■■Raspberry Pi is a popular example of a 64-bit microcontroller or a single-board computer.These types of microcontrollers provide a small form-factor computer that can be used to add computer control and monitoring almost anything. A Raspberry Pi includes a CPU, RAM, video, and peripheral support (via USB), and some include onboard networking.The Raspberry Pi includes its own custom OS, but dozens of alternative OSs can be installed as a replacement.There is a broad and diverse development community around the Raspberry Pi that is using it as part of science experiments to control coffeemakers.

■■Arduino is an open source hardware and software organization that creates singleboard 8-bit microcontrollers for building digital devices. An Arduino has limited RAM, a single USB port, and I/O pins for controlling additional electronics (such as servo motors or LED lights), and does not include an OS. Instead, Arduino can execute C++ programs specifically written to its limited instruction set. Whereas Raspberry Pi is a miniature computer, Arduino is a much simpler device.

■■A field-programmable gate array (FPGA) is a flexible computing device intended to be programmed by the end user or customer. FPGAs are often used as embedded devices in a wide range of products, including industrial control systems (ICSs).

Embedded systems can be a security risk because they are generally static systems, meaning that even the administrators who deploy them have no real means to alter the device’s operations in order to address security vulnerabilities. Some embedded systems can be updated with patches from the vendor, but often patches are released months after a known exploit is found in the wild. It is essential that embedded systems be isolated from the internet and from a private production network to minimize exposure to remote exploitation, remote control, or malware compromise.

Security concerns for embedded systems include the fact that most are designed with a focus on minimizing cost and extraneous features. This often leads to a lack of security and difficulty with upgrades or patches. Because an embedded system may be in control of a mechanism in the physical world, a security breach could cause harm to people and property.

Static Systems

Another concept similar to that of embedded systems is static systems (aka static environments). A static environment is a set of conditions, events, and surroundings that don’t change. In theory, once understood, a static environment doesn’t offer new or surprising elements. A static IT environment is any system that is intended to remain unchanged by users and administrators. The goal is to prevent, or at least reduce, the possibility of a user implementing change that could result in reduced security or functional operation. This is also known as a nonpersistent environment or a stateless system, as opposed to a persistent environment or stateful system, which allows changes and retains them between access events and reboots.

Examples of static systems include the check-in kiosk at the airport, an ATM, and often the complimentary guest computer at a hotel or library. Those guest computers are configured to provide the user with a temporary desktop environment to perform a restricted range of tasks. However, when the user terminates their session due to timeout or logging out, the system discards all the previous sessions information and changes and restores a pristine version of the environment for the next user. Static systems can be implemented in a variety of ways, including using local VMs or remotely accessed VDI (Virtual Desktop Infrastructure).

In technology, static environments are applications, OSs, hardware sets, or networks that are configured for a specific need, capability, or function, and then set to remain unaltered. However, although the term static is used, there are no truly static systems. There is

always the chance that a hardware failure, a hardware configuration change, a software bug, a software-setting change, or an exploit may alter the environment, resulting in undesired operating parameters or actual security intrusions.

Sometimes the phrase static OS is used to refer to the concept of a static system/environment or to indicate a slight variation. That variation is that the OS itself is beyond the ability of the user to change but the user can install or use applications. Often, those applications may be limited, restricted, or controlled in order to avoid allowing an application to alter the otherwise static OS. Some potential examples of static OSs would be smart TVs, gaming systems/consoles, or mobile devices where only applications from a vendor-controlled app store can be installed.

Network-Enabled Devices

Network-enabled devices are any type of device (whether mobile or stationary) that has native network capabilities. This generally assumes the network in question is a wireless type of network, primarily that provided by a mobile telecommunications company. However, it can also refer to devices that connect to Wi-Fi (especially when they can connect automatically), devices that share data connectivity from a wireless telco service (such as a mobile hot spot), and devices with RJ-45 jacks to receive a standard Ethernet cable for a wired connection. Network-enabled devices include smartphones, mobile phones, tablets, smart TVs, settop boxes, or an HDMI-stick streaming-media player (such as a Roku Player, Amazon Fire TV, or Google TV [previously known as Android TV and Chromecast]), network-attached printers, game systems, and much more. Examples of embedded systems include networkattached printers, smart TVs, HVAC controls, smart appliances, smart thermostats, vehicle entertainment/driver assist/self-driving systems, and medical devices. Network-enabled devices may be embedded systems or used to create embedded systems. Network-enabled devices are also often static systems.

In some cases, network-enabled devices might include equipment supporting Bluetooth, NFC, and other radio-based connection technologies. Additionally, some vendors offer devices to add network capabilities to devices that are not network enabled on their own. These add-on devices might be viewed as network-enabled devices themselves (or more specifically, network-enabling devices), and their resultant enhanced device might be deemed a network-enabled device.

