8

Programming in C and C++

This chapter gives background material for Chapter 9, which shows how C or C++ statements are encoded in assembly language. Together, they illustrate what a programmer is doing when he or she writes high-level language programs. However, if you have already covered this material, it can be skipped.

The first section provides terminology and understanding of where to use high-level language compilers and interpreters. We then begin with a description of C, illustrating first operators and statements and then conditional and loop expressions. We give an example of a program that uses many of the features we need in the next chapter, and then discuss C++ and object-oriented programming.

8.1 Compilers and Interpreters

We first discuss the difference between an assembler and a compiler. A compiler is a program that converts a sequence of (ASCII) characters that are written in a high-level language into machine code or into assembly language that can be converted into machine code. A high-level language is different from an assembly language in two ways. First, a line of a high-level language statement will often generate five to a few tens of machine instructions, whereas an assembly-language statement will usually generate (at most) one machine instruction. Second, a high-level language is designed to be oriented to the specification of the problem that is to be solved by the program and to the human thought process, while a program in an assembly language is oriented to the computer instruction set and to the hardware used to execute the program. Consider the dot product subroutine used in the previous chapter, written in C below. Each line of the program generates many machine instructions or lines of assembly-language code. Each high-level language statement is designed to express an idea used in the statement of the problem and is oriented to the user rather than the machine. The compiler could generate the assembly-language program or the machine code produced by this program.

}

221

A class's function members are written rather like C procedures with the return type and class name in front of two colons and the function member name.

void Cstack::push{int i){if(Ptr==Top){Error=l; return?} *(++Ptr)=i; }

int Cstack::pull{){if(Ptr==Bottom){ Error=l; return 0;} return *(Ptr—);}

char Cstack::error{){ char i; i = Error; Error = 0; return i; }

Any data member, such as Top, may be accessed inside any function member of class Cstack, such as push() . Inside a function member, when a name appears in an expression, the variable's name is first searched against local variables and function formal parameters. If the name matches, the variable is local or an argument. Then the variable is matched against the object data members and finally against the global variables. In a sense, object data members are global among the function members, because each of them can get to these same variables. However, it is possible that a data member and a local variable or argument have the same name such as Error. The data member can be identified as this->Error, using key word this to point to the object that called the function member, while the local variable or argument is just Error.

C++ uses constructors, allocators, destructors, and deallocators. An allocator allocates data member storage. A constructor initializes these variables; it has the same function name as the class name. Declaring or blessing an object automatically calls the allocator and constructor, as we will see shortly. A destructor terminates the use of an object. A destructor has the same function name as the class name but has a tilde (~) in front of the function member name. A deallocator recovers storage for data members for later allocation. We do not use a deallocator in our experiments; it is easier to reset the 6812 to deallocate storage. Here's Cstack's constructor:

Cstack::Cstack(int i){Top=(Ptr=Bottom=(char*)allocate(i))+i;Qlen= Error=0;}

Throughout this section, a conventional C procedure allocate provides buffer storage for an object's data members and for an object's additional storage such as its stacks. The contents of global variable free are initialized to the address just above the last global; storage between free and the stack pointer is subdivided into buffers for each object by the allocate routine. The stack used for return addresses and local variables builds from one end and the allocator builds from the other end of a common RAM buffer area, allocate's return type void * means a pointer toanything.

char *free=0xb80;

void *allocate(int i) { void *p=free; free += i; return p; }

A global object of a class is declared and then used as shown below:

Cstack S(10);

void main() { int i;

S.push(l); i = S.pull();

}
