Warfare Unleashed –

Implementing Gameplay

In Chapter 5, Diverting the Game Flow – State Stack and Chapter 6, Waiting and Maintenance Area – Menus, you have seen how to handle menus and states, now it is time to return to the actual game. Up till now, we have built a world that can

contain various entities, and implemented the basic interaction mechanisms through updates, drawing, and commands. However, this is not particularly interesting as long as the world is empty.

In this chapter, we are going to populate the world, and implement the core part of the game; the actual gameplay with enemies, weapons, battles, and goodies. We are going to cover the following topics:

•Enemy aircraft controlled by a simple artificial intelligence

•Projectiles such as a machine gun or missiles

•Pickups that improve the player's equipment

•Collision detection and response between entities in the scene graph

•The world's update cycle and automatic removal of entities

Equipping the entities

You have heard about entities for the first time in Chapter 3, Forge of the Gods – Shaping Our World, where we built the World class and the scene graph. As a quick reminder, the SceneNode base class was inherited by the Entity class. Entities are the central part of this chapter. It's all about the interaction between entities of

different kinds. Before starting to implement all those interactions, it is reasonable to think about crucial properties our entities need to have.

www.it-ebooks.info

Warfare Unleashed – Implementing Gameplay

Introducing hitpoints

Since, we are preparing our airplanes for the battlefield, we need to provide them with new specific attributes. To our class definition of Entity, we add a new member variable that memorizes the current hitpoints. Hitpoints (HP) are a measure for the hull integrity of an entity; the entity is destroyed as soon as the hitpoints reach or fall below zero.

In addition to the member variable, we provide member functions that allow the modification of the hitpoints. We do not provide direct write access, however, the hitpoints can be decreased (the plane is damaged) or increased (the plane is repaired). Also, a destroy() function instantly destroys the entity.

class Entity : public SceneNode

{

};

The implementation is as expected: repair() adds the specified hitpoints, damage() subtracts them, and destroy() sets them to zero.

Storing entity attributes in data tables

In our game, there are already two different airplanes with different attributes. For this chapter, we introduce a third one to make the game more interesting. With an increasing amount of new aircraft types, attributes such as speed, hitpoints, used texture, or fire rate may vary strongly among them. We need to think of a way to store those properties in a central place, allowing easy access to them.

What we clearly want to avoid are case differentiations in every Aircraft method, since this makes the local logic code less readable, and spreads the attributes across different functions. Instead of if/else cascades or switch statements, we can store the attributes in a central table, and just access the table every time we need an attribute.

[ 152 ]

www.it-ebooks.info

Chapter 7

Let's define the type of such a table entry in the case of an airplane. We choose the simplest way, and have a structure AircraftData with all members public. This type is defined in the file DataTables.hpp.

struct AircraftData

{

};

While AircraftData is a single table entry, the whole table is represented as a sequence of entries, namely std::vector<AircraftData>.

Next, we write a function that initializes the table for different aircraft types.

We begin to define a vector of the correct size (Aircraft::TypeCount is the last enumerator of the enum Aircraft::Type, it contains the number of different aircraft types). Since the enumerators are consecutive and begin at zero, we can use them

as indices in our STL container. We thus initialize all the attributes for different airplanes, and eventually return the filled table.

std::vector<AircraftData> initializeAircraftData()

{

std::vector<AircraftData> data(Aircraft::TypeCount);

data[Aircraft::Eagle].hitpoints = 100; data[Aircraft::Eagle].speed = 200.f; data[Aircraft::Eagle].texture = Textures::Eagle;

data[Aircraft::Raptor].hitpoints = 20; data[Aircraft::Raptor].speed = 80.f; data[Aircraft::Raptor].texture = Textures::Raptor;

...

return data;

}

The global function initializeAircraftData() is declared in DataTables.hpp and defined in DataTables.cpp. It is used inside Aircraft.cpp, to initialize a global constant Table. This constant is declared locally in the .cpp file, so only the

Aircraft internals can access it. In order to avoid name collisions in other files, we use an anonymous namespace.

namespace

{

const std::vector<AircraftData> Table = initializeAircraftData();

}

[ 153 ]

www.it-ebooks.info

Warfare Unleashed – Implementing Gameplay

Inside the Aircraft methods, we can access a constant attribute of the own plane type using the member variable mType as index. For example, Table[mType]. hitpoints denotes the maximal hitpoints of the current aircraft.

Data tables are only the first step of storing gameplay constants. For more flexibility, and to avoid recompiling the application, you can also store these constants externally, for example, in a simple text file or using a specific file format. The application initially loads these files, parses the values, and fills the data tables accordingly.

Nowadays, it is very common to load gameplay information from external resources. There are text-based formats such as YAML or XML, as well as, many application-specific text and binary formats. There are also well-known C++ libraries such as Boost.Serialize (www.boost. org) that help with loading and saving data structures from C++.

One possibility that has recently gained popularity consists of using script languages, most notably Lua (www.lua.org), in addition to C++. This has the advantage that not only constant data, but dynamic functionality can be outsourced and loaded during runtime.

Displaying text

We would like to add some text on the display, for example, to show the hitpoints or ammunition of different entities. Since this text information is supposed to be shown next to the entity, it stands to reason to attach it to the corresponding scene node.

We therefore, create a TextNode class which inherits SceneNode as shown in the following code:

class TextNode : public SceneNode

{

};

The implementation of the functions is not complicated. The SFML class sf::Text provides most of what we need. In the TextNode constructor, we retrieve the font from the resource holder and assign it to the text.

[ 154 ]

www.it-ebooks.info

Chapter 7

TextNode::TextNode(const FontHolder& fonts, const std::string& text)

{

mText.setFont(fonts.get(Fonts::Main));

mText.setCharacterSize(20);

setString(text);

}

The function to draw the text nodes just forwards the call to the SFML render target, as you know it from sprites.

void TextNode::drawCurrent(sf::RenderTarget& target, sf::RenderStates states) const

{

target.draw(mText, states);

}

For the interface, mainly the following method is interesting. It assigns a new string to the text node, and automatically adapts to its size. centerOrigin() is a utility function we wrote; it sets the object's origin to its center, which simplifies positioning a lot.

void TextNode::setString(const std::string& text)

{

mText.setString(text);

centerOrigin(mText);

}

In the Aircraft constructor, we create a text node and attach it to the aircraft itself. We keep a pointer mHealthDisplay as a member variable and let it point to the attached node.

std::unique_ptr<TextNode> healthDisplay(new TextNode(fonts, "")); mHealthDisplay = healthDisplay.get(); attachChild(std::move(healthDisplay));

In the method Aircraft::update(), we check for the current hitpoints, and convert them to a string, using our custom toString() function. The text node's string and relative position are set. Additionally, we set the text node's rotation to the negative aircraft rotation, which compensates the rotation in total. We do this in order to have the text always upright, independent of the aircraft's orientation.

mHealthDisplay->setString(toString(getHitpoints()) + " HP"); mHealthDisplay->setPosition(0.f, 50.f); mHealthDisplay->setRotation(-getRotation());
