DISCRETE SEMICONDUCTORS
book, halfpage
M3D088
BAS19; BAS20; BAS21
General purpose diodes
Product specification |
1996 Apr 16 |
Supersedes data of November 1993
File under Discrete Semiconductors, SC01
Philips Semiconductors |
Product specification |
|
|
|
|
General purpose diodes |
BAS19; BAS20; BAS21 |
|
|
|
|
FEATURES
∙Small plastic SMD package
∙Switching speed: max. 50 ns
∙General application
∙Continuous reverse voltage: max. 100; 150; 200 V
∙Repetitive peak reverse voltage: max. 120; 200; 250 V
∙Repetitive peak forward current: max. 625 mA
∙Forward voltage: max. 1 V.
APPLICATIONS
∙General purpose switching in e.g. surface mounted circuits.
DESCRIPTION
The BAS19, BAS20, BAS21 are general purpose diodes fabricated in planar technology, and encapsulated in small plastic SMD SOT23 packages.
MARKING
TYPE NUMBER
MARKING
CODE
BAS19 JPp
BAS20 JRp
BAS21 JSp
PINNING
PIN |
DESCRIPTION |
|
|
1 |
anode |
|
|
2 |
not connected |
|
|
3 |
cathode |
|
|
handbook, |
2 |
1 |
2
1 n.c.
3
3 |
MAM185 |
Fig.1 Simplified outline (SOT23) and symbol.
1996 Apr 16 |
2 |
Philips Semiconductors |
|
|
|
Product specification |
||
|
|
|
|
|
|
|
General purpose diodes |
|
BAS19; BAS20; BAS21 |
||||
|
|
|
|
|
|
|
LIMITING VALUES |
|
|
|
|
|
|
In accordance with the Absolute Maximum Rating System (IEC 134). |
|
|
|
|
||
|
|
|
|
|
|
|
SYMBOL |
PARAMETER |
CONDITIONS |
|
MIN. |
MAX. |
UNIT |
|
|
|
|
|
|
|
VRRM |
repetitive peak reverse voltage |
|
|
|
|
|
|
BAS19 |
|
|
− |
120 |
V |
|
BAS20 |
|
|
− |
200 |
V |
|
BAS21 |
|
|
− |
250 |
V |
|
|
|
|
|
|
|
VR |
continuous reverse voltage |
|
|
|
|
|
|
BAS19 |
|
|
− |
100 |
V |
|
BAS20 |
|
|
− |
150 |
V |
|
BAS21 |
|
|
− |
200 |
V |
|
|
|
|
|
|
|
IF |
continuous forward current |
see Fig.2; note 1 |
|
− |
200 |
mA |
IFRM |
repetitive peak forward current |
|
|
− |
625 |
mA |
IFSM |
non-repetitive peak forward current |
square wave; Tj = 25 °C prior to |
|
|
|
|
|
|
surge; see Fig.4 |
|
|
|
|
|
|
t = 1 μs |
|
− |
9 |
A |
|
|
t = 100 μs |
|
− |
3 |
A |
|
|
t = 10 ms |
|
− |
1.7 |
A |
|
|
|
|
|
|
|
Ptot |
total power dissipation |
Tamb = 25 °C; note 1 |
|
− |
250 |
mW |
Tstg |
storage temperature |
|
|
−65 |
+150 |
°C |
Tj |
junction temperature |
|
|
− |
150 |
°C |
Note
1. Device mounted on an FR4 printed-circuit board.
1996 Apr 16 |
3 |
Philips Semiconductors |
|
|
Product specification |
||
|
|
|
|
|
|
General purpose diodes |
BAS19; BAS20; BAS21 |
||||
|
|
|
|
|
|
ELECTRICAL CHARACTERISTICS |
|
|
|
|
|
Tj = 25 °C; unless otherwise specified. |
|
|
|
|
|
|
|
|
|
|
|
SYMBOL |
PARAMETER |
CONDITIONS |
MIN. |
MAX. |
UNIT |
|
|
|
|
|
|
VF |
forward voltage |
see Fig.3 |
|
|
|
|
|
IF = 100 mA |
− |
1.0 |
V |
|
|
IF = 200 mA |
− |
1.25 |
V |
IR |
reverse current |
see Fig.5 |
|
|
|
|
BAS19 |
VR = 100 V |
− |
100 |
nA |
|
|
VR = 100 V; Tj = 150 °C |
− |
100 |
μA |
|
BAS20 |
VR = 150 V |
− |
100 |
nA |
|
|
VR = 150 V; Tj = 150 °C |
− |
100 |
μA |
|
BAS21 |
VR = 200 V |
− |
100 |
nA |
|
|
VR = 200 V; Tj = 150 °C |
− |
100 |
μA |
Cd |
diode capacitance |
f = 1 MHz; VR = 0; see Fig.6 |
− |
5 |
pF |
trr |
reverse recovery time |
when switched from IF = 30 mA to |
− |
50 |
ns |
|
|
IR = 30 mA; RL = 100 Ω; |
|
|
|
|
|
measured at IR = 3 mA; see Fig.8 |
|
|
|
THERMAL CHARACTERISTICS
SYMBOL |
PARAMETER |
|
CONDITIONS |
VALUE |
UNIT |
|
|
|
|
|
|
Rth j-tp |
thermal resistance from junction to tie-point |
|
|
330 |
K/W |
Rth j-a |
thermal resistance from junction to ambient |
note 1 |
|
500 |
K/W |
Note
1. Device mounted on an FR4 printed-circuit board.
1996 Apr 16 |
4 |
Philips Semiconductors |
Product specification |
|
|
General purpose diodes |
BAS19; BAS20; BAS21 |
|
|
GRAPHICAL DATA
MBG442
300 handbook, halfpage
IF (mA)
200
100
0
0 |
100 |
Tamb |
o |
C) |
200 |
|
|
( |
|
Device mounted on an FR4 printed-circuit board.
