Table 439. SELECTING TANGENT LOSS IN GLASS

(SHEET 1 OF 5)



Frequency



Tangent Loss

Glass

(Hz)

Temperature

(tan δ)

















SiO2 glass

100 Hz

25˚C

0.00002

SiO2 glass

1 kHz

25˚C

0.00002

SiO2 glass

10 kHz

25˚C

0.00002

SiO2 glass

10 kHz

200˚C

0.00004

B2O3 glass

32 kHz

50K

0.00005

B2O3 glass

32 kHz

100K

0.00011

SiO2 glass

1 kHz

200˚C

0.00012

B2O3 glass

32 kHz

300K

0.0003

B2O3-Na2O glass (10% mol Na2O)

1 kHz

134.5˚C

0.0003

B2O3 glass

1 MHz

100˚C

0.0004

B2O3 glass

1 MHz

200˚C

0.0005

B2O3-Na2O glass (12.5% mol Na2O)

1 kHz

134.5˚C

0.0005

SiO2 glass

100 Hz

200˚C

0.00052

B2O3 glass

32 kHz

150K

0.0007

SiO2 glass

10 kHz

300˚C

0.00072

B2O3 glass

32 kHz

250K

0.0008

B2O3 glass

1 MHz

300˚C

0.0009

B2O3-Na2O glass (10% mol Na2O)

1 kHz

214˚C

0.0009

B2O3-Na2O glass (20% mol Na2O)

1 kHz

16˚C

0.0009

B2O3-CaO glass (33.3% mol CaO)

2 MHz

25˚C

0.001

B2O3 glass

32 kHz

200K

0.0010

SiO2-B2O3 glass (46.3% mol B2O3)

10 GHz



0.0014

SiO2 glass

9.4 GHz

20˚C

0.0015

B2O3-Na2O glass (15% mol Na2O)

1 kHz

134.5˚C

0.0015









Source: data compiled by J.S. Park from O. V. Mazurin, M. V. Streltsina and T. P. ShvaikoShvaikovskaya, Handbook of Glass Data, Part A and Part B, Elsevier, New York, 1983.

©2001 CRC Press LLC

Table 439. SELECTING TANGENT LOSS IN GLASS

(SHEET 2 OF 5)



Frequency



Tangent Loss

Glass

(Hz)

Temperature

(tan δ)

















SiO2 glass

9.4 GHz

200˚C

0.0018

SiO2 glass

9.4 GHz

400˚C

0.002

B2O3-CaO glass (33.3% mol CaO)

2 MHz

100˚C

0.002

SiO2-Al2O3 glass (0.5% mol Al2O3)

100 K

100 K

0.0021

B2O3-Na2O glass (10% mol Na2O)

1MHz

room temp.

0.0022

B2O3-Na2O glass (12.5% mol Na2O)

1 kHz

214˚C

0.0022

B2O3-Na2O glass (25% mol Na2O)

1 kHz

16˚C

0.0022

SiO2-Al2O3 glass (0.5% mol Al2O3)

50 K

50 K

0.0025

B2O3-Na2O glass (8% mol Na2O)

1MHz

room temp.

0.0025

B2O3-CaO glass (33.3% mol CaO)

2 MHz

200˚C

0.0025

SiO2-Al2O3 glass (0.5% mol Al2O3)

150 K

150 K

0.0026

B2O3-Na2O glass (20% mol Na2O)

1 kHz

90.5˚C

0.0026

SiO2 glass

9.4 GHz

600˚C

0.0029

B2O3-Na2O glass (16% mol Na2O)

1MHz

room temp.

0.0031

B2O3-CaO glass (33.3% mol CaO)

2 MHz

300˚C

0.0035

B2O3-Na2O glass (10% mol Na2O)

1 kHz

277˚C

0.0038

B2O3-CaO glass (33.3% mol CaO)

2 MHz

400˚C

0.0045

SiO2 glass

9.4 GHz

800˚C

0.0048

SiO2-PbO glass (40% mol PbO)

100 GHz

room temp.

0.005

B2O3-CaO glass (33.3% mol CaO)

2 MHz

500˚C

0.0055

SiO2-Na2O glass (16% mol Na2O)

4.5x108 Hz

20˚C

0.0058

B2O3-Na2O glass (25% mol Na2O)

1MHz

room temp.

0.0063

B2O3-Na2O glass (15% mol Na2O)

1 kHz

214˚C

0.0064

B2O3-Na2O glass (10% mol Na2O)

1 kHz

298˚C

0.0066









Source: data compiled by J.S. Park from O. V. Mazurin, M. V. Streltsina and T. P. ShvaikoShvaikovskaya, Handbook of Glass Data, Part A and Part B, Elsevier, New York, 1983.

