12.2.6Unconnected Pins
If some pins are unused, it is recommended to ensure that these pins have a defined level. Even though most of the digital inputs are disabled in the deep sleep modes as described above, floating inputs should be avoided to reduce current consumption in all other modes where the digital inputs are enabled (Reset, Active mode and Idle mode).
The simplest method to ensure a defined level of an unused pin, is to enable the internal pull-up. In this case, the pull-up will be disabled during reset. If low power consumption during reset is important, it is recommended to use an external pull-up or pulldown. Connecting unused pins directly to VCC or GND is not recommended, since this may cause excessive currents if the pin is accidentally configured as an output.
12.3Alternate Port Functions
Most port pins have alternate functions in addition to being general digital I/Os. Figure 12-5 on page 62 shows how the port pin control signals from the simplified Figure 12-2 on page 57 can be overridden by alternate functions. The overriding signals may not be present in all port pins, but the figure serves as a generic description applicable to all port pins in the AVR microcontroller family.
61
8006E–AVR–09/06
Figure 12-5. Alternate Port Functions(1) |
|
|
|
|
|
|
|
|
|
PUOExn |
|
|
|
|
|
|
|
1 |
PUOVxn |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
0 |
|
|
|
|
|
|
PUD |
|
|
|
|
|
|
|
|
|
|
|
DDOExn |
|
|
|
|
|
|
|
1 |
DDOVxn |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
0 |
|
|
|
|
Q |
D |
|
|
|
|
|
|
|
DDxn |
|
|
|
|
|
|
|
|
Q CLR |
|
|
|
|
PVOExn |
|
|
|
RESET |
WDx |
|
|
|
|
|
|
|
|
|||
|
PVOVxn |
|
|
|
|
|
RDx |
|
|
|
|
|
|
|
|
BUS |
|
Pxn |
|
|
|
|
|
1 |
|
|
1 |
|
|
|
|
|
|
|
|
0 |
|
|
|
Q |
D |
0 |
|
DATA |
|
|
|
|
PORTxn |
|
PTOExn |
||
|
DIEOExn |
|
|
|
|
|
|
|
|
|
|
Q CLR |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
DIEOVxn |
|
|
RESET |
|
|
WPx |
|
1 |
|
|
|
WRx |
|
|||
|
|
|
|
|
|
|
||
0 |
SLEEP |
|
|
|
|
|
RRx |
|
|
|
|
|
|
|
|
||
|
SYNCHRONIZER |
|
|
RPx |
|
|||
|
|
|
|
|
|
|
|
|
|
D SET |
Q |
D |
Q |
|
|
|
|
|
|
|
PINxn |
|
|
|
|
|
|
L CLR |
Q |
|
CLR Q |
|
|
|
|
|
|
|
|
|
|
|
clk I/O |
|
|
|
|
|
|
|
|
DIxn |
|
|
|
|
|
|
|
|
AIOxn |
|
PUOExn: |
Pxn PULL-UP OVERRIDE ENABLE |
PUOVxn: |
Pxn PULL-UP OVERRIDE VALUE |
DDOExn: |
Pxn DATA DIRECTION OVERRIDE ENABLE |
DDOVxn: |
Pxn DATA DIRECTION OVERRIDE VALUE |
PVOExn: |
Pxn PORT VALUE OVERRIDE ENABLE |
PVOVxn: |
Pxn PORT VALUE OVERRIDE VALUE |
DIEOExn: |
Pxn DIGITAL INPUT-ENABLE OVERRIDE ENABLE |
DIEOVxn: |
Pxn DIGITAL INPUT-ENABLE OVERRIDE VALUE |
SLEEP: |
SLEEP CONTROL |
PTOExn: |
Pxn, PORT TOGGLE OVERRIDE ENABLE |
PUD: |
PULLUP DISABLE |
WDx: |
WRITE DDRx |
RDx: |
READ DDRx |
RRx: |
READ PORTx REGISTER |
WRx: |
WRITE PORTx |
RPx: |
READ PORTx PIN |
WPx: |
WRITE PINx |
clk : |
I/O CLOCK |
I/O |
DIGITAL INPUT PIN n ON PORTx |
DIxn: |
|
AIOxn: |
ANALOG INPUT/OUTPUT PIN n ON PORTx |
Note: 1. WRx, WPx, WDx, RRx, RPx, and RDx are common to all pins within the same port. clkI/O,
SLEEP, and PUD are common to all ports. All other signals are unique for each pin.
Table 12-2 on page 63 summarizes the function of the overriding signals. The pin and port indexes from Figure 12-5 on page 62 are not shown in the succeeding tables. The overriding signals are generated internally in the modules having the alternate function.
