DISCRETE SEMICONDUCTORS
book, halfpage
M3D088
BAV74
High-speed double diode
Product specification |
1996 Apr 03 |
Supersedes data of November 1993
File under Discrete Semiconductors, SC01

Philips Semiconductors |
Product specification |
|
|
|
|
High-speed double diode |
BAV74 |
|
|
|
|
FEATURES
∙Small plastic SMD package
∙High switching speed: max. 4 ns
∙Continuous reverse voltage: max. 50 V
∙Repetitive peak reverse voltage: max. 60 V
∙Repetitive peak forward current: max. 450 mA
∙Forward voltage: max. 1 V.
APPLICATIONS
∙High-speed switching in thick and thin-film circuits.
DESCRIPTION
The BAV74 consists of two high-speed switching diodes with common cathodes, fabricated in planar technology, and encapsulated in the small plastic SMD SOT23 package.
PINNING
PIN |
DESCRIPTION |
|
|
1 |
anode (a1) |
|
|
2 |
anode (a2) |
|
|
3 |
cathode |
|
|
handbook, 4 columns |
|
|
2 |
|
1 |
|
|
|
|
|
|
|
|
|
|
|
|
2 1
3
3
Top view |
MAM108 |
Marking code: JAp.
Fig.1 Simplified outline (SOT23) and symbol.
LIMITING VALUES
In accordance with the Absolute Maximum Rating System (IEC 134).
SYMBOL |
PARAMETER |
CONDITIONS |
MIN. |
MAX. |
UNIT |
|
|
|
|
|
|
Per diode |
|
|
|
|
|
|
|
|
|
|
|
VRRM |
repetitive peak reverse voltage |
|
− |
60 |
V |
VR |
continuous reverse voltage |
|
− |
50 |
V |
IF |
continuous forward current |
single diode loaded; see Fig.2; |
− |
215 |
mA |
|
|
note 1 |
|
|
|
|
|
|
|
|
|
|
|
double diode loaded; see Fig.2; |
− |
125 |
mA |
|
|
note 1 |
|
|
|
|
|
|
|
|
|
IFRM |
repetitive peak forward current |
|
− |
450 |
mA |
IFSM |
non-repetitive peak forward current |
square wave; Tj = 25 °C prior to |
|
|
|
|
|
surge; see Fig.4 |
|
|
|
|
|
t = 1 μs |
− |
4 |
A |
|
|
t = 1 ms |
− |
1 |
A |
|
|
t = 1 s |
− |
0.5 |
A |
|
|
|
|
|
|
Ptot |
total power dissipation |
Tamb = 25 °C; note 1 |
− |
250 |
mW |
Tstg |
storage temperature |
|
−65 |
+150 |
°C |
Tj |
junction temperature |
|
− |
150 |
°C |
Note
1. Device mounted on an FR4 printed-circuit board.
1996 Apr 03 |
2 |

Philips Semiconductors |
|
|
Product specification |
||
|
|
|
|
|
|
High-speed double diode |
|
|
BAV74 |
||
|
|
|
|
|
|
ELECTRICAL CHARACTERISTICS |
|
|
|
|
|
Tj = 25 °C; unless otherwise specified. |
|
|
|
|
|
|
|
|
|
|
|
SYMBOL |
PARAMETER |
CONDITIONS |
MIN. |
MAX. |
UNIT |
|
|
|
|
|
|
Per diode |
|
|
|
|
|
|
|
|
|
|
|
VF |
forward voltage |
see Fig.3 |
|
|
|
|
|
IF = 1 mA |
− |
715 |
mV |
|
|
IF = 10 mA |
− |
855 |
mV |
|
|
IF = 100 mA |
− |
1.0 |
V |
IR |
reverse current |
see Fig.5 |
|
|
|
|
|
VR = 25 V |
− |
30 |
nA |
|
|
VR = 50 V |
− |
0.1 |
μA |
|
|
VR = 25 V; Tj = 150 °C |
− |
30 |
μA |
|
|
VR = 50 V; Tj = 150 °C |
− |
100 |
μA |
Cd |
diode capacitance |
f = 1 MHz; VR = 0; see Fig.6 |
− |
1.5 |
pF |
trr |
reverse recovery time |
when switched from IF = 10 mA to |
− |
4 |
ns |
|
|
IR = 10 mA; RL = 100 Ω; |
|
|
|
|
|
measured at IR = 1 mA; see Fig.7 |
|
|
|
Vfr |
forward recovery voltage |
when switched from IF = 10 mA; |
− |
1.75 |
V |
|
|
tr = 20 ns; see Fig.8 |
|
|
|
THERMAL CHARACTERISTICS
SYMBOL |
PARAMETER |
|
CONDITIONS |
VALUE |
UNIT |
|
|
|
|
|
|
Rth j-tp |
thermal resistance from junction to tie-point |
|
|
360 |
K/W |
Rth j-a |
thermal resistance from junction to ambient |
note 1 |
|
500 |
K/W |
Note
1. Device mounted on an FR4 printed-circuit board.
1996 Apr 03 |
3 |