©2001 CRC Press LLC

Table 439. SELECTING TANGENT LOSS IN GLASS

(SHEET 3 OF 5)





Frequency



Tangent Loss

Glass

(Hz)

Temperature

(tan δ)

















B2O3-CaO glass (33.3% mol CaO)

2 MHz

550˚C

0.007

SiO2 glass

1 kHz

300˚C

0.0072

SiO2-Na2O glass

(20% mol Na2O)

4.5x108 Hz

20˚C

0.0073

SiO2-Na2O glass (22.2% mol Na2O)

4.5x108 Hz

20˚C

0.0081

B2O3-Na2O glass (28% mol Na2O)

1MHz

room temp.

0.0081

B2O3-Na2O glass (12.5% mol Na2O)

1 kHz

277˚C

0.0100

SiO2-Na2O glass (28.6% mol Na2O)

4.5x108 Hz

20˚C

0.0102

SiO2 glass

9.4 GHz

1000˚C

0.011

B2O3-Na2O glass (20% mol Na2O)

1 kHz

157˚C

0.0149

SiO2-PbO glass

(40% mol PbO)

32 GHz

-150˚C

0.015

B2O3-Na2O glass (25% mol Na2O)

1 kHz

90.5˚C

0.0150

SiO2-Na2O glass

(36% mol Na2O)

4.5x108 Hz

20˚C

0.0162

B2O3-Na2O glass (12.5% mol Na2O)

1 kHz

298˚C

0.0170

SiO2-PbO glass

(40% mol PbO)

32 GHz

-100˚C

0.018

SiO2-PbO glass

(40% mol PbO)

32 GHz

-50˚C

0.020

SiO2 glass

10 kHz

400˚C

0.022

SiO2-PbO glass

(40% mol PbO)

32 GHz

0˚C

0.022

SiO2-PbO glass

(40% mol PbO)

32 GHz

50˚C

0.024

SiO2 glass

9.4 GHz

1200˚C

0.025

SiO2-Na2O glass (19.5% mol Na2O)

300 kHz

room temp.

0.0295

B2O3-Na2O glass (15% mol Na2O)

1 kHz

277˚C

0.0296

SiO2-Na2O glass (19.5% mol Na2O)

100 kHz

room temp.

0.0364

SiO2-Na2O glass (24.4% mol Na2O)

300 kHz

room temp.

0.0369

SiO2-Na2O glass (19.5% mol Na2O)

50 kHz

room temp.

0.0428











Source: data compiled by J.S. Park from O. V. Mazurin, M. V. Streltsina and T. P. ShvaikoShvaikovskaya, Handbook of Glass Data, Part A and Part B, Elsevier, New York, 1983.

©2001 CRC Press LLC

Table 439. SELECTING TANGENT LOSS IN GLASS

(SHEET 4 OF 5)



Frequency



Tangent Loss

Glass

(Hz)

Temperature

(tan δ)

















SiO2-Na2O glass (24.4% mol Na2O)

100 kHz

room temp.

0.0456

SiO2 glass

9.4 GHz

1400˚C

0.046

B2O3-Na2O glass (15% mol Na2O)

1 kHz

298˚C

0.0477

SiO2-Na2O glass (19.5% mol Na2O)

30 kHz

room temp.

0.0492

SiO2-PbO glass (40% mol PbO)

1000 GHz

room temp.

0.050

SiO2-Na2O glass (24.4% mol Na2O)

50 kHz

room temp.

0.0563

SiO2-Na2O glass (29.4% mol Na2O)

300 kHz

room temp.

0.0568

SiO2-Na2O glass (24.4% mol Na2O)

30 kHz

room temp.

0.0652

SiO2-Na2O glass (19.5% mol Na2O)

10 kHz

room temp.

0.0656

SiO2-Na2O glass (29.4% mol Na2O)

100 kHz

room temp.

0.0758

SiO2 glass

100 Hz

300˚C

0.080

SiO2-Na2O glass (19.5% mol Na2O)

5 kHz

room temp.

0.0832

B2O3-Na2O glass (20% mol Na2O)

1 kHz

219˚C

0.0890

SiO2-Na2O glass (24.4% mol Na2O)

10 kHz

room temp.

0.0916

SiO2-Na2O glass (34.3% mol Na2O)

300 kHz

room temp.

0.0936

SiO2-Na2O glass (29.4% mol Na2O)

50 kHz

room temp.

0.0972

SiO2-Na2O glass (19.5% mol Na2O)

3 kHz

room temp.

