Annex III.1 (II.1)

IP code

Coding system is a system presenting protection level provided by a component which shields against contact with dangerous parts, penetration of solid matters or water from outside and additional information of protection.

	IP arrangement
For instance: IP 23CH	IP	2	3	C	H
Coded letters


(International protection)
First characteristic number


(from 0 to 6, or letter X)
Second characteristic number


(from 0 to 8, or letter X)
Auxiliary letter (freely selected)


(Alphabets:A, B, C, D)

Additional letter (freely selected) (Alphabets: H, M, S, W)

•If indication of characteristic numbers, these numbers can be replaced by letter “X”(or. can be replaced by letter “XX” if omitted two characteristics)

•Auxiliary and additional letters can be omitted without replacement with letters.

•If more additional letters used, alphabetical order must be applied.

• If a shielding component generated different protection levels for different arrangement, corresponding protection levels must be indicated by manufacturers in documents related to installation and arrangement.

313

Elements of IP code and their meanings Table II.1 Brief description of elements of IP code

Element

Coded capital letters

The first characteristics letter

Auxiliary

Letter (freely selected)

Additional

Letter (freely selected)

Number		Meaning for protection of
or letter		equipment

IP		-


		Preventing water penetration:

0- Not protected

1- Water vertically falling

2- Water falling with angle of 15o.

3- Jet water in small drops

4- Jet water in rain form

5- Jet water in ray form

6- Pressured water jet

7- Temporary submerse in water

8- Permanent submerse in water

A		-
B		-
B
C
D

		Additional information for:
	H	- High pressure equipment
	M	- High pressure equipment
	M	- Movable during water testing
		- Movable during water testing

S- Fixed during water testing

W- Weather conditions

Meaning for protection of persons

Protection against contact dangerous parts:

-By hand arch

-Fingers

-Tools

-Rope

314

Annex III.3 (II.4)

Annex III.3.1 (II.4.1)

Table III.3.1-1 Conductor sag and deviation due to wind of cable 4x95mm2 with pulling force of 2.75kN at head of pole

					Sag, m						Deviation (a)	due to wind m
Pole span, m
				Temperature, oC
	5	10	15	20	25	30	35	40	-5	80


18	0.20	0.20	0.21	0.22	0.23	0.24	0.24	0.25	0.18	0.30		0.22

20	0.24	0.25	0.26	0.27	0.28	0.29	0.30	0.31	0.22	0.38		0.28
22	0.29	0.31	0.32	0.33	0.34	0.35	0.36	0.38	0.26	0.45		0.34
24	0.35	0.36	0.38	0.39	0.41	0.42	0.43	0.45	0.31	0.65		0.39
26	0.41	0.43	0.44	0.46	0.48	0.49	0.51	0.52	0.37	0.63		0.47
28	0.47	0.49	0.52	0.54	0.55	0.57	0.59	0.61	0.43	0.74		0.54

30	0.54	0.57	0.59	0.61	0.64	0.66	0.68	0.70	0.49	0.84		0.62
32	0.62	0.65	0.67	0.70	0.72	0.75	0.77	0.80	0.56	0.96		0.70
34	0.70	0.73	0.76	0.79	0.82	0.84	0.87	0.90	0.63	1.08		0.79
35	0.74	0.77	0.81	0.84	0.87	0.90	0.92	0.95	0.67	1.15		0.84
36	0.78	0.82	0.85	0.88	0.92	0.95	0.98	1.01	0.71	1.22		0.89
38	0.87	0.91	0.95	0.99	1.02	1.06	1.09	1.12	0.79	1.36		0.99
40	0.97	1.01	1.05	1.09	1.13	1.17	1.21	1.24	0.97	1.50		1.10
42	1.07	1.11	1.16	1.20	1.25	1.29	1.33	1.37	0.96	1.66		1.21
44	1.17	1.22	1.27	1.32	1.37	1.42	1.46	1.50	1.06	1.82		1.34
46	1.28	1.34	1.39	1.45	1.50	1.55	1.60	1.64	1.16	1.99		1.46
48	1.39	1.45	1.52	1.57	1.63	1.69	1.74	1.79	1.26	2.17		1.59

