LCN Indentured Item

EIAC

LSA Control Number (LCN)

Alternate LCN Code

LCN - Type

XB

Transportation

JA

Transported End Item

Narrative

Transported End Item Narrative

Code

Transported End Item Narrative

Text sequencing Code

JD

Figure 15 J Table Relationships

DEF STAN 00-60 (PART 0)/3

ANNEX C (CONTINUED)

C.13.1 Table JA, Transportation. This Table identifies the transportation characteristics of the system/equipment under analysis. It describes what is required for the system/equipment to be transported. The Table keys consist of EIAC (EIACODXA), LCN (LSACONXB), ALC (ALTLCNXB), LCN Type (LCNTYPXB). For a given row of information, the following cross-element edits apply to Table JA :

(a)The transportability area may only be used if an item has been identified by a Sectionalized Item Transportation Indicator (SECITMXB) Table XB, or by a Transportation End Item Indicator (TRASEIXC) Table XC.

(b)If the system/equipment is being sectionalized for transportation, then Sectionalized Identification (SECTIDJA) shall be entered.

(c)If the system/equipment has environmental considerations, a ‘Y’ shall be entered in the Environmental Handling and Transportation Indicator (ENHATCJA).

C.13.2 Table JB, Transportation Mode. This Table identifies the different possible transportation modes for the system/equipment under analysis. This Table can identify the different types of aircraft and whether the aircraft will transport the item under analysis externally or internally. This Table can identify the different type of helicopters, their mission capabilities, and whether the helicopter will transport the item under analysis externally or internally. This Table can identify the road prime and alternate model types and what type of payload capacity the transporter has. This Table can identify the type of lighterages and whether the item under analysis can be stowed on deck. This Table can identify the type of rail system that will be used and which countries the rail system will run through for the item under analysis. This Table can identify the type of ships and whether the item under analysis can be stowed on deck. The Table keys consist of EIAC (EIACODXA), LCN (LSACONXB), ALC (ALTLCNXB), LCN Type (LCNTYPXB), Transportation Characteristic Number

C-109

DEF STAN 00-60 (PART 0)/3

ANNEX C (CONTINUED)

(TRANCNJB), and Transportation Mode Type (TRCHMTJB). For a given row of information, the following cross-element edits apply to Table JB :

(a)This Table can only be used if an ‘S’ or ‘B’ has been entered in the Transportation Indicator (TRNINDJA) Table JA.

(b)Transportation Item Designator (TRITDRJB) and External or Internal Load Indicator (EOILINJB) shall only be used when the Transportation Character Mode Type of ‘A’ for an aircraft is entered.

(c)External or Internal Load Indicator (EOILINJB) and Transportation Item Designator (TRITDRJB) for an aircraft shall either both be blank, or both have entries.

(d)Transportation Item Designator (TRITDRJB), Helicopter Mission Altitude (HMATLRJB), Helicopter Mission Distance (HMDISRJB), Helicopter Mission Payload (HMPAYRJB), Helicopter Mission Temperature (HMTMPRJB), Helicopter Mission Time (HMTIMRJB), and External or Internal Load Indicator (EOILINJB) shall only be entered when the Transportation Character Mode Type (TRCHMTJB) of ‘B’ for a helicopter is entered.

(e)External or Internal Load Indicator (EOILINJB) and Transportation Item Designator (TRITDRJB) for a helicopter shall either both be blank, or both have entries.

(f)Road Prime Transporter Capacity Code (HIPRMLJB), Road Prime Transporter Model Type (HIPRMTJB), Road Alternate Load (HALTMLJB), and Road Alternate Model Type (HALTMTJB) shall only be filled in when the Transportation Character Mode Type (TRCHMTJB) of ‘C’ is entered.

(g)Road Prime Transporter Capacity Code (HIPRMLJB) and Road Prime Transporter Model Type (HIPRMTJB) shall either both be blank, or both have entries.

(h)Road Alternate Transporter Capacity Code (HALTMLJB) and Road Alternate Transporter Model Type (HALTMTJB) shall either both be blank, or both have entries.

(i)Deck Stowage (SDECKSJB) and Transportation Item Designator (TRITDRJB) shall only be entered when the Transportation Character Mode Type (TRCHMTJB) of ‘D’ is entered.

(j)Deck Stowage (SDECKSJB) and Transportation Item Designator (TRITDRJB) shall either both be blank, or both have entries.

(k)Transportation Item Designator (TRITDRJB), Rail Use (RAILUSJB) and Rail Transportation Country (RAILTCJB) shall only be entered when the Transportation Character Mode Type (TRCHMTJB) of ‘E’ is entered.

(l)Rail Use Code (RAILUSJB) and Rail Transportation Country (RAILTCJB) shall either both be blank, or both have entries.