0.0984

SiO2-Na2O glass (34.3% mol Na2O)

1kHz

room temp.

0.10324

B2O3-Na2O glass (25% mol Na2O)

1 kHz

157˚C

0.1080

SiO2-Na2O glass (29.4% mol Na2O)

30 kHz

room temp.

0.1172

SiO2-Na2O glass (24.4% mol Na2O)

5 kHz

room temp.

0.1194

SiO2-Na2O glass (34.3% mol Na2O)

100 kHz

room temp.

0.1388

SiO2-Na2O glass (39.3% mol Na2O)

300 kHz

room temp.

0.1402

SiO2-Na2O glass (19.5% mol Na2O)

1kHz

room temp.

0.144









Source: data compiled by J.S. Park from O. V. Mazurin, M. V. Streltsina and T. P. ShvaikoShvaikovskaya, Handbook of Glass Data, Part A and Part B, Elsevier, New York, 1983.

©2001 CRC Press LLC

Table 439. SELECTING TANGENT LOSS IN GLASS

(SHEET 5 OF 5)



Frequency



Tangent Loss

Glass

(Hz)

Temperature

(tan δ)

















SiO2-Na2O glass (24.4% mol Na2O)

3 kHz

room temp.

0.1455

SiO2-Na2O glass (29.4% mol Na2O)

10 kHz

room temp.

0.1764

SiO2-Na2O glass (34.3% mol Na2O)

50 kHz

room temp.

0.1864

SiO2 glass

1 kHz

400˚C

0.2

SiO2-Na2O glass (39.3% mol Na2O)

100 kHz

room temp.

0.2144

SiO2-Na2O glass (24.4% mol Na2O)

1kHz

room temp.

0.2207

SiO2-Na2O glass (34.3% mol Na2O)

30 kHz

room temp.

0.2314

SiO2-Na2O glass (29.4% mol Na2O)

5 kHz

room temp.

0.2426

B2O3-Na2O glass (20% mol Na2O)

1 kHz

274˚C

0.2480

SiO2-Na2O glass (29.4% mol Na2O)

3 kHz

room temp.

0.3027

SiO2-Na2O glass (39.3% mol Na2O)

50 kHz

room temp.

0.3032

SiO2-Na2O glass (34.3% mol Na2O)

10 kHz

room temp.

0.3752

SiO2-Na2O glass (39.3% mol Na2O)

30 kHz

room temp.

0.3835

SiO2-Na2O glass (29.4% mol Na2O)

1kHz

room temp.

0.4923

SiO2-Na2O glass (34.3% mol Na2O)

5 kHz

room temp.

0.5280

SiO2-Na2O glass (39.3% mol Na2O)

10 kHz

room temp.

0.6338

SiO2-Na2O glass (34.3% mol Na2O)

3 kHz

room temp.

0.6520

SiO2 glass

100 Hz

400˚C

1.0









Source: data compiled by J.S. Park from O. V. Mazurin, M. V. Streltsina and T. P. ShvaikoShvaikovskaya, Handbook of Glass Data, Part A and Part B, Elsevier, New York, 1983.

©2001 CRC Press LLC

Table 440. SELECTING TANGENT LOSS IN GLASS BY

TEMPERATURE (SHEET 1 OF 5)







Frequency

Tangent Loss

Temperature

Glass

(Ηz)

(tan δ)

















-100˚C

SiO2-PbO glass (40% mol PbO)

32 GHz

0.018

-150˚C

SiO2-PbO glass

(40% mol PbO)

32 GHz

0.015

-50˚C

SiO2-PbO glass

(40% mol PbO)

32 GHz

0.020

0˚C

SiO2-PbO glass

(40% mol PbO)

32 GHz

0.022

16˚C

B2O3-Na2O glass (20% mol Na2O)

1 kHz

0.0009

16˚C

B2O3-Na2O glass (25% mol Na2O)

1 kHz

0.0022

20˚C

SiO2 glass

9.4 GHz

0.0015

20˚C

B2O3-Na2O glass (10% mol Na2O)

1MHz

0.0022

20˚C

B2O3-Na2O glass (8% mol Na2O)

1MHz

0.0025

20˚C

B2O3-Na2O glass (16% mol Na2O)

1MHz

0.0031

20˚C

SiO2-PbO glass

(40% mol PbO)

100 GHz

0.005

20˚C

SiO2-Na2O glass

(16% mol Na2O)

4.5x108 Hz

0.0058

20˚C

B2O3-Na2O glass (25% mol Na2O)

1MHz

0.0063

20˚C

SiO2-Na2O glass

(20% mol Na2O)