Fig.2 Maximum permissible continuous forward current as a function of ambient temperature.
MBG384
600 handbook, halfpage
IF (mA)
(1) |
(2) |
(3) |
400
200
0
0 |
1 |
VF |
(V) |
2 |
|
|
|
(1)Tj = 150 °C; typical values.
(2)Tj = 25 °C; typical values.
(3)Tj = 25 °C; maximum values.
Fig.3 Forward current as a function of forward voltage.
MBG703
102 handbook, full pagewidth
IFSM
(A)
10
1
10−1 |
|
|
|
|
|
|
|
|
|
102 |
103 |
|
104 |
||
1 |
10 |
tp (μs) |
|||||
|
|
|
|
|
|
|
|
Based on square wave currents.
Tj = 25 °C prior to surge.
Fig.4 Maximum permissible non-repetitive peak forward current as a function of pulse duration.
1996 Apr 16 |
5 |
Philips Semiconductors |
Product specification |
|
|
General purpose diodes |
BAS19; BAS20; BAS21 |
|
|
MBG381
102 handbook, halfpage
IR
(μA)
10
(1)(2)
1
10 1
10 2
0 |
100 |
Tj |
( |
o |
C) |
200 |
|
|
|
(1)VR = VRmax; maximum values.
(2)VR = VRmax; typical values.
Fig.5 Reverse current as a function of junction temperature.
MBG445
300 handbook, halfpage
VR
(V)
(1)
200
(2)
(3)
100
0
0 |
100 |
Tamb |
o |
C) |
200 |
|
|
( |
|
(1)BAS21.
(2)BAS20.
(3)BAS19.
Fig.7 Maximum permissible continuous reverse voltage as a function of the
ambient temperature.
MBG447
1.0 handbook, halfpage
Cd (pF)
0.8
0.6
0.4
0.2
0 |
2 |
4 |
6 VR (V) 8 |
f = 1 MHz; Tj = 25 °C.
Fig.6 Diode capacitance as a function of reverse voltage; typical values.
1996 Apr 16 |
6 |
Philips Semiconductors |
Product specification |
|
|
General purpose diodes |
BAS19; BAS20; BAS21 |
|
|
handbook, full pagewidth |
|
t r |
t p |
|
|
|
|
||
|
|
|
t |
|
|
D.U.T. |
10% |
|
|
R = 50 Ω |
IF |
|
I F |
t rr |
S |
|
SAMPLING |
|
t |
|
|
OSCILLOSCOPE |
|
|
|
|
|
|
|
V = VR IF x R S |
|
R i = 50 Ω |
|
|
|
|
|
90% |
(1) |
|
|
VR |
|
|
|
|
|
|
|
|
|
MGA881 |
|
|
input signal |
output signal |
(1) IR = 3 mA.
Fig.8 Reverse recovery voltage test circuit and waveforms.
1996 Apr 16 |
7 |
Philips Semiconductors |
Product specification |
|
|
General purpose diodes |
BAS19; BAS20; BAS21 |
|
|
PACKAGE OUTLINE |
|
|
|
|
|
3.0 |
|
|
ok, full pagewidth |
|
|
|
2.8 |
|
|
|
|
|
|
1.9 |
B |
|
|
|
0.150 |
|
|
|
|
|
|
|
|
|
|
|
0.75 |
|
0.090 |
0.95 |
|
A |
0.2 M A B |
|
|
|
||||
0.60 |
|
|
|
|
|
|
|
|
|
2 |
1 |
|
|
10o |
|
0.1 |
|
|
|
|
|
max |
|
|
1.4 |
2.5 |
|
max |
|
|
|
|||
|
|
|
|
1.2 |
max |
|
|
|
10o |
|
|
||
|
|
|
|
|
|
|
|
|
max |
|
|
|
|
|
|
|
3 |
|
|
|
1.1 |
|
0 |
|
|
|
|
max |
30o |
|
|
|
||
0.48 0.1 |
|
0.1 M A B |
MBC846 |
|||
|
|
max |
|
|
|
|
|
|
|
TOP VIEW |
|
|
|
Dimensions in mm. |
|
|
|
|
|
|
|
|
|
Fig.9 SOT23. |
|
|
|
DEFINITIONS |
|
|
|
|
|
|
Data Sheet Status |
|
|
|
|
|
|
Objective specification |
This data sheet contains target or goal specifications for product development. |
|||||
Preliminary specification |
This data sheet contains preliminary data; supplementary data may be published later. |
|||||
Product specification |
This data sheet contains final product specifications. |
|||||
Limiting values
Limiting values given are in accordance with the Absolute Maximum Rating System (IEC 134). Stress above one or more of the limiting values may cause permanent damage to the device. These are stress ratings only and operation of the device at these or at any other conditions above those given in the Characteristics sections of the specification is not implied. Exposure to limiting values for extended periods may affect device reliability.
Application information
Where application information is given, it is advisory and does not form part of the specification.
LIFE SUPPORT APPLICATIONS
These products are not designed for use in life support appliances, devices, or systems where malfunction of these products can reasonably be expected to result in personal injury. Philips customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Philips for any damages resulting from such improper use or sale.
