50501-01H |
|
|
Cylinder Head |
|
Plate |
|||||||||
|
|
|
Page 2 (2) |
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
||
L23/30H |
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
Item |
|
|
|
|
|
Item |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
|
No. |
Qty. |
|
Designation |
Benævnelse |
|
No. |
|
Qty. |
|
Designation |
Benævnelse |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
015 |
1/C |
|
Cylinder head |
Cylinderdæksel |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
as plate 50501 |
som plate 50501 |
|
|
|
|
|
|
|
|
|
039 |
1/C |
|
Sleeve |
Foring |
|
|
|
|
|
|
|
|
|
|
040 |
1/C |
|
O-ring |
O-ring |
|
|
|
|
|
|
|
|
|
|
052 |
1/C |
|
Snap ring |
Låsering |
|
|
|
|
|
|
|
|
|
|
064 |
2/C |
|
Valve seat ring, |
Ventilsædering, |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
(inlet) |
(indstrømning) |
|
|
|
|
|
|
|
|
|
076 |
2/C |
|
Valve seat ring, |
Ventilsædering, |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
(exhaust) |
(udstødning) |
|
|
|
|
|
|
|
|
|
111 |
2/C |
|
Plug screw |
Propskrue |
|
|
|
|
|
|
|
|
|
|
123 |
2/C |
|
Sealing ring |
Tætningsring |
|
|
|
|
|
|
|
|
|
|
135 |
8/C |
|
Plug screw |
Propskrue |
|
|
|
|
|
|
|
|
|
|
147 |
8/C |
|
Sealing ring |
Tætningsring |
|
|
|
|
|
|
|
|
|
|
159 |
2/C |
|
Spring pin |
Fjederstift |
|
|
|
|
|
|
|
|
|
|
160 |
1/C |
|
Water guide jacket |
Kølekappe |
|
|
|
|
|
|
|
|
|
|
172 |
4/C |
|
Screw |
Skrue |
|
|
|
|
|
|
|
|
|
|
184 |
8/C |
|
O-ring |
O-ring |
|
|
|
|
|
|
|
|
|
|
196 |
4/C |
|
Cooling water con- |
Kølevandsovergang |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
nection |
|
|
|
|
|
|
|
|
|
|
218 |
4/C |
|
Valve Guide |
Ventilstyr |
|
|
|
|
|
|
|
|
|
|
231 |
2/C |
|
Stud |
Tap |
|
|
|
|
|
|
|
|
|
|
243 |
2/C |
|
Distance pipe |
Afstandsstykke |
|
|
|
|
|
|
|
|
|
|
255 |
2/C |
|
Nut |
Møtrik |
|
|
|
|
|
|
|
|
|
|
267 |
2/C |
|
Stud |
Tap |
|
|
|
|
|
|
|
|
|
|
279 |
2/C |
|
Nut |
Møtrik |
|
|
|
|
|
|
|
|
|
|
280 |
1/C |
|
Spring pin |
Fjederstift |
|
|
|
|
|
|
|
|
|
|
292 |
3/C |
|
Stud |
Tap |
|
|
|
|
|
|
|
|
|
|
302 |
2/C |
|
Thrust piece |
Trykstykke |
|
|
|
|
|
|
|
|
|
|
338 |
2/C |
|
O-ring |
O-ring |
|
|
|
|
|
|
|
|
|
|
351 |
4/C |
|
O-ring |
O-ring |
|
|
|
|
|
|
|
|
|
|
363 |
4/C |
|
O-ring |
O-ring |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
When ordering spare parts, see also page 500.50. |
Ved bestilling af reservedele, se også side 500.50. |
||||
* |
= |
Only available as part of a spare parts kit. |
* |
= |
Kun tilgængelig som en del af et reservedelssæt. |
Qty./C |
= |
Qty./Cylinder |
Antal/C = |
Antal/Cylinder |
|
08028-0D/H5250/94.08.12
98.34 - ES0S
Plate
Page 1 (2)
Valve Spindles and Valve Gear |
50502-01H |
|
|
L23/30H
08028-0D/H5250/94.08.12
02.38 - ES0
50502-01H |
|
|
Valve Spindles and Valve Gear |
|
Plate |
||||||||
|
|
|
Page 2 (2) |
||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
||
L23/30H |
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|||
|
Item |
|
|
|
Designation |
Benævnelse |
|
Item |
|
Designation |
Benævnelse |
||
|
|
|
|
||||||||||
|
no. |
Qty. |
|
|
|
no. |
Qty. |
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
010 |
2/C |
|
|
Valve bridge, compl. |
Ventilbro, komplet |
490 |
4/C |
Outer spring |
Udvendig fjeder |
||||
|
|
|
|
|
incl. item 022, 034, 046, |
inkl. item 022, 034, 046, |
|
|
4/C |
|
|
|
|
|
|
|
|
|
071, 083, 095, 105, 117, |
071, 083, 095, 105, 117, |
512 |
Valve spindle, inlet |
Ventilspindel, inds. |
||||
|
|
|
|
|
129 and 130 |
129 og 130 |
|
|
|
and outlet |
og uds. |
||
022 |
2/C |
|
|
Valve bridge |
Ventilbro |
524 |
28/C |
Spring |
Fjeder |
||||
034 |
2/C |
|
|
Spring |
Fjeder |
536 |
28/C |
Ball |
Kugle |
||||
046 |
2/C |
|
|
Ball guide |
Kuglestyr |
548 |
4/C |
