Part II • Managing Data in C

The PC Communications Ports

The serial communications ports are more complex than the printer ports. First, they require more initialization because the speed (baud rate) and the format of the characters (number of bits) must be set. To make things easy, I have DOS initialize (in my AUTOEXEC.BAT file) all the communications ports to a known state.

Following are the addresses used by the PC communications ports. When a communications port is accessed, the first address used is referred to as the I/O base address. The communications port I/O address starts at 0x03F8 or 0x02F8 (COM1 and COM2) in most PCs. All addresses are accessed using input and output functions, either in C or assembler.

In the following discussion, the COM1 base I/O address of 0x3F8 is used. To access COM2, you must use the COM2 base I/O address of 0x2F8. To access a port other than COM1 or COM2, you must know the port’s base I/O address. The addresses for COM1 through COM4 are stored in the BIOS data page as follows:

COM1 0000:0400

COM2 0000:0402

COM3 0000:0404

COM4 0000:0406

The UART (Universal Asynchronous Receiver/Transmitter) is the part of the communications port that converts a byte of data to a serial data stream. The UART in the PC’s communications port has eight separate addresses. The following paragraphs and Table 9.5 describe each of these addresses.

Table 9.5. The serial board’s I/O port usage.

			Name in
Name	Address	Description	SENDCOMM.C	Bits

Receive	I/O base	Characters received	RBR_PORT 0–7	Eight bits of
buffer	address	may be retrieved		received data
	+ 0	from this I/O
		address. LCR_PORT
		bit 80 must be clear.

296

			Disk Files and Other I/O		C C C
					C9C
					C C C
					C

			Name in
Name	Address	Description	SENDCOMM.C	Bits

Divisor	I/O base	Used to set the baud	DLL_PORT 0–7	Divisor’s LSB
register	address	rate, which is deter-		(eight bits)
(LSB)	+ 0	mined using a 16-bit
		divisor.
		LCR_PORT bit
		80 must be set.
Transmit	I/O base	Characters to be	THR_PORT 0–7	Eight bits of
buffer	address	transmitted are		data to be
	+ 0	output to this I/O		transmitted
		address. LCR_PORT
		bit 80 must be clear.
Interrupt	I/O base	Enables the con-	IER_PORT 01	Received data
enable	address	ditions that cause the		available. A
register	+ 1	UART to generate an		character has
		interrupt to be gener-		been received.
		ated. When a specified
		bit is set and the con-
		dition occurs, an inter-
		rupt is generated.
			02	Transmit
				holding register
				is empty. The
				character that
				was being sent
				has completed.
				A new character
				can now be
				sent.
			04	Receive line status.
				The receive line has
				changed.
			08	MODEM status.
				The modem status
				line has changed.
			10	Not used

continues

297

Part II • Managing Data in C

Table 9.5. continued

			Name in
Name	Address	Description	SENDCOMM.C	Bits

			20	Not used
			40	Not used
			80	Not used
Divisor	I/O base	Used to set the baud	DLM_PORT 0–7	Divisor’s MSB
register	address	rate, which is deter-		(eight bits)
(MSB)	+ 1	mined using a 16-bit
		divisor. LCR_PORT
		bit 80 must be set.
Interrupt	I/O base	Tells the program	IIR_PORT 01	If clear, an
identifier	address	what condition caused		interrupt is
register	+ 2	the interrupt.		pending
			02	Interrupt ID, bit 0
			04	Interrupt ID, bit 1
			08	Not used
			10	Not used
			20	Not used
			40	Not used
			80	Not used
Line	I/O base	Controls the format	LCR_PORT 01	Word length,
control	address	of the characters be-		bit 0
register	+ 3	ing transmitted, in-
		cluding the number
		of bits, the number of
		stop bits, and the
		parity. The divisor
		latch (see the divi-
		sor register) is also
		located at this
		address, bit 80.
			02	Word length, bit 1
			04	Stop bits (clear = 1,
				set = 2)
			08	Parity enable

