b. Using EMULS

Figure 73.8-Bit Signed Multiply Subroutine

Another approach to multiplication of signed 8-bit numbers is to use signed 16-bit multiplication available in the EMULS instruction. See Figure 7.3b. This method is far better on the 6812, because the EMULS instruction is available, but the former method is useful on other machines and shows how signed multiplication is derived from unsigned multiplication having the same precision. A modification of it is used to multiply 32-bit signed numbers, using a procedure to multiply 32-bit unsigned numbers.

7.2 Integer Conversion

A microcomputer frequently communicates with the outside world through ASCII characters. For example, subroutines INCH and DUTCH allow the MPU to communicate with a terminal, and this communication is done with ASCII characters. When numbers are being transferred between the MPU and a terminal, they are almost always decimal numbers. For example, one may input the number 3275 from the terminal keyboard, using the subroutine INCH, and store these four ASCII decimal digits in a buffer. After the digits are input, the contents of the buffer would be

While each decimal digit can be converted to binary by subtracting $30 from its ASCII representation, the number 3275 still has to be converted to binary (e.g., $OCCB) or some other representation if any numerical computation is to be done with it. One also has to convert a binary number into an equivalent ASCII decimal sequence if this number is to be displayed on the terminal screen. For example, suppose that the result of some arithmetic computation is placed in accumulator D, say, $OCCB. The equivalent decimal number, in this case 3275, must be found and each digit converted to ASCII before the result can be displayed on the terminal screen. We focus on the ways of doing these conversions in this section.

One possibility is to do all of the arithmetic computations with binary-coded decimal (BCD) numbers, where two decimal digits are stored per byte. For example, the BCD representation of 3275 in memory would be

Going between the ASCII decimal representation of a number to or from equivalent BCD representation is quite simple, involving only shifts and the AND operation. With the 6812, it is a simple matter to add BCD numbers; use ADDA or ADCA with the DAA instruction. Subtraction of BCD numbers on the 6812 must be handled differently from the decimal adjust approach because the subtract instructions do not correctly set the halfcarry bit H in the CC register. (See the problems at the end of the chapter.) For some applications, addition and subtraction may be all that is needed, so that one may prefer to use just BCD addition and subtraction. There are many other situations, however, that require more complex calculations, particularly applications involving control or scientific algorithms. For these, the ASCII decimal numbers are converted to binary because binary multiplication and division are much more efficient than multiplication and division with BCD numbers. Thus we convert the input ASCII decimal numbers to binary when we are preparing to multiply and divide efficiently. However, depending on the MPU and the application, BCD arithmetic may be adequate so that the conversion routines below are not needed.

We consider unsigned integer conversion first, discussing the general idea and then giving conversion examples between decimal and binary representations. A brief discussion of conversion of signed integers concludes this section. The conversion of numbers with a fractional part is taken up in a later section.

An unsigned integer N less than bm has a uniquerepresentation

*CVBTD converts the unsigned contents of D into an equivalent 5-digit ASCII decimal

*number ending at the location passed in X. Register Y is unchanged.

*

a.Using a Loop

*SUBROUTINE CVBTD converts unsigned binary number in D into five

*ASCII decimal digits ending at the location passed in X, using recursion.

*

b. UsingRecursion

Figure 7.8 Conversion from Binary to Decimal by Division by 10

Looking at the expansion (3) we see that N4 is the quotient of the division of (D) by (K):(K + 1). If we divide the remainder by (K + 2):(K+ 3), we get N3 for the quotient, and so forth. These quotients are all in binary, so that a conversion to ASCII is also necessary. The subroutine CVBTD of Figure 7.6 essentially uses this technique, except that the division is carried out by subtracting the largest possible multiple of each power of ten which does not result in a carry.

Figure 7.13. Algorithm to Write a Sequence of Subroutine Calls for (8)

The reader is invited to find these parsing trees for the formulas given in the problems at the end of the chapter. Note that a parsing tree is really a good way to write a formula because you can see "what plugs into what" better than if you write the formula in the normal way. In fact, some people use these trees as a way to write all of their formulas,even if they are not writing programs as you are, because it is easier to spot mistakes and to understand the expression. Once the parsing tree is found, we can write the sequence of subroutine calls in the following way. Draw a string around the tree, as shown in Figure 7.13. As we follow the string around the tree, a subroutine call or PUSH is made each time we pass a node for the last time or, equivalently, pass the node on the right. When a node with an operand is passed, we execute the macro PUSH for that operand. When a node for an operation is passed, we execute a subroutine call for that operation. Compilers use parsing trees to generate the subroutine calls to evaluate expressions in high-level languages. The problems at the end of the chapter give you an opportunity to learn how you can store parsing trees the way that a compiler might do it, using techniques from the end of Chapter 6, and how you can use such a tree to write the sequence of subroutinecalls the way a compiler might.

As a second example, we consider a program evaluatingthe consecutive expressions

delta = delta + c

s = s + (delta *delta) These can be described by the trees

This program segment's first two instructions alone will duplicate the top stack element,

Similarly, to maintain the stack mechanism, a long word can be pulled from the stack to fill L. The following program segment pulls a long word into location ALPHA.

If you use a macro assembler, these operations are easily made into macros. Otherwise, you can "hand-expand" these "macros" whenever you need these operations.

A 32-bit negate subroutine is shown in Figure 7.14. The algorithm is implemented by subtracting register L from 0, putting the result in L. This is a monadic operation, an operation on one operand. You are invited to write subroutines for other simple monadic operations. Increment and decrement are somewhat similar, and shift left and right are much simpler than this subroutine. (See the problems at the end of the chapter.)

