Make conclusions reached on the following network configurations
Router(config)#hostname R1
R1(config)#interface fastEthernet 0/0
R1(config-if)#ip address 200.0.0.2 255.255.255.252
R1(config-if)#no shutdown
R1(config)#interface fastEthernet 0/1
R1(config-if)#ip address 10.0.255.254 255.255.0.0
R1(config-if)#no shutdown
R1(config)#router rip
R1(config-router)#network 10.0.0.0
R1(config-router)#network 200.0.0.0
Make conclusions reached on the following network configurations
R4(config)#interface fastEthernet 0/0
R4(config-if)#ip address 100.0.0.2 255.255.255.252
R4(config-if)#no shutdown
R4(config)#interface fastEthernet 0/1
R4(config-if)#ip address 172.16.0.62 255.255.255.192
R4(config-if)#no shutdown
R4(config)#router rip
R4(config-router)#network 10.0.0.0
R4(config-router)#network 200.0.0.0
Make conclusions reached on the following network configurations
Router(config)#hostname Center
Center(config)#interface fastEthernet 0/0
Center(config-if)#ip address 200.0.0.1 255.255.255.252
Center(config-if)#no shutdown
Center(config)#interface fastEthernet 1/0
Center(config-if)#ip address 155.0.0.1 255.255.255.252
Center(config)#interface fastEthernet 8/0
Center(config-if)#ip address 100.0.0.1 255.255.255.252
Center(config-if)#no shutdown
Center(config)#interface fastEthernet 9/0
Center(config-if)#ip address 50.0.0.1 255.255.255.252
Center(config-if)#no shutdown
Center(config)#router rip
Center(config-router)#network 50.0.0.0
Center(config-router)#network 100.0.0.0
Center(config-router)#network 155.0.0.0
Center(config-router)#network 200.0.0.0
Make conclusions reached on the following network configurations!
interface FastEthernet0/0
ip address 192.168.0.174 255.255.255.240
duplex auto
speed auto!
interface Serial0/0/0
ip address 20.0.0.9 255.255.255.252!
interface Serial0/0/1
ip address 20.0.0.6 255.255.255.252!
router eigrp 1
network 192.168.0.0
network 20.0.0.0
no auto-summary
Make conclusions reached on the following network configurations!
!
interface FastEthernet0/0
ip address 192.168.0.254 255.255.255.192
duplex auto
speed auto!
interface FastEthernet0/1
ip address 192.168.0.190 255.255.255.240
duplex auto
speed auto!
interface Serial0/0/0
ip address 20.0.0.10 255.255.255.252
clock rate 64000!
interface Serial0/0/1
ip address 20.0.0.13 255.255.255.252
clock rate 64000!
router eigrp 1
network 192.168.0.0
network 20.0.0.0
no auto-summary!
Make conclusions reached on the following network configurations(to je chto I 4 zada4a)
7, 11.Make conclusions reached on the following network configurations
Gateway of last resort is not set
20.0.0.0/8 Is variably subnetted, 5 subnets, 2 masks
D 20.0.0.0/8 is a summary, 00:00:01, Null0
C 20.0.0.0/30 is directly connected, Serial0/0/0
D 20.0.0.4/30 [90/2681856] via 20.0.0.2, 00:00:02, Serial0/0/0
D 20.0.0.8/30 [90/2681856] via 20.0.0.13, 00:00:04, Serial0/0/1
C 20.0.0.12/30 is directly connected, Serial0/0/1
