Figure 11 U Table Relationships

DEF STAN 00-60 (PART 0)/3

ANNEX C (CONTINUED)

C.9.1 Table UA, Article Requiring Support/Unit Under Test. This Table identifies the UUT which is a component of weapon system breakdown structure. A UUT can be either a component of the system/equipment or a piece of complex SE itself which shall be documented under the end article (weapon system) for contractual or provisioning purposes. Table keys are migrated from Table XB, but are given the role name ‘UUT’ to distinguish them (UUTLCNUA, UUTALCUA, and UTLCNTUA). The EIAC shall be the same as in Table XB, therefore it, is not role named. For a given row of information, the following crosselement edit applies to Table UA :

(a) Table keys (EIACODXA, UUTLCNUA, UUTALCUA, and UTLCNTUA) shall have a matching set of identical values already established in Table CA (Task Requirement).

C.9.2 Table UB, Unit Under Test Support Equipment. This Table serves as the tie-in between the SE and the UUT. Keys are migrated into Table UB from the EA and UA Tables. Table keys are EIAC (EIACODXA), UUT LCN (UUTLCNUA), UUT ALC (UUTALCUA), UUT LCN Type (UTLCNTUA), SE CAGE Code (SECAGEEA) and SE Reference Number (SEREFNEA).

C.9.3 Table UC, Operational Test Programme. This Table allows documenting identification and cost data pertaining to the Operational Test Programme (OTP). The OTP is used in conjunction with another support equipment item, normally ATE. This Table provides supporting information to the UD Table. Keys are migrated from the HA Table and given the role name ‘OTP’ to distinguish them (OTPCAGUC and OTPREFUC). For a given row of information, the following cross-element edits apply to Table UC :

(a) Operational Test Programme Apportioned Unit Cost Recurring (OTPACRUC) and OTP Apportioned Unit Cost Recurring Currency Code (OACRCCUC) shall either both be blank or both have entries.

C-67

DEF STAN 00-60 (PART 0)/3

ANNEX C (CONTINUED)

(b) Operational Test Programme Apportioned Unit Cost Non-Recurring (OTPACNUC) and OTP Apportioned Unit Cost Non-Recurring Currency Code (OACNCCUC) shall either both be blank or both have entries.

C.9.4 Table UD, Unit Under Test Support Equipment Operational Test Programme. This Table ties together the relationship between the SE, UUT, and the OTP to maintain the specific application of the OTP. Table keys are EIAC (EIACODXA), UUT LCN (UUTLCNUA), UUT ALC (UUTALCUA), UUT LCN Type (UTLCNTUA), SE CAGE Code (SECAGEEA), SE Reference Number (SEREFNEA) (these migrate from the UB Table), and OTP CAGE Code (OTPCAGUC) and OTP Reference Number (OTPREFUC) migrate from the UC Table.

C.9.5 Table UE, Test Programme Instruction. This Table allows documenting basic identification and cost information pertaining to a Test Programme Instruction (TPI). The TPI is used as an aid in the use of an OTP. Table keys are migrated from the HA Table and given the role name ‘TPI’ to form the following keys: TPI CAGE Code (TPICAGUE) and TPI Reference Number (TPIREFUE). Also, the keys from Table UC (OTP CAGE and Reference Number) are migrated in as foreign keys. For a given row of information, the following crosselement edits apply to Table UE :

(a)Test Programme Instruction Apportioned Unit Cost Recurring (TPAUCRUE) and TPI Apportioned Unit Cost Recurring Currency Code (TACRCCUE) shall either both be blank or both have entries.

(b)Test Programme Instruction Apportioned Unit Cost Non-Recurring (TPAUCNUE) and TPI Apportioned Unit Cost Non-Recurring Currency Code (TACNCCUE) shall either both be blank or both have entries.

C-68

C.9.6 Table UF, Unit Under Test Explanation. Narrative statements may be entered in this Table to further explain, justify, or substantiate any data entry concerning UUT (U Tables) related data elements. When the information is related to a specific data element, the explanation should be prefaced with a reference to that element. Table keys are migrated from Table UA and include EIAC (EIACODXA), UUT LCN (UUTLCNUA), UUT ALC (UUTALCUA), and UUT LCN Type (UTLCNTUA). Also, Text Sequencing Code (TEXSEQUF) is a key attribute.

C.9.7 Table UG, Unit Under Test Parameter Group. This Table allows documenting specific information about individual parameters which the UUT requires to have measured, generated, etc. by the SE. This Table is used when the UUT is a sub-element of the system/equipment (CMRS category I item), as opposed to being another piece of SE, with one exception. This Table can be used to document parameters for a piece of complex SE which is an LSA candidate, thereby, making it the UUT. Table keys are EIAC (EIACODXA), UUT LCN (UUTLCNUA), UUT ALC (UUTALCUA), UUT LCN Type (UTLCNTUA), SE CAGE Code (SECAGEEA) and SE Reference Number (SEREFNEA). For a given row of information, the following cross-element edit applies to Table UG :

(a) The UUT Parameter Grouping Code (UUTPGCUG) and the SE Parameter Grouping Code (PARGPCEC) (Table EC) provide the common link between the parameters that need to be tested by the UUT and the parameters that the piece of SE can test. Therefore, the values for UUTPGCUG and PARGPCEC shall be identical to link the UUT to the corresponding piece of SE.