50	1.51	1.58	1.64	1.71	1.77	1.83	1.89	1.94	1.37	2.35		1.72
52	1.63	1.71	1.78	185	1.91	1.98	2.04	2.10	1.48	2.54		1.86
54	1.76	1.84	1.92	1.99	2.06	2.13	2.20	2.27	1.59	2.74		2.01
56	1.90	1.98	2.06	2.14	2.22	2.30	2.37	2.44	1.71	2.95		2.16
58	2.03	2.13	2.21	2.30	2.38	2.46	2.54	2.62	1.84	3.16		2.32

60	2.18	2.27	2.37	2.46	2.55	2.64	2.72	2.80	1.97	3.39		2.48
62	2.32	2.43	2.53	2.63	2.72	2.82	2.90	2.99	2.10	3.62		2.65
64	2.48	2.59	2.70	2.80	2.90	3.00	3.10	3.19	2.24	3.86		2.83
66	2.63	2.75	2.87	2.98	3.09	3.19	3.29	3.39	2.38	4.10		3.01
68	2.80	2.92	3.05	3.16	3.28	3.39	3.50	3.60	2.53	4.36		3.19

70	2.96	3.10	3.23	3.35	3.47	3.59	3.71	3.82	2.68	4.62		3.38

315

Table III.3.1-2 Conductor sag and deviation due to wind of cable 4x95mm2 with pulling force of 4kN at head of pole

						Sag, m						Deviation (a)	due to wind m

Pole span, m					Temperature, oC
	5	10	15	20		25	30	35	40	-5	80


26	0.28	0.30	0.31	0.33		0.34	0.36	0.37	0.38	0.25	0.47		0.34
28	0.33	0.35	0.36	0.38		0.40	0.41	0.43	0.44	0.29	0.55		0.39

30	0.38	0.40	0.42	0.44		0.46	0.47	0.49	0.51	0.34	0.63		0.45
32	0.43	0.45	0.48	0.50		0.52	0.54	0.56	0.58	0.38	0.71		0.52
34	0.49	0.51	0.54	0.56		0.59	0.61	0.63	0.65	0.43	0.80		0.58
36	0.55	0.57	0.60	0.63		0.66	0.68	0.71	0.73	0.48	0.90		0.65
38	0.61	0.64	0.67	0.70		0.73	0.76	0.79	0.81	0.54	1.00		0.73

40	0.67	0.71	0.74	0.78		0.81	0.84	0.87	0.90	0.60	1.11		0.80
42	0.74	0.78	0.82	0.86		0.89	0.93	0.96	0.99	0.66	1.23		0.88
44	0.52	0.86	0.90	0.94		0.98	1.02	1.06	1.09	0.72	1.35		0.98
45	0.85	0.90	0.94	0.99		1.03	1.07	1.10	1.14	0.76	1.41		1.02
46	0.89	0.94	0.99	1.03		1.07	1.11	1.15	1.19	0.79	1.47		1.07
48	0.97	1.02	1.07	1.12		1.17	1.21	1.26	1.30	0.86	1.60		1.16

50	1.05	1.11	1.16	1.22		1.27	1.32	1.36	1.41	0.93	1.74		1.25
52	1.14	1.20	1.26	1.32		1.37	1.42	1.48	1.53	1.01	1.88		1.36
54	1.23	1.29	1.36	1.42		1.48	1.54	1.59	1.64	1.09	2.02		1.47
56	1.32	1.39	1.46	1.53		1.59	1.65	1.71	1.77	1.17	2.18		1.59
58	1.42	1.50	1.57	1.64		1.71	1.77	1.84	1.90	1.26	2.4		1.70

60	1.52	1.60	1.68	1.75		1.83	1.90	1.97	2.03	1.35	2.51		1.81
62	1.62	1.71	1.79	1.87		1.95	2.03	2.10	2.17	1.44	2.68		1.93
64	1.73	1.82	1.91	2.00		2.08	2.16	2.24	2.31	1.53	2.86		2.06
66	1.84	1.94	2.03	2.12		2.21	2.30	2.38	2.46	1.63	3.04		2.20
68	1.95	2.06	2.16	2.25		2.35	2.44	2.53	2.61	1.73	3.23		2.33

70	2.07	2.18	2.29	2.39		2.49	2.59	2.68	2.77	1.83	3.42		2.47
72	2.19	2.31	2.42	2.53		2.63	2.74	2.83	2.93	1.94	3.62		2.61
74	2.31	2.44	2.56	2.67		2.78	2.89	2.99	3.10	2.05	3.82		2.76
76	2.44	2.57	2.70	2.82		2.93	3.05	3.16	3.27	2.16	4.03		2.91
78	2.57	2.71	2.84	2.97		3.09	3.21	3.33	3.44	2.28	4.24		3.07

