Chapter 4
Programmer’s Model for Test
This chapter describes the registers of the ARM PrimeCell Static Memory Controller (PL092) and provides details required when programming the microcontroller. It contains the following:
•Scan testing on page 4-2.
ARM DDI 0203B |
Copyright © ARM Limited 2001. All rights reserved. |
4-1 |

Programmer’s Model for Test
4.1Scan testing
The PrimeCell SMC has been designed to simplify:
•the insertion of scan test cells
•the use of Automatic Test Pattern Generation (ATPG).
This is the recommended method of manufacturing test.
4-2 |
Copyright © ARM Limited 2001. All rights reserved. |
ARM DDI 0203B |

Appendix A
ARM PrimeCell Static Memory Controller
(PL092) Signal Descriptions
This chapter describes the AMBA AHB and module-specific non-AMBA AHB signals used with the ARM PrimeCell SMC. It contains the following sections:
•AMBA AHB interface signals on page A-2
•AMBA AHB slave interface signals on page A-3
•AMBA AHB master interface signals on page A-5
•Internal signals on page A-7
•Input/output pad signals on page A-9.
ARM DDI 0203B |
Copyright © ARM Limited 2001. All rights reserved. |
A-1 |

ARM PrimeCell Static Memory Controller (PL092) Signal Descriptions
A.1 AMBA AHB interface signals
Table A-1 describes the common AMBA AHB signals.
|
|
Table A-1 Common AMBA AHB signals |
||
|
|
|
|
|
Signal name |
Type |
Source/ |
Description |
|
destination |
||||
|
|
|
||
|
|
|
|
|
nHCLK |
Input |
Clock control |
Inverted bus clock input. It is used |
|
|
|
|
only for the generation of the write |
|
|
|
|
enable output. |
|
|
|
|
|
|
HCLK |
Input |
Clock control |
Bus clock input, that times all bus |
|
|
|
|
transfers. All signal timings are |
|
|
|
|
related to the rising edge. |
|
|
|
|
|
|
HRESETn |
Input |
Reset controller |
Bus reset input, active LOW, used to |
|
|
|
|
reset the system and the bus when |
|
|
|
|
asserted LOW. |
|
|
|
|
|
|
HREADYIN |
Input |
Other AHB slaves |
Transfer completed input. When |
|
|
|
|
HIGH the HREADYIN signal |
|
|
|
|
indicates that a transfer has finished |
on the bus. This signal can be driven LOW to extend a transfer.
A-2 |
Copyright © ARM Limited 2001. All rights reserved. |
ARM DDI 0203B |
