eret Save the descriptor on the top of the stack. Unwind the C stack. Remove the current expression frame from the stack and push the saved descriptor.
escan Dereference the top descriptor on the stack if necessary. Copy it to the place on the stack prior to the saved values of &subject and &pos (see bscan). Exchange the current values of &subject and &pos with the saved values on the stack. Then suspend. If resumed, restore the values of &subject and &pos from the stack and fail.
esusp Create a generator frame containing a copy of the portion of the stack that is needed if the generator is resumed.
field n Replace the record descriptor on the top of the stack by a descriptor for field n of that record.
global n Push a variable descriptor pointing to global identifier n. goto n Set ipc to n.
init n Change init instruction to goto. int n Push a descriptor for the integer n. inter expr1 ** exp'2
invoke n exp1lJ(expr1, exp'2, ..., exprn) keywd n Push a descriptor for keyword n. lconcat expr1 ||| expr2
lexeq expr1 == expr2 lexge expr1 »= expr2 lexgt expr1 » expr2 lexle expr1 «= expr2 lexlt expr1 « expr2 lexne expr1 == expr2
limit Convert the descriptor on the top of the stack to an integer. If the conversion cannot be performed or if the result is negative, terminate execution with an error message. If it is zero, fail. Otherwise, create an expression frame with a zero failure ipc.
line n Set the current line number to n. llist n [expr1,expr2,...,exprn]
local n Push a variable descriptor pointing to local identifier n.
lsusp Decrement the current limitation counter, which is immediately prior to the current expression frame on the stack. If the limit counter is nonzero, create a generator frame containing a copy of the portion of the interpreter stack that is needed if the generator is resumed. If the limitation counter is zero, unwind the C stack and remove the current expression frame from the stack.
366
mark Create an expression frame whose marker contains the failure ipc corresponding to the label n, the current efp, gfp, and ilevel.
mark0 Create an expression frame with a zero failure ipc. minus expr1 expr2
mod expr1 % expr2 mult expr1 * expr2 neg expr
neqv exprl === expr2
nonnull \expr |
|
null /expr |
|
number |
+expr . |
numeq expr1 = expr2 numge exprl >= expr2 numgt expr1 > expr2 numle exprl <= expr2 numlt exprl < expr2 numne exprl = expr2
pfail |
If &trace is nonzero, decrement it and produce a trace message. Unwind the C |
stack and remove the current procedure frame from the stack. Then fail. |
|
plus |
exprl + expr2 |
pnull |
Push a null descriptor. |
pop |
Pop the top descriptor. |
power |
exprl ~ expr2 |
pret |
Dereference the descriptor on the top of the stack, if necessary, and copy it to the |
place where the descriptor for the procedure is. If &trace is nonzero; decrement it and produce a trace message. Unwind the C stack and remove the current procedure frame from the stack.
psusp Copy the descriptor on the top of the stack to the place where the descriptor for the procedure is, dereferencing it if necessary. Produce a trace message and decrement &trace if it is nonzero. Create a generator frame containing a copy of the portion of the stack that is needed if the procedure call is resumed.
push1 Push a descriptor for the integer 1. pushn1Push a descriptor for the integer 1. quit Exit from the interpreter.
random ?expr
|
|
367 |
rasgn |
expr1 < expr2 |
|
real a |
Push a descriptor for the real number block at address a onto the stack. |
|
refresh ~expr |
|
|
rswap |
expr1 <> expr2 |
|
sdup |
Push a copy of the descriptor on the top of the stackr |
|
sect |
expr1 [ expr2: expr3 ] |
|
size |
*expr |
|
static n Push a variable descriptor pointing to static identifier n. |
||
str n, a Push a descriptor for the string of length n at address a. |
||
subsc expr1[expr2] |
||
swap |
expr1 :=: exp12 |
|
tabmat =exp' |
|
|
toby |
expr1 to expr2 by expr3 |
|
unions expr1 ++ expr2 |
||
unmark |
Remove the current expression frame from the stack and unwind the C |
|
stack. |
|
|
value |
|
.expr |

368
Appendix C: Virtual Machine Code
The virtual machine code that is generated for various kinds of Icon expression is listed below. The form of code given is icode, the output of the Icon linker cast in a readable format. The ucode produced' by the Icon translator, which serves as input to the Icon linker, is slightly different in some cases, since th linker performs some refinements.
C.1 Identifiers
As mentioned in Sec. 8.2.2, the four kinds of identifiers are distinguished by where their values are located. All are referred to by indices, which are zero based.