C-110

DEF STAN 00-60 (PART 0)/3

ANNEX C (CONTINUED)

(m)Deck Stowage (SDECKSJB) and Transportation Item Designator (TRITDRJB) shall only be entered when the Transportation Character Mode Type (TRCHMTJB) of ‘F’ is entered.

(n)Deck Stowage (SDECKSJB) and Transportation Item Designator (TRITDRJB) shall either both be blank, or both have entries.

(o)Container Length (CONLENJB) and Container Type (CONTYPJB) shall either both be blank, or both have entries.

(p)End Item Dimensions (EIDLENJB, EIDWIDJB, EIDHGTJB) and End Item Dimension Unit Of Measure (EIDUOMJB) shall either all be blank, or all have entries.

(q)End Item Weight/Displacement (EIWDSCJB, EIWLSCJB, EIWLHCJB) and End Item Weight/Displacement Unit Of Measure (EIWDUMJB) shall either all be blank, or all have entries.

C-111

DEF STAN 00-60 (PART 0)/3

ANNEX C (CONTINUED)

C.13.3 Table JC, Transported End Item. This Table provides information pertaining to a System/EI that is to be transported. The Table keys consist of EIAC (EIACODXA), LCN (LSACONXB), ALC (ALTLCNXB), LCN Type (LCNTYPXB), Transported Configuration Number (TRANCNJC), and Mobility Type (MOBTYPJC). For a given row of information, the following cross-element edits apply to Table JC :

(a)This Table can only be used if an ‘E’ or ‘B’ has been entered in the Transportation Indicator (TRNINDJA) Table JA.

(b)Operational Weight Empty (OPWEEMJC) and Military Load Classification Empty (HICLNEJC) shall either both be blank, or both have entries.

(c)Operational Weight Loaded (OPWELDJC) and Military Load Classification Loaded (HICLNLJC) shall either both be blank, or both have entries.

(d)Skid Number of Skids (SNUMSKJC), Skid Area (SKARDIJC), and Skid Area UM (SKADUMJC) shall only be used when the Mobility Type (MOBTYPJC) of ‘A’ is entered.

(e)Skid Area (SDSICGJC) and Skid Area UM (SKADUMJC) shall either both be blank, or both have entries.

(f)Tracked Ground Pressure (TRGRPRJC), Tracked Road Wheel Weight (TRRWWTJC), Tracked Pads Touching (TRNUPTJC), Tracked Pad Shoe Area (TRPSARJC), and Tracked Pad Shoe Area UM (TPSAUMJC) shall only be used when the Mobility Type (MOBTYPJC) of ‘B’ is entered. Wheeled Inflation Pressure (WHINPRJC), Wheeled Number of Tyres (WHNUTIJC), Wheeled Tyre Load Ratings (WHTLDRJC), Wheeled Tyre Size (WHTIFTJC), and Wheeled Weight Ratings (WHWERAJC) may also apply to tracked vehicles.

(g)Tracked Pad Shoe Area (TRPSARJC) and Tracked Pad Shoe Area UM (TPSAUMJC) shall either both be blank, or both have entries.

(h)Wheeled Inflation Pressure (WHINPRJC), Wheeled Number of Tyres (WHNUTIJC), Wheeled Tyre Load Ratings (WHTLDRJC), Wheeled Tyre Size (WHTIFTJC), and Wheeled Weight Ratings (WHWERAJC) shall be used when the Mobility Type (MOBTYPJC) of ‘C’ is entered.

C-112

C.13.4 Table JD, Transported End Item Narrative. This Table may be used to identify Tyre Requirements, Skid Remarks, Tracked Wheeled Remarks, Turning Information, Axle and Suspension Remarks, and Other Transported Equipment. The Table keys consist of EIAC (EIACODXA), LCN (LSACONXB), ALC (ALTLCNXB), LCN Type (LCNTYPXB), Transported Configuration Number (TRANCNJC), and Mobility Type (MOBTYPJC), Transported End Item Narrative Code (TREINCJD), and Transported End Item Narrative Text Sequencing Code (TEXSEQJD). For a given row of information, the following cross-element edits apply to Table JD :

(a)If the Transported End Item Narrative Code (TREINCJD) is ‘A’, then this Table identifies any pertinent information pertaining to the tyres for the system under analysis (Wheeled Tyre Requirements, DED 511).

(b)If the Transported End Item Narrative Code (TREINCJD) is ‘B’, then this Table describes any pertinent information pertaining to skid areas for the system under analysis (Skid Remarks DED, 385).

(c)If the Transported End Item Narrative Code (TREINCJD) is ‘C’, then this Table describes the tracked/wheeled turning diameter which will include wall-to-wall, curb-to-curb (Turning Information, DED 477).

C-113

DEF STAN 00-60 (PART 0)/3

ANNEX C (CONTINUED)

(d)If the Transported End Item Narrative Code (TREINCJD) is ‘D’, then this Table describes any information pertaining to the axle and suspension system of the item under analysis (Wheeled Axle and Suspension Remarks, DED 506).