4.5x108 Hz

0.0073

20˚C

B2O3-Na2O glass (28% mol Na2O)

1MHz

0.0081

20˚C

SiO2-Na2O glass (22.2% mol Na2O)

4.5x108 Hz

0.0081

20˚C

SiO2-Na2O glass (28.6% mol Na2O)

4.5x108 Hz

0.0102

20˚C

SiO2-Na2O glass

(36% mol Na2O)

4.5x108 Hz

0.0162

20˚C

SiO2-Na2O glass (19.5% mol Na2O)

300 kHz

0.0295

20˚C

SiO2-Na2O glass (19.5% mol Na2O)

100 kHz

0.0364

20˚C

SiO2-Na2O glass (24.4% mol Na2O)

300 kHz

0.0369

20˚C

SiO2-Na2O glass (19.5% mol Na2O)

50 kHz

0.0428











Source: data compiled by J.S. Park from O. V. Mazurin, M. V. Streltsina and T. P. ShvaikoShvaikovskaya, Handbook of Glass Data, Part A and Part B, Elsevier, New York, 1983.

©2001 CRC Press LLC

Table 440. SELECTING TANGENT LOSS IN GLASS BY

TEMPERATURE (SHEET 2 OF 5)





Frequency

Tangent Loss

Temperature

Glass

(Ηz)

(tan δ)

















20˚C

SiO2-Na2O glass (24.4% mol Na2O)

100 kHz

0.0456

20˚C

SiO2-Na2O glass (19.5% mol Na2O)

30 kHz

0.0492

20˚C

SiO2-PbO glass (40% mol PbO)

1000 GHz

0.050

20˚C

SiO2-Na2O glass (24.4% mol Na2O)

50 kHz

0.0563

20˚C

SiO2-Na2O glass (29.4% mol Na2O)

300 kHz

0.0568

20˚C

SiO2-Na2O glass (24.4% mol Na2O)

30 kHz

0.0652

20˚C

SiO2-Na2O glass (19.5% mol Na2O)

10 kHz

0.0656

20˚C

SiO2-Na2O glass (29.4% mol Na2O)

100 kHz

0.0758

20˚C

SiO2-Na2O glass (19.5% mol Na2O)

5 kHz

0.0832

20˚C

SiO2-Na2O glass (24.4% mol Na2O)

10 kHz

0.0916

20˚C

SiO2-Na2O glass (34.3% mol Na2O)

300 kHz

0.0936

20˚C

SiO2-Na2O glass (29.4% mol Na2O)

50 kHz

0.0972

20˚C

SiO2-Na2O glass (19.5% mol Na2O)

3 kHz

0.0984

20˚C

SiO2-Na2O glass (34.3% mol Na2O)

1kHz

0.10324

20˚C

SiO2-Na2O glass (29.4% mol Na2O)

30 kHz

0.1172

20˚C

SiO2-Na2O glass (24.4% mol Na2O)

5 kHz

0.1194

20˚C

SiO2-Na2O glass (34.3% mol Na2O)

100 kHz

0.1388

20˚C

SiO2-Na2O glass (39.3% mol Na2O)

300 kHz

0.1402

20˚C

SiO2-Na2O glass (19.5% mol Na2O)

1kHz

0.144

20˚C

SiO2-Na2O glass (24.4% mol Na2O)

3 kHz

0.1455

20˚C

SiO2-Na2O glass (29.4% mol Na2O)

10 kHz

0.1764

20˚C

SiO2-Na2O glass (34.3% mol Na2O)

50 kHz

0.1864

20˚C

SiO2-Na2O glass (39.3% mol Na2O)

100 kHz

0.2144

20˚C

SiO2-Na2O glass (24.4% mol Na2O)

1kHz

0.2207









Source: data compiled by J.S. Park from O. V. Mazurin, M. V. Streltsina and T. P. ShvaikoShvaikovskaya, Handbook of Glass Data, Part A and Part B, Elsevier, New York, 1983.