The values of global identifiers are kept in an array that is loaded from thl icode file and is at a fixed place in memory during program execution. By con vention, the zeroth global identifier contains the procedure descriptor for main The following instruction pushes a variable pointing to the value of main onto the interpreter stack:
main |
global |
0 |
|
|
|
Static identifiers are essentially global identifiers that are only known on a perprocedure basis. Like global identifiers, the values of static identifiers are in an array that is at a fixed location. Static identifiers are numbered starting at zero and continuing through the program. For example, if count is static identifier 10 the following instruction pushes a variable descriptor pointing to that static identifier onto the stack:
count |
static |
10 |
|
|
|
The space for the values of arguments and local identifiers is allocated on the stack when the procedure in which they occur is called. If x is argument zero and i is local zero for the current procedure, the following instructions push variable descriptors for them onto the stack:
x |
arg |
0 |
|
|
|
|
|
|
i |
local |
0 |
|
|
|
C.2 Literals
The virtual machine instruction generated for an integer literal pushes the integer onto the stack as an Icon descriptor. The value of the integer is the argument to the instruction:
100 |
int |
100 |
|
|
|
The instruction generated for a string literal is similar to that for an integer literal, except that the address of the string and its length are given as arguments. The string itself is in a region of data produced by the linker and is loaded as part of the icode file:
"hello" |
str |
5,a1 |
|
|
|
The instruction generated for a real or cset literal has an argument that is the address of a data block for the corresponding value. Such blocks are in the data region generated by the linker:
369
100.2 |
real |
a2 |
|
|
|
|
|
|
'aeiou' |
cset |
a3 |
|
|
|
C.3 Keywords
The instruction generated for most keywords results in a call to a C function that pushes a descriptor for the keyword onto the stack. The argument is an index that identifies the keyword. For example, &date is keyword 4:
&date |
keywd |
4 |
|
|
|
Some keywords correspond directly to virtual machine instructions. Examples are &null and &fail:
&null |
pnull |
|
|
|
|
&fail |
efail |
|
|
C.4 Operators
The code generated for a unary operator first pushes a null descriptor, then evaluates the code for the argument, and finally executes a virtual machine instruction that is specific to the operator:
*expr |
pnull |
|
code for expr |
|
size |
|
|
The code generated for a binary operator is the same as the code generated for a unary operator, except that there are two arguments:
expr1 + expr2 |
pnull |
|
code for expr1 |
|
code for expr2 |
|
plus |
|
|
An augmented assignment operator uses the virtual machine instruction dup to duplicate the result produced by its first argument:
expr1 +:= expr2 |
pnull |
|
code for expr1 |
|
dup |
|
code for expr2 |
|
plus |
|
asgn |
|
|
The difference between the code generated for left and rightassociative operators is illustrated by the following examples:
370
expr1 + expr2 + expr3 |
pnull |
|
pnull |
|
code for expr1 |
|
code for expr2 |
|
plus |
|
code for expr3 |
|
plus |
|
|
expr1 := expr2 := expr3 |
pnull |
|
code for expr1 |
|
pnull |
|
code for expr2 |
|
code for expr3 |
|
asgn |
|
asgn |
|
|
A subscripting expression is simply a binary operator with a distinguished syntax:
|
expr1 [ expr2 ] |
|
pnull |
|
|
|
code for expr1 |
|
|
|
code for expr2 |
|
|
|
subsc |
|
|
|
|
A sectioning expression is a ternary operator: |
|
||
|
|
|
|
|
expr1 [ expr2 : expr3 ] |
|
pnull |
|
|
|
code for expr1 |
|
|
|
code for expr2 |
|
|
|
code for expr3 |
|
|
|
sect |
|
|
|
|
Sectioning expressions with relative range specifications are simply abbreviations. The virtual machine instructions for them include the instructions for performing the necessary arithmetic:
expr1 [ expr2 +: expr3 ] |
pnull |
|
code for expr1 |
|
code for expr2 |
|
dup |
|
code for expr3 |
|
plus |
|
sect |
|
|
A toby expression is another ternary operator with a distinguished syntax:
expr1 to expr2 by expr3 |
pnull |
|
code for expr1 |
|
code for expr2 |
|
code for expr3 |
|
toby |
|
|
371
If the by clause is omitted, an instruction that pushes a descriptor for the integer is supplied:
expr1 to expr2 |
pnull |
|
code for expr1 |
|
code for expr2 |
|
push1 |
|
toby |
|
|
The code generated for an explicit list is similar to the code generated for an operator. The instruction that constructs the list has an argument that indicates the number of elements in the list:
[expr1, expr2, expr3] |
pnull |
|
code for expr1 |
|
code for expr2 |
|
code for expr3 |
|
llist |
|
|
C.5 Calls
The code generated for a call also is similar to the code generated for an operator except that a null descriptor is not pushed (it is provided by the invoke instruction). The argument of invoke is the number of arguments present in the call, not counting the zeroth argument, whose value is the procedure or integer that is applied to the arguments:
expr0(expr1, expr2) |
code for expr0 |
|
|
code for expr1 |