Spring washer |
Fjederskive |
||||
071 |
2/C |
|
|
Thrust piece |
Trykstykke |
573 |
2/C |
Bearing bush |
Lejebøsning |
||||
083 |
2/C |
|
|
Thrust screw |
Trykskrue |
585 |
4/C |
Retainer ring |
Låsering |
||||
095 |
4/C |
|
|
Nut |
Møtrik |
607 |
1/C |
Rocker arm shaft |
Aksel for vippearm |
||||
105 |
4/C |
|
|
Thrust piece |
Trykstykke |
|
|
|
|
|
|
|
|
117 |
4/C |
|
|
Circlip |
Fjederring |
|
|
|
|
|
|
|
|
129 |
2/C |
|
|
Thrust piece |
Trykstykke |
|
|
|
|
|
|
|
|
130 |
4/C |
|
|
Spring pin |
Fjederstift |
|
|
|
|
|
|
|
|
178 |
1/C |
|
|
Rocker arm |
Buk for vippearm |
|
|
|
|
|
|
|
|
|
|
|
|
|
bracket |
|
|
|
|
|
|
|
|
201 |
1/C |
|
|
Plug |
Prop |
|
|
|
|
|
|
|
|
237 |
1/C |
|
|
Rocker arm, exhaust, |
Vippearm udst, komplet |
|
|
|
|
|
|
|
|
|
|
|
|
|
compl. incl. item 095, |
inkl. item 095, 249, 262, |
|
|
|
|
|
|
|
|
|
|
|
|
249, 262, 286, 298, 585 |
286, 298, 585 |
|
|
|
|
|
|
|
249 |
1/C |
|
|
Rocker arm, exhaust |
Vippearm, udstødning |
|
|
|
|
|
|
|
|
262 |
4/C |
|
|
Plug |
Prop |
|
|
|
|
|
|
|
|
286 |
2/C |
|
|
Thrust piece |
Trykstrykke |
|
|
|
|
|
|
|
|
298 |
2/C |
|
|
Thrust screw |
Trykskrue |
|
|
|
|
|
|
|
|
345 |
1/C |
|
|
Rocker arm inlet, |
Vippearm inds., komp- |
|
|
|
|
|
|
|
|
|
|
|
|
|
complete incl. item |
let inkl. item 095, 249, |
|
|
|
|
|
|
|
|
|
|
|
|
095, 249, 262, 286, 298, |
262, 286, 298, 585 |
|
|
|
|
|
|
|
|
|
|
|
|
585 |
|
|
|
|
|
|
|
|
357 |
1/C |
|
|
Rocker arm, inlet |
Vippearm, indsugning |
|
|
|
|
|
|
|
|
441 |
2/C |
|
|
Disc |
Skive |
|
|
|
|
|
|
|
|
453 |
2/C |
|
|
Securing ring |
Sikringsring |
|
|
|
|
|
|
|
|
465 |
4/C |
|
|
Conical ring in 2/2 |
Konisk ring 2/2 |
|
|
|
|
|
|
|
|
477 |
4/C |
|
|
Rotocap, compl. |
Rotationsgiver, kompl. |
|
|
|
|
|
|
|
|
489 |
4/C |
|
|
Inner spring |
Indvendig fjeder |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
When ordering spare parts, see also page 500.50. |
Ved bestilling af reservedele, se også side 500.50. |
||||
* |
= Only available as part of a spare parts kit. |
* |
= |
Kun tilgængelig som en del af et reservedelssæt. |
|
Qty./C |
= |
Qty./Cylinder |
Antal/C = |
Antal/Cylinder |
|
Qty./ |
= |
Qty./Individual |
Antal/I |
= |
Antal/Individuelt |
08028-0D/H5250/94.08.12
02.38 - ES0
Plate
Page 1 (2)
08028-0D/H5250/94.08.12
Indicator Valve |
50508-01H |
|
|
L23/30H
049
037
013
025
95.50 - ES0S
50508-01H |
|
|
|
Indicator Valve |
|
Plate |
|||||||||
|
|
|
|
Page 2 (2) |
|||||||||||
L23/30H |
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
Item |
|
|
|
Designation |
Benævnelse |
|
Item |
|
|
|
Designation |
Benævnelse |
||
|
|
|
|
|
|||||||||||
|
No. |
Qty. |
|
|
|
No. |
|
Qty. |
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
013 |
1/C |
|
|
Connecting piece |
Forbindelsesstykke |
|
|
|
|
|
|
|
|
|
|
025 |
3/C |
|
|
Gasket |
Gasket |
|
|
|
|
|
|
|
|
|
|
037 |
1/C |
|
|
Gasket |
Gasket |
|
|
|
|
|
|
|
|
|
|
049 |
1/C |
|
|
Indicator valve |
Indikatorventil |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
When ordering spare parts, see also page 500.50. |
Ved bestilling af reservedele, se også side 500.50. |
||||
* |
= |
Only available as part of a spare parts kit. |
* |
= |
Kun tilgængelig som en del af et reservedelssæt. |
Qty./C |
= |
Qty./Cylinder |
Antal/C = |
Antal/Cylinder |
|
08028-0D/H5250/94.08.12
95.50 - ES0S
Plate
Page 1 (2)
Cylinder Head, Top Cover |
50510-01H |
|
|
L23/30H
087
099
063
075 |
110 |
|
051 |
038
122
014
026
08028-0D/H5250/94.08.12
94.22 - ES0S
50510-01H |
|
|
|
Cylinder Head, Top Cover |
|
Plate |
|||||||||
|
|
|
|
Page 2 (2) |
|||||||||||
L23/30H |
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
Item |
|
|
|
Designation |
Benævnelse |
|
Item |
|
|
|
Designation |
Benævnelse |
||
|
|
|
|
|
|||||||||||
|
No. |
Qty. |
|
|
|
No. |