A multiple-precision comparison is tricky in almost all microcomputers if you want to correctly set all of the condition code bits so that, in particular, all of the conditional branch instructions will work after the comparison. The subroutine of Figure 7.15 shows

Figure 7.14.32-Bit Negation Subroutine

*SUBROUTINE MULT multiplies the unsigned next word on the stack with

*L, and pulls the next word

sK

Figure 7.18. 32-Bit by 32-Bit Unsigned Divide Subroutine

24 * 1.00 . . . 0

+22 * 1.00 . . . 0

we first unnormalize the number with the smaller exponent and then add as shown,

24 * 1.000 .. . 0

+24 * 0.010 . . . 0

24 * 1.010 .. . 0

(For this example and all those that follow, we give the value of the exponent in decimal and the 24-bit magnitude of the significand in binary.) Sometimes, as in adding,

the sum will have to be renormalized before it is used elsewhere. In this example

25 * 1.00 . . . 0

is the renormalization step. Notice that the unnormalization process consists of repeatedly shifting the magnitude of the significand right one bit and incrementing the exponent until the two exponents are equal. The renormalization process after addition or subtraction may also require several steps of shifting the magnitude of the significand left and decrementing the exponent. For example,

24 * 1.0010 .. . 0

-24 * 1.0000 . . .0

24 * 0.0010 .. . 0

requires three left shifts of the significand magnitude and three decrements of the exponent to get the normalized result:

21 * 1.00 . . . 0

With multiplication, the exponents are added and the significands are multiplied to get the product. For normalized numbers, the product of the significands is always less than 4, so that one renormalization step may be required. The step in this case consists of shifting the magnitude of the significand right one bit and incrementing the exponent. With division, the significands are divided and the exponents are subtracted. With normalized numbers, the quotient may require one renormalization step of shifting the magnitude of the significand left one bit and decrementing the exponent. This step is required only when the magnitude of the divisor significand is larger than the magnitude of the dividend significand. With multiplication or division it must be remembered also that the exponents are biased by 127 so that the sum or difference of the exponents must be rebiased to get the proper biased representation of the resulting exponent.

In all of the preceding examples, the calculations were exact in the sense that the operation between two normalized floating-point numbers yielded a normalized floatingpoint number. This will not always be the case, as we can get overflow, underflow, or a result that requires some type of rounding to get a normalized approximation to the result. For example, multiplying

256 * i.oo . . . 0

*210Q * 1.00 . . . 0

2*56 * 1.00 . . . 0

yields a number that is too large to be represented in the 32-bit floating-point format. This is an example of overflow, a condition analogous to that encountered with integer arithmetic. Unlike integer arithmetic, however, underflow can occur, that is, we can get a result that is too small to be represented as a normalized floating-point number. For example,

2-126 * 1.0010 . . . 0

-2-l26 * 1.0000 . . . 0 2-126 * 0.0010 . . . 0

yields a result that is too small to be represented as a normalized floating-point number with the 32-bit format.

The third situation is encountered when we obtain a result that is within the normalized floating-point range but is not exactly equal to one of the numbers (14). Before this result can be used further, it will have to be approximated by a normalized floating-point number. Consider the addition of the following two numbers.

(in parenthesis: least significant bits of the significand)

The exact result is expressed with 25 bits in the fractional part of the significand so that we have to decide which of the possible normalized floating-point numbers will be chosen to approximate the result. Rounding toward plus infinity always takes the approximate result to be the next larger normalized number to the exact result, while rounding toward minus infinity always takes the next smaller normalized number to approximate the exact result. Truncation just throws away all the bits in the exact result beyond those used in the normalized significand. Truncation rounds toward plus infinity for negative results and rounds toward minus infinity for positive results. For this reason, truncation is also called rounding toward zero. For most applications, however, picking the closest normalized floating-point number to the actual result is preferred. This is called rounding to nearest. In the case of a tie, the normalized floating-point number with the least significant bit of 0 is taken to be the approximate result. Rounding to nearest is the default type of rounding for the IEEE floating-point standard. With rounding to nearest, the magnitude of the error in the approximate result is less than or equal to the magnitude of the exact result times 2~24.

One could also handle underflows in the same way that one handles rounding.For example, the result of the subtraction

2-126 * i . oilO . . . 0

-2-126 * i.oooo . . . Q 2-126 * 0.0110 . . . 0

could be put equal to 0, and the result of the subtraction

could be put equal to 2~126 * 1.0000. More frequently,all underflow results are put equal to 0 regardless of the rounding method used for the other numbers. This is termed flushing to zero. The use of denormalized floating-point numbers appears natural here, as it allows for a gradual underflow as opposed to, say, flushing to zero. To see the advantage of using denormalized floating-point numbers, consider the computation of the expression (Y — X) + X. I f Y - X underflows, X will always be the computed result if flushing to zero is used. On the other hand, the computed result will always be Y if denormalized floating-point numbers are used. The references mentioned at the end of the chapter contain further discussions on the merits of using denormalized floating point numbers. Implementing all of the arithmetic functions with normalized and denormalized floating-point numbers requires additional care, particularly with multiplication and division, to ensure that the computed result is the closest represented number, normalized or denormalized, to the exact result. It should be mentioned that the IEEE standard requires that a warning be given to the user when a denormalized result occurs. The

normalized floating-point number. Flushing to zero would, of course, always produce zero for this expression when (Y — X) underflows.

The process of rounding to nearest, hereafter just called rounding, is straightforward after multiplication. However, it is not so apparent what to do after addition, subtraction, or division. We consider addition/subtraction. Suppose, then, that we add the two numbers

20 * 1.0000 . . . 0

+2-23 * 1.1110 . . . 0

After unnormalizing the second number,we have

20 * 1.0000 .. . 00

+2° * 0.0000 . . . Qlflll) 20 * 1.0000 . . . 01(111)