|
|
code for expr2 |
|
|
invoke |
2 |
|
|
|
In a mutual evaluation expression in which the zeroth argument of the "call" is omitted, the default value is 1, for which an instruction is provided:
(expr1, expr2, expr3) |
pushn1 |
|
|
code for expr1 |
|
|
code for expr2 |
|
|
code for expr3 |
|
|
invoke |
3 |
|
|
|
C.6 Compound Expressions and Conjunction
The difference between a compound expression and a conjunction expression is illustrated by the following examples. Note that the code generated for conjunction is considerably simpler than that generated for a compound expression, since no separate expression frames are needed:

372
{expr1; expr2; expr3} |
mark |
L1 |
|
code for expr1 |
|
|
unmark |
|
|
L1: |
|
|
mark |
L2 |
|
code for expr2 |
|
|
unmark |
|
|
L2: |
|
|
code for expr3 |
|
|
|
|
expr1 & expr2 & expr3 |
code for expr1 |
|
pop |
|
code for expr2 |
|
pop |
|
code for expr3 |
|
|
C.7 Selection Expressions
In the code generated for an ifthenelse expression, the control expression bounded and has an expression frame of its own:
if expr1 then expr2 |
mark |
L1 |
else expr3 |
code for expr1 |
|
|
unmark |
|
|
code for expr2 |
|
|
goto |
L2 |
|
L1: |
|
code for expr3
L2:
If the else clause is omitted, mark0 is used, so that if the control expression fails, this failure is transmitted to the enclosing expression frame:
if expr1 then expr2 |
mark0 |
|
code for expr1 |
|
unmark |
|
code for expr2 |
|
|
The code generated for a case expression is relatively complicated. As for similar control structures, the control expression is bounded. The result it produces is placed on the top of the stack by the eret instruction, which saves the result of evaluating expr1, removes the current expression frame, and then push the saved result on the top of the stack. The ccase instruction pushes a null descriptor onto the stack and duplicates the descriptor just below the current efp on the top of the stack. This has the effect of providing a null descriptor and the first argument for the equivalence comparison operation performed by eqv. The second argument of eqv is provided by the code for the selector clause. The remainder of the code for a case clause removes the current expression frame marker. in case the comparison succeeds. and evaluates the selected expression:

373
case expr1 of { |
mark0 |
|
expr2 : expr3 |
code for expr1 |
|
expr4 : expr5 |
eret |
|
default: expr6 |
mark |
L2 |
} |
ccase |
|
|
code for expr2 |
|
|
eqv |
|
|
unmark |
|
|
pop |
|
|
code for expr3 |
|
|
goto |
L1 |
|
L2: |
|
mark L3 ccase
code for expr4 eqv
unmark pop
code for expr5 goto L1
L3:
pop
code for expr6
L1:
C.8 Negation
The not control structure fails if its argument succeeds but produces the null value if its argument fails:
not expr |
mark |
L1 |
|
code for expr |
|
|
unmark |
|
|
efail |
|
|
L1: |
|
|
pnull |
|
|
|
|
C.9 Generative Control Structures
If the first argument of an alternation expression produces a result, esusp produces a generator frame for possible resumption and duplicates the surrounding expression frame on the top of the stack. The result of the first argument is then pushed on the top of the stack, so that it looks as if the first argument merely produced a result. The second argument is then bypassed. When the first argument does not produce a result, its expression frame is removed, leaving the second argument to be evaluated:

374
expr1 | expr2 |
mark |
L1 |
|
code for expr1 |
|
|
esusp |
|
|
goto |
L2 |
|
L1: |
|
code for expr2
L2:
Since alternation is treated as a binary operation, a succession of alternations produces the following code:
expr1 | expr2 | expr3 |
mark |
L1 |
|
code for expr1 |
|
|
esusp |
|
|
goto |
L2 |
|
L1: |
|
|
mark |
L3 |
|
code for expr2 |
|
|
esusp |
|
|
goto |
L2 |
|
L2: |
|
code for expr3
L3:
Repeated alternation is complicated by the special treatment of the case in which its argument does not produce a result. If it does not produce a result, the failure is transmitted to the enclosing expression frame, since the failure ipc is 0. However, if it produces a result, the failure ipc is changed by chfail so that subsequent failure causes transfer to the beginning of the repeated alternation expression. The esusp instruction produces the same effect as that for regular alternation. Note that changing the failure ipc only affects the expression frame marker on the stack. When mark is executed again, a new expression frame marker with a failure ipc of 0 is created.
| expr |
L1: |
mark0
code for expr chfail L1 esusp
In the limitation control structure, the normal lefttoright order of evaluation is reversed and the limiting expression is evaluated first. The limit instruction checks that the value is an integer and pushes it. It then creates an expression frame marker with a zero failure ipc. Thus, the limit is always one descriptor below the expression marker created by the subsequent mark instruction. The lsusp instruction is similar to the esusp instruction, except that it checks the limit. If the limit is zero, it fails instead of suspending. Otherwise, the limit is decremented:
expr1 \ expr2 |
code for expr2 |
|
limit |
|
code for expr1 |
|
lsusp |
|
|