|
Qty. |
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
014 |
1/C |
|
|
Coaming |
Karm |
|
|
|
|
|
|
|
|
|
|
026 |
1/C |
|
|
Gasket |
Pakning |
|
|
|
|
|
|
|
|
|
|
038 |
13/C |
|
|
Screw |
Skrue |
|
|
|
|
|
|
|
|
|
|
051 |
4/C |
|
|
Spring pin |
Fjederstift |
|
|
|
|
|
|
|
|
|
|
063 |
1/C |
|
|
Top cover |
Topdæksel |
|
|
|
|
|
|
|
|
|
|
075 |
1/C |
|
|
Gasket |
Pakning |
|
|
|
|
|
|
|
|
|
|
087 |
3/C |
|
|
Handle |
Håndtag |
|
|
|
|
|
|
|
|
|
|
099 |
3/C |
|
|
O-ring |
O-ring |
|
|
|
|
|
|
|
|
|
|
110 |
3/C |
|
|
Nut |
Møtrik |
|
|
|
|
|
|
|
|
|
|
122 |
13/C |
|
|
Washer |
Skive |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
When ordering spare parts, see also page 500.50. |
Ved bestilling af reservedele, se også side 500.50. |
||||
* |
= |
Only available as part of a spare parts kit. |
* |
= |
Kun tilgængelig som en del af et reservedelssæt. |
Qty./C |
= |
Qty./Cylinder |
Antal/C = |
Antal/Cylinder |
|
08028-0D/H5250/94.08.12
94.22 - ES0S
Index
Page 1 (1)
Description
Piston, Connecting Rod and Cylinder Liner |
506 |
L23/30H
Piston, Connecting Rod and Cylinder liner.................................................................... |
|
506.01(01H) |
|||
Working Card |
|
|
|
|
|
Dismounting of Piston and Connecting Rod.................................................................... |
|
506-01.00.(01H) |
|||
Separation of Piston and Connecting |
Rod..................................................................... |
|
506-01.05.(01 H) |
||
Piston......................................................................................................................... |
|
|
|
|
.... . 506-01.10.(01 H) |
Connecting |
Rod.............................................................................................................. |
|
|
|
.......506-01.15.(01H) |
Criteria for Replacement of Connecting Rod Big-end and Main Bearing Shells......... |
506-01.16.(01H) |
||||
Mounting of Piston and Connecting |
Rod......................................................................... |
|
506-01.20.(01H) |
||
Hydraulic |
Tightening and Check of Connecting Rod |
Screws.................................. |
506-01.25.(04 H) |
||
In-situ Inspection of Connecting Rod Big-end Bearing............................................ |
506-01.30.(01H) |
||||
Inspection and Honing of Cylinder |
Liner................................................................ |
......... |
506-01.35.01H) |
||
Replacement of Cytinder |
Liner.................................................................................. |
|
....... |
506-01.40.(01H) |
|
Grinding of Seal Face on Cylinder Liner and Cylinder |
Head......................................... |
506-01.45.(01 H) |
|||
Dismounting of Piston and Cylinder Liner at Low Overhaul Heights.......................... |
506-01.50.(01H) |
||||
Plates |
|
|
|
|
|
Piston and |
Connecting |
Rod........................................................................................ |
|
|
50601-05H |
Piston and |
Connecting |
Rod....................................................................................... |
|
|
50601-05H |
Cylinder Liner............................ |
........................................................................................................ |
|
|
50610-01H |
|
CylinderLiner......................................................................................................... |
|
|
|
50610-01H |
|
97.05 - ESOU
Description |
Piston, Connecting Rod and Cylinder Liner |
506.01 |
Page 1 (1) |
Edition 01H |
|
|
|
|
|
|
|
|
|
L23/30H |
Piston |
Connecting Rod |
|
The piston, which is oil-cooled and of the monobloc type made of nodular cast iron, is equipped with 3 compression rings and 1 scraper ring.