(e)If the Transported End Item Narrative Code (TREINCJD) is ‘E’, then this Table captures all other information pertaining to an item that is being transported which is not tracked, wheeled, or skid mounted (Transported Other Equipment, DED 475).

C.13.5 Table JE, Transport by Fiscal Year. This Table contains information about the system/equipment procurement and delivery schedule. The Table keys consist of EIAC (EIACODXA), LCN (LSACONXB), ALC (ALTLCNXB), LCN Type (LCNTYPXB), and Transport Fiscal Year (TRAFYRJE).

C.13.6 Table JF, Transportation Narrative. This Table may be used to identify Transportation Shock and Vibration Requirements, Lifting and Tiedown Remarks, Projection Characteristics, Regulatory Requirements, Special Services and Equipment, Sectionalized Remarks, Transportation Remarks, Transport To/From Remarks, Environmental Considerations, Unusual and Special Requirements, Venting and Protective Clothing. The Table keys consist of EIAC (EIACODXA), LCN (LSACONXB), ALC (ALTLCNXB), LCN Type (LCNTYPXB), Transportation Narrative Code (TRANCDJF) and Transportation Narrative Text Sequencing Code (TRANARJF). For a given row of information, the following cross-element edits apply to Table JF :

C-114

DEF STAN 00-60 (PART 0)/3

ANNEX C (CONTINUED)

(a)If the Transportation Narrative Code (TRANCDJF) is ‘A’, then this Table shall state the fragility, shock, and vibration considerations required for the system/equipment under analysis (Transportation Shock Vibration Remarks, DED 382).

(b)If the Transportation Narrative Code (TRANCDJF) is ‘B’, then this Table identifies the number, location, and strength of the lifting provisions and tiedown remarks for the system/equipment under analysis (Lifting and Tiedown Requirement for Transportation, DED 192).

(c)If the Transportation Narrative Code (TRANCDJF) is ‘C’, then this Table states the dimensions and locations of any significant projections of the system under analysis (Transportation Projection Remarks, DED 471).

(d)If the Transportation Narrative Code (TRANCDJF) is ‘D’, then this Table describes data to show compliance with regulatory requirements (Transportation Regulatory Requirements, DED 340).

(e)If the Transportation Narrative Code (TRANCDJF) is ‘E’, then this Table provides a narrative field for transportation remark which may include towing, self-propelled, handling, and air dropped information, plus any transportation information not captured in other data elements or other narrative fields. (Transportation Remarks, DED 472).

(f)If the Transportation Narrative Code (TRANCDJF) is ‘F’, then this Table describes any information concerning the requirements for special services and equipment (railcars, road vehicles, or materiel handling equipment) when required for the system under analysis (Specialized Service and Equipment Requirements, DED 398).

(g)If the Transportation Narrative Code (TRANCDJF) is ‘G’, then this Table provides the sectionalization information for each section that is being transported (Sectionalized Remarks, DED 368).

(h)If the Transportation Narrative Code (TRANCDJF) is ‘H’, then this Table describes from where the item is transported and to where the item is transported (Transport To and From, DED 476).

(i)If the Transportation Narrative Code (TRANCDJF) is ‘I’, then this Table provides information concerning any special environmental/hazardous considerations required for the transportation of the system/equipment under analysis (Environmental/Hazardous Material, DED 099). For this Table to be used, a ‘Y’ shall be entered into the Environmental Handling and Transportation Indicator (ENHATCJA) Table JA.

(j)If the Transportation Narrative Code (TRANCDJF) is ‘K’, then this Table describes any unusual item transportation characteristics (eg, temperature limits, humidity limits, escorts required, etc.) (Unusual and Special Transportation Requirements, DED 500). For this Table to be used, a ‘Y’ shall be entered into the Environmental Handling and Transportation Indicator (ENHATCJA) Table JA.

C-115

DEF STAN 00-60 (PART 0)/3

ANNEX C (CONTINUED)

(k) If the Transportation Narrative Code (TRANCDJF) is ‘L’, then this Table describes the venting and protective clothing requirements (Venting and Protective Clothing Requirements, DED 504). For this Table to be used, a ‘Y’ shall be entered into the Environmental Handling and Transportation Indicator (ENHATCJA) Table JA.

C-116

DEF STAN 00-60 (PART 0)/3

ANNEX C (CONTINUED)

C.14 Ammunition Packaging, Handling, Storage and Transportation Requirements

Data Tables beginning with ‘Z’ in the first position of the Table Code are structured to consolidate information related directly to the ammunition management requirements with respect to Packaging, Handling, Storage and Transportation (PHS&T), in accordance JSP 422. Figure 16 depicts the relational hierarchy of these tables/entities.

C-117