©2001 CRC Press LLC

Table 440. SELECTING TANGENT LOSS IN GLASS BY

TEMPERATURE (SHEET 3 OF 5)





Frequency

Tangent Loss

Temperature

Glass

(Ηz)

(tan δ)

















20˚C

SiO2-Na2O glass (34.3% mol Na2O)

30 kHz

0.2314

20˚C

SiO2-Na2O glass (29.4% mol Na2O)

5 kHz

0.2426

20˚C

SiO2-Na2O glass (29.4% mol Na2O)

3 kHz

0.3027

20˚C

SiO2-Na2O glass (39.3% mol Na2O)

50 kHz

0.3032

20˚C

SiO2-Na2O glass (34.3% mol Na2O)

10 kHz

0.3752

20˚C

SiO2-Na2O glass (39.3% mol Na2O)

30 kHz

0.3835

20˚C

SiO2-Na2O glass (29.4% mol Na2O)

1kHz

0.4923

20˚C

SiO2-Na2O glass (34.3% mol Na2O)

5 kHz

0.5280

20˚C

SiO2-Na2O glass (39.3% mol Na2O)

10 kHz

0.6338

20˚C

SiO2-Na2O glass (34.3% mol Na2O)

3 kHz

0.6520

25˚C

SiO2 glass

100 Hz

0.00002

25˚C

SiO2 glass

1 kHz

0.00002

25˚C

SiO2 glass

10 kHz

0.00002

25˚C

B2O3-CaO glass (33.3% mol CaO)

2 MHz

0.001

50˚C

SiO2-PbO glass (40% mol PbO)

32 GHz

0.024

90.5˚C

B2O3-Na2O glass (20% mol Na2O)

1 kHz

0.0026

90.5˚C

B2O3-Na2O glass (25% mol Na2O)

1 kHz

0.0150

100˚C

B2O3 glass

1 MHz

0.0004

100˚C

B2O3-CaO glass (33.3% mol CaO)

2 MHz

0.002

134.5˚C

B2O3-Na2O glass (10% mol Na2O)

1 kHz

0.0003

134.5˚C

B2O3-Na2O glass (12.5% mol Na2O)

1 kHz

0.0005

134.5˚C

B2O3-Na2O glass (15% mol Na2O)

1 kHz

0.0015

157˚C

B2O3-Na2O glass (20% mol Na2O)

1 kHz

0.0149

157˚C

B2O3-Na2O glass (25% mol Na2O)

1 kHz

0.1080









Source: data compiled by J.S. Park from O. V. Mazurin, M. V. Streltsina and T. P. ShvaikoShvaikovskaya, Handbook of Glass Data, Part A and Part B, Elsevier, New York, 1983.

©2001 CRC Press LLC

Table 440. SELECTING TANGENT LOSS IN GLASS BY

TEMPERATURE (SHEET 4 OF 5)





Frequency

Tangent Loss

Temperature

Glass

(Ηz)

(tan δ)

















200˚C

SiO2 glass

10 kHz

0.00004

200˚C

SiO2 glass

1 kHz

0.00012

200˚C

B2O3 glass

1 MHz

0.0005

200˚C

SiO2 glass

100 Hz

0.00052

200˚C

SiO2 glass

9.4 GHz

0.0018

200˚C

B2O3-CaO glass (33.3% mol CaO)

2 MHz

0.0025

214˚C

B2O3-Na2O glass (10% mol Na2O)

1 kHz

0.0009

214˚C

B2O3-Na2O glass (12.5% mol Na2O)

1 kHz

0.0022

214˚C

B2O3-Na2O glass (15% mol Na2O)

1 kHz

0.0064

219˚C

B2O3-Na2O glass (20% mol Na2O)

1 kHz

0.0890

274˚C

B2O3-Na2O glass (20% mol Na2O)

1 kHz

0.2480

277˚C

B2O3-Na2O glass (10% mol Na2O)

1 kHz

0.0038

277˚C

B2O3-Na2O glass (12.5% mol Na2O)

1 kHz

0.0100

277˚C

B2O3-Na2O glass (15% mol Na2O)

1 kHz

0.0296

298˚C

B2O3-Na2O glass (10% mol Na2O)

1 kHz

0.0066

298˚C

B2O3-Na2O glass (12.5% mol Na2O)

1 kHz

0.0170

298˚C

B2O3-Na2O glass (15% mol Na2O)

1 kHz

0.0477

300˚C

SiO2 glass

10 kHz

0.00072

300˚C

B2O3 glass

1 MHz

0.0009

300˚C

B2O3-CaO glass (33.3% mol CaO)

2 MHz

0.0035

300˚C

SiO2 glass

1 kHz

0.0072

300˚C

SiO2 glass

100 Hz

0.080









Source: data compiled by J.S. Park from O. V. Mazurin, M. V. Streltsina and T. P. ShvaikoShvaikovskaya, Handbook of Glass Data, Part A and Part B, Elsevier, New York, 1983.

