Index
Page 1 (1)
Engine Frame and Base Frame |
511S |
|
|
L23/30H
Description
Engine Frame and Base Frame ............................................................................. |
511.01(01H) |
Working Card
Functional Test of Crankcase Safety Relief Valves .......................................... |
511-01.00 (01H) |
Plates
Frame with Main Bearings ........................................................................................ |
51101-01H |
Frame with Main Bearings ........................................................................................ |
51101-02H |
Front Cover of Lubricating Oil pump ........................................................................ |
51102-01H |
Mounting of Pumps .................................................................................................. |
51102-02H |
Covers on Frame ...................................................................................................... |
51106-01H |
Covers on Frame ...................................................................................................... |
51106-02H |
Covers on Frame ...................................................................................................... |
51106-03H |
Covers on Frame ...................................................................................................... |
51106-03S |
Crankcase Safety Relief Valves ............................................................................... |
51107-03S |
08028-0D/H5250/94.08.12
98.35-ES0U
Description |
Engine Frame and Base Frame |
511.01 |
Page 1 (1) |
Edition 01H |
|
|
|
|
|
|
|
|
|
L23/30H |
Frame
The engine frame is made of cast iron, and is attached to the top of the base frame by means of bolts. The cross girders of the frame are provided with bores for themainbearingsinwhichthecrankshaftisunderslung, i.e. it is carried by the main bearing caps.
The main bearing caps are attached by means of studs and nuts, which are loosened and tightened with the aid of hydraulic tools. After mounting, the main bearing caps are further secured by means of bracing screws, which are screwed horizontally into the sides of the caps and tightened against the sides of the engine frame. The main bearings are equipped with replaceable shells which are fitted without scraping.
The crankshaft guide bearing is located at the flywheel end of the engine.
On the sides of the frame there are covers for acces to the camshaft, the charge air receiver and crankcase. Some of the covers are fitted with relief valves which will act, should oil vapours in the crankcase be ignited, for instance in the event of a hot bearing.
The charge air cooler housing is a integrated part of the frame.
Base Frame
Engine and alternator (gear, pump) are mounted on a common base frame which is in welded design.
The base frame is used as lubricating oil reservoir "wet sump".
94.26 - ES0U
Working Card |
Functional Test of Crankcase Safety Relief Valves |
511-01.00 |
Page 1 (2) |
Edition 01H |
|
|
|
|
|
|
|
|
|
L23/30H |
08028-0D/H5250/94.08.12
Safety precautions:
Stopped engine
Shut-off starting air
Shut-off cooling water
Shut-off fuel oil
Shut-off cooling oil
Stopped lub. oil circul.
Description:
Functional test of crankcase safety relief valves.
Starting position:
Related procedure:
Manpower: |
|
|
|
Working time |
: |
1/4 |
hour |
Capacity |
: |
1 |
man |
Data: |
|
|
|
Data for pressure and tolerance |
(Page 500.35) |
Data for torque moment |
(Page 500.40) |
Declaration of weight |
(Page 500.45) |
Special tools:
Plate no |
Item no |
Note. |
Hand tools:
Allen key, 12 mm.
Ring and open end spanner, 17 mm. Loctite 243
Replacement and wearing parts:
Plate no |
Item no |
Qty/ |
51106 |
034 |
1/cyl. |
51106 |
058 |
1/cyl. |
51106 |
071 |
1/cyl. |
97.06 - ES0S-G
511-01.00 |
Functional Test of Crankcase Safety Relief Valves |
Working Card |
||
Edition 01H |
Page 2 (2) |
|||
|
|
|
|
|
|
|
|
|
|
L23/30H |
|
|
|
|
Functional testing of the crankcase safety relief |
|
|
|
|
|
|
|
||
valves cannot be effected during operation of the |
|
|
|
|
engine, but it must be checked during overhauls that |
|
|
|
|
the valve flap is movable. |
|
|
|
|
Take care when painting the engine, not to block up |
|
|
|
|
the safety relief valves with paint. |
|
|
|
|
The safety relief valves have been set to open at an |
|
|
|
|
excess pressure in the crankcase of, see page |
|
|
|
|
500.35. |
|
|
|
|
If the safety relief valves are actuated, the engine |
|
|
|
|
must be stopped immediately, and it must not be |
|
|
|
|
restarted until the cause has been found and the fault |
|
|
|
|
has been rectified, see also description 503.04, |
|
|
|
|
ignition in crankcase. |
Fig 1. |
|
|
|
|
|
|
|
|
08028-0D/H5250/94.08.12
97.06 - ES0S-G