Philips Semiconductors |
Product specification |
|
|
High-speed double diode |
BAV74 |
|
|
GRAPHICAL DATA |
|
MBD033
300
I F (mA)
200
single diode loaded
double diode loaded
100
0
0 |
100 |
Tamb ( oC) |
200 |
Device mounted on an FR4 printed-circuit board.
Fig.2 Maximum permissible continuous forward current as a function of ambient temperature.
MBG383
300 handbook, halfpage
IF (mA)
(1) (2) (3)
200
100
0
0 |
1 |
VF |
(V) |
2 |
|
|
|
(1)Tj = 150 °C; typical values.
(2)Tj = 25 °C; typical values.
(3)Tj = 25 °C; maximum values.
Fig.3 Forward current as a function of forward voltage.
MBG704
102 handbook, full pagewidth
IFSM
(A)
10
1
10−1 |
|
|
|
|
|
|
|
|
|
102 |
103 |
|
104 |
||
1 |
10 |
tp (μs) |
|||||
|
|
|
|
|
|
|
Based on square wave currents.
Tj = 25 °C prior to surge.
Fig.4 Maximum permissible non-repetitive peak forward current as a function of pulse duration.
1996 Apr 03 |
4 |

Philips Semiconductors |
Product specification |
|
|
High-speed double diode |
BAV74 |
|
|
MBG376
105 handbook, halfpage
IR (nA)
104
103 |
(1) |
(2) |
(3) |
|
|
|
102
10
0 |
100 |
Tj (oC) |
200 |
(1)VR = 50 V; maximum values.
(2)VR = 50 V; typical values.
(3)VR = 25 V; typical values.
Fig.5 Reverse current as a function of junction temperature.
MBG446
0.8 handbook, halfpage
Cd (pF)
0.6
0.4
0.2
0
0 |
4 |
8 |
12 VR (V) 16 |
f = 1 MHz; Tj = 25 °C.
Fig.6 Diode capacitance as a function of reverse voltage; typical values.
1996 Apr 03 |
5 |

Philips Semiconductors |
Product specification |
|
|
High-speed double diode |
BAV74 |
|
|
handbook, full pagewidth |
|
t r |
t p |
|
|
|
|
||
|
|
|
t |
|
|
D.U.T. |
10% |
|
|
R = 50 Ω |
IF |
|
I F |
t rr |
S |
|
SAMPLING |
|
t |
|
|
|
||
|
|
OSCILLOSCOPE |
|
|
|
|
|
|
|
V = VR IF x R S |
|
R i = 50 Ω |
|
|
|
|
|
90% |
(1) |
|
|
VR |
|
|
|
|
|
|
|
|
|
MGA881 |
|
|
input signal |
output signal |
(1) IR = 1 mA.
Fig.7 Reverse recovery voltage test circuit and waveforms.
I |
1 k Ω |
450 Ω |
|
|
I |
90% |
|
V |
|
|
|
|
|
|
RS = 50 Ω |
OSCILLOSCOPE |
|
|
V fr |
|
|
D.U.T. |
Ω |
|
|
|
|
R i = 50 |
|
|
|
|
|
|
10% |
|
|
|
|
MGA882 |
|
|
t |
t |
|
|
t r |
t p |
|
|
|
|
|
input |
|
output |
|
|
|
signal |
|
signal |
Fig.8 Forward recovery voltage test circuit and waveforms.
1996 Apr 03 |
6 |

Philips Semiconductors |
Product specification |
|
|
High-speed double diode |
BAV74 |
|
|
PACKAGE OUTLINE |
|
|
|
|
|
3.0 |
|
|
ok, full pagewidth |
|
|
|
2.8 |
|
|
|
|
|
|
1.9 |
B |
|
|
0.150 |
|
|
|
|
|
|
|
|
|
|
|
|
0.75 |
0.090 |
|
0.95 |
|
A |
0.2 M A B |
|
|
|
||||
0.60 |
|
|
|
|
|
|
|
|
|
2 |
|
1 |
|
10o |
0.1 |
|
|
|
|
|
max |
|
|
|
1.4 |
2.5 |
|
max |
|
|
|
|||
|
|
|
|
1.2 |
max |
|
|
10o |
|
|
|
||
|
|
|
|
|
|
|
|
max |
|
|
|
|
|
|
|
|
3 |
|
|
|
1.1 |
|
|
0 |
|
|
|
max |
30o |
0.48 |
|
0.1 M A B |
MBC846 |
|
0.1 |
|
max
TOP VIEW
Dimensions in mm.
Fig.9 SOT23.