80	2.70	2.85	2.90	3.12		3.25	3.38	3.50	3.62	2.39	4.47		3.24

316

Table III.3.1-3 Conductor sag and deviation due to wind of cable 4x95mm2 with pulling force of 5kN at head of pole

						Sag, m						Deviation (a) due to wind m
Pole span, m
					Temperature, oC
	5	10	15	20		25	30	35	40	-5	80

38	0.49	0.50	0.52	0.63		0.66	0.56	0.57	0.50	0.46	0.68	0.53
40	0.54	0.56	0.57	0.59		0.60	0.62	0.64	0.65	0.51	0.76	0.57
42	0.60	0.61	0.63	0.65		0.67	0.68	0.70	0.72	0.56	0.84	0.62
44	0.65	0.67	0.69	0.71		0.73	0.75	0.77	0.79	0.61	0.92	0.69
46	0.71	0.74	0.76	0.78		0.80	0.82	0.84	0.86	0.67	1.00	0.75
48	0.78	0.80	0.83	0.85		0.87	0.89	0.91	0.94	0.73	1.09	0.82

50	0.84	0.87	0.90	0.92		0.95	0.97	0.99	1.02	0.79	1.19	0.88
52	0.91	0.94	0.97	1.00		1.02	1.05	1.07	1.10	0.85	1.28	0.96
54	0.98	1.02	1.05	1.07		1.10	1.13	1.16	1.18	0.92	1.38	1.03
56	1.06	1.09	1.12	1.16		1.19	1.22	1.25	1.27	0.99	1.49	1.11
58	1.14	1.17	1.21	1.24		1.27	1.30	1.34	1.37	1.06	1.60	1.20

60	1.22	1.25	1.29	1.33		1.36	1.40	1.43	1.46	1.14	1.71	1.28
62	1.30	1.34	1.38	1.42		1.45	1.49	1.53	1.56	1.21	1.82	1.37
64	1.38	1.43	1.47	1.51		1.55	1.59	1.63	1.66	1.29	1.94	1.46
66	1.47	1.52	1.56	1.61		1.65	1.69	1.73	1.77	1.38	2.07	1.55
68	1.56	1.61	1.66	1.70		1.75	1.79	1.84	1.88	1.46	2.19	1.65

70	1.65	1.71	1.76	1.81		1.85	1.90	1.95	1.99	1.55	2.32	1.75
72	1.75	1.81	1.86	1.91		1.96	2.01	2.06	2.11	1.64	2.46	1.84
74	1.85	1.91	1.96	2.02		2.07	2.12	2.18	2.23	1.73	2.60	2.95
76	1.90	1.96	2.02	2.07		2.13	2.18	2.24	2.29	1.78	2.67	2.00
78	1.95	2.01	2.07	2.13		2.19	2.245	2.30	2.35	1.82	2.74	2.06
	2.06	2.12	2.18	2.24		2.30	2.36	2.42	2.47	1.92	2.89	2.17

80	2.16	2.23	2.30	2.36		2.42	2.48	2.54	2.60	2.02	3.04	2.28
82	2.27	2.34	2.41	2.48		2.54	2.61	2.67	2.73	2.12	3.19	2.39
84	2.38	2.46	2.53	2.60		2.67	2.74	2.80	2.87	2.23	3.35	2.52
86	2.50	2.58	2.65	2.73		2.80	2.87	2.94	3.01	2.34	3.51	2.64
88	2.62	2.70	2.78	2.86		2.93	3.01	3.08	3.15	2.45	3.68	2.76

317

			Table III.3.1-3				(continued)
						Sag, m						due
Polespan, m												Deviation(a)	to wind m
					Temperature, oC
	5	10	15	20		25	30	35	40	-5	80
	5	10	15	20		25	30	35	40	-5	80

90	2.74	2.82	2.91	2.99		3.07	3.14	3.22	3.30	2.56	3.85		2.88
92	2.86	2.95	3.04	3.12		3.20	3.29	3.37	3.44	2.67	4.02		3.02
94	2.99	3.09	3.18	3.27		3.35	3.44	3.52	3.60	2.80	4.20		3.15
96	3.12	3.22	3.32	3.41		3.50	3.59	3.67	3.76	2.92	4.38		3.29
98	3.26	3.36	3.46	3.55		3.65	3.74	3.83	3.92	3.05	4.57		3.43