298

			Disk Files and Other I/O		C C C
					C9C
					C C C
					C

			Name in
Name	Address	Description	SENDCOMM.C	Bits

			10	Even parity
			20	Stick parity
			40	Set break
			80	Enable divisor
				latches
MODEM	I/O base	Sets the output control	MCR_PORT 01	DTR
control	address	lines.	02	RTS
register	+ 4		04	OUT1
			08	OUT2
			10	Loop back
			20	Not used
			40	Not used
			80	Not used
Line status	I/O base	Status of various	LSR_PORT 01	Data has been
register	address + 5	parameters.		received.
			02	Overrun error. The
				previous character
				received was not
				read by the
				computer and has
				been overwritten
				by the following
				character.
			04	Parity error. There
				was a parity error
				in the character
				being received.
			08	Framing error. The
				start/stop bits could
				not be detected
				correctly.
			10	Break interrupt. A
				break has been
				detected.
			20	Transmit buffer
				empty

continues

299

Part II • Managing Data in C

Table 9.5. continued

			Name in
Name	Address	Description	SENDCOMM.C	Bits

			40	Transmit shift
				register is empty.
				The output shift
				register is currently
				empty.
			80	Not used
MODEM	I/O base	Status of MODEM	MSR_PORT 01	DCTS
status	address + 6	signal lines.	02	DDSR
register			04	TERI
			08	DDCD
			10	CTS
			20	DSR
			40	RI (ring indicator)
			80	DCD

The receive buffer is located at base address + 0. The functionality of base address + 0 is controlled by bit 0x80 of LCR_PORT. If this bit is clear (zero), base address + 0 is used as the receive buffer.

The baud rate divisor register (LSB) is also located at base address + 0. The functionality of base address + 0 is controlled by bit 0x80 of LCR_PORT. If this bit is set, base address + 0 is used as the divisor register (LSB).

The transmit buffer is located at base address + 0. The functionality of base address + 1 is controlled by bit 0x80 of LCR_PORT. If this bit is clear (zero), base address + 1 is used as the interrupt enable register.

The baud rate divisor register (MSB) is also located at base address + 1. The functionality of base address + 1 is controlled by bit 0x80 of LCR_PORT. If this bit is set, base address + 1 is used as the divisor register (MSB).

The interrupt enable register is located at base address + 1. Only the first four bits are used in this register.

The interrupt identifier register is located at base address + 2. It is used to tell the program what condition caused the interrupt.

300

Disk Files and Other I/O	C C C
	C9C
	C C C
	C

The line control register is located at base address + 3. This register controls the character format and the mapping of the divisor latch (see offset +0 and +1).

The modem control register is located at base address + 4. This register is used to control the port’s I/O connector control signals. These signals are then used to control the modem (or whatever else is connected to the port).

The line status register is located at base address + 5. It is used to pass to the program information regarding the status of the UART and the data being received.

The MODEM status register is located at base address + 6. The program uses this register to determine the status of the device connected to the port.

Note how the DLL and DLM registers (the speed registers) have the same address as the RBR and IER registers. This is accomplished with the divisor latch enable bit (0x80) of the LCR register. If this bit is set, these registers are used for the speed divisor. If this bit is cleared, these registers serve their other purpose.

A communications program can rely on the DOS MODE command setting the communications port parameters, or the program can set the parameters itself. Each of the port’s registers may be read (except transmitted data), modified, and written back. This process of reading, modifying, and writing a register is all that is required to initialize the serial port.

Listing 9.8, SENDCOMM.C, sends a single string, followed by a LF/CR character pair, to COM1:. Before you run SENDCOMM.C, COM1: must be initialized with the DOS MODE command.

Listing 9.8. SENDCOMM.C.

/* SENDCOMM, written 1992 by Peter D. Hipson

*This program outputs to the serial port. You should

*run this program under DOS on a PC. If your computer

*is not a PC-compatible, DO NOT RUN this program. Also,

*the program should be compiled with Microsoft C.

*/
#include <stdio.h>	// Make includes first part of file
#include <conio.h>	//	Console I/O functions
#include <string.h>	//	For string functions

continues

301

Part II • Managing Data in C

Listing 9.8. continued

#include <stdlib.h>		// Standard include items
#include	<process.h>	//	For exit(), etc.
#include	<time.h>	//	To seed random numbers