C-69

DEF STAN 00-60 (PART 0)/3

ANNEX C (CONTINUED)

C.9.8 Table UH, Unit Under Test Fault Isolated Replaceable Unit. This Table allows documenting the relationship between SE, UUT, task provisioned items, and Fault Isolated Replaceable Units (FIRU). The FIRU is an item which is subordinate to the UUT LCN (UUTLCNUA) and the Task LCN (TSKLCNCI) in hardware breakdown. In fact, the UUT LCN and the Task LCN are one in the same and therefore, shall be identical to each other. This Table also allows documenting the percentage of faults which can be isolated to a given ambiguity group (up to two groups) and its respective number of items per ambiguity group. Table keys include those which originate in Table CI (EIACODXA, TSKLCNCI, TSKALCCI, TSKLTYCI, TSKTCDCI, PROLCNCI, PROALCCI, PROLTYCI, PROCAGCI and PROREFCI) and are migrated to Table UH. Keys from Table EA migrate down as nonidentifying. For a given row of information, the following cross-element edits apply to Table UH :

(a)PROLCNCI shall be subordinate to TSKLCNCI.

(b)PROLCNCI identifies the FIRU item.

(c)To qualify as an FIRU, the PROLCNCI shall have an ICC of ‘X’, ‘Y’, ‘9’, ‘AA’, or ‘AB’ (identified in Table HG) and shall be identifiable through fault isolation procedures for the TSKLCNCI.

C-70

C.9.9 Table UI, Adaptor/Interconnection Device. This Table contains pricing and identification information about items which are utilized to interface the UUT with the SE. The Table keys are migrated from Table HA and given the role names Adaptor/ Interconnection Device (AID) CAGE Code (AIDCAGUI) and AID Reference Number (AIDREFUI). For a given row of information, the following cross-element edits apply to Table UI :

(a)AID Apportioned Unit Cost Recurring (AIDUCRUI) and AID Apportioned Unit Cost Recurring Currency Code (AACRCCUI) shall either both be blank or both have entries.

(b)AID Apportioned Unit Cost Non-Recurring (AIDUCNUI) and AID Apportioned Unit Cost Non-Recurring Currency Code (AACNCCUI) shall either both be blank or both have entries.

C.9.10 Table UJ, Unit Under Test Support Equipment Adaptor/Interconnection Device. This Table cross-references data pertaining to the relationship between the SE, AID, and the UUT. Table keys include the CAGE and Reference Number for the AID (AIDCAGUI and AIDREFUI respectively) from Table UI and the keys migrated from Table UB which are EIAC (EIACODXA), UUT LCN (UUTLCNUA), UUT ALC (UUTALCUA), UUT LCN Type (UTLCNTUA), SE CAGE Code (SECAGEEA) and SE Reference Number (SEREFNEA).

C-71

DEF STAN 00-60 (PART 0)/3

ANNEX C (CONTINUED)

C.9.11 Table UK, Automatic Test Equipment Test Station. This Table is used to document identification information concerning the Automatic Test Equipment (ATE) Test Station required on a SERD summary. Table keys are migrated from Table HA and given role names of ATE CAGE Code (ATECAGUK) and ATE Reference Number (ATEREFUK).

C.9.12 Table UL, Unit Under Test Support Equipment Automatic Test Equipment. This Table cross-references the ATE Test Station (Table UK) data with the UUT SE (Table UB). Table keys are ATE Reference Number (ATEREFUK) and ATE CAGE Code (ATECAGUK) migrated from Table UK and the keys migrated from Table UB which are EIAC (EIACODXA), UUT LCN (UUTLCNUA), UUT ALC (UUTALCUA), UUT LCN Type (UTLCNTUA), SE Reference Number (SEREFNEA) and SE CAGE Code (SECAGEEA).

C.9.13 Table UM, Support Equipment Item Unit Under Test. This Table identifies pieces of SE (Calibration and Measurement Requirement Summary (CMRS) category II items) that are linked with CMRS category III items (SE in support of the category II SE). Normally, Tables UM and UN are only used if a CMRS (LSA-076) is required on contract. Table keys are migrated down from the EA Table (Support Equipment) and given a role name of Support Equipment Unit Under Test to distinguish them (SUTCAGUM and SUTREFUM).

C.9.14 Table UN, Support Equipment Unit Under Test Parameter Group. This Table allows documenting specific information about individual parameters which a piece of support equipment (SE) (CMRS category II) requires to have calibrated, measured, etc. by another piece of SE (CMRS category III item). Data from this Table will be used on the CMRS Report (LSA-076). Table keys include the SE UUT Parameter Group Code (SEUPGCUN), keys migrated from Table EA and given role names of ‘Testing’ (TGSCAGUN and TGSREFUN), and keys from Table UM are also migrated into this Table (SUTCAGUM and

C-72

DEF STAN 00-60 (PART 0)/3

ANNEX C (CONTINUED)

SUTREFUM). For a given row of information, the following cross-element edit applies to Table UN :

(a) The SE UUT Parameter Grouping Code (SEUPGCUN) and the SE Parameter Grouping Code (PARGPCEC) (Table EC) provide the link between the parameters of CMRS category III items and category II items, respectively. Therefore, the values for PARGPCEC and SEUPGCUN shall be identical to link the SE UUT to the corresponding piece of testing SE.

C-73

DEF STAN 00-60 (PART 0)/3

ANNEX C (CONTINUED)

C.10 Facilities Considerations

Data Tables beginning with ‘F’ in the first position of the Table Code are structured to describe and justify all proposed special and additional facilities requirements, which are indicated as a result of the operational/maintenance task analysis. Figure 12 depicts the relational hierarchy of these Tables/entities.