100	3.39	3.50	3.60	3.70		3.80	3.89	3.99	4.08	3.17	4.76		3.56
102	3.53	3.64	3.74	3.85		3.95	4.05	4.15	4.24	3.30	4.95		3.71
104	3.67	3.78	3.89	4.00		4.11	4.21	4.31	4.41	3.43	5.15		3.86
106	3.81	3.93	4.04	4.16		4.27	4.37	4.48	4.58	3.56	5.35		4.01
108	3.95	4.08	4.20	4.31		4.43	4.54	4.65	4.76	3.70	5.55		4.16

110	4.10	4.23	4.35	4.48		4.60	4.71	4.83	4.94	3.84	5.76		4.32
112	4.25	4.39	4.52	4.64		4.76	4.89	5.00	5.12	3.98	5.97		4.47
114	4.41	4.54	4.68	4.81		4.94	5.06	5.18	5.30	4.12	6.19		4.64
116	4.56	4.71	4.84	4.98		5.11	5.24	5.37	5.49	4.27	6.41		5.80
118	4.72	4.87	5.01	5.15		5.29	5.42	5.56	5.68	4.42	6.63		4.97

120	4.88	5.04	5.18	5.33		5.47	5.61	5.75	5.88	4.57	6.86		5.15
122	5.05	5.21	5.36	5.51		5.66	5.80	5.94	6.08	4.72	7.09		5.32
124	5.22	5.38	5.54	5.69		5.84	5.99	6.14	6.28	4.88	7.33		5.49
126	5.39	5.55	5.72	5.88		6.03	6.19	6.34	6.48	5.04	7.57		5.67
128	5.56	5.73	5.90	6.07		6.23	6.39	6.54	6.69	5.20	7.81		5.85

130	5.73	5.91	6.09	6.26		6.42	6.59	6.75	6.90	5.36	8.06		6.04
132	5.91	6.10	6.28	6.45		6.62	6.79	6.96	7.12	5.53	8.31		6.23
134	6.09	6.28	6.47	6.65		6.83	7.00	7.17	7.34	5.70	8.57		6.47
136	6.28	6.47	6.66	6.85		7.03	7.21	7.39	7.56	5.87	8.82		6.65
138	6.46	6.67	6.86	7.05		7.24	7.43	7.61	7.78	6.05	9.09		7.86

140	6.65	6.68	7.06	7.26		7.45	7.64	7.83	8.01	6.22	9.35		7.06

318

Annex III.3.2 (II.4.2)

Table III.3.2-1 Technical data of twisted conductor (aluminum conductor) cables

Parameter		Unit		Nominal cross section area of conductor,mm2
Parameter		Unit	16	25	35	50	70	95	120	150
			16	25	35	50	70	95	120	150

Number of cores			2/4	2/3/4	2/3/4	2/3/4	4	2/4	4	4

Conductor type					Round	area, stranded and		pressed
Number							19(*)	19(*)	19(*)	19(*)
aluminum	fibers		7	7	7	7	19(*)	19(*)	19(*)	19(*)
in one core
Minimal		mm	4.5	5.8	6.8	8.0	9.6	11.3	12.8	14.1
diameter of core		mm	4.5	5.8	6.8	8.0	9.6	11.3	12.8	14.1
diameter of core
Maximal		mm	4.8	6.1	7.2	8.4	10.1	11.9	13.5	14.9
diameter of core		mm	4.8	6.1	7.2	8.4	10.1	11.9	13.5	14.9
diameter of core
Maximal
resistance		Ω/km	1.910	1.200	0.868	0.641	0.443	0.320	0.253	0.206
conductor	at 20	Ω/km	1.910	1.200	0.868	0.641	0.443	0.320	0.253	0.206
oC
Minimal
breaking	forc	kN	2.2	3.5	4.9	7.0	9.8	13.3	16.8	21.0
(LKD)
Minimal average
thickness
insulation		mm	1.3	1.3	1.3	1.5	1.5	1.7	1.7	1.7
(measured
normal point)
Minimal
thickness
insulation		mm	1.07	1.07	1.07	1.25	1.25	1.43	1.43	1.43
(measured at any
point)
Maximal
thickness
insulation		mm	1.9	1.9	1.9	2.1	2.1	2.3	2.3	2.3
(measured at any
point)
Maximal
diameter
conductor	(n	mm	7.9	9.2	10.3	11.9	13.6	15.9	17.5	18.9
included
protruded part)
Minimal load for
insulation
adhesion		kg	+	+	+	100	140	190	240	300
-X-90&X-FP-90		kg	+	+	+	100	140	190	240	300
- for X-FP-90		kg	+	+	+	+	+	110	+	+