©2001 CRC Press LLC

Table 440. SELECTING TANGENT LOSS IN GLASS BY

TEMPERATURE (SHEET 5 OF 5)





Frequency

Tangent Loss

Temperature

Glass

(Ηz)

(tan δ)

















323˚C

B2O3 glass

32 kHz

0.00005

373˚C

B2O3 glass

32 kHz

0.00011

373˚C

SiO2-Al2O3 glass (0.5% mol Al2O3)

100 K

0.0021

323˚C

SiO2-Al2O3 glass (0.5% mol Al2O3)

50 K

0.0025

400˚C

SiO2 glass

9.4 GHz

0.002

400˚C

B2O3-CaO glass (33.3% mol CaO)

2 MHz

0.0045

400˚C

SiO2 glass

10 kHz

0.022

400˚C

SiO2 glass

1 kHz

0.2

400˚C

SiO2 glass

100 Hz

1.0

423˚C

SiO2-Al2O3 glass (0.5% mol Al2O3)

150 K

0.0026

423˚C

B2O3 glass

32 kHz

0.0007

473˚C

B2O3 glass

32 kHz

0.0010

500˚C

B2O3-CaO glass (33.3% mol CaO)

2 MHz

0.0055

523˚C

B2O3 glass

32 kHz

0.0008

550˚C

B2O3-CaO glass (33.3% mol CaO)

2 MHz

0.007

573˚C

B2O3 glass

32 kHz

0.0003

600˚C

SiO2 glass

9.4 GHz

0.0029

800˚C

SiO2 glass

9.4 GHz

0.0048

1000˚C

SiO2 glass

9.4 GHz

0.011

1200˚C

SiO2 glass

9.4 GHz

0.025

1400˚C

SiO2 glass

9.4 GHz

0.046









Source: data compiled by J.S. Park from O. V. Mazurin, M. V. Streltsina and T. P. ShvaikoShvaikovskaya, Handbook of Glass Data, Part A and Part B, Elsevier, New York, 1983.

©2001 CRC Press LLC

Table 441. SELECTING TANGENT LOSS IN GLASS BY FREQUENCY

(SHEET 1 OF 5)

Frequency





Tangent Loss

(Ηz)

Glass

Temperature

(tan δ)

















100 Hz

SiO2 glass

25˚C

0.00002

100 Hz

SiO2 glass

200˚C

0.00052

100 Hz

SiO2 glass

300˚C

0.080

100 Hz

SiO2 glass

400˚C

1.0

1 kHz

SiO2 glass

25˚C

0.00002

1 kHz

SiO2 glass

200˚C

0.00012

1 kHz

B2O3-Na2O glass (10% mol Na2O)

134.5˚C

0.0003

1 kHz

B2O3-Na2O glass (12.5% mol Na2O)

134.5˚C

0.0005

1 kHz

B2O3-Na2O glass (10% mol Na2O)

214˚C

0.0009

1 kHz

B2O3-Na2O glass (20% mol Na2O)

16˚C

0.0009

1 kHz

B2O3-Na2O glass (15% mol Na2O)

134.5˚C

0.0015

1 kHz

B2O3-Na2O glass (12.5% mol Na2O)

214˚C

0.0022

1 kHz

B2O3-Na2O glass (25% mol Na2O)

16˚C

0.0022

1 kHz

B2O3-Na2O glass (20% mol Na2O)

90.5˚C

0.0026

1 kHz

B2O3-Na2O glass (10% mol Na2O)

277˚C

0.0038

1 kHz

B2O3-Na2O glass (15% mol Na2O)

214˚C

0.0064

1 kHz

B2O3-Na2O glass (10% mol Na2O)

298˚C

0.0066

1 kHz

SiO2 glass

300˚C

0.0072

1 kHz

B2O3-Na2O glass (12.5% mol Na2O)

277˚C

0.0100

1 kHz

B2O3-Na2O glass (20% mol Na2O)

157˚C

0.0149

1 kHz

B2O3-Na2O glass (25% mol Na2O)

90.5˚C

0.0150

1 kHz

B2O3-Na2O glass (12.5% mol Na2O)

298˚C

0.0170

1 kHz

B2O3-Na2O glass (15% mol Na2O)

277˚C

0.0296

1 kHz

B2O3-Na2O glass (15% mol Na2O)

298˚C

0.0477









Source: data compiled by J.S. Park from O. V. Mazurin, M. V. Streltsina and T. P. ShvaikoShvaikovskaya, Handbook of Glass Data, Part A and Part B, Elsevier, New York, 1983.

©2001 CRC Press LLC

Table 441. SELECTING TANGENT LOSS IN GLASS BY FREQUENCY

(SHEET 2 OF 5)

Frequency





Tangent Loss

(Ηz)

Glass

Temperature

(tan δ)

















1 kHz

B2O3-Na2O glass (20% mol Na2O)

219˚C

0.0890

1 kHz

SiO2-Na2O glass (34.3% mol Na2O)

room temp.