By use of a combination of compression rings with different barrel-shaped profiles and chrome-plated running surface on all rings, the piston ring pack is optimized for maximum sealing effect and minimum wear rate.
The piston has a cooling oil space close to the piston crown and the piston ring zone. The heat transport, and thus the cooling effect are based on the shaker effect arising during the piston movement. Oil from the engine's lubricating oil system is used as cooling oil.
The piston is provided with a turned edge at the top due to the flame ring mounted in the cylinder liner.
Piston Pin
The piston pin is fully floating which means that it can turn freely in the pin bosses of the piston as well as in the connecting rod bush. The piston pin is turned in place upwords in axial direction by two circlips (seeger rings).
08028-0D/H5250/94.08.12
The connecting rod is die-forged. The big-end has an inclined joint in order to facilitate the piston and connecting rod assembly to be withdrawn up through the cylinder liner. The joint faces on the connecting rod and the bearing cap are serrated to ensure precise location and to prevent relative movement of the parts.
The big-end bearing is of the trimetal type, i.e. steel shells lined with tin-aluminium or lead-bronze coated with a running layer. Designed as plain type or rillentype. The bearing shells are of the precision type and are therefore to be fitted without scraping or any other kind of adaption.
The small-end bearing is of the trimetal type and is pressed into the connecting rod.
Cylinder Liner
The cylinder liner is made of fine-grained, pearlite cast iron and is fitted in a bore in the engine frame. Replaceable cast iron sealing rings are fitted between the liner and the cylinder head and between the liner and the frame. The liner is clamped by the cylinder head and is guided by a bore at the bottom of the cooling water space of the engine frame. The liner can thus expand freely downwards, when heated during the running of the engine. Sealing for the cooling water is obtained by means of silicone rubber rings which are fitted in grooves machined in the liner.
The cylinder liner is of the socalled "stepped cylinder" type, provided with flame ring inserted in the top of the liner.
96.19 - ES0U
Working Card |
Dismounting of Piston and Connecting Rod |
506-01.00 |
Page 1 (3) |
Edition 01H |
|
|
|
|
|
|
|
08028-0D/H5250/94.08.12
L23/30H
Safety precautions:
Stopped engine
Shut-off starting air
Shut-off cooling water
Shut-off fuel oil
Shut-off cooling oil
Stopped lub. oil circul.
Description:
Dismounting of piston and connecting rod assembly, for inspection and/or overhaul.
Starting position: |
|
Cylinder head has been dismounted |
|
from engine |
505-01.00 |
Crankcase open. |
|
Related procedure: |
|
Separation of piston and connecting |
|
rod |
506-01.05 |
Inspection and honing of cylinder |
|
liner |
506-01.35 |
Manpower: |
|
|
|
Working time |
: |
1 |
hour |
Capacity |
: |
2 |
men |
Data: |
|
|
|
Data for pressure and tolerance |
(Page 500.35) |
Data for torque moment |
(Page 500.40) |
Declaration of weight |
(Page 500.45) |
Special tools: |
|
|
Plate no |
Item no |
Note |
52006 |
021 |
|
52006 |
033 |
|
52006 |
094 |
2 pieces |
52006 |
224 |
|
52006 |
273 |
80-360 Nm |
52010 |
011 |
|
Tool combination for dismounting of connecting rod screw, see working card 520-01.20.
Hand tools:
Threaded pin M12.
Open-end spanner 24 mm.
Wire.
Scraper or similar.
Small adjustable spanner.
Replacement and wearing parts:
Plate no |
Item no |
Qty/ |
96.20 - ES0S