Notes: (*): Permissible tolerance of 1 for aluminum conductor; “+”: not determined yet

319

Table III.3.2-2 Technical data of 2-core, 3-core, aluminum conductor cable

					Nominal cross section area of conductor,mm2
Parameter			Unit
Parameter			Unit	16	25	35	50	95	25	35	50
				16	25	35	50	95	25	35	50

Number of cores				2	2	2	2	2	3	3	3

Maximal				15.8	18.4	20.6	23.8	31.8	19.8	22.2	25.6
calculated			mm	15.8	18.4	20.6	23.8	31.8	19.8	22.2	25.6
diameter of cable
Specific weight of				0.14	0.20	0.26	0.35	0.68	0.30	0.39	0.53
cable			kg/m	0.14	0.20	0.26	0.35	0.68	0.30	0.39	0.53
(approximate)
Maximal
resistance			Ω/km	2.37	1.49	1.08	0.796	0.398	1.49	1.08	0.796
conductor	at	18	Ω/km	2.37	1.49	1.08	0.796	0.398	1.49	1.08	0.796
oC
Positive	sequence
reactance(1)		of	Ω/km	0.094	0.088	0.085	0.084	0.078	0.088	0.085	0.084
cable at 50 Hz
Maximal
continuous			oC	80	80	80	80	80	80	80	80
working
temperature
Maximal				96	125	155	185	285	105	125	150
continuous			A	96	125	155	185	285	105	125	150
working current
Minimal	breaking			4.4	7.0	9.8	14.0	2606	10.5	14.7	21.0
load	of	c	kN	4.4	7.0	9.8	14.0	2606	10.5	14.7	21.0
(LKD)
Elasticity module			GPa	59	59	59	59	59	59	59	59

Longitudinal			10-6/oC	23	23	23	23	23	23	23	23
expansion			10-6/oC	23	23	23	23	23	23	23	23
coefficient
Minimal	bending			30	40	60	70	95	40	60	70
radius			Mm	30	40	60	70	95	40	60	70
of conductor
Minimal	bending			95	110	125	145	285	120	135	155
radius			mm	95	110	125	145	285	120	135	155
of cable
Maximal	value	of
maximal	working		kN	1.23	1.96	2.74	3.92	7.45	2.94	4.12	5.88
tensile		(2)	kN	1.23	1.96	2.74	3.92	7.45	2.94	4.12	5.88
tensile		force
(28% of LKD)
Maximal	value			0.79	1.26	1.76	2.52	4.79	1.89	2.65	3.78
normal tensile force			kN	0.79	1.26	1.76	2.52	4.79	1.89	2.65	3.78
(18% of LKD)

Notes: (1) In most cases, this value is used for zero sequence reactance.

(2) For most projects, lower values can be used.

