetime were undertaken

a) Plutonium melting leads to the HNED failure

211

b)

Fig. 6.17. Radial temperature profiles in the HNED, when all the measures on prolongation of the HNED lifetime were undertaken

b) Plutonium melting does not lead to the HNED failure

According to the IAEA documents, plutonium containing above 80% 238Pu.is regarded as a proliferation-protected material. Discrepancy be-

tween the IAEA-declared value (80% 238Pu) and the results of previous numerical evaluations (18-42% 238Pu) can be explained by the following

considerations:

1. The adopted criterion for thermal stability of chemical HE, i.e. dissociation of 2% HE molecules.

212

2. The adopted criterion for the HNED failure, i.e. the HNED lifetime

must be no longer than five hours. By the way, if plutonium contains 80% 238Pu, then the HNED fails in two hours.

3.The chosen geometrical model of the implosive HNED.

4.The chosen chemical HE with the highest heat conductivity and maximal acceptable temperature.

6.4.5. Higher fuel burn-up in denatured (Np-U-Pu) NFC

Good neutron-multiplying properties of 238Pu and its neutron predecessor 237Np make it possible to extend substantially time period for continuous reactor operation without refuelings. As a consequence, unauthorized extraction of plutonium from SNF becomes practically unfeasible. Indeed, neutron irradiation of (Np-U-Pu) fuel initiates the following “non-traditional” transition chain:

237Np(n,γ)238Pu(n,γ)239Pu(n,γ)...

A successive transition of these nuclides leads to enhancement of neutron-multiplying properties.

Actually, as it can be seen in Fig. 6.18, excess neutron generation per one absorption (νeff-1) in 237Np is negative for neutrons of all energy range (excepting fast neutrons), positive for neutrons with En > 1 keV for 238Pu and, as is known, essential positive one for 239Pu. So, for (Np-

U-Pu)-fuel the nuclides we are dealing with can be characterized as follows: 237Np plays a role of “burnable poison", 238Pu is a moderately fissile nuclide by fast neutrons (En > 1 keV), and 239Pu is a well-known fissile nuclide with excellent neutron-multiplying properties.

At the same time, during irradiation in the reactor core, FP accumulation results in growth of neutron absorption. So, these tendencies can be counterbalanced, and such fuel will be characterized by stabilized neutron-multiplying properties over long fuel lifetime and, as a consequence, high fuel burn-up.

213

0.1 1 eV 10 100 1 keV 10 100 1 MeV 10.5

Neutronenergyenergy

Neutron energy, eV

Fig. 6.18. Dependencies of excessive neutron number per one absorption (νeff-1) on neutron energy for nuclides of (Np-U-Pu) fuel.

Burn-up calculations for mono-nitride (Np-U-Pu) fuel in elementary cell of PWR-type reactor with heavy water as a coolant were performed by using code GETERA. The cell parameters are presented in Table 6.7 (they were similar to those of VVER-1000 cell).

214

1.40

K∞

1.30

LWR-UOX

1.20

72%Np+5.6% Pu+22.4% Pu

1.10

239

76%Np+24% Pu

1.00

Fig. 6.19. Dependencies of K∞ on fuel burn-up (% HM) for various fuel compositions

It’s a factor for internationalization of Nuclear Energy System fuel cycle. Since fuel cycles under consideration here are “rich” with respect to excess neutron generation in CFR, there is no necessity to perform fine purification of spent fuel by the SNF reprocessing technologies. It’s a factor of enhancement of NFC proliferation protection.

Application of NPP with ultra long-life core concepts is expected to be profitable for electricity generation in the developing countries which have not improved nuclear infrastructure.

216

Control questions to Chapter 6

1. What methods can be used to prevent diversion of fissile NM from

peaceful to military purposes?

2. What properties of 231Pa and 232U make it possible to use these isotopes for uranium proliferation protection?

3.What properties of 237Np and 238Pu make it possible to use these isotopes for plutonium proliferation protection?

4.What advantages can be offered by power reactors with ultra-high fuel burn-up for nuclear non-proliferation regime?

217