#define MAKELONG(low, high) ((long)(((unsigned short int)(low)) \
\| (((unsigned long int)((unsigned short int)(high))) << 16)))
#define MAKELP(sel, off)	((void _far*)MAKELONG((off), (sel)))
/* Comm port definitions */
#define BIOS_DATA_PAGE		0x0040
#define COM1		0x0000
/* Receive a character port (read only) */
#define RBR_PORT		(nPort)
/* Send (transmit) a character port (write only) */
#define THR_PORT		(nPort)
/* Interrupt enable register */
#define IER_PORT		(nPort + 1)
#define RECEIVED_DATA_AVAILABLE		0x01
#define TRANSMIT_HOLD_EMPTY		0x02
#define RECIEVER_LINE_STATUS		0x04
#define MODEM_STATUS		0x08
/* Other bits undefined */
/* Interrupt identify register (read only) */
#define IIR_PORT		(nPort + 2)
#define INTERUPT_PENDING_0		0x01
#define INTERUPT_ID_BIT_1		0x02
#define INTERUPT_ID_BIT_2		0x04
/* Other bits undefined */
/* Line control register */
#define LCR_PORT		(nPort + 3)
#define WORD_LENGTH_SELECT_1		0x01	/* 00 = 5 bits, 01 = 6 bits */
#define WORD_LENGTH_SELECT_2		0x02	/* 10 = 7 bits, 11 = 8 bits	*/
#define NUMBER_STOP_BITS		0x04	/* 0 = 1 stop, 1 = 2 stop	*/
#define PARITY_ENABLE		0x08
#define EVEN_PARITY_SELECT		0x10

302

Disk Files and Other I/O

#define STICK_PARITY	0x20
#define SET_BREAK	0x40
#define DIVISOR_LATCH_BIT	0x80	/* For DLL and DLH access */
/* Other bits undefined */
/* Modem control register */
#define MCR_PORT	(nPort + 4)
#define DTR	0x01
#define RTS	0x02
#define OUT_1	0x04
#define OUT_2	0x08
#define LOOP	0x10
/* Other bits undefined */
/* Line status register */
#define LSR_PORT	(nPort + 5)
#define DATA_READY	0x01
#define OVERRUN_ERROR	0x02
#define PARITY_ERROR	0x04
#define FRAMING_ERROR	0x08
#define BREAK_INTERUPT	0x10
#define TRANS_HOLDING_REGISTER	0x20
#define TRANS_SHIFT_REGISTER	0x40
/* Other bits undefined */
/* Modem status register */
#define MSR_PORT	(nPort + 6)
#define DCTS	0x01
#define DDSR	0x02
#define TERI	0x04
#define DDCD	0x08
#define CTS	0x10
#define DSR	0x20
#define RI	0x40
#define DCD	0x80

C C C

C9C C

C C C

/* Divisor latch least significant (sets speed) */ #define DLL_PORT (nPort + 0)

/* Bits 0 - 7 */

continues

303

Part II • Managing Data in C

Listing 9.8. continued

/* Divisor latch most significant (sets speed) */ #define DLM_PORT (nPort + 1)

/* Bits 8 - 15 */

#define BAUD_50	0x0900
#define BAUD_75	0x0600
#define BAUD_110	0x0417
#define BAUD_134	0x0359
#define BAUD_150	0x0300
#define BAUD_300	0x0180
#define BAUD_600	0x00C0
#define BAUD_1200	0x0060
#define BAUD_1800	0x0040
#define BAUD_2000	0x003A
#define BAUD_2400	0x0030
#define BAUD_3600	0x0020
#define BAUD_4800	0x0018
#define BAUD_7200	0x0010
#define BAUD_9600	0x000C
#define BAUD_14400	0x0008
#define BAUD_19200	0x0006
#define BAUD_38400	0x0003
#define BAUD_56000	0x0002
#define BAUD_112000	0x0001

/* End serial port definitions */

int main(	// Define main() and the fact that this
int	argc, // program uses the passed parameters
char	*argv[],
char	*envp[]
);

int SerialCharacter(char chChar);

int	SerialStatus(void);
int	main(
	int	argc,
	char	*argv[],

304

Disk Files and Other I/O

char	*envp[]
)
{
char	szNowIsTheTime[] = {
“Now is the time for all good men to come to the aid...\n\r”};
int	nStatus;
int	i;

if (!SerialStatus())

{

printf(“There was a serial error!\n”); exit(4);

}

for (i = 0; i < strlen(szNowIsTheTime); i++)

{

if (SerialCharacter(szNowIsTheTime[i]) == 0)

{

printf(“\nCouldn’t send from character ‘%s’\n”, &szNowIsTheTime[i]);

	break;
	}
}
return (0);
}
int	SerialCharacter(
char	chChar)
{
int _far	*pSerialPort;
int	nPort;

C C C

C9C C

C C C

continues

305