0.10324

1 kHz

B2O3-Na2O glass (25% mol Na2O)

157˚C

0.1080

1 kHz

SiO2-Na2O glass (19.5% mol Na2O)

room temp.

0.144

1 kHz

SiO2 glass

400˚C

0.2

1 kHz

SiO2-Na2O glass (24.4% mol Na2O)

room temp.

0.2207

1 kHz

B2O3-Na2O glass (20% mol Na2O)

274˚C

0.2480

1 kHz

SiO2-Na2O glass (29.4% mol Na2O)

room temp.

0.4923

3 kHz

SiO2-Na2O glass (19.5% mol Na2O)

room temp.

0.0984

3 kHz

SiO2-Na2O glass (24.4% mol Na2O)

room temp.

0.1455

3 kHz

SiO2-Na2O glass (29.4% mol Na2O)

room temp.

0.3027

3 kHz

SiO2-Na2O glass (34.3% mol Na2O)

room temp.

0.6520

5 kHz

SiO2-Na2O glass (19.5% mol Na2O)

room temp.

0.0832

5 kHz

SiO2-Na2O glass (24.4% mol Na2O)

room temp.

0.1194

5 kHz

SiO2-Na2O glass (29.4% mol Na2O)

room temp.

0.2426

5 kHz

SiO2-Na2O glass (34.3% mol Na2O)

room temp.

0.5280

10 kHz

SiO2 glass

25˚C

0.00002

10 kHz

SiO2 glass

200˚C

0.00004

10 kHz

SiO2 glass

300˚C

0.00072

10 kHz

SiO2 glass

400˚C

0.022

10 kHz

SiO2-Na2O glass (19.5% mol Na2O)

room temp.

0.0656

10 kHz

SiO2-Na2O glass (24.4% mol Na2O)

room temp.

0.0916

10 kHz

SiO2-Na2O glass (29.4% mol Na2O)

room temp.

0.1764

10 kHz

SiO2-Na2O glass (34.3% mol Na2O)

room temp.

0.3752

10 kHz

SiO2-Na2O glass (39.3% mol Na2O)

room temp.

0.6338









Source: data compiled by J.S. Park from O. V. Mazurin, M. V. Streltsina and T. P. ShvaikoShvaikovskaya, Handbook of Glass Data, Part A and Part B, Elsevier, New York, 1983.

©2001 CRC Press LLC

Table 441. SELECTING TANGENT LOSS IN GLASS BY FREQUENCY

(SHEET 3 OF 5)

Frequency





Tangent Loss

(Ηz)

Glass

Temperature

(tan δ)

















30 kHz

SiO2-Na2O glass (19.5% mol Na2O)

room temp.

0.0492

30 kHz

SiO2-Na2O glass (24.4% mol Na2O)

room temp.

0.0652

30 kHz

SiO2-Na2O glass (29.4% mol Na2O)

room temp.

0.1172

30 kHz

SiO2-Na2O glass (34.3% mol Na2O)

room temp.

0.2314

30 kHz

SiO2-Na2O glass (39.3% mol Na2O)

room temp.

0.3835

32 kHz

B2O3 glass

50K

0.00005

32 kHz

B2O3 glass

100K

0.00011

32 kHz

B2O3 glass

300K

0.0003

32 kHz

B2O3 glass

150K

0.0007

32 kHz

B2O3 glass

250K

0.0008

32 kHz

B2O3 glass

200K

0.0010

50 kHz

SiO2-Na2O glass (19.5% mol Na2O)

room temp.

0.0428

50 kHz

SiO2-Na2O glass (24.4% mol Na2O)

room temp.

0.0563

50 kHz

SiO2-Na2O glass (29.4% mol Na2O)

room temp.

0.0972

50 kHz

SiO2-Na2O glass (34.3% mol Na2O)

room temp.

0.1864

50 kHz

SiO2-Na2O glass (39.3% mol Na2O)

room temp.

0.3032

100 kHz

SiO2-Na2O glass (19.5% mol Na2O)

room temp.

0.0364

100 kHz

SiO2-Na2O glass (24.4% mol Na2O)

room temp.

0.0456

100 kHz

SiO2-Na2O glass (29.4% mol Na2O)

room temp.

0.0758

100 kHz

SiO2-Na2O glass (34.3% mol Na2O)

room temp.

0.1388

100 kHz

SiO2-Na2O glass (39.3% mol Na2O)

room temp.

0.2144

300 kHz

SiO2-Na2O glass (19.5% mol Na2O)

room temp.

0.0295

300 kHz

SiO2-Na2O glass (24.4% mol Na2O)

room temp.