Cyber-Physical Systems

Cyber-physical systems refer to devices that offer a computational means to control something in the physical world. In the past, these might have been referred to as embedded systems, but the category of cyber-physical seems to focus more on the physical world results rather than the computational aspects. Cyber-physical devices and systems are essentially key elements in robotics and sensor networks. Basically, any computational device that

can cause a movement to occur in the real world is considered a robotic element, whereas any such device that can detect physical conditions (such as temperature, light, movement, and humidity) is a sensor. Examples of cyber-physical systems include prosthetics to provide human augmentation or assistance, collision avoidance in vehicles, air traffic control coordination, precision in robot surgery, remote operation in hazardous conditions, and energy conservation in vehicles, equipment, mobile devices, and buildings.

Another extension of cyber-physical systems, embedded systems, and network-enabled devices is that of the Internet of Things (IoT). As discussed earlier, IoT is the collection of devices that can communicate over the internet with one another or with a control console in order to affect and monitor the real world. IoT devices might be labeled as smart devices or smart-home equipment. Many of the ideas of industrial environmental control found in office buildings are finding their way into more consumer-available solutions for small offices or personal homes. IoT is not limited to static location equipment but can also be used in association with land, air, or water vehicles or on mobile devices. IoT devices are usually static systems, since they may only run the firmware provided by the manufacturer.

Elements Related to Embedded and Static Systems

Mainframes are high-end computer systems used to perform highly complex calculations and provide bulk data processing. Older mainframes may be considered static environments because they were often designed around a single task or supported a single mission-critical application. These configurations didn’t offer significant flexibility, but they did provide for high stability and long-term operation.

Modern mainframes are much more flexible and are often used to provide high-speed computation power in support of numerous virtual machines. Each virtual machine can be used to host a unique OS and in turn support a wide range of applications. If a modern mainframe is implemented to provide fixed or static support of one OS or application, it may be considered a static environment.

Game consoles, whether home systems or portable systems, are potentially examples of static systems. The OS of a game console is generally fixed and is changed only when the vendor releases a system upgrade. Such upgrades are often a mixture of OS, application, and firmware improvements. Although game console capabilities are generally focused on playing games and media, modern consoles may offer support for a range of cultivated and third-party applications. The more flexible and open-ended the app support, the less of a static system it becomes.

HVAC can be controlled by an embedded solution (which might be also known as a smart device or an IoT device). Physical security controls protect against physical attacks, whereas logical and technical controls only protect against logical and technical attacks. HVAC is discussed further in Chapter 10.

Many printers are network-attached printers, meaning they can be directly connected to the network without being directly attached to a computer. A network-attached printer serves as its own print server. It may connect to the network via cable or through wireless.

Some devices are more than just printers and may include fax, scanning, and other functions. These are known as multifunction devices (MFDs) or MFPs. Any device connected to a network can be a potential breach point. This may be due to flaws in the firmware of the device as well as whether the device uses communication encryption.

An MFD/MFP can be considered an embedded device if it has integrated network capabilities that allow it to operate as an independent network node rather than a direct-attached dependent device. Thus, network-attached printers and other similar devices pose an increased security risk because they often house full-fledged computers within their chassis. Network security managers need to include all such devices in their security management strategy in order to prevent these devices from being the targets of attack, used to house malware or attack tools, or grant outsiders remote-control access. Many MFDs/MFPs have embedded web servers for remote management, which can be a vector of compromise. Also, most MFPs/MFDs (as well as fax machines and copiers) have storage devices where print jobs are stored, which may allow for access or recovery by unauthorized entities.

Surveillance systems include any device that is intended to monitor and track assets and/ or subjects. These can be embedded systems, or they can be dedicated sensors. Examples include security cameras, door open/close sensors, movement sensors, scales in access control vestibules, and smartcard readers.

In-vehicle computing systems, medical systems/devices, aircraft/UAV/drones, and smart meters are all potential examples of embedded, static, network-attached, and cyber-physical systems. These were discussed previously in this chapter.

Security Concerns of Embedded and Static Systems

Embedded, static, network-enabled, cyber-physical, and specialized systems are usually more limited or constrained based on their design or hardware capabilities compared to typical endpoint, server, and networking hardware. These constraints can have security implications.

Some embedded and specialized systems run on replaceable or rechargeable batteries. Others only receive a small amount of power from a USB plug or special power adapter/converter. These power limitations can restrict the speed of operations, which in turn can limit the execution of security components. If additional power is consumed, the device might overheat. This could result in slower performance, crashing, or destruction.

Most embedded and specialized systems use less-capable CPUs. This is due to cost and power savings or limitations. Fewer computing capabilities means fewer functions, which means fewer security operations.

Many embedded and specialized systems have limited network capabilities. These network capabilities could be limited to wired only or wireless only. Within wireless, the device could be limited to a specific Wi-Fi version, frequency, speed, and/or encryption. Some devices using wireless are limited to special communication protocols, such as Zigbee or Bluetooth Low Energy (BLE).