320

Table III.3.2-3 Technical data of 4-core, aluminum conductor cable

Parameter				Unit		Nominal cross section area of conductor,mm2
Parameter				Unit	16	25	35	50	70	95	120	150
					16	25	35	50	70	95	120	150
Number of cores					4	4	4	4	4	4	4	4
Maximal					19.1	22.2	24.9	28.7	32.8	38.4	42.2	45.6
calculated				mm	19.1	22.2	24.9	28.7	32.8	38.4	42.2	45.6
diameter of cable
Specific weight		o			0.28	0.40	0.52	0.70	0.96	1.35	1.66	2.02
cable				kg/m	0.28	0.40	0.52	0.70	0.96	1.35	1.66	2.02
(approximate)
Maximal
resistance			Ω/km		2.37	1.49	1.08	0.796	0.551	0.398	0.315	0.257
conductor	at	1	Ω/km		2.37	1.49	1.08	0.796	0.551	0.398	0.315	0.257
conductor	at	1
oC
Positive	sequenc
reactance(1)	of		Ω/km		0.102	0.095	0.092	0.092	0.086	0.085	0.084	0.082
cable at 50 Hz
Maximal
continuous				0C	80	80	80	80	80	80	80	80
working
temperature
Maximal					78	105	125	150	185	225	260	285
continuous				A	78	105	125	150	185	225	260	285
working current
Minimal	breakin				8.8	14.0	19.6	28.0	39.2	53.2	67.2	84.0
load	of			kN	8.8	14.0	19.6	28.0	39.2	53.2	67.2	84.0
(LKD)
Elasticity module				GPa	59	59	59	59	56	56	56	56
Longitudinal			10-6/0C		23	23	23	23	23	23	23	23
expansion			10-6/0C		23	23	23	23	23	23	23	23
coefficient
Minimal	bendin				30	40	60	70	80	95	105	115
radius				mm	30	40	60	70	80	95	105	115
of conductor
Minimal	bendin				115	135	150	160	285	345	380	410
radius				mm	115	135	150	160	285	345	380	410
of cable
Maximal	value	o
maximal	workin			kN	2.46	3.92	5.49	7.84	11.0	14.9	18.8	3.5
tensile	(2)			kN	2.46	3.92	5.49	7.84	11.0	14.9	18.8	3.5
tensile		force
(28% of LKD)
Maximal	value	o
normal		te		kN	1.58	2.52	3.53	5.00	7.10	9.60	12.1	15.1
force	(18% of			kN	1.58	2.52	3.53	5.00	7.10	9.60	12.1	15.1
force	(18% of
LKD)

Notes: (1) In most cases, this value is used for zero sequence reactance.

(2) For most projects, lower values can be used.

321

Table III.3.2-4 Main technical data of twisted cable, force bearing neutral , aluminum conductor

Nominal cross section area			Conductor					Core
						Average thickness of insulation sheath
	Number of fibres	C	Diameter of		Minimal breaking force		Outer diameter
		C
		o	conductor
		Resistivity at 20	conductor

			Minimal	Maximal			Minimal		Maximal

mm2		Ω/km	mm	mm	daN	mm	mm		mm
1. Phase conductor

25	7	1.200	5.8	6.3	300	1.4	8.6		9.4

35	7	0.868	6.8	7.3	420	1.6	10.0		10.9

50	7	0.641	7.9	8.4	600	1.6	11.1		12.0

70	12	0.443	9.7	10.2	840	1.8	13.3		14.2

95	19	0.320	11.0	12.2	1140	1.8	14.6		15.7

120	19	0.252	12.0	13.1	1440	1.8	15.6		16.7

150	19	0.206	13.9	15.0	1800	1.7	17.3		18.6

2. Force bearing neutral conductor

54.6	7	0.630	9.2	9.6	1660	1.6	12.3		13.0

70	7	0.500	10.0	10.2	2050	1.5	12.9		13.6

95	19	0.343	12.2	12.2	2750	1.6	15.3		16.3

322

Annex III.3.3 (II.4.3)

Table III.3.3-1 Conductor tension, sag of twisted cable, Aluminum conductor 4x25mm2

Pole span, m		Conductor sag at ambient temperature, cm

	0 0C		20 0C	30 0C	40 0C
	0 0C		20 0C	30 0C	40 0C
		Stretching stress 30 N/mm2
20	16		29	34	38

30	35		50	57	63

40	68		84	92	99

50	110		127	135	144

60	163		180	188	196

		Stretching stress 40 N/mm2
20	11		24	30	35

30	23		40	48	54

40	42		63	72	80

50	73		95	105	114

60	112		135	145	155

		Stretching stress 60 N/mm2
20	6		15	21	27

30	13		27	35	43

40	22		41	51	61

50	34		56	69	80

60	54		81	94	107

323

Table III.3.3-2 Conductor tension, sag of twisted cable, Aluminum conductor 4x35mm2

Pole span,				Conductor sag at ambient temperature, cm

m	0	0	C		20	0	C	30	0	C	40	0	C


				Stretching stress 30 N/mm2
20	16				28			33			38

30	29				46			53			59

40	52				71			80			87

50	87				107			116			125

60	126				149			159			168

				Stretching stress 40 N/mm2
20	11				24			30			35

30	22				39			47			54

40	35				56			66			75

50	55				80			92			102

60	86				113			124			136

				Stretching stress 60 N/mm2
20	05				14			21			27

30	12				26			35			43

40	21				39			50			60

50	32				54			85			98

60	44				71			137			153

324

Table III.3.3-3 Conductor tension, sag of twisted cable, Aluminum conductor 4x50mm2