0.0369

300 kHz

SiO2-Na2O glass (29.4% mol Na2O)

room temp.

0.0568









Source: data compiled by J.S. Park from O. V. Mazurin, M. V. Streltsina and T. P. ShvaikoShvaikovskaya, Handbook of Glass Data, Part A and Part B, Elsevier, New York, 1983.

©2001 CRC Press LLC

Table 441. SELECTING TANGENT LOSS IN GLASS BY FREQUENCY

(SHEET 4 OF 5)

Frequency





Tangent Loss

(Ηz)

Glass

Temperature

(tan δ)

















300 kHz

SiO2-Na2O glass (34.3% mol Na2O)

room temp.

0.0936

300 kHz

SiO2-Na2O glass (39.3% mol Na2O)

room temp.

0.1402

1 MHz

B2O3 glass

100˚C

0.0004

1 MHz

B2O3 glass

200˚C

0.0005

1 MHz

B2O3 glass

300˚C

0.0009

1 MHz

B2O3-Na2O glass (10% mol Na2O)

room temp.

0.0022

1 MHz

B2O3-Na2O glass (8% mol Na2O)

room temp.

0.0025

1 MHz

B2O3-Na2O glass (16% mol Na2O)

room temp.

0.0031

1 MHz

B2O3-Na2O glass (25% mol Na2O)

room temp.

0.0063

1 MHz

B2O3-Na2O glass (28% mol Na2O)

room temp.

0.0081

2 MHz

B2O3-CaO glass (33.3% mol CaO)

25˚C

0.001

2 MHz

B2O3-CaO glass (33.3% mol CaO)

100˚C

0.002

2 MHz

B2O3-CaO glass (33.3% mol CaO)

200˚C

0.0025

2 MHz

B2O3-CaO glass (33.3% mol CaO)

300˚C

0.0035

2 MHz

B2O3-CaO glass (33.3% mol CaO)

400˚C

0.0045

2 MHz

B2O3-CaO glass (33.3% mol CaO)

500˚C

0.0055

2 MHz

B2O3-CaO glass (33.3% mol CaO)

550˚C

0.007

4.5x108 Hz

SiO2-Na2O glass (16% mol Na2O)

20˚C

0.0058

4.5x108 Hz

SiO2-Na2O glass (20% mol Na2O)

20˚C

0.0073

4.5x108 Hz

SiO2-Na2O glass (22.2% mol Na2O)

20˚C

0.0081

4.5x108 Hz

SiO2-Na2O glass (28.6% mol Na2O)

20˚C

0.0102

4.5x108 Hz

SiO2-Na2O glass (36% mol Na2O)

20˚C

0.0162









Source: data compiled by J.S. Park from O. V. Mazurin, M. V. Streltsina and T. P. ShvaikoShvaikovskaya, Handbook of Glass Data, Part A and Part B, Elsevier, New York, 1983.

©2001 CRC Press LLC

Table 441. SELECTING TANGENT LOSS IN GLASS BY FREQUENCY

(SHEET 5 OF 5)

Frequency





Tangent Loss

(Ηz)

Glass

Temperature

(tan δ)

















9.4 GHz

SiO2 glass

20˚C

0.0015

9.4 GHz

SiO2 glass

200˚C

0.0018

9.4 GHz

SiO2 glass

400˚C

0.002

9.4 GHz

SiO2 glass

600˚C

0.0029

9.4 GHz

SiO2 glass

800˚C

0.0048

9.4 GHz

SiO2 glass

1000˚C

0.011

9.4 GHz

SiO2 glass

1200˚C

0.025

9.4 GHz

SiO2 glass

1400˚C

0.046

10 GHz

SiO2-B2O3 glass (46.3% mol B2O3)



0.0014

32 GHz

SiO2-PbO glass (40% mol PbO)

-150˚C

0.015

32 GHz

SiO2-PbO glass (40% mol PbO)

-100˚C

0.018

32 GHz

SiO2-PbO glass (40% mol PbO)

-50˚C

0.020

32 GHz

SiO2-PbO glass (40% mol PbO)

0˚C

0.022

32 GHz

SiO2-PbO glass (40% mol PbO)

50˚C

0.024

100 GHz

SiO2-PbO glass (40% mol PbO)

room temp.

0.005

1000 GHz

SiO2-PbO glass (40% mol PbO)

room temp.

0.050









Source: data compiled by J.S. Park from O. V. Mazurin, M. V. Streltsina and T. P. ShvaikoShvaikovskaya, Handbook of Glass Data, Part A and Part B, Elsevier, New York, 1983.