Many embedded and specialized systems are unable to process high-end encryption. The crypto on these special devices is often limited and may use older algorithms or poor keys, or just lack good key management. Some devices are known to have preshared and/or hardcoded encryption keys.

Some embedded and specialized systems are difficult to patch, whereas others might not even offer patching or upgrading. Without update and patch management, vulnerable code will remain at risk.

Some embedded and specialized systems do not use authentication to control subjects or restrict updates. Some devices use hard-coded credentials. These should be avoided. Only use equipment that allows for customized credentials, and choose devices that support mutualcertificate authentication.

Some embedded and specialized systems have a limited transmission range due to lowpower antennae. This can restrict the device’s usefulness or require signal boosting to compensate.

Due to the low cost of some embedded and specialized systems, they might not include necessary security features. Other devices that do include needed security components may be too costly to be considered.

Similar to supply chain issues, when an embedded or specialized system is used, the organization is automatically trusting the vendor of the device and the cloud service behind it. This implied trust may be misguided. Always thoroughly investigate vendors before relying on their product, and even then, segregate specialized systems in their own constrained network segments. See zero trust in Chapter 8.

Based on these constraints and other concerns, security management of embedded and static systems must accommodate the fact that most are designed with a focus on minimizing costs and extraneous features. This often leads to a lack of security mechanisms and difficulty with upgrades or patches.

Static environments, embedded systems, network-enabled devices, cyber-physical systems, high-performance computing (HPC) systems, edge computing devices, fog computing devices, mobile devices, and other limited or single-purpose computing environments need security management. Although they may not have as broad an attack surface and aren’t exposed to as many risks as a general-purpose computer, they still require proper security government. Many of the same general security management principles used over servers and endpoints can be applied to embedded, static, and cyber-physical systems.

Network segmentation involves controlling traffic among networked devices. Complete or physical network segmentation occurs when a network is isolated from all outside communications, which means transactions can occur only between devices within the segmented network. You can impose logical network segmentation with switches using virtual local area networks (VLANs), or through other traffic-control means, including MAC addresses, IP

addresses, physical ports, TCP or UDP ports, protocols, or application filtering, routing, and access control management. Network segmentation can be used to isolate embedded devices and static environments in order to prevent changes and/or exploits from reaching them. See Chapter 11 for more on segmentation.

An application firewall is a device, server add-on, virtual service, or system filter that defines a strict set of communication rules for a service and all users. It’s intended to be an application-specific server-side firewall to prevent application-specific protocol and payload attacks. A network firewall is a hardware device, typically called an appliance, designed for general network filtering. A network firewall is designed to provide broad protection for an entire network. An internal segmentation firewall (ISFW) is used to create a network division or segment. Every network needs a network firewall. Many application servers need an application firewall. However, the use of an application firewall generally doesn’t negate the need for a network firewall. You should use firewalls in a series to complement each other, rather than seeing them as competitive solutions. See Chapter 17 for more on firewalls.

Security layers exist where devices with different levels of classification or sensitivity are grouped together and isolated from other groups with different levels. This isolation can be absolute or one-directional. For example, a lower level may not be able to initiate communication with a higher level, but a higher level may initiate with a lower level. Isolation can also be logical or physical. Logical isolation requires the use of classification labels on

data and packets, which must be respected and enforced by network management, OSs, and applications. Physical isolation requires implementing network segmentation or air gaps between networks of different security levels. See Chapter 5, “Protecting Security of Assets,” to learn more about managing data and asset classification.

Manual updates should be used in static environments to ensure that only tested and authorized changes are implemented. Using an automated update system would allow for untested updates to introduce unknown security reductions. As with manual software

updates, strict control over firmware in a static environment is important. Firmware updates should be implemented on a manual basis, only after thorough testing and review. Firmware version control or oversight of firmware release should focus on maintaining a stable operating platform while minimizing exposure to downtime or compromise.

A wrapper is something used to enclose or contain something else. Wrappers are well known in the security community in relation to Trojan horse malware. A wrapper of that sort is used to combine a benign host with a malicious payload. Wrappers are also used as encapsulation solutions. Some static environments may be configured to reject updates, changes, or software installations unless they’re introduced through a controlled channel.

That controlled channel can be a specific wrapper, such as an encrypted connection, mutual- certificate-based authentication, sourced from a preset IP address or domain name, and/or a digital signature. The wrapper may include integrity and authentication features to ensure that only intended and authorized updates are applied to the system.

Even embedded and static systems should be monitored for performance, violations, compliance, and operational status. Some of these types of devices can perform on-device monitoring, auditing, and logging, whereas others may require external systems to collect activity data. Any and all devices, equipment, and computers within an organization should
