Description
Page 1 (1)
Data for Pressure and Tolerance |
500.35 |
|
Edition 01H |
|
|
L23/30H
08028-0D/H5250/94.08.12
Section |
Description |
mm. / bar |
505 |
Maximum inner diameter, valve guide |
14.25 mm. |
|
Fer grinding of valve spindle and valve seat ring |
|
|
(see also working card 505-01.10) |
|
|
Minimum height of valve head, inlet vale and exhaust valve, "H" 1 |
5.0 mm. |
|
Maximum height of spindle above cylinder head, "H" 2 |
83.3 mm |
506 |
Piston and piston ring grooves (see working card 500-01.10) |
|
|
Clearance in big-end bearing |
0.15-0.20 mm |
|
Clearance between conneeing rod bush and piston pin |
0.15-0.20mm. |
|
Maximum ovalness in big-end bore (without bearing) |
0.08 mm. |
|
New cylinder liner, inside diameter |
225,000-5,046mm. |
|
Maximum inside diameter cylinder liner, max. ovalness 0.1 mm |
225.50 mm |
507 |
Clearance between teeth on intermediate wheel |
0.2-0.3 mm. |
508 |
Valve olearance, Inlet valve (cold engine 15-55°C) |
0.50 mm. |
|
Valve clearance, Exhaust vale (cold engine 15-55°C) |
0.90 mm. |
|
Maximum clearance between rocker arm bush and rocker arm shaft |
0.30 mm. |
509 |
Clearance between pick-up and impulse wheel |
|
|
|
1 ±0.3mm |
510Deflection of crankchaft (autolog) (see working card 510-01.00) Clearance between crankshaft and sealing ring, (upper and lower part)
|
Clearance in main bearing |
0.30 – 0.40 mm. |
|
|
0,2-0,3 mm |
514 |
Maximum combustion pressure at full load |
|
|
Maximum difference between oylinders before overhaul |
130 bar |
|
A change of the height of the thrust piece spacer ring of 0.10 mm. |
6 bar |
|
will change the maximum pressure by |
|
|
1° turning of camshaft gear wheel changes max. pressure by approx |
1 bar |
|
Opening pressure of fuel valve |
3 bar |
|
|
320 bar |
96.19-ES0U

Description |
Data for Pressure and Tolerance |
500.35 |
|
Page 1 (1) |
Edition 11H |
||
|
|||
|
|
||
|
|
L23/30H |
08028-0D/H5250/94.08.12
|
Section |
Description |
mm. / bar |
|
|
|
|
|
|
|
505 |
Maximum inner diameter, valve guide |
14.25 mm. |
|
|
|
For grinding of valve spindle and valve seat ring |
|
|
|
|
(see also working card 505-01.10) |
|
|
|
|
Minimum height of valve head, inlet valve and exhaust valve, "H" 1 |
5.0 mm. |
|
|
|
Maximum height of spindle above cylinder head, "H" 2 |
83.3 mm |
|
|
506 |
Piston and piston ring grooves (see working card 506-01.10) |
|
|
|
|
Clearance in big-end bearing |
0.15-0.20 mm |
|
|
|
Clearance between connecting rod bush and piston pin |
0.15-0.20 mm. |
|
|
|
Maximum ovalness in big-end bore (without bearing) |
0.08 mm. |
|
|
|
New cylinder liner, inside diameter |
225,000-225,046 mm. |
|
|
|
Maximum inside diameter cylinder liner, max. ovalness 0.1 mm |
225.50 mm |
|
|
507 |
Clearance between camshaft and camshaft bearing |