Pole span,				Conductor sag at ambient temperature, cm


m	0	0	C		20	0	C	30	0	C	40	0	C


				Stretching stress 30 N/mm2
20	16				28			33			38

30	29				46			53			59

40	52				71			80			87

50	87				107			116			125

60	126				149			159			168

				Stretching stress 40 N/mm2
20	11				24			30			35

30	22				39			47			54

40	35				56			66			75

50	55				80			92			102

60	86				113			124			136

				Stretching stress 60 N/mm2
20	05				14			21			27

30	12				26			35			43

40	21				39			50			60

50	32				54			85			98

60	44				71			137			153

325

Table III.3.3-4 Cable 3x70mm2 + 1x54.6mm2

Pole			Tension force of neutral conductor, daN
Pole
span, m	10°C	15°C		20°C	25°C	30°C	35°C	40°C
	10°C	15°C		20°C	25°C	30°C	35°C	40°C

10	180	160		140	125	115	105	95

15	195	175		160	150	140	130	120

20	215	200		190	180	170	160	150

25	225	210		200	190	185	180	170

30	225	220		210	200	195	185	180

35	220	210		200	195	190	185	180

Pole		Sag of force bearing neutral conductor, daN
Pole
span, m	10°C	15°C	20°C	25°C	30°C	35°C	40°C
	10°C	15°C	20°C	25°C	30°C	35°C	40°C

10	8	9	10	11	12	14	15

15	16	17	20	21	23	25	26

20	27	29	31	33	35	37	39

25	40	43	45	47	49	52	54

30	58	61	63	66	68	70	72

35	83	86	88	91	93	96	98

40	108	111	114	117	119	122	125

326

Table III.3.3-5 Cable 3x70mm2 + 1x70mm2

Pole span,			Tension force of neutral conductor, daN
Pole span,
m	10°C	15°C		20°C	25°C	30°C	35°C	40°C
	10°C	15°C		20°C	25°C	30°C	35°C	40°C

10	167	146		129	116	105	97	90

15	193	175		161	148	138	129	122

20	213	198		185	174	164	156	148

25	228	215		204	194	185	177	170

30	240	229		219	211	202	195	183

35	250	240		232	224	216	210	203

40	258	249		242	234	228	222	216

Pole span,		Sag of force bearing neutral conductor, daN
Pole span,
m	10°C	15°C	20°C	25°C	30°C	35°C	40°C
	10°C	15°C	20°C	25°C	30°C	35°C	40°C

10	9	10	11	13	14	15	16

15	17	19	21	22	24	26	27

20	28	30	32	34	36	38	40

25	40	43	45	47	50	52	54

30	55	58	60	63	65	68	70

35	72	75	78	81	83	86	89

40	91	94	97	100	103	106	109

327

Table III.3.3-.6 Cable 3x150mm2 + 1x70mm2

Pole span,			Tension force of neutral conductor, daN
Pole span,
m	10°C	15°C		20°C	25°C	30°C	35°C	40°C
	10°C	15°C		20°C	25°C	30°C	35°C	40°C

10	196	179		165	153	142	134	126

15	224	211		199	189	180	172	165

20	244	233		223	215	207	200	193

25	257	248		241	233	227	220	214

30	267	260		253	247	241	236	231

35	273	268		262	257	252	248	243

40	278	274		269	265	261	257	253

Pole		Sag of force bearing neutral conductor, daN
Pole
span, m	10°C	15°C	20°C	25°C	30°C	35°C	40°C
	10°C	15°C	20°C	25°C	30°C	35°C	40°C

10	12	13	14	16	17	18	19

15	23	24	26	28	29	31	32

20	38	40	41	43	45	46	48

25	56	58	60	62	63	65	67

30	78	80	82	84	86	88	90

35	104	106	108	110	113	115	117

40	133	135	138	140	142	144	147

328

<<< < Предыдущая 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 5354 / 5454

Соседние файлы в папке Guide

#
28.12.20233.74 Mб4Vol 1-Designing Regulation of Network.pdf
#
28.12.20231.67 Mб1Vol 3-Construction-Power grid.pdf
#
28.12.20236.05 Mб1Vol 4-Operation - Plants and Grid.pdf
#
28.12.20235.43 Mб1Vol 5-Inspection.pdf
