2.3 Coding gain
Coding gain (CG) shows how many decibels lower required SNR at the input of the demodulator in a transmission system with a error-control code, rather than in a transmission system without error-control code for a given value рd.
Let
SNR (dB) at the input of the demodulator in a transmission system
without error-control code
,
and in a transmission system with error-control code
with the same symbol error probability. Then, if the signal to noise
ratio expressed in decibels,
CG = – . (1)
We remind that a ratio is determined as
=
=
, (2)
where Ps/N0 is ratio of average power of signal to noise power density at the demodulator input; Tb is duration of information binary symbol (bit) at the transmission system input.
CG can be calculated in theory or measured experimentally. For example (figure 2), in a transmission system is required to ensure the symbol error probability p = 10–5. In a transmission system without error-control code SNR = 9,6 dB is required, and in a transmission system with error-control code SNR = 6,3 dB is required, then CG = 9,6 – 6,3 = 3,3 dB.
If CG > 0 dB (on figure 2 at рd < 10–2), such error-control code allows to decrease the signal/noise ratio at the demodulator input, if CG 0 dB, such error-control code does not allow to decrease the signal/noise ratio at the demodulator input, its application is worsened by quality of reception.
Dependencies р = f ( ) and рd = f ( ) can be obtained experimentally by the method described in the laboratory work 3.3. In this laboratory we study noise immunity of transmission system with error-control code using a model of digital communication channel with errors (figure 3).
The order of experimental determination of the CG when using the model of digital communication channel with errors.
1. A series of values of error probability at the channel output р in a certain range of values, such as, р = 10–1–10–3 is setting (model of the digital communication channel with errors should allow such settings). For each value of p the error probability at the output of the decoder is determined рd.
2. Must be specified modulation type which is used in digital communication channel. For transmission system without error-control code and with this type of modulation р = f ( ) is plotted. Figure 2 this dependence is built for BPSK and QPSK signals.
3. Graphing рd = f ( ) is produced in the following order. For one of the values of p on plot р = f ( ) determine the value, which for the transmission system with a error-control code will be equal to the ratio signal/noise
=
=
, (3)
where
Ts is duration of the binary symbols at the
modulator input in a transmission system with error-control codes
(the output of the error-control code encoder). As
,
so in a transmission system with an error-control code
.
In the presentation in decibels
.
This conversion takes into account the fact that at the error-control
code encoding in nonredundant code word n – k
checking symbols are introduced which lead to a decrease in a
duration of all symbols in the code word and a corresponding decrease
in signal energy.
In the resulting value and the corresponding value рd point depending is set рd = f ( ). The same procedure is repeated for all other values of p. Points are connected by a smooth curve and get dependence рd = f ( ).
4. At a given level of error probability determine the values and . CG is calculated by the formula (1).
Example calculation of points on the graph рd = f ( ). (31, 26) code is used; BPSK modulation; error probability р = 510–3 and рd = 10–5. On the value of p and the graph in figure 2 h2 = 5,5 dB is defined. Calculate
= 5,5 + 10lg(31/26) = 6,3 dB.
Lay off the point schedule рd = f ( ), whose coordinates is (6,3; 10–5).