0.11-0.20 mm |
|
|
|
Maximum clearance between camshaft and camshaft bearing |
0.35 mm |
|
|
|
Clearance between teeth on intermediate wheel |
0.2-0.3 mm. |
|
|
508 |
Valve clearance, Inlet valve (cold engine 15 - 55°C) |
0.50 mm. |
|
|
|
Valve clearance, Exhaust valve (cold engine 15 - 55°C) |
0.90 mm. |
|
|
|
Maximum clearance between rocker arm bush and rocker arm shaft |
0.30 mm. |
|
|
509 |
Clearance between pick-up and impulse wheel |
1 ±0.3 mm |
|
|
510 |
Deflection of crankchaft (autolog) (see working card 510-01.00) |
|
|
|
|
Clearance between crankshaft and sealing ring, (upper and lower part) |
0.30 - 0.40 mm. |
|
|
|
Clearance in main bearing |
0,2-0,3 mm |
|
|
|
Clearance in guide bearing (axial) |
0.15 - 0.44 mm |
|
|
|
Maximum clearance in guide bearing (axial) |
0.8 mm |
|
|
514 |
Maximum combustion pressure at full load |
130 ± 3 bar |
|
|
|
Individual cylinders; admissible deviation from average |
± 3 bar |
|
|
|
For L23/30H 900 rpm version a pressure of 135 bar measured at the |
|
|
|
|
indicator cock correspond to 130 bar in the combustion chamber |
|
|
|
|
Opening pressure of fuel valve |
320 bar |
|
|
|
|
|
|
|
|
|
|
|
01.51 - ES0

08028-0D/H5250/94.08.12
Description |
|
Data for Torque Moment |
|
|
|
500.40 |
||||
Page 1 (1) |
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
Edition 01S |
|
|
|
|
|
|
|
|
|
|
L23/30H |
|
|
|
|
|
|
|
|
|
|
720/750 rpm |
|
|
|
|
|
|
|
|
|
|
|
|
|
Section |
Description |
|
Thread |
Tightening |
Lubricant |
|
|||
|
|
Torque |
Pressure |
|
||||||
|
|
|
|
|
|
Nm |
bar |
|
|
|
|
505 |
Cylinder cover stud(in frame) |
Stud |
M 48 |
200 |
|
|
Copaslip |
|
|
|
|
Nur for cylinder cover stud |
Nut |
M 45 |
|
750 |
|
Copaslip |
|
|
|
|
Cooling jacket cylinder cover |
Screw |
|
22 |
|
|
Copaslip |
|
|
|
506 |
Connecting rod(see section 506) |
|
|
|
|
|
|
|
|
|
507 |
Camshaft assembly |
Nut |
M12 |
50 |
|
|
Copaslip |
|
|
|
|
Intermediate wheel shaft |
Nut |
M 20 x 1.5 |
250 |
|
|
Copaslip |
|
|
|
|
Intermediate wheel gear |
Nut |
M12 |
40 |
|
|
Copaslip |
|
|
|
|
Gear wheel on camshaft |
Screw |
M12 |
50 |
|
|
Unimoly |
|
|
|
508 |
Housing for valve gear |
Screw |
M 12 |
60 |
|
|
Copaslip |
|
|
|
|
Valve gear bracket rocker arm |
Nut |
M 16 |
150 |
|
|
Copaslip |
|
|
|
510 |
Main bearing stud (in frame) |
Stud |
M 48 |
200 |
|
|
Copaslip |
|
|
|
|
Nut for main bearing stud |
Nut |
M 45x3 |
|
750 |
|
Copaslip |
|
|
|
|
Main bearing side screw |
Screw |
M 24 |
300 |
|
|
Copaslip |
|
|
|
|
Counteweight on crankshaft |
Screw |
M 30X2 |
200 |
|
|
Copaslip |
|
|
|
|
|
|
|
|
+ 60° turn |
|
|
|
|
|
|
Vibrationdamper on crankshaft |
Nut |
M 27 |
400 |
|
|
Copaslip |
|
|
|
|
Frame / baseframe |
Nut |
M 24 |
500 |
|
|
Copaslip |
|
|
|
|
Flywheel mounting (fitted bolt) |
Nut |
M 20 x 1.5 |
200 |
|
|
Copaslip |
|
|
|
|
Gear rim on flywheel |
Screw |
|
34 |
|
|
Copaslip |
|
|
|
|
Gear wheel on crankshaft |
Nut |
M 10 |
40 |
|
|
Copaslip |
|
|
|
514 |
Fuel pump distribution piece |
Screw |
M 8 |
25 - 30 |
|
|
Copaslip |
|
|
|
|
Fuel pump top flange (barrel) |
Screw |
M 10 |
55 - 65 |
|
|
Copaslip |
|
|
|
|
Fuel pump caviation plugs |
Plug |
M 20 x 1.5 |
100 - 120 |
|
|
Copaslip |
|
|
|
|
Fuel primp mounting |
|
|
|
|
|
|
|
|
|
|
(bottom flange) |
Screw |
M 16 |
150 |
|
|
Copaslip |
|
|
|
|
Fuel valve (nozzle nut) |
Nut |
M 26 x 1.5 |
100 - 120 |
|
|
Copaslip |
|
|
|
|
ruel valve mounting |
Nut |
M 16 |
40 |
|
|
Copaslip |
|
|
|
|
Fuel vale (cap nut) |
Nut |
|
70 |
|
|
Copaslip |
|
|
|
|
Fuel vale adjusting (lock nut) |
Nut |
|
100 |
|
|
Copaslip |
|
|
|
|
High pressure pipe |
Nut |
M 18 X 1.5 |
40 |
|
|
Copaslip |
|
|
|
515 |
Gear wheel on lub. oil pump |
Nut |
|
300 |
|
|
Copaslip |
|
|
|
519 |
Conical elements mounting |
Screw |
M 20 |
150 |
|
|
Copaslip |
|
|
|
|
Upper mouthing |
Nut |
M 20 |
320 |
|
|
Copaslip |
|
|
|
|
Lower mounting |
|
|
|
|
|
|
|
|
|
|
Conical elements mounting |
|
|
|
|
|
|
|
|
|
|
Upper mouthing |
Nut |
M 27 |
300 |
|
|
Copaslip |
|
|
|
|
Lower mounting |
Screw |
M 16 |
205 |
|
|
Copaslip |
|
|
|
|
|
|
|
|
|
|
|
|
|
96.37-ES0U

Description |
Declaration of Weight |
500.45 |
Page 1 (1) |
Edition 01H |
|
|
|
|
|
|
|
|
|
L23/30H |
08028-0D/H5250/94.08.12
Section |
Component |
Plate No. |
Item No. |
Weight in Kg. |
|
|
|
|
|
505 |
Cylinder Head, complete |
50501-50502 |
|
250 |
|
|
50508-50510 |
|
|
506 |
Piston, complete |
50601 |
081 |
45 |
|
Piston Pin |
50601 |
019 |
19 |
|
Connecting Rod, complete without bearing |
50601 |
068 |
95 |
|
Cylinder Liner, complete |
50610 |
018 |
100 |
|
Cooling Water Jacket |
50610 |
055 |
33 |
507 |
Camshaft, section |
50705 |
014,026,038 |
29 |
508 |
Housing for Roller Guide |
50801 |
016 |
17 |
509 |
Governor, complete |
50901 |
021,104,116 |
28 |
511 |
Main Bearing Cap |
51101 |
108 |
75 |
|
Guide Bearing Cap |
51101 |
300 |
85 |
|
Front cover |
51102 |
019 |
164 |
|
End cover, complete |
51106 |
237 |
179 |
512 |
Turbocharger, complete |
|
|
See special |
|
|
|
|
instruction |
|
Intermediate piece |
51202 |
181 |
9 |
|
Air Cooler |
51203 |
054 |
450 |
|
Inlet Bend |
51203 |
138 |
93 |
513 |
Air Starter |
51309 |
756 |
40 |
514 |
Fuel Injection Pump |
51401 |
381 |
15 |
|
Fuel Injection Valve |
51402 |
177 |
5 |
|
Fuel Oil Feed Pump |
51410 |
290 |
22 |
515 |
Lubricating Oil Pump |
51501 |
330 |
45 |
|
Thermostatic Valve |
51503 |
115 |
29 |
|
Prelubricating Oil Pump, incl. el-motor |
51504 |
242 |
20 |
|
Centrifugal Filter |
51515 |
337 |
24 |
516 |
Thermostatic Valve |
51604 |
114 |
29 |
|
Cooling Water Pump |
51610 |
201 |
30 |
|
|
|
|
|
97.06 - ES0U
